AgfaPhoto sensor 505-X User manual

sensor 500-X, sensor 505-X,
sensor 510-X
User manual

i
Thank you for purchasing this AgfaPhoto digital camera. Please read these operating instructions
carefully in order to use the digital camera correctly. Keep the instructions in a safe place after
reading so that you can refer to them later.
Notice: this User's Manual has been written for the following camera models:
AgfaPhoto sensor 500-X, AgfaPhoto sensor 505-X and AgfaPhoto sensor 510-X.
Precautions
Before using the camera, please ensure that you read and understand the safety
precautions described below. Always ensure that the camera is operated correctly.
•Do not point the camera directly into the sun or other intense light sources which could
damage your eyesight.
•Do not try to open the case of the camera or attempt to modify this camera in any way.
High-voltage internal components create the risk of electric shock when exposed.
Maintenance and repairs should be carried out only by authorized service providers.
•Do not fire the flash too close to the eyes of animals or people, especially young children.
Eye damage may result. In particular, keep at least one meter away from infants when
using the flash.
•Keep the camera away from water and other liquids. Do not use the camera with wet
hands. Never use the camera in the rain or snow. Moisture creates the danger of electric
shock.
•Keep the camera and its accessories out of the reach of children and animals to prevent
accidents or damage to the camera.
•If you notice smoke or a strange odor coming from the camera, turn the power off
immediately. Take the camera to the nearest authorized service center for repair. Never
attempt to repair the camera on your own.
•Use only the recommended power accessories. Use of power sources not expressly
recommended for this equipment may lead to overheating, distortion of the equipment,
fire, electrical shock or other hazards.

i
i
Disclaimer
We assume no responsibility over and above the provisions of the Product Liability Law for
damages suffered by the user or third parties as a result of inappropriate handling of the
product or its accessories, or by theiroperational failure and by their use.We reserve the right
to make changes to this product and its accessories without prior notice.
Warning! Never open the camera or remove any parts of it. This will void all guarantee
claims.
Using your batteries
For best performance and prolonged battery life, we recommend the use of AAA-sized
rechargeable NiMH batteries.
Extending battery life
The following functions use up a great deal of battery power and should therefore only be
used occasionally:
• Excessive use of flash
• Editing images on the camera display
The battery life can be affected by soiling. Please clean the contacts with a clean, dry cloth
before putting the batteries in the camera. Battery performance drops at temperatures below
5° C (41° F). If you use the camera at low temperatures you should have replacement
batteries to hand and ensure they do not get too cold. Please note: you should not dispose of
cold and seemingly flat batteries because these batteries may work again at room
temperature.

ii
i
Contents
PRECAUTIONS I
DISCLAIMER II
USING YOUR BATTERIES II
EXTENDING BATTERY LIFE II
CONTENTS ________________________ III
GETTING STARTED __________________ 1
USING THIS MANUAL 1
PACKAGE CONTENTS 2
PARTS OF THE CAMERA 3
ATTACHING THE STRAP 5
INSERTING THE BATTERIES 5
LOW BATTERY INDICATOR 6
INSERTING A MEMORY CARD 6
ABOUT CAMERA MEMORY 7
TURNING POWER ON &OFF 7
POWER SAVING FUNCTION 7
SETTING THE DISPLAY LANGUAGE /DATE &
TIME 8
SETTING DISPLAY LANGUAGE 8
SETTING DATE &TIME 9
USING THE LCD MONITOR 9
CAPTURE MODE 10
VIDEO MODE 11
PLAYBACK MODE 12
BASIC OPERATION _________________ 13
TURNING POWER ON &OFF 13
CHANGING THE MODE 13
SWITCHING BETWEEN RECAND PLAYBACK
MODE 13
SELECTING THE REC MODE 14
USING THE MENU IN REC MODE 15
CAPTURE MENU LIST 16
VIDEO MENU LIST 16
SETUP MENU 17
BASIC RECORDING_________________ 19
RECORDING STILL IMAGES 19
SELECTING THE RESOLUTION AND QUALITY
20
USING THE ZOOM FUNCTION 21
USING THE FLASH 22
USING THE SELFTIMER 23
USING THE BURST-SNAPSHOT 24
RECORDING MOVIE CLIPS 25
SETTING THE MOVIE SIZE 25
RECORDING AUDIO 26
PLAYING BACK AUDIO 26
OTHER RECORDING FUNCTIONS _____ 27
SETTING THE WHITE BALANCE 27
SETTING THE COLOR EFFECT 28
SETTING THE EXPOSURE 28
SETTING DATE STAMP 29
PLAYBACK ________________________ 30
PLAYING BACK IMAGES 30
PLAYING BACK MOVIE CLIPS 30
USING THE MENU IN PLAYBACK MODE 31
USING THE MENU IN PLAYBACK MODE 31
VIEWING THUMBNAILS 32
PLAYING A SLIDE SHOW 32
DELETING FILES 33
DELETING A SINGLE FILE 33
DELETING ALL FILES 34
FORMATTING THE SD CARD OR INTERNAL
MEMORY 34

