1
Preliminary Draft
Agilent U1115A Wireless Logging Display
Operating Instructions
The Agilent U1115A Wireless Logging display is designed to be used with the
Agilent U1200 Series handheld meters, Agilent U1117A IR-to-Bluetooth®1 Adapter,
Agilent U1177A IR-to-Bluetooth Adapter and mobile/software2applications to
provide you a total wireless remote connectivity solution.
With the U1115A, you can view readings from up to four handheld meters, which
means you can virtually be at multiple places simultaneously from an extended
distance of up to 100-metres (U1117A) within the line-of-sight.
Figure 1 Agilent wireless remote connectivity solution
1The Bluetooth®word mark and logos are registered trademark owned by Bluetooth SIG, Inc and any
use of such marks by Agilent is under license. Other trademark and trade names are those of their
respective owners.
2The Agilent U1115A only supports Agilent Handheld Meter Logger software for downloading logged data to
PC via Bluetooth connection.
Standard Shipped Items Checklist
The following items are included when you make a purchase:
• U1115AWirelessLoggingDisplay.
• Three1.5VAAbatteries.
• USBtomicroUSBcable(servesasexternalpoweronly).
• OperatingInstructions(thisbooklet).
Agilent U1200
Series Handheld
meters
U1115A wireless
logging display
Windows PC
Android devices
iOSdevices
U1117A IR-to-
Bluetooth adapter
U1177A IR-to-
Bluetooth adapter
Agilent PC Application Software
Agilent Handheld Meter Logger 2
Agilent Mobile Application
Agilent Mobile Meter
Agilent Mobile Logger

2
Preliminary Draft
Product Characteristics
Temperature Operatingcondition–20°Cto55°C
Storagecondition–40°Cto70°C
Relative Humidity (R.H) Upto95%at40°C(non-condensing)
Dimension (W x L x H) 92.0 mm × 107.9 mm × 33.5 mm
Weight 238 g with batteries , 170 g without batteries.
Battery Type •Lithium24–LF(ANSI)andFR03(IEC)
•Alkaline24A(ANSI/NEDA)andLR03(IEC)
•ZincChloride24D(ANSI/NEDA)andR03(IEC)
Battery Lifespan •Lithium batteries: 30 hours
•Alkaline batteries: 20 hours
Power Consumption Maximum1VAfor3AAbatteries
Maximum5V+10%,250mAforexternalpower
AutoPowerOffmode,currentconsumption3mA
Warranty Oneyear(Doesnotcovernormalwearandtearof
mechanical parts and batteries)
Bluetooth BluetoothSPPprole,Class1device
Compatibility AgilentHandheldMeter/Display:
•AgilentU1200SeriesHandheldMeters
•AgilentU1117AIR-to-Bluetooth Adapter
•AgilentU1177AIR-to-Bluetooth Adapter
Agilent Application Software:
•AgilentHandheldMeterLogger
HardwareDevice:
•WindowsPC(withBluetooth-enabled)
Regulatory
Complies with
IDAStandards
DB102425
The U1115A complies with the requirements of the
following product standards:
•EMCEN301489–1:V1.9.2
EN301489–17:V2.1.1
EN55022:2006+A1:2007
EN55024:1998+A1:2001+A2:2003
•RF(Bluetooth)EN300328V1.7.1(2006–10)
•RF(Health)EN62311:2008
•Safety EN60950–1:2006+A11:2009
+A1:2010+A12:2011

Preliminary Draft
3
Preliminary Draft
Regulatory •IndiaEquipmentTypeApproval(ETA)Certicate
No:1424/2011/WRLO
•COFETELCerticateNo:RCPAGU111-1066,
registered under Agilent Technologies Mexico S
deRLdeCV
“This telecommunication equipment conforms to the
NTCtechnicalrequirement”
Table 1 Connectivity distance (approximate) within the line-of-sight
U1177A U1117A U1115A
U1177A – – 10 m
U1117A – – 100 m
U1115A 10 m 100 m –
Other Class 1 devices 10 m 100 m 100 m
Other Class 2 devices 10 m 10 m 10 m
•FCC:ThedevicecontainsFCCID:QOQWT11IA
•CanadaIC:ThedevicecontainstransmitterIC:5123A–BGTWT11IA
•TocomplywithFCCandIndustryCanadaRFradiationexposurelimitsfor
general population, the antenna(s) used for this transmitter must be
installed such that a minimum separation distance of 20cm is maintained
between the radiator (antenna) and all persons at all times and must not be
colocated or operating in conjunction with any other antenna or transmitter.
•“La operación de este equipo está sujeta a las siguientes dos condiciones:
(1) es posible que este equipo o dispositivo no cause interferencia
perjudicial y (2) este equipo o dispositivo debe aceptar cualquier
interferencia,incluyendolaquepuedacausarsuoperaciónnodeseada.”
•TheradiomodulecertiedbyJapaneseRadioLawisintegratedinside.
•NCCWarningStatement:
•Article12
Withoutpermission,anycompany,rmorusershallnotalterthe
frequency, increase the power, or change the characteristics and
functionsoftheoriginaldesignofthecertiedlowerpowerfrequency
electric machinery.
•Article14
The application of low power frequency electric machineries shall not
affect the navigation safety nor interfere a legal communication, if an
interference is found, the service will be suspended until improvement is
made and the interference no longer exists.

