ICP-MS Cone Magnifier, 10X with LED Illumination
Quick Start Instructions
The magnifier is used for inspection and measurement of the ICP-MS cone orifice. Featuring ten times
magnification with LED illumination, manual focus and +/- 15 mm scaled reticle with 0.1 mm divisions.
Installing and replacing the batteries
The magnifier is supplied without any batteries due to restrictions on shipment of hazardous goods.
For operation of the LED illumination, four SR45 batteries are required. The batteries are a button type that are also
used in watches. Alternative names for the battery type required may include: AG9, SG9, LR936.
Steps Images
1Rotate the lower half of the magnifier counter-clockwise by
holding the black ring which houses the LED light switch
(Figure 1).
Figure 1 Opening the battery compartment
2The magnifier will unscrew in half and expose the battery
compartment into which the 4 x SR45 batteries can be installed
(Figure 2).
Figure 2 Battery compartment
3Install the batteries with the positive (+) side facing in towards the center.
4Once the batteries have been installed, refit the two sections of the magnifier.

ICP-MS Cone Magnifier, 10X with LED Illumination Quick Start Instructions
Using the magnifier
The magnifier is used to visually inspect the condition and cleanliness of the cone orifice. If the cone orifice is
deformed in any way (not circular) or enlarged, the cone should be replaced.
Steps Images
1The tip of the removed sampler or skimmer cone is viewed, with
one eye, through the eyepiece (Figure 3).
Figure 3 Using the magnifier
2A reticule is included providing a measuring scale to check the
size of the orifice (Figure 4).
Figure 4 Magnifier reticule
3If the image viewed through the magnifier is blurry, rotate the
focusing ring (Figure 5) to bring the scale markings on the reticule
into focus.
Figure 5 Focusing ring
4To be in focus, the magnifier must be very close to (almost touching) the tip of the cone.
CAUTION
Do not press the magnifier against the tip of the cone to avoid damaging the delicate cone tip.