iv
PROTECTING FILES 35
CHOOSING A STARTUP IMAGE 36
SETTING THE LOGO 36
EDITING IMAGES 37
ROTATING STILL IMAGES 37
PRINTING 38
MAKING CONNECTIONS_____________ 39
CONNECTING THE CAMERA TO A TV 39
CONNECTING THE CAMERA TO A PC 40
USING A CARD READER (NOT INCLUDED) 40
CONNECTING THE CAMERA TO A PC WITH
THE USB CABLE 40
SYSTEM REQUIREMENTS ___________ 41
APPENDIX_________________________ 42
ABOUT THE FOLDER &FILE NAMES 42
FOLDER STRUCTURE 42
NAMING FILES 42
TROUBLESHOOTING 43
SPECIFICATIONS 44
CUSTOMER CARE 46
DISPOSAL OF WASTE EQUIPMENT BY USERS
IN PRIVATE HOUSEHOLDS IN THE EUROPEAN
UNION 47
FCC COMPLIANCE AND ADVISORY 47

1
Getting Started
Using This Manual
Getting Started
This section contains information you should know prior to using this camera.
Basic Operation
This section explains all recording features of the camera.
Basic Recording
This section explains how to record still images, movies and audio files.
Other Recording Functions
This section explains common operations when recording images.
Playback
This section explains playback, delete and edit functions of still images, movies and
audio files.
Making Connections
This section explains how to connect the camera to a computer or TV.
Appendix
This section provides troubleshooting and the camera specifications.
The meanings of the symbols used in this user's manual are explained below:
This indicates warnings that should be read before using these
functions.
This indicates useful information for the use of this camera.
This indicates the reference page.

2
Package Contents
AgfaPhoto sensor USB / AV cable 2 x AAAbatteries
Pouch Strap Software Installation
CD-ROM
Quick guide

3
Parts of the Camera
1. Flash
2. Selftimer lamp
3. Lens
4. Operation lamp
5. LCD display
6. Playback button
Five-way control button
7. OK/Enter button
(vertically)
8. Right
9. Down
10. Up
11. Left
12. MENU button

4
13. Shutter button
14. Mode button
15. Power button
16. Microphone
17. Strap mount
18. Battery cover
19. USB jack
20. Tripod socket

5
Attaching the Strap
Attach the strap to your camera as shown
in the image.
yDo not swing the camera around by the strap
Inserting the Batteries
The camera is powered by two AAA-size alkaline batteries or rechargeable NiMH
batteries.
Open the battery cover.
Slide the battery cover in the
direction indicated by the arrows.
Insert the batteries.
Insert two AAA-size batteries
with the positive (+) and
negative (-) poles matching the
directions indicated inside the
battery compartment.
Close the battery cover.
C
Ca au ut ti io on n
1
2
3

6
Low Battery Indicator
A low battery indicator appears on the LCD screen when the batteries are nearly
exhausted. Batteries should be replaced promptly when the low battery indicator
appears.
yThere is a risk of explosion if the battery is replaced by an incorrect type.
Dispose of used batteries according to instructions.
yBe sure to turn off the camera power before inserting or removing batteries.
yUse only Alkaline or NiMH batteries to power this camera. Use of any other type
of battery is not recommended.
yReplace all batteries at the same time. Never mix old and new batteries.
yRemove batteries if you will not be using the camera for a long time.
yThe camera body may feel warm after extended use. This is normal.
Inserting a Memory Card
You can use an SD card card with this digital camera. The memory card slot is adjacent
to the battery compartment.
Open the battery cover.
Slide the battery cover in the
direction indicated by the arrows.
Insert the card.
Insert the card with the label facing
up and the arrow pointing inwards.
yTo remove the card, gently press on the edge of the card to release it. Pull the
card out and close the battery cover.
Close the battery cover.
3
C
Ca au ut ti io on n
1
2
T
Ti ip ps s

7
yIf you insert or remove the card while the camera is powered on, it may damage
the card or data.
yDo not touch the connection terminals on the back of the card.
About Camera Memory
This camera is equipped with an internal memory. If a memory card is not inserted in the
camera, all images and movie clips recorded by the camera will be stored in the internal
memory. If a memory card is inserted, images and movie clips will be stored on the
memory card.
Turning Power On & Off
Press the Power button (1) to turn on the
camera in the Capture mode. The power
turns on and the LED (2) lights red.
Press the Power button (1) again to turn the power off. The power turns off and
the LED turns off.
yYou can turn on the camera without the startup and operating sound by setting
the function [Play Logo] and [Buzzer].
ySwitch between Capture mode and Playback mode (page 13).
Power Saving Function
To save battery power, the LCD monitor automatically turns off 30 seconds after the last
control accessed (factory-preset setting). Press any button other than the power button
to turn on the LCD monitor. After the power saving function has been active for the set
time, the power will turn off completely. Press the power button to power the camera
back on. You can change the power-off timeout by setting the function [auto power off
time] in the Setup menu.
C
Ca au ut ti io on n
1
2
T
Ti ip ps s