4
Preliminary Draft
Front View
Sample annunciator Time indicator
Batteryindicator
F3key
Functionkeys
Logger keyNavigationkeys
Meter key
Figure 2FrontviewoftheU1115AWirelessLoggingDisplay
Side View
Slide power switch
Stand
Externalpowerport
(microUSBport)
Figure 3SideviewoftheU1115AWirelessLoggingDisplay(standingposition)
Save
Logger
isplay
HOLD MODE CONNECT SETTINGS
01:01
F1 F2 F3 F4
Meter
Agi l ent U111 5A
Clas s 1
1 0 0 m

Preliminary Draft
5
Preliminary Draft
Back View
Slide power switch
Stand
Batterycover
with attached
magnet
Figure 4BackviewoftheU1115AWirelessLoggingDisplay
Turning On the U1115A
To turn on the U1115A , set the slide power switch to On. (gure 4)
•OnceaconnectedIR-to-Bluetooth Adapter is turned off, below
scenarios will occur :
1 The Not Connected annunciator will appear on the display.
2 Subsequently, the annunciator will only appear after 15s-20s.
Supplying External Power to the U1115A
1PlugthemicroUSBheadtothemicroUSBportonthesideoftheU1115A.
(gure 3)
2PlugtheUSBconnectortoaUSBpowersourcetosupplyanexternalpowertothe
U1115A.
•ThemicroUSBportontheU1115Aservesasanexternalpowerport
and not for data transfer or battery charger.
•The batteries are safe to remain inside the U1115A while it is being
powered up by an external power.

6
Preliminary Draft
Install and Replace the Batteries
Make sure you turn off the U1115A before installing or replacing the
batteries.
To avoid the U1115A being damaged from battery leakage:
Always remove dead batteries immediately.•
Always remove the batteries and store them separately if the•
U1115A is not going to be used for a long period of time.
Remove the battery protective sheet
beforeusingforthersttime.
1 2
3 4

Preliminary Draft
7
Preliminary Draft
Connecting to devices
EnsurethattheLinkLEDatthebackoftheIR-to-Bluetooth adapter
is blinking before establishing a connection.
Power cycle if necessary.
Press to enter the Connection Manager. Typical Connection Manager display.
Press to add devices. Press to scan for devices.
Typical Available Devices display.
Press to navigate to
desired device.
F3
CONNECT
Back
A> Add Device
B> Add Device
C> Add Device
D> Add Device
Bluetooth Enter
Connection Manager
01:01
F4
Enter Scan
57AE5B
1
Scan Select
U1177A-2718DE
2
Available
1 2
3 4
5 6
F3

8
Preliminary Draft
Connecting to devices (continued)
Press to select the desired device. Typical Connection display.
Press to navigate to desired
function.
Select• Connect to make a connection.
Select• Cancel to cancel a connection.
Select• Pairing PIN : 1234 to change
PINnumber.EnsurethattheU1115A
and the IR-to-Bluetooth adapter(s)
havematchingPINnumber(s).
Select• Connect at Startup to set
thedevicetoconnectonstartup.By
selecting this option, it will determine
the number of views as shown in
Table 1.
7 8
9 10
Select
F4
Connectionmanagercanaddupto4devicesatanyonetime.
Meter view is automatically selected based on the table below :
Table 2 MeterViewselection
Connected
devices Connect at Startup Meter View
1 1-meter view
2 2-meter view
3or4 4-meterview

Preliminary Draft
9
Preliminary Draft
Meter Views
Typical screen display when no meter is
connected to the U1115A.
Typical screen display when one meter
is connected to the U1115A.
Typical screen display when two meters
are connected to the U1115A.
Typical screen display when three
or four meters are connected to the
U1115A.
The U1115A screen display will show ----- when below scenarios occur :
1Nometerisconnected.
2 Meter(s) function/mode is not supported by the U1115A.
3 When the user changes the meter’s function. Typical wait time is 5s.
01:01
HOLD MODE CONNECT SETTINGS
-----
A> U1117A-57AE5B Not Connected
A> U1273A-MY51430008U1117A-57AE5B
A> U1273A-MY51430008
B> U1177A-2718DE U1272A-MY52800017
U1117A-57AE5B
U1273A-MY51430008
A> U1272A-MY52800017
B> U1177A-2718DE
U1252B-MY51040033
C> U1117A-2391BA Not Connected
U1117A-57AE5B
1 2
3 4

