aguri AGR400 Series User manual

Aguri AGR400 & AGR500 Series
User Manual
www.aguriworld.co.uk
1.

Contents
3. What’s in the box?
4. AGR400 series product overview
5. AGR500 series product overview
6. AGR500 series product overview cont.
7. Quick start & installation guide
9. Detailed operating instructions
10. Navigation map view explained
11. Junction view explained
13. Calculating a route
14. Summary screen & setting ‘Home’
15. Setting office
16. Multi-stop route planner
20. Using Recent routes
21. Route by Points of interest
22. Route by nearest Point of interest
23. Route by POI using a different location
24. Route using map
25. Route to junction
26. Route by co-ordinate
26. Recalculate route
27. Recalculate route cont.
28. Route to and manage Favourites
29. Environmental settings
30. Setting up your vehicle –Motorhome & Caravan Edition
31. Setting up your vehicle –Truck Edition
32. Tunnel category settings –Truck Edition
2.
34. Brightness
34. Volume
34. Change language
35. Select map view - 2D, 3D or N
35. MPH/KMH –select speed/distance unit type.
35. Map text size
35. Location Icon -select an icon to represent your vehicle
35. Lane view
35. Speed trap alert settings
36. Touch sounds
36. Missed turn alert
36. Auto scale
36. E Speed
37. User speed alert
37. Tight bend alert –Motorhome & Caravan, and Truck Edition
37. GPS status
37. Unit version details
37. Show POI icons on map.
38. Calibrate LCD
38. Mini-drop down menu
39. DVR dash cam operation –AGR500 series only
40. DVR dash cam operation –AGR500 series only
41. Bluetooth hands free operation –AGR500 series only
47. Map updates
48. Speedshield speed trap updates
49. Disposal of Old Electrical & Electronic Equipment
50. Service under warranty

3.
Aguri AGR400 Series
What’s in the box?
1 x Aguri AGR400 PND (portable navigation device)
1 x Micro SD card including navigation software
1 x Dash mounting disc
1 x USB cable
1 x Vehicle charger
1 x Windscreen bracket
1 x User guide
Aguri AGR500 Series
What’s in the box?
1 x Aguri AGR500 PND (portable navigation device)
1 x Micro SD card including navigation software
1 x USB cable
1 x Vehicle charger
1 x Windscreen bracket
1 x CD Rom inc User Manual
1 x Dash mounting disc
1 x Micro SD card for DVR player

Aguri AGR400 Series product overview
8. LED power indicator
9. Stylus
10. 4.3” Touch screen LCD
11. Built-in speaker
1. Power on / off
2. Built-in GPS antenna
3. Headphone socket
4. Micro USB socket
5. Audio/video in
6. USB socket
7. Reset
10
5
3
4
7
19
8
11
2
4.
6

5.
Aguri AGR500 Series product overview - Front
7. Built-in GPS antenna
8. LED power/charging indicator
9. 5” Touch screen LCD
10. Stylus
11. DVR Micro SD card
1. Power on / off
2. Enter DVR view
3. Headphone socket
4. Map Micro SD card
5. Audio/video in
6. USB socket
5
3
4
7
6
9
10
12
8
11

6.
Aguri AGR500 Series product overview - Rear
1. DVR Lens
2. Built-in speaker
3. Reset button
4. DVR Micro SD card
1
2
3
4