8
The power saving feature will not activate in the following situations:
yWhen recording movie clips or audio files
yWhen playing movie clips or audio files
yWhen playing the slideshow
yWhen connecting the camera to a computer or printer with the USB cable
Setting the Display Language / Date & Time
When using the camera for the first time after purchasing it, be sure to choose a
language and set the date & time before using the camera.
Setting Display Language
Turn the power on, and set the camera
to the Setup Menu ( page 17).
Select [Language].
Press or to select [Language]
then press to launch the submenu.
Select a language.
Press or on the five-way control button to select a language and press
OK/Enter button to apply the setting.
Press the MENU button to close the menu.
2
4
C
Ca au ut ti io on n
1
3

9
Setting Date & Time
Turn the power on, and set the camera
to the Setup Menu ( page 17).
Select [Date/Time].
Press or on the five-way control
button to select [Date/Time] and then
press on the five-way control button to
launch the submenu.
Set date and time.
Press or on the five-way control button to change the highlighted value. Press
on the five-way control button to move the cursor between settings.
yHolding down or changes the values continuously. For date stamp setting
(page 29).
Apply the setting.
After adjusting the settings, press OK/Enter to apply the setting. Finally press the
MENU button to close the setup menu.
Using the LCD Monitor
The LCD monitor is used to compose images while recording, adjust settings and play
back images. The following indicators may appear on the LCD monitor while recording
or playing back images.
2
4
1
3
T
Ti ip ps s

10
Capture Mode
1 Capture mode 2 Resolution indicator
2592 x 1944
2048 x 1536
1600 x 1200
1280 x 960
640 x 480
3 White balance indicator:
Cloudy
Daylight
Fluorescent
Tungsten
Auto
4 Quality indicator:
Super
Fine
Normal
5 Memory card inserted 6 Date stamp
7 Images taken/image capacity 8 EV value
-2.0EV-------------2.0EV
9 Battery level indicator: 10 Selftimer indicator:

11
Empty
Half
Full
20 seconds
10 seconds
11 Digital zoom bar
Video Mode
1 Video mode 2 Resolution indicator:
640 x 480
320 x 240
3 White balance indicator:
Cloudy
Daylight
Fluorescent
Tungsten
Auto
4 Memory card inserted
5 Recording time 6 Battery level indicator:
Empty
Half
Full
7 Digital zoom bar

12
Playback Mode
1 Playback mode:
Audio file
Video file
Still image
2 Protect indicator
3 Number of current file/total number
of recorded files
4 Battery level indicator:
Empty
Half
Full

13
Basic Operation
Turning Power On & Off
Press the Power button (1) to turn on the
camera in the Capture mode. The power
turns on and the LED (2) lights red.
Press the Power button (1) again to turn the power off. The power turns off and
the LED turns off.
yYou can turn on the camera without the startup and operating sound by setting
the function [Play Logo] and [Buzzer].
ySwitch between Capture mode and Playback mode (page 13).
Changing the Mode
You can record images and voices in the REC mode and use the Playback mode to
replay, delete or edit images on the LCD monitor.
Switching between REC and Playback Mode
In REC mode, press the Playback button
(2) to switch to the Playback mode.
In Playback mode, press the Playback
button (2) to switch to the REC mode.
1
T
Ti ip ps s
2

14
Selecting the REC Mode
Press the Power button to enter the Capture mode.
If the camera is in Playback mode, press the Playback button to change to REC
mode.
Press the Mode button (1) to change the REC mode.
Each time the Mode button is pressed the REC mode icon changes. It includes
three modes in REC mode: Capture mode, Video mode and Audio mode.
•The Mode button will not work when the camera is in Playback mode.
Display Title Description
Capture mode For taking still photos.
Video mode For recording movie clips.
Audio mode For recording audio files.
C
Ca au ut ti io on n
1
2

15
Using the Menu in REC Mode
When a menu is displayed, the five-way control button is used to make the desired
settings. The Audio mode does not have a menu so the MENU button will not work in
Audio mode.
Capture menu.
Turn the power on, and set the camera to
the Capture mode (page 13).
Open the Capture menu.
Press the MENU button (2) to display the
menu.
Select an item.
Press or on the five-way control button (1) to select an item.
Change the setting.
Press on the five-way control button (1) to launch the submenu. Press or
on the five-way control button (1) to change the setting.
Press OK/Enter on the five-way control button (1) to save the settings and finally
press the MENU button (2) to close the menu
2
4
3
1
5