10
Preliminary Draft
Selecting Measurement Mode
Typical Meter view display.
Press to navigate
to the desired
meter.
Press to enter
Mode menu.
Typical Mode display.
The active window will be highlighted.
Press to select
desired mode. In
thisexample,ACV
is selected.
Press to exit Mode
menu.
U1273A-MY51430008 U1272A-MY52800017
B> U1177A-2718DE
U1252B-MY51040033
C> U1117A-2391BA Not Connected
A> U1117A-57AE5B
MODEHOLD CONNECT SETTINGS
123
4
MODE
F2
Vac
F2
U1273A-MY51430008 U1272A-MY52800017
B> U1177A-2718DE
U1252B-MY51040033
C> U1117A-2391BA Not Connected
A> U1117A-57AE5B
Vac Vdc Vacdc
56
Meter

Preliminary Draft
11
Preliminary Draft
Performing Data Logging
TheDataLoggingfunctionprovidesyoutheconvenienceofrecordingtestdatafor
future review or analysis.
Table 3 Dataloggingmaximumcapacity
Data logging option Maximum capacity for saving
Manual log 500
Interval log 60000pts/100sessions1
1For interval log, a maximum of 60 000 points or 100 sessions can be stored, whichever occurs rst.
Session ends when the U1115A powers off, count mode ends, restarts new logging or all connected meter(s)
disconnect
Performing Manual Logs
Press to enter Data Log mode.1
1Proceed to step 2 if the U1115A is already in meter
view.
Press for >1s to store the present value.
Typical Manual Log display.
Manual Logged : x1is displayed at the
top left of the display once a value is
logged.
1 X denotes 1,2,3,4,...which represents the current
log count.
Press to exit Data Log mode.
Logger
Manual Logged : 1
A> U1117A-57AE5B
12
4
Meter
3
Logger

12
Preliminary Draft
Performing Interval Logs
Press to enter Data Log menu. Press to start Interval Log mode.
Subsequent readings are automatically
recorded into the multimeter’s memory at
theintervalspeciedinthesetupmenu.
Typical Interval Log display.
Log Counts : x1is displayed at the
top left of the display once a value is
logged.
1 X denotes 1,2,3,4,...which represents the current
log count.
Press to exit Interval log mode.
START
STOP
Log Counts : 1
A> U1117A-57AE5B
STOP
12
4
3
Logger
F1
F1

Preliminary Draft
13
Preliminary Draft
Table 4 Datalogsetupoptions
Option Available settings Description
Interval 1s-10mins Delaytimebetweensubsequent
readings.Bydefaultitissetat2s.
Count Mode On/Off(default) Total readings that need to be
logged.
Count 1-60000 Total readings that need to be
logged.Itcanbeconguredfrom
1-60000readings.
Changing Data Log setup options
Press to enter Data Log mode. Press to enter Datalogger Setup menu.
Typical Datalogger Setup display.
Press to navigate to
desired function.
Press to edit the
selected value.
Press to toggle the
selected check box.
MENU
01:01
Datalogger Setup
Interval 00:02
Count Mode
Count 60000
Back Edit
Available Sessions : 100
Available Interval Counts : 60000
Available Manual Counts : 500
12
4
3
Logger
F2
Edit
F4
Toggle
F4

14
Preliminary Draft
Reviewing Previously Recorded Data
Press to enter Data Log mode. Press to enter Data menu.
Press to view the interval or manual
previously stored records.
Typical Interval Log Data display.
Typical Manual Log Data display.
Press to navigate to
desired logged data.
Press to view the
selected data.
Interval Manual
01:01
Interval Log (1/2)
25 Jan 2013 00:54:35 AM ( 4 pts)
Back Erase AllView
25 Jan 2013 00:54:05 AM ( 4 pts)
01:01
Manual Log (1/2)
Back Erase AllView
26 Jan 2013 00:54:35 AM ( 4 pts)
26 Jan 2013 00:54:05 AM ( 4 pts)
View
12
4
3
6
5
Logger
DATA
F3
F3
F2
F2

