Operating and Service Manual
Agilent Technologies
85130F
NMD 2.4 mm to 3.5 mm
Adapter Kit
Part Number 85130-90030
Printed in USA
May 1988
© Copyright 1988 Agilent Technologies

,
WARRANTY
This Hewlett-Packard instrument product is warranted against defects in material and workmanship
for a period of one year from date of delivery. During the warranty period, Hewlett-Packard Company
will, at its option, either repair or replace products which prove to be defective.
For warranty service or repair, this product must be returned to a service facility designated by HP.
Buyer shall prepay shipping charges to HP and HP shall pay shipping charges to return the product to
Buyer. However, Buyer shall pay all shipping charges, duties, and taxes for products returned to HP
from another country.
HP warrants that its software and firmware designated by HP for use with an instrument will execute
its programming instructions when properly installed on that instrument. HP does not warrant that the
operation of the instrument, or software, or firmware will be uninterrupted or error free.
LIMITATION OF WARRANTY
The foregoing warranty shall not apply to defects resulting from improper handling by Buyer, Buyer-
supplied software or interfacing, unauthorized modification or misuse, or operation outside of the
environmental specifications for the product.
NO OTHER WARRANTY IS EXPRESSED OR IMPLIED, HP SPECIFICALLY DISCLAIMS THE
IMPLIED WARRANTIES OR MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
EXCLUSIVE REMEDIES
THE REMEDIES PROVIDED HEREIN ARE BUYER’S SOLE AND EXCLUSIVE REMEDIES, HP SHALL
NOT BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES, WHETHER BASED ON CONTRACT, TORT, OR ANY OTHER LEGAL THEORY.
ASSISTANCE
Product maintenance agreements and other customer assistance agreements are available for Hewlett-
Packard Products.
For any assistance, contact your nearest Hewlett-Packard Sales and Service Office. Addresses are
provided at the back of this manual.
- c--x.
-.
.
c
l
a

Printed in USA March 2000
Notice
Hewlett-Packard to Agilent Technologies Transition
This documentation supports a product that previously shipped under the Hewlett-
Packard company brand name. The brand name has now been changed to Agilent
Technologies. The two products are functionally identical, only our name has changed. The
document still includes references to Hewlett-Packard products, some of which have been
transitioned to Agilent Technologies.

c
HP 85130F Adapter Kit
c
To obtain optimum performance from this adapter kit, observe these simple precautions:
l Make connections carefully to avoid misalignment and connector damage, which will result in
inaccurate measurements.
l Keep the connectors free of dirt and any particles.
l When you clean the connectors, try compressed air first. Do not use abrasives. With a clean foam
swab, apply only Freon TF as a solvent.
l For more information, refer to the Microwave Connector Care manual.
The HP 85130F adapter kit consists of two NMD-2.4 mm to 3.5 mm adapters and a spanner wrench.
The test set end of the adapters has a NMD-2.4 mm connector while the Device Under Test (DUT) end
has a precision connector. The NMD-2.4 mm to NMD-3.5 mm (m) adapter is used when a male test
port is required. The NMD-3.5 mm to PSC-3.5 (9 (precision slotless connector) adapter is used when a
female test port is required.
The HP 85130F kit contains the following:
Description
Test port adapters
NMD-2.4 mm to NMD-3.5 mm (m)
NMD-2.4 mm to PSC-3.5 (f)
Storage box, foam lined
d .
4
Operating and Service Manual
.
Spanner wrench
Quantity
Replacement
Part Number
85130-60010
85130-60011
85130-60013
85130-90030
08513-20014
HP 85130F
NMD-2.4 mm to 3.5 mm Adapter Kit
1

SPECIFICATIONS
Hewlett-Packard guarantees that your adapters will equal or exceed the following specifications:
Table 1. HP 8513OF Specifications
CENTER CONDUCTOR PROTRUSION
No center conductor shoulder (male pin end of female center pin) protrusion is allowable
on any connector.
NMD-2.4 mm
Female
CENTER CONDUCTOR RECESSION
PSC-3.5
Female NMD-3.5 mm
Male
--Gp+
OUTER I I +ypp
I I
OUTER
+
II
CONDUCTOR
11
OUTER
CONDUCTOR
CENTER /
CONDUCTOR
I
‘I”-
OUTER CONDUCTOR
MATING PIANE
CENTER
I
CONDUCTOR
CONDUCTOR
L OUTER CONDUCTOR
I
MATING PLANE
!, OUTER CONDUCTOR
I
MATING PLANE
MP = male contact pin shoulder recession behind the outer conductor mating plane.
FP =recession of the end of female center pin behind the outer conductor mating plane.
Connector
Allowable Recession
mm in
NMD-2.4 mm female +O.OOO to +0.056 +o.ooo to +0.0022
PSC-3.5 female + 0.00254 to + 0.0127 +0.0001
to +0.0005
NMD-3.5 mm male + 0.00254 to + 0.0127 +0.0001
to +0.0005
ELECTRICAL
Adapter Frequency Range
Return Loss
NMD-2.4 mm to PSC-3.5 female
DC to 8 GHz 232 dB
and
8Ghzto18GHz 228
dB
NMD-2.4 mm to NMD-3.5 mm male
18 GHz to 26.5
~26 dB
2NMD-2.4
mm to 3.5 mm Adapter Kit
HP 85130F