7.
Navigation Quick Start Guide.
All Aguri sat navs come preloaded with your choice of UK & Ireland or Pan European mapping plus the Speedshield speed trap
database, so they are ready to use straight out of the box.
1. Insert the SD card if the SD card is not already installed. When you first power on the device the unit will automatically
sychronise with the SD card. At this point the SD card will not function with any other device. If the unit does not activate when
you turn it on it may require charging which you can do by using the vehicle charger or USB cable. Once the unit is fully charged
the LED will turn blue.
2. Install the device in your car using the windscreen bracket provided. Ensure that the unit has a clear view of the sky and does
not interfere with the vehicles controls. Clean the area of the windscreen where you want to mount your unit and then attached
the windscreen bracket making sure that it is securely attached. Finally insert the device in to the windscreen bracket and adjust
it so that you can easily view the display and safely reach the touch screen.
3. Connect the vehicle charger and power the device on by pressing and holding the power button. Follow the on-screen
instructions to launch the navigation software. Please note that it can take a few minutes for the unit to achieve a satellite lock
the first time you use it so it is best to remain stationery to ensure the fastest result. Subsequent start-ups will be much faster
however and your device will locate satellites within a few seconds when using it regularly. Once satellite lock is achieved, the
screen will indicate your current position and direction of travel on the map.
4. Calculating a route using a post code. Touch the centre of the screen to enter the menu. Select ‘Route by post code’. Enter the
post code details of your destination where indicated and press ‘OK’. Press ‘Calculate’ and the unit will determine the fastest
route from your current position to your chosen destination.
User note. Truck and Motorhome & Caravan editions only.
If you have the Truck or Motorhome & Caravan edition, an additional screen will be displayed at this point asking you to select your vehicle type. If
this is the first time you have used the device you will need to enter the attributes of your vehicle now. More details are about how to set-up and
enter your vehicle attributes can be found later in this manual. Once your vehicle details have been entered, your device will calculate a route
based on the attributes saved.

8.
5. Summary screen. A summary screen of your journey will be displayed enabling you to check that the destination address and
route calculated is correct. To proceed, press ‘Go’ and the map view will be displayed with the route calculated by the device
highlighted. As you drive, carefully follow the highlighted route, route description and voice instructions. The navigation view will
constantly update with your current position and road information. If you do accidentally take a wrong turn the unit will
automatically re-route and give you turn by turn voice instructions as before.
For more information please follow the detailed instructions provided below.
User note. Whilst all Aguri satellite navigation systems have been designed to provide safe and efficient routing they are not a
substitute for driving with due care and attention. The driver is fully responsible for paying attention to road signs, road conditions,
other road users, legal road restrictions, pedestrians and the operation of their vehicle at all times.

9.
Detailed Operating instructions
Once you have checked that the Micro SD card is correctly installed in the unit, switch the unit on by pressing and holding the standby power
button. The following warning message will be displayed:-
“Please do not attempt to operate your Aguri navigation system whilst driving. Whilst this navigation system has been designed to provide the most
appropriate route for you vehicle it is not a substitute for driving with due care and attention. The driver is fully responsible for paying attention to
all road signs, legal restrictions, road conditions, other road users, pedestrians and the operation of their vehicle at all times.”
Please read the warning and press “I Agree” to continue.
User note. Truck and Motorhome & Caravan editions.
If you have a Truck or Motorhome & Caravan edition, you will have the option to select the vehicle type you are currently driving. Please select as
appropriate.

10.
Navigation map view explained.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
9. GPS signal strength.
10. Battery back-up power indicator.
11. Speed limit display. Displays the speed limit of the road you are travelling on.
12. Your speed of travel.
13. Name or number of the road your are currently travelling on.
14. GPS compass. Indicates your current direction of travel.
15. Icon showing current position of your vehicle.
16. Icons showing location of speed traps, hazards and other legal restriction.
1. Lane View displays the lane or lanes that you can use or should be
using depending on the vehicle you are driving and the junction or
intersection you are approaching.
Please note that Lane View is only available for motorways,
dual carriageways, and complexand major inner city junctions.
2. Visual warning of approaching speed trap, hazard or other legal restriction.
3. Displays the road name or number of the next road you need to turn on to.
4. Distance left to destination.
5. Time left to destination.
6. Estimated time of arrival.
7. Icon displaying next manoeuvre required.
8. Distance to next manoeuvre required.

11.
Additional screen graphics explained.
Additional screen graphics and instructions will appear from time to time during your journey.
Junction view
Visually indicates exactly what action to take. Particularly useful at complex motorway junctions.
Please note that Junction View graphics are only available for motorways.

