Agility Technologies FirstLook360 User manual

ADVANCING TECHNICAL RESCUE
www.agilitycorp.com
FIRSTLOOK360 Camera
User Manual
v.3.5

1
TABLE OF CONTENTS
TABLE OF CONTENTS............................................................................................................................................... 1
OVERVIEW............................................................................................................................................................... 2
GENERAL PRECAUTIONS ......................................................................................................................................... 3
KIT CONTENTS......................................................................................................................................................... 6
FL360 CAMERA OVERVIEW ..................................................................................................................................... 7
FL360 LED INDICATOR –MULTI-FUNCTION............................................................................................................ 8
BATTERY LIDS .......................................................................................................................................................... 9
CHARGING PROCEDURES...................................................................................................................................... 11
MOUNTING OPTIONS............................................................................................................................................ 14
FIRST TIME TABLET SETUP .................................................................................................................................... 15
GETTING STARTED................................................................................................................................................. 16
FL360 APP OVERVIEW........................................................................................................................................... 21
BATTERY HANDLING.............................................................................................................................................. 31
ALTERNATE POWER .............................................................................................................................................. 32
KIT ACCESSORIES................................................................................................................................................... 33
CARE & STORAGE.................................................................................................................................................. 36
FL360 SPECIFICATIONS.......................................................................................................................................... 37
SERVICE ................................................................................................................................................................. 39
WARRANTY............................................................................................................................................................ 40

2
OVERVIEW
FIRSTLOOK360 Technical Rescue Camera
The FL360 Camera is a live-streaming 360° multipurpose technical rescue camera. It is designed to advance
rescue capabilities at emergency scenes.
FL360 provides a completely new dimension in imaging technology giving rescuers the ability to harness high-
definition, streaming video transmitted via wireless or wired connections to a mobile device. The FL360 takes
a complete spherical image, allowing the rescue technician the ability to quickly view any space in its entirety.
FL360 has the capability to record 360° video, take screenshots, and communicate via two-way audio. All
recorded media is digitally overlaid on a map and time-, date-, and GPS-stamped.
This manual provides information for the safe and proper operation and maintenance of the FL360. Please
read the complete user manual before operating FL360. If you have any questions regarding the operation of
FL360 or have suggestions for improvement, please contact us at:
Phone: [phone] (Canada)
Email: in[email protected]
Ensure you have the latest version of the user manual. Please scan the QR code below or follow the link:
http://manual.firstlook360.com

3
GENERAL PRECAUTIONS
Read me first
▪Please read this manual before using this device to ensure safe and proper use. Images may differ in
appearance from the actual product. Content is subject to change without prior notice. Visit
www.agilitycorp.com/firstlook360 to view information on FL360, downloads, and more.
▪Please note that the FL360 camera and app have been optimized for the tablet included with the kit.
Please contact us prior to using any other unsupported device.
▪This product includes certain free and or open source software. To see the free and or open source
licenses go to the licenses section in the FL360 app.
▪FL360 is designed to work for a variety of technical rescue applications and conditions. It is important
to understand that even though the camera was built to withstand harsh conditions, it can be damaged
if not properly cared for.
▪FCC Compliance Statement (Class A): This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired
operation.
▪CAN ICES-3 (A)/NMB-3(A) (Canada) This digital apparatus does not exceed the Class A limits for radio
noise emissions from digital apparatus set out in the interference-causing equipment standard
entitled: “Digital Apparatus,” ICES-003 of the Canadian Department of Communications. This device
complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following
two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
▪Contains FCC ID: 2ALXI-SOMWB1
Precautions
The following precautions should be advised in order to prevent damage or misuse:
▪High Temperature Conditions - the maximum recommended continuous ambient operating
temperature for the FL360 is -10° C to 60° C. The system is designed to operate at this temperature
indefinitely. The system can be operated at higher or lower temperatures for short periods of time
when necessary. Avoid leaving the system in direct sunlight when not in use.
▪Cold Temperature Conditions - The system is designed to function at temperatures as low as -10° C.
However, at temperatures below 0° C, changes in system operation may occur.
▪Do not use the provided coiled tethering cable to support the full weight of the camera. Use rescue
rope and the provided eye hook as a means to lower FL360 into a space.
▪Do not expose the device to physical impact or damage.
▪Use manufacturer-approved batteries, chargers, accessories, and supplies.
CAUTION: Changes or modifications to this equipment, not expressly approved by the manufacturer will void
the warranty and could void the user’s authority to operate the equipment.