Using an HP 8510 Network Analyzer perform the following test on your adapters as soon as you
receive them, and periodically repeat the test to determine if their performance meets the electrical
specifications stated above or if they need to be replaced. An initial period of one year between
performance tests is recommended.
Required Equipment HP Model/Part Number
HP 851OB Network Analyzer
. . . . . . . . . . . . . . . . . . . HP 8510 Option 010
with time domain option and B.04.OX firmware or higher
HP 8516A S-parameter Test Set
HP 834Xx Synthesized Sweeper
NOTE: Refer to the HP 8516A Operating and Service Manual for informa-
tion on instrument compatibility.
3.5 mm loads
(part of the HP 850528 calibration kit)
male . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...85052-60010
female . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85052-60010
3.5 mm 5OQ airline, 7.5 cm . . . . . . . . . . . . . . . . . . . . . . . . . .85053-60005
(part of the HP 850538 verification kit)
TEST SET
PORT
50 OHtl
ONE AIRLINE
LOAD
m-
II
4
,
1 . \ I 7 , I ,
mm e-
--
I
ADFlPTER
Figure 1. Return Loss Set-up
Return loss is measured by connecting a 50.ohm fixed load termination through a 7.5 cm airline to the
adapter, then attaching the adapter to port one of the test set (see Figure 7).
The effects of an imperfect load may be gated out using the HP 8510 time domain option as follows:
1. Press [PRESET]. The HP 8510 will be set to a predetermined state.
2. Under STIMULUS, press [START] [4] [5] [M/p]. This sets the start frequency to 45 MHz.
3. Under STIMULUS, press [STOP] [2] [6] [.] [5] [G/n]. This sets the stop frequency to 26.5 GHz.
4. Perform a 2.4 mm one port sliding load Sll calibration with 32 averaging at port one of your test
set, as described in the HP 8510 Operating and Programming manual. Save the calibration. Set up
as shown in Figure 1.
HP 85l30F NMD-2.4 mm to 3.5 mm Adapter Kit
3

5. With correction turned on, under MENUS, press [DOMAIN]. This brings up a set of time domain
and frequency functions to the softkeys. Select [TIME BANDPASS]. This puts you in time domain
=-----I
I
9
d’
mode.
6.
Under STIMULUS, press [START] [-I [.] [0] [5] [G/n]. This sets the start time of the sweep to
t
- .05 nanoseconds. !,
7.
Under STIMULUS, press [STOP] [l] [G/n]. This sets the stop time of the sweep to 1 nanosecond.
7
8.
Under RESPONSE, press [AUTO]. This brings the trace on screen.
9. Under the softkey functions, press [SPECIFY GATE]. A new menu should appear that will allow
you to press [STOP] softkey.
10. Using the RPG, adjust the stop gate to the center of the airline (see Figure 2).
11. Under the softkey functions press [GATE ON]. The HP 8510 will now compute the gate coeffi-
cients to gate out everything but the adapter.
12. Press the [PRIOR MENU] button just to the right of the softkeys and a new menu should appear
that will allow you to press the [FREQUENCY] softkey.
13. Under MENUS, press [MARKER]. This brings up a set of functions to the softkeys. Select [MORE]
[MAXIMUM] softkeys.
14. You can now read the return loss value from the screen marker value, and record the results on
the Performance Test Record provided.
C
A
Adapter End
of Airline
\
Start
Gate
StoD Gate
*11
.
LINEAR
REF -5.0 mUnits
4.007 mUni ts/
/
Load End
START -50.0 ps
STOP 1.0 ns
Figure 2. Location of Gates and Airline
of Airline
.--.+
.
\
\
4NMD-2.4 mm to 3.5 mm Adapter Kit
HP 85130F

Pedomance Test Record
c
I
1
ELECTRICAL SPECIFICATIONS
Adapter Frequency Range
NMD-2.4 mm to WC-35 female DC to 8 GHr
and
8 GHz to 18 GHz
NMD-2.4 mm to NMD-3.5 mm male
18 GHz to 26.5 GHz
Tested by:
Date:
Return Loss
232 dB
228 dB
226 dB
Measured
Attach the adapters to the test ports and tighten them finger tight. Use the spanner wrench to hold the
test set end of the adapter and torque the test set connector with a 20 mm torque wrench set to 96 N-cm
(8 in-lb). Attach a non-rotating clamp to each test port.
f-
1
L
There no replaceable parts in the HP 8513OF adapter kit. A worn or damaged adapter must be replaced
in whole.
.
The following equipment and supplies are required for the maintenance and use of, but are not supplied
with, your HP 85130F adapter kit.
3.5 mm gage kit
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85052-80010
(part of the HP 85052A/B calibration kits)
Torque wrench, 20 mm, 96 N-cm (8 in-lb) . . . . . . . . . . . . . . . . .8710-1764
Torque wrench, 5/16 inch, 96 N-cm (8 in-lb) . . . . . . . . . . . . . . . 8710-1765
(part of the HP 85052A/B calibration kits)
Microwave Connector Care Manual
. . . . . . . . . . . . . . . . . . .08510-90064
Connector cleaning kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92193Z
Non-rotating Clamp
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .08515-60003
(two included with the HP 8516A test set)
