AgroMax INFINITY 8 User manual

ASSEMBLY
INSTRUCTIONS
Powerful output combined with expansive and uniform coverage makes the
AgroMax Infinity 8 COB LED Grow Light one of the best LED grow lights available
for both large-scale growing and home use. Unlike standard LED's with fixed
panels, the Infinity 8 COB LED features a modular-bar design, which allows bars to
be adjusted individually in 5 different positions. Each LED grow light bar is housed
inside of a premium aluminum heat sink and fitted with a combination (6) advanced
horticultural COB LED arrays and (24) 3w HP LED chips. Angle customization
capabilities and precision wide-angle optics allow the Infinity COB LED to provide
effective grow lighting from a wider range of height positions.
A | Infinity 8 Driver Housing
C | Light Bar Mounting Bracket
D | Mounting Screw (Light Bar)
F | Wire Hanger
G | Wire Hanging Adapter
E | Mounting Screw (Driver)
B | Infinity 8 30-Diode Light Bar
1 | Using mounting screws (D) attach the
mounting bracket (C) to the light bar (B).
Repeat this for all light bars.
2 | Using mounting screws (E) attach the
mounting bracket (C) to the driver housing (A).
At this point, the light bar’s position can be
adjusted to fit the garden’s needs
4 | Repeat steps 1-3 for all 8 light bars, until the
fixture is completely assembled.
5 | Attach the hanger adapters (G) to the holes
in the driver bar (A) end plate.
4 | Feed the hanging wire (F) through the
stem of the slide lock on the wire hanging
adapter (G)
3 | Connect the daisy-chains from the driver
housing (A) to the light bar (B).

ASSEMBLY
INSTRUCTIONS
5 | Once fed through the adapter, hold the free
wire in one hand while you raise the adapter up
the wire. The weight will lock the fixture’s
hanging height above canopy.
6 | To lower the height, first support the weight
of the fixture with one hand.
7 | While supporting the weight, depress the
slide-lock stem (where the wire was fed
through) with other hand, and you can freely
adjust the fixture down the wire.
SPECIFICATIONS
• Power Draw: 450w, 3.75 amps @ 120v AC
• Recommended Hanging Height: 18-36” above canopy
• Multi-volt operation 120-240v
• 120v power cord with NEMA 5-15 grounded plug
• Measures 35.5” L x 30” W x 5.5”
• Operating temperature 0-110° F
1.0