Preliminary Draft
15
Preliminary Draft
Install the U1115A to PC via Bluetooth
Beforeyoubegin,makesuretheBluetooth connection to your PC is
enabled.
1First,followthestepsbelowtosettheU1115Atoslavemode:
Press to enter
Connection Manager.
Press to enter
Bluetooth Setup. Typical Bluetooth Setup display.
Press to edit Master
Role.
Press to navigate to
Slave Role.
Press to save.
2FromyourPC(Windows7),gotostart > Devices and Printers.
3Click Add a device.
4Select U1115A-XXXXXX1and click Next.
5Type the default Bluetoothpairingcode“1234”(default)andclick Next.
6Oncepairingissuccessful,anoticationwindowwillappear.ClickClose.
7The U1115A-XXXXXX is now added and successfully connected to your PC.
8Then, you can connect the U1115A to the Agilent Handheld Meter Logger software
which is available at www.agilent.com/nd/hhmeterlogger
1 XXXXXX denotes the U1115A device name and can be obtained from the U1115A System Info (for more information,
refer to page 19).
CONNECT
F3
Bluetooth
F3
01:01
Bluetooth Setup
Role Master
Default PIN 1234
Back Edit
Edit
F4
OK
F4
12 3
456

16
Preliminary Draft
Changing the Display Settings
Press to enter the Settings menu. Press to enter the Display menu.
Press to select Outdoor display.
Seen here is typical outdoor display.
Press to select Indoor display.
Seen here is typical indoor display
(default).
Press to increase or decrease the
display brightness from lowest
[Backlight(1)]tohighest[Backlight
(7)].
ThedefaultisBacklight(3).
SETTINGS Display
U1273A-MY51430008 U1272A-MY52800017
B> U1177A-2718DE
U1252B-MY51040033
C> U1117A-2391BA Not Connected
A> U1117A-57AE5B
ON
Backlight(6)Back Outdoor Indoor
01:01
U1273A-MY51430008 U1272A-MY52800017
B> U1177A-2718DE
U1252B-MY51040033
C> U1117A-2391BA Not Connected
A> U1117A-57AE5B
U1273A-MY51430008 U1272A-MY52800017
B> U1177A-2718DE
U1252B-MY51040033
C> U1117A-2391BA Not Connected
A> U1117A-57AE5B
12
3 4
5
F4
F3
F3
F4
F2

Preliminary Draft
17
Preliminary Draft
Changing the Power Save Settings
Press to enter the Settings menu. Press to enter next page.
Press to enter the Power Save menu. Typical Power SaveDisplay.
Press to navigate to
desired function.
Press to toggle the
selected check box.
Press to edit the
selected value.
Enableordisable(default)auto•
dim by toggling the check box next to
the Auto Dim Enable function.
You may change the timeout period•
by editing the time stated next to the
Auto Dim Timeout function.Bydefault
it is set at 30s.
Enableordisable(default)autooff•
by toggling the check box next to the
Auto Off Enable function.
You may change the timeout period•
by editing the time stated next to the
Auto Off Timeout function.Bydefault
it is set at 15s.
More
Power
01:01
Power Save
Auto Dim Enable
Auto Dim Timeout (s) 00.30
Auto Off Enable
Auto Off Timeout (m) 15
Back Toggle
12
3 4
5
SETTINGS
F4
F4
F2
Edit
F4
Toggle
F4

18
Preliminary Draft
Changing the Date and Time
Typical Date/Time display.
Press to navigate
to desired function.
Press to edit the
selected values.
Resetting the U1115A
Typical Reset display.
Press to restore
the U1115A to
factory stage.
Press to cancel.
01:01
Date/Time
Date 21 June 2013
Time 00:29:24
Back Edit
SETTINGS
F4
More
F4
System
F3
Date/Time
F2
Edit
F4
123 4
567
SETTINGS
F4
More
F4
System
F3
Reset
F3
01:01
System Reset
Factory reset will erase all your
data and settings to restore the
U1115A back to factory stage.
Do you want to proceed?
No Yes
Yes
F4
No
F1
12 3 4
567

Preliminary Draft
19
Preliminary Draft
Viewing the System Info
Typical System Info display.
Enabling/Disabling the Beeper
Typical Utility display.
Toggle the check box to enable or
disable the beeper.
Sys Info
01:01
System Info
Model U1115A
Serial MY51080009
Fw version 01.00
Device Name U1115A-6A1F81
Back
SETTINGS
F4
More
F4
System
F3
F4
01:01
Utility
Beeper
Back Toggle
SETTINGS
F4
More
F4
Utility
F4
Toggle
F4
1234
5
123
45

20
Preliminary Draft
©Agilent Technologies, Inc., 2013
Printed in Malaysia
July15,2013
U1115-90103
Assistance
Fortechnicalassistance,contactyournearestAgilentSalesOfceorvisitthe
Agilent website at www.agilent.com/nd/assistfor further information.