4
Safety Precautions
▪Only use the FL360 system in a safe manner.
▪Operating at the scene of a structure collapse is inherently dangerous. Rescuers require skill,
experience, training and adherence to their organization's safety protocols and procedures to minimize
risk and work safely and successfully work in this environment.
▪Rescue personnel should address any safety concerns to their Incident Commander/Safety Officer and
follow their instructions while working at the rescue scene.
▪It is important to understand and follow all standard operating procedures, safety precautions and
practices when conducting rescue operations of any kind.
▪Rescue Personnel should always wear appropriate personal protective equipment when conducting
operations.
▪Rescuers that have not been appropriately trained or have sufficient experience should not attempt
activities that could result in injury to themselves or others
Temperature Precautions
The FL360 Camera heatsink (see picture below) will become warm when operated for long periods or in areas
with limited airflow. This is normal as the on-board processor within the camera uses the heatsink to dissipate
heat to ensure smooth and uninterrupted operation.
The maximum recommended continuous ambient operating temperature for the FL360 is 140° F (60° C). The
camera is designed to operate at this temperature indefinitely. The system can be operated at higher
temperatures for short periods of time when necessary but avoid leaving the system in direct sunlight when
not in use.
Electrical Safety
The FL360 Camera will conduct electricity. Do not operate in the vicinity of or during an electrical storm. Avoid
contact with any live sources of electrical power. Ensure that the working area is safe and all sources of power
have been disconnected or made safe before conducting rescue operations. Take all precautions necessary to
avoid electrocution which could result in death or serious injury.
Hazardous Atmospheres
The FL360 Camera is not certified for use in atmospheres that contain flammable, combustible, conductive or
explosive agents; or contain contaminants such as fumes, dusts, mists etc.
Ensure that the working environment is free of flammable gases or liquids before operating the camera.
Operating the camera within these hazardous environments could cause an explosion.
It is important to follow all safety protocols and procedures relating to potentially hazardous atmospheres and
areas.

5
Batteries and Battery Chargers - Warnings
Only use approved Battery Cells recommended specifically by the manufacturer for use in the FL360. Failure to
do so could damage the camera or cause some or all of the camera functions to fail.
WARNING: Under no circumstances are UNPROTECTED lithium-ion cells to be used in the FL360. These could
irreparably damage the onboard electronics and image sensors. In addition, the misuse or mishandling of
lithium ion rechargeable batteries can pose a serious risk of personal injury or property damage.
Damage caused by unauthorized batteries will void the manufacturer's warranty of the FL360.
Each FL360 Battery lithium ion cell is equipped with a protection circuit to increase safety and to minimize the
potential for risk. The misuse or mishandling of lithium ion rechargeable batteries can pose a serious risk of
personal injury or property damage.
Use caution when working with and using lithium ion batteries as they are very sensitive to charging
characteristics and may explode or burn if mishandled or misused. The user must have appropriate
understanding of lithium ion batteries when charging, discharging, and assembly before use.
Always charge on a fireproof surface. Never leave batteries unattended while charging.
Make sure to take the batteries out of the camera body when the FL360 Camera is not in use.
Agility Technologies Corporation are not responsible for any damage caused by misuse or mishandling Li-ion
batteries and chargers.
Charge only in a recommended smart charger designed for this specific type of lithium ion battery.
Do not mix and match old, new, used, and unused batteries.
Regulations and laws pertaining to the recycling and disposal of lithium ion batteries vary from country to
country as well as by state and local governments so please consult your local jurisdiction regarding
appropriate disposal. Many retail stores offer free recycling of rechargeable batteries.
Do not overcharge or over-discharge batteries.
Recharge drained batteries as soon as possible.
Do not short circuit batteries.
Do not dispose of batteries in fire.
Do not expose to extreme heat or water.
Usage of batteries is at your own risk!
Do not store 18650 batteries in or near objects that will produce a static electric charge.
Very quick pressure changes can cause 18650 batteries to malfunction.

