Agility Technologies FirstLook360 User manual

Quick Start Guide
Wired Mode
www.agilitycorp.com

See rescue in a whole new way.
www.agilitycorp.com

Congratulations and thank you for purchasing FirstLook360.
Your department now has the markets first streaming wireless
360°multipurpose technical rescue camera ever developed for Fire
& Emergency Services. Over time, will be offering new features to
the FL360 camera allowing you to have the latest software by
simply updating the app. Keep up to date by following us on
social media, our website, email or just give us call.
www.agilitycorp.com
Let’s get you familiar with the operation of the camera and get
you started. Thanks again!

LETS DO THIS!
www.agilitycorp.com
Step 1. Download the detailed user manual at our website shown
below so you can familiarize yourself with all the hardware provided
and to make sure you’ve received everything.
Step 2. Take the provided Multi-Charger provided in the kit and plug
into a power source and insert all 4 x FL360 Li-ion Protected Batteries
to check current power capacity and start charging if needed. The
provided Multi-Charger user manual will show you how use the
charger and read the LCD screen. Also make sure the tablet battery
is fully charged. You can use the Multi-Charger USB port to charge or
the provided wall charger.

www.agilitycorp.com
Step 3. Once the batteries are fully charged, take the provided 4mm
Hex Battery Compartment Tool and unscrew both 4mm screws and
remove the Speaker/Mic Lid from the FL360 camera housing.

www.agilitycorp.com
Step 4. Once the Speaker/Mic Lid is removed, take two (2) fully
charged FL360 batteries and insert them into the camera. Each
battery is marked positive and negative so make sure they line up
correctly in the battery housing. It is also important to lay both
batteries on the orange ribbon as shown below. Tuck excess ribbon
into the middle of both batteries.

www.agilitycorp.com
Step 5. Now that you’ve installed the batteries, you can now install
the Speaker/Mic Lid back onto the camera. Make sure you have the
lid positioned correctly (shown below), then tighten the screws using
the provided 4mm Hex Battery Compartment Tool. Make sure not to
over tighten but enough that the lid is lined up with the housing and
secure.

www.agilitycorp.com
Step 1. To i nstal l the boom coiled tethering cable, make sure you’ve
collapsed the telescoping boom completely.
Te le sc o p in g Boom Coiled Tethering Cable Installation
Step 2. Insert the circular tethering connector into the opening at the
rear of the boom pole.

www.agilitycorp.com
Step 3. Slowly twist the boom coiled tethering cable clockwise while
at the same time pushing it toward the the the camera head
attachment point.
Step 4. When the circular tethering connector is visible in slot of the
red anodized pole coupler, feed it out and connect the tethering
connector to high speed wired connector port located at the rear of
the FL360 camera. The connector is keyed so it might take some time
to feel it click in.

www.agilitycorp.com
Step 5. The right-angle connector on other end of the boom coiled
tethering cable will nestle into the cut out of the boom poles rear
coupler.
Step 6. Connect the provided tablet tethering right-angle connector
to the right-angle boom coiled tethering cable. These two connectors
match right-angle to right-angle and must be tightened once fitted
together.

www.agilitycorp.com
Step 7. To finish the wired connection, make sure to take the other
end of the tablet tethering cable and insert the micro-usb connector
into the tablet.

www.agilitycorp.com
Step 8. Turn on the camera by holding the power button for 4
seconds. To notify you the camera is on, the Multifunction LED light
will turn on and flash blue for 37 seconds while loading the on board
system module in the camera. When this is complete the camera will
go into pairing mode and flash blue/red.
Power'Button Multifunction' LED
Camera'Head'LED Camera'Head'LED

www.agilitycorp.com
Step 10. In the app, find the Tethering icon on the lower left and
press it. It will automatically take you to the Mobile Hotspot and
Tethering s etti ng s wi thi n the t ab l et. Turn on Tethering , head b ac k t o
the FL360 App where you will notice the USB Tethering icon is green.
FL360
USB Tethering iconFL360 app icon
Step 9. Power up the Tablet and open the FL360 app.

www.agilitycorp.com
Step 12. To live stream, press the green START icon on the lower
right of the diagnostics screen and the screen will go live. At this
point you’re ready to use the camera in full 360°. Use your finger on
the screen to view or use the virtual joystick to move around the
space.

www.agilitycorp.com
Support, FAQ’s and troubleshooting.
For all your support needs, FAQ’s, user input and additional details,
please visit agilitycorp.com/resources.
Things can and do change from time to time so please visit our
website, social media properties, or call us direct to keep up-to-date
on new features, application updates, and hardware features.
Thank you for your support from the ATC Team!
