FIRSTLOOK360 Camera
User Manual
v.4.0

1
TABLE OF CONTENTS
TABLE OF CONTENTS............................................................................................................................................... 1
OVERVIEW............................................................................................................................................................... 2
GENERAL PRECAUTIONS ......................................................................................................................................... 3
FL360 CAMERA OVERVIEW..................................................................................................................................... 6
FL360 LED INDICATOR –MULTI-FUNCTION............................................................................................................ 7
BATTERY LIDS .......................................................................................................................................................... 8
CHARGING PROCEDURES...................................................................................................................................... 10
PREPARING THE TABLET ....................................................................................................................................... 11
CONNECTING THE CAMERA.................................................................................................................................. 12
FL360 APP OVERVIEW........................................................................................................................................... 19
BATTERY HANDLING.............................................................................................................................................. 30
ALTERNATE POWER .............................................................................................................................................. 31
FL360 SPECIFICATIONS.......................................................................................................................................... 33
SERVICE ................................................................................................................................................................. 34
WARRANTY............................................................................................................................................................ 35

2
OVERVIEW
FIRSTLOOK360 Technical Rescue Camera
The FIRSTLOOK360 (hereafter referred to as FL360) is a live-streaming 360° multipurpose technical rescue
camera. It is designed to advance rescue capabilities at emergency scenes.
FL360 provides a completely new dimension in imaging technology, giving rescuers the ability to harness high-
definition, streaming video that can be transmitted via wireless or wired connections to a mobile device. The
complete spherical image taken by FL360 allows the rescue technician to quickly view any space in its entirety.
FL360 has the capability to record 360° video, take screenshots, and communicate via two-way audio. All
recorded media is digitally overlaid on a map, and is time-, date-, and GPS-stamped.
This manual provides information for the safe and proper operation and maintenance of the FL360. Please
read the complete user manual before operating this device. If you have any questions regarding the
operation of FL360 or have suggestions for its improvement, please contact us at:
Phone: [phone] (Canada)
Email: in[email protected]
Ensure you have the latest version of the user manual. Please scan the QR code below or follow the link:
http://manual.firstlook360.com

3
GENERAL PRECAUTIONS
Read me first
•Please read this manual before using FL360 to ensure safe and proper usage of the device. Note that
images may differ in appearance from the actual product, and that content is subject to change without
prior notice. Visit www.agilitycorp.com/firstlook360 to view the latest information, downloads, and more
concerning FL360.
•Please note that the FL360 camera and app have been optimized for the tablet included in the kit. Please
contact us prior to attempted usage of a different, unsupported device.
•This product includes certain free and open source software. To see the free and/or open source licenses,
please refer to the licenses section in the FL360 app.
•FL360 is designed to work for a variety of technical rescue applications and conditions. It is important to
understand that even though the camera was built to withstand harsh conditions, it can be damaged if not
properly cared for.
•FCC Compliance Statement (Class A): This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation.
•CAN ICES-3 (A)/NMB-3(A) (Canada): This digital apparatus does not exceed the Class A limits for radio noise
emissions from digital apparatus set out in the interference-causing equipment standard entitled: “Digital
Apparatus,” ICES-003 of the Canadian Department of Communications. This device complies with Industry
Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
•Contains FCC ID: 2ALXI-SOMWB1
Usage Precautions
The following precautions should be taken in order to prevent damage or misuse:
•The recommended continuous ambient operating temperature for the FL360 ranges from -10° C to 60° C.
The system is designed to operate at this temperature indefinitely. If necessary, however, the system can
be operated at higher or lower temperatures for short periods of time.
Note that at temperatures below 0° C, changes in system operation may occur.
•Avoid leaving FL360 in direct sunlight when not in use.
•Never use the provided coiled tethering cable to support the full weight of the camera. Use rescue rope
and the provided eye hook as a means to lower FL360 into a space.
•Do not expose the device to physical stress or impact.
•Always use manufacturer-approved batteries, chargers, accessories, and supplies only.
CAUTION: Changes or modifications to this equipment not expressly approved by the manufacturer will void
the warranty and could void the user’s authority to operate the equipment.

4
Safety Precautions
•Only use the FL360 system in a safe manner.
•It is important to understand and follow all standard operating procedures, safety precautions and
practices when conducting rescue operations of any kind.
•Rescue Personnel should always wear appropriate personal protective equipment when conducting
operations.
•Operating at the scene of a structure collapse is inherently dangerous. Rescuers require skill, experience,
training, and adherence to their organization's safety protocols and procedures to minimize risk and work
safely and successfully in this environment.
•Rescue personnel should address any safety concerns to their Incident Commander or Safety Officer and
follow their superior’s instructions while working at the rescue scene.
•Rescuers that have not been appropriately trained or have insufficient experience should not attempt
activities that could result in injury to themselves or others.
Heat Precautions
The FL360 Camera heatsink (see picture below) will become warm when operated for long periods or in areas
with limited airflow. This is normal as the on-board processor within the camera uses the heatsink to dissipate
heat in order to ensure smooth and uninterrupted operation of FL360.
The maximum recommended continuous ambient operating temperature for the FL360 is 140° F (60° C). The
camera is designed to operate at this temperature indefinitely. The system can be operated at higher
temperatures when necessary, but only for short periods of time.
To prevent overexposure to heat, avoid leaving the system in direct sunlight when not in use.
Electrical Safety
The FL360 Camera will conduct electricity. Please do not operate the camera in the vicinity of or during an
electrical storm. Avoid contact with any live sources of electrical power. Ensure that the working area is safe,
and all sources of power have been disconnected or made safe before conducting rescue operations. Take all
precautions necessary to avoid electrocution, which could result in serious injury or death.
Hazardous Atmospheres
The FL360 Camera is not certified for use in atmospheres that contain flammable, combustible, conductive or
explosive agents; or in atmospheres that contain contaminants such as fumes, dusts, mists etc. Please ensure
that the working environment is free of flammable gases or liquids before operating the camera. Operating
the camera within these hazardous environments could cause an explosion.
It is important to follow all safety protocols and procedures relating to potentially hazardous atmospheres and
areas.
Heatsink