6
KIT CONTENTS
ATC USAR TASK FORCE KIT #1
PN#0607-10-001
FL360 KIT COMPONENTS:
PART NUMBER
QTY
Figure
No.
FL360 Camera
0607-69-001
1
1
FL360 Rechargeable Li-ion Battery with Protection Circuit (Single)
0607-52-001
4
2
FL360 Collapsible/Telescoping Camera Boom
0607-50-003
1
3
FL360 Forward Sling Attachment Point
0607-59-005
1
3
FL360 Grip Handle with Camera Support
0607-50-002
1
4
FL360 Rail Mount for Grip Handle
0607-59-006
1
5
FL360 Headset (Behind Head Double Sided)
0607-53-001
1
6
FL360 Smart Battery Holder
0607-52-004
1
7
FL360 Environmental Battery Lid
0607-59-003
1
8
FL360 Speaker Microphone Battery Lid
0607-59-002
1
9
FL360 Battery Compartment Tool
0607-59-004
1
10
FL360 Boom Mount with 1” Ball
0607-51-007
1
11
FL360 Coiled Cable with Connectors
0607-55-002
1
12
FL360 Tethering Cable with Connectors
0607-55-003
1
13
FL360 Multi-Charger for Batteries/Tablet (with Vehicle Charging Adapter)
0607-52-003
1
14
FL360 Power Bank Battery (10,050 mAh)
0607-52-002
1
15
FL360 Two Point Shoulder Sling
0607-50-001
1
16
FL360 Tablet 9.7" Samsung S2 with LTE
0607-51-202
1
17
FL360 Mount for 9.7" Tablet
0607-51-013
1
18
FL360 Tablet Mount Base
0607-51-005
1
19
FL360 Double Socket Mounting Arm
0607-51-006
1
20
FL360 Protective Tablet Cover - 9.7" Black
0607-56-006
1
21
FL360 Tablet Memory Expansion SD (64GB)
0607-51-009
1
22
FL360 Hard Case with Custom Foam Interior
0607-60-001
1
23
FL360 Rear Attachment Eye Hook
0607-59-007
1
24
FL360 CR123A Adapter Tube
0607-52-005
2
25
FL360 Utility Bag
1
26
Contents - Figure numbers above:

7
FL360 CAMERA OVERVIEW

8
FL360 LED INDICATOR –MULTI-FUNCTION
Power Button
Press and hold - 4 sec
Power ON
Power Button
Press and hold - 4 sec
Power OFF
Multi-function LED
Colour
Multi-function LED time
interval
Description
Blue
Continuous/Solid
Booting up
Red
4 Quick Flash
During boot up, if battery level is too
low
Blue-Red
Alternating
Camera booted, waiting for
connection to tablet
Green
Every 2 seconds
Batt level greater than 75%
Green
Every second
Batt level between >25% <75%
Yellow
Every second
Batt level between >10% <25 %
Red
Every second
10% or less - replace batteries
White
Continuous/Solid
Using CR123A Batteries / Battery
malfunction when using FL360
Rechargeable Li-ion Batteries -shut
down camera and test batteries.

9
BATTERY LIDS
Environmental Battery Lid (0607-59-003)
The Environmental Battery Lid (see picture below) is the go to lid for the FL360 Camera. This lid is designed to
allow the camera to be used for short periods in depth up to 3 meters under water.
●Ensure that the gasket on the interior face of the environmental Lid is in good condition and contains
no nicks or cuts that would negatively affect the seal.
●The Environmental Lid is held in place by two captive stainless-steel screws and must be hand
tightened securely and evenly into place using the provided FL360 Battery Compartment Tool.

10
Speaker Microphone Battery Lid (0607-59-002)
The Speaker Microphone Battery Lid (see picture below) incorporates a speaker and microphone to allow the
two-way audio functionality of the FL360. This lid is held in place by two captive stainless-steel screws and
must be hand tightened securely and evenly into place. The speaker microphone battery lid is water resistant
for rain or water spray and accidental dunking (IP67). If you wish to use the FL360 Camera under water switch
the Speaker Microphone Battery Lid for the Environmental Battery Lid.
●Ensure that the gasket on the interior face of the Speaker Microphone Battery Lid is in good condition
and contains no nicks or cuts that would negatively affect the seal.
●Flush out any debris from the speaker grill by removing it from the camera and running it under a flow
of clean water. Shake out all water from the lid and allow to dry thoroughly before reinstalling.
●Do not poke anything into the speaker grill or microphone port as it might pierce the diaphragm
causing a leak which will damage the FL360 electronics.

11
CHARGING PROCEDURES
Charging the tablet and power bank
The USB A port labeled “SMART” on the rear of the charger will charge the tablet or Power bank when
connected via their corresponding charging cable. The FL360 Multi-Charger will beep and the tablet will
indicate it is being charged. The battery level indicator on the device will show level of charge, it will not be
indicated on the display of the Multi-Charger.
Charging FL360 Batteries
Plug the provided FL360 Multi-Charger into a power source.
Insert the FL360 Li-ion protected batteries into the slots marked CH1 thru 4 of the FL360 Multi-Charger
observing correct polarity. An alarm will sound if a battery is installed incorrectly an “Err”will show on the
display.
To quick charge 2 batteries place them in the outside battery slots, bays CH1 and CH4, and press the
“Current/Refresh” button until the display reads 2.0 Amps and the LEDS are Green.
Tip: It is good practice to check what charging current has been selected on the read out at the beginning of
the charge cycle.
Battery Slot Number
Charging Current in Amps
Charge Time
CH1
.5 / 1.0 / 2.0
6 hours / 3 hours / 1.5 hours
CH2
.5 / 1.0
6 hours / 3 hours
CH3
.5 / 1.0
6 hours / 3 hours
CH4
.5 / 1.0 / 2.0
6 hours / 3 hours / 1.5 hours
PRESS “Current Refresh” button to change amperage settings
LED Colour
Function
Red
Charging
Blue
Discharging
Green
Charged
Caution: If you long press the “Current/Refresh” button and the LED turns BLUE this means you have enabled
Battery Refresh and the FL360 Multi-Charger will discharge all the Batteries before it starts charging them
again… This takes a considerable length of time. To disable this feature long press the “Current Refresh”
button and the LEDs will change to Green and then Red to show the Batteries are being charged.

12
Controls and Connections

13
FL360 Multi-Charger Display
FL360 Multi-Charger Accessories
Vehicle Adapter - Plug into a vehicle power port or cigarette lighter then into the rear of the Multi-charger
Test Probes - Used to test the Internal resistance and voltage of a battery.
Insert the Probe connector into the IN-R Connection on the rear of the Multi-charger. Touch the Positive and
negative Probe tips together to enter battery test mode. Observing battery polarity (Red + Positive) and (Black
- Negative) Touch the probe tips to the respective ends of the battery. The display will cycle between the
battery voltage and the internal resistance of the battery in ohms. These probes allow for the condition testing
of virtually any Li-ion or NiMH battery
Tip: It is recommended to remove the Batteries from the FL360 Multi-Charger when they reach full capacity to
prevent discharging. Always store FL360 Batteries in the FL360 Smart Battery Holder.

14
MOUNTING OPTIONS
Boom Mount
The operator can increase the reach of the FL360 Camera when it is mounted onto the FL360
Collapsible/Telescoping Camera Boom. Thread the FL360 Camera onto the FL360 Collapsible/Telescoping
Camera Boom. For correct orientation please make sure that the power button faces right as viewed from the
rear when the boom is resting on the support legs (see picture).
Eye Hook Mount
The FL360 Rear Attachment Eye Hook threads into the rear of the FL360 Camera. This large 1” Eye allows the
user to operate the camera using standard rope equipment and carabiners to secure the camera in position or
lower it into a void space or hard to reach viewing area.

15
FIRST TIME TABLET SETUP
Internet Connection
When turned on for the first time, the tablet will need to be connected to the Google Play Store to download
critical updates of the FL360 App. For this first-time configuration, an internet connection is required. Make
sure to use a Wi-Fi network that has a reliable internet connection.
Please use the following steps to connect to a Wi-Fi network:
1. Open Settings by tapping on the gear icon.
2. Tap Network & Internet > Wi-Fi.
3. Turn on Wi-Fi.
4. Tap on a network to connect to it.
Tip: Swipe down from the top of the screen to quickly access Wi-Fi settings by tapping the Wi-Fi icon of the pull-
down menu.
Register Google Account
To download FL360 App updates from the Google Play Store, a Google Account is required. Please use an
existing Google Account or register a new one.
1. Open Settings by tapping on the gear icon.
2. Tap “Accounts.”
3. Tap the plus icon in the top right corner to add a new account.
4. Tap “Google.”
Please either login with your existing Google Account, or tap “Or create a new account” to create a new
account and follow the instructions on the screen.
WARNING - SIM CARD INSTALLATION
Because of a security measure inherent to the operation of the supplied SAMSUNG tablet, inserting a SIM card
into the tablet will initiate a factory reset on the device. This reset will cause all existing data such as apps,
recorded images, and videos to be erased.
If you intend to use a SIM Card in the Tablet go to the Settings tab in the FL360 App and toggle the BACK UP
files to SD CARD setting. This will save your recorded data and application files. If you neglect to select this
prior to putting in the sim card go to the Google play store and download and install the FL360 application
again.