5
Batteries and Battery Chargers - Warnings
The usage of batteries is at your own risk. Before handling, ensure any user has appropriate understanding of
the charging, discharging, and installing of lithium ion batteries. Agility Technologies Corporation is not
responsible for any damage caused by misuse or mishandling of li-ion batteries and/or chargers.
Make sure to:
•Only use approved Battery Cells recommended specifically by the manufacturer for use in the FL360.
Failure to do so could damage the camera or cause some or all of the camera functions to fail. Each FL360
Battery lithium ion cell is equipped with a protection circuit to increase safety and to minimize the
potential for risk. Nevertheless, the misuse or mishandling of lithium ion rechargeable batteries can pose a
serious risk of personal injury or property damage.
•Use caution when working with lithium ion batteries as they are very sensitive to charging characteristics
and may explode or burn if mishandled or misused. For this reason, do not store FL360 batteries (18650) in
or near objects that will produce a static electric charge. Very quick pressure changes can cause 18650
batteries to malfunction.
•Always charge on a fireproof surface.
•Charge only in a recommended smart charger designed for this specific type of lithium ion battery.
•Do not overcharge or over-discharge batteries.
•Recharge drained batteries as soon as possible.
•Do not short-circuit batteries.
•Do not mix and match old, new, used, and unused batteries.
•Never leave batteries unattended while charging.
•Always take the batteries out of the camera body when the FL360 Camera is not in use.
•Do not expose batteries to extreme heat or moisture.
•Do not dispose of batteries in fire. Regulations and laws pertaining to the recycling and disposal of lithium
ion batteries vary from country to country as well as by state and local government. Please consult your
local jurisdiction regarding appropriate disposal. Note that many retail stores offer free recycling of
rechargeable batteries.
CAUTION: Under no circumstances are UNPROTECTED lithium-ion cells to be used in the FL360. These could
irreparably damage the onboard electronics and image sensors. Damage caused by unauthorized batteries will
void the manufacturer's warranty of the FL360.

6
FL360 CAMERA OVERVIEW

7
FL360 LED INDICATOR –MULTI-FUNCTION
Power Button
Press and hold - 4 sec
Power ON
Power Button
Press and hold - 4 sec
Power OFF
Multi-function LED
colour
Multi-function LED
time interval
Description
Blue
Continuous/Solid
Booting up
Red
4 Quick Flashes
During boot up, if battery level is too low
Blue-Red
Alternating
Camera booted, waiting for connection
to tablet
Green
Every 2 seconds
Battery level greater than 75%
Green
Every second
Battery level between 25% and 75%
Yellow
Every second
Battery level between 10% and 25 %
Red
Every second
Battery level 10% or less - replace
batteries
White
Continuous/Solid
Using CR123A Batteries / Battery
malfunction when using FL360
Rechargeable Li-ion Batteries - shut
down camera and test batteries

8
BATTERY LIDS
Environmental Battery Lid (0607-59-003)
The Environmental Battery Lid (pictured below) is the go-to lid for the FL360 Camera. This lid is designed to
allow the camera to be used for short periods under water at depths of up to 3 meters.
●Ensure that the gasket on the interior face of the Environmental Lid is in good condition, free from debris,
and contains no nicks or cuts that could negatively affect the seal.
●The Environmental Lid is held in place by two captive stainless-steel screws and must be securely and
evenly hand-tightened into place using the provided FL360 Battery Compartment Tool.
WARNING: DO NOT over-tighten the screws, or the camera may be damaged.
Environmental Battery Lid

9
Speaker Microphone Battery Lid (0607-59-002)
The Speaker Microphone Battery Lid (pictured below) incorporates a speaker and microphone to allow the
two-way audio functionality of the FL360. This lid is held in place by two captive stainless-steel screws and
must be hand-tightened securely and evenly into place. The Speaker Microphone Battery Lid is water resistant
for rain, water spray, and accidental dunking (IP67). If you wish to use the FL360 Camera under water,
exchange the Speaker Microphone Battery Lid with the Environmental Battery Lid.
●Ensure that the gasket on the interior face of the Speaker Microphone Battery Lid is in good condition, free
from debris, and contains no nicks or cuts that could negatively affect the seal.
●Flush out any debris from the speaker grill by removing it from the camera and running it under a flow of
clean water. Shake out all the water from the lid and allow to dry thoroughly before reinstalling.
WARNING: Do not stick anything into the speaker grill or microphone port, as doing so might puncture the
diaphragm causing a leak which will damage the FL360 camera’s interior electronics.
Speaker Microphone Battery Lid –interior face
Speaker Microphone Battery Lid –exterior face