16
GETTING STARTED
Operation Mode
FL360 is has two operational modes, wireless and wired. The wireless mode is the preferred method as it
allows the operator(s) more freedom of movement. Use the wired mode if the signal quality of the wireless
mode is adversely affected by interference of structures or competing wireless signals.
Wireless Operation
Step 1
Ensure all FL360 batteries and the tablet are fully charged. See CHARGING PROCEDURES on page 11 for
detailed instructions.
Step 2
Once the batteries are fully charged, take the provided FL360 Battery Compartment Tool (or any 4mm hex
socket tool) and unscrew both 4mm screws and remove the battery lid from the FL360 Camera housing.
Step 3
Insert two (2) fully charged FL360 Batteries over the orange ribbon into the camera, while carefully observing
polarity by lining up the red (positive) side of the FL360 Battery with the positive terminal in the battery
compartment. The FL360 Batteries should lay on top of the orange ribbon as shown in the picture below (fig 1)
to allow for easy battery removal. Tuck excess ribbon in between the batteries as shown in the second picture
to avoid interference with the sealing gasket of the battery lid.
Note: Always remove FL360 Rechargeable Li-ion Batteries after use. Batteries left in the FL360 Camera
batteries will discharge even when the camera has been turned off.
Figure 1
Figure 2

17
Step 4
Install the Battery Lid back onto the camera.
Align the Battery Lid with the camera housing and tighten both screws securely and evenly using the provided
FL360 Battery Compartment Tool. Spin the tool until the screws are seated then turn one rotation.
Caution DO NOT - Over Tighten or you could damage the brass inserts in the camera housing
Step 5
Press and hold the camera power button for 4 seconds until the multifunction LED starts flashing Blue/Red to
turn the FL360 Camera on. The camera can take 30-40 seconds to complete the initial boot sequence. At this
point, the camera is ready to be paired with the supplied tablet.
Step 6
Power on the tablet and allow it to boot up by pressing and holding the power button until the screen lights
up (this step can be done simultaneously while booting up the FL360 Camera).
Step 7
Tap the FL360 App icon (fig 1) on the tablet to open it.
Once the app is open, tap and hold the red Wi-Fi icon to connect to the FL360 Camera (this process can take a
few seconds). Once the camera is connected the Wi-Fi icon will turn green (fig 2).
Figure 1
Figure 2

18
Step 8
To start live-streaming, press the start icon (fig 3).
You will be taken to the Camera Control Screen where the camera will stream full 360°. See FL360 APP
OVERVIEW on page 21 for more details.
After a factory reset OR if you press Forget network
If the Tablet is reset to factory settings the pairing of the FL360 Camera to the tablet requires a one-time Wi-Fi
connection configuration. Navigate to the main tablet settings and tap the gear icon. Tap Connections, tap Wi-
Fi, and tap the FL360 Camera network to connect.
You will be asked for a Password: Default password is FL360123 (case sensitive)
Upon successful connection “Connected” will be displayed in the camera networks when you press the
wireless connection icon on the Home screen of the FL360 App.
Alternatively swipe your finger from the top of the screen to access the pull-down menu. Tap and hold the Wi-
Fi icon to show available networks. Tap the FL360 Camera network, enter the password if asked, and connect.
Figure 3

19
Wired Operation
Use this mode if the wireless signal between the FL360 Camera and Tablet is compromised.
Step 1-6
Repeat steps 1-6 from the above wireless mode operation
Step 7
Thread the camera onto the FL360 Collapsible/Telescoping Camera Boom.
Step 8
To install the coiled cable, collapse the telescoping boom. Insert the circular camera connector into the
opening at the rear of the boom pole.
Step 9
Slowly twist the coiled cable clockwise while at the same time pushing it toward the camera attachment point.
When the circular connector is visible in the slot of the pole coupler, pull it out and connect it to the port at
the rear of the FL360 Camera. The connector has an orientation notch, so slowly rotate and push to align, the
connector will click into place.
Step 9
Connect the tablet cable to the end of the coiled cable as shown below. The right-angled connectors naturally
route the cable forward on the boom. Plug the right-angled USB connector into the tablet.