12.
Additional screen graphics explained. Truck and Motorhome & Caravan editions only.
If you have the Truck or Motorhome & Caravan edition, your navigation device will alert to a number of hazards and other legal restrictions that
relate directly to the type of vehicle you are driving.
Risk of grounding
No trucks allowed Height restriction Width restriction Side winds
Road narrows
No vehicles carrying
explosives
No vehicles with goods
Harmful to water Axle weight restriction Width restriction
No vehicles or combinations
of vehicles over maximum
length shown
Steep hill upwards
Double bend Steep hill downwards Sharp bend right Weight restriction
Sharp bend left

13.
Calculating a route
There are several ways to calculate a route
Route by postcode
Press the middle of the screen to access the “Navigate” menu and then press “Route by postcode” icon. If your unit is the European version select
“Country” before you type in the postcode. Use the arrows on the right of the display to scroll through and then select the correct country option.
Then press “Postcode” and enter the full postcode and press “OK”.
If an error has been made the message “Error, incorrect postcode” will be shown. Press “OK” and retype the postcode. The unit will then display a
postcode and street name. If you know the number of the property press the “House No” icon, enter the details and press “OK”. Finally press
“Calculate” to continue.
Route by address
Press the middle of the screen to access the “Navigate” menu. Press the “Route by address” icon. If your unit is the European version select
“Country” before you type in the city. Use the arrows on the right of the display to scroll through and then select the correct country option. Press
“City” and enter the city name and the unit will prompt you from a list of cities until you find your selection and then press “OK”. Then press “Street”
and the unit will again prompt you with a list of street names until you find your selection and then press “OK”. Finally press “Calculate” to continue.
Route options
When the route has been calculated you have various options.
Press “Go” to start navigation
Press “Simulation” to show a simulation of the route that has been calculated.

14.
Press “Route Option” to tailor your route by choosing between the options ‘Shortest route, Fastest route, Change start position, Avoid motorway and
Avoid toll’
Press “Guide” to see a description of the calculated route turn by turn, road by road.
Summary screen
The “Summary Screen” will give you the distance to your destination along with the estimated time the journey will take and the estimated time of
arrival. The summary screen will be displayed for approximately 10 seconds and then your device will automatically proceed to the navigation map view
so you can begin navigating. If you want to manually proceed to the navigation map view before the 10 second period has elapsed, press the “Go”
button.
Setting “Home”
Press the middle of the screen to access the “Navigate” menu and press the “Home” icon. The first time the “Home” function is used the screen will
display “Set home?” -press “OK”. You can set “Home” using one of the following options “Find address”, “Find by POI”, “Find by recently used” and
“Save using current location” Once you have found the correct address for ‘Home’ you can choose to name it as necessary by tapping on the ‘Name’
field. Press ‘Save’ to save the location.
To calculate a route to “Home”, press the middle of the screen to access the “Navigate” menu and then press the “Home” icon. The unit will display
details of the destination. Press the “Go” button to begin your journey, or press the “Route Option” if you want to tailor the route.

15.
Setting the “Office” destination
Press the middle of the screen to access the “Navigate” menu and press the “Office” icon. The first time the “Office” function is used the screen will
display “Set office?” -press “OK”.
You can set “Office” using one of the following options “Find address”, “Find by POI”, “Find by recently used” and “Save using current location”
To calculate a route to “Office”, press the middle of the screen to access the “Navigate” menu and then press the “Office” icon. The unit will display
details of the destination. Press the “Go” button to begin your journey, or press the “Route Option” if you want to tailor the route.
Last journey or Clear route
The unit stores the last journey you have travelled, so that if you want to go back to that address your do not have to input the details again. To do
this press the middle of the screen to access the “Navigate” menu and then press “Last journey” and a route will automatically calculated to the last
destination selected.
Once a route has been calculated, the “Last journey” icon will be replaced with a “Clear Route” icon. To cancel a route, press the middle of the
screen to access the “Navigate” menu and then press “Clear Route”.

16.
Multi-stop Route Planner
If you want to visit a number of different locations in one day, it is possible to enter up to sixteen locations and the navigation software will create the
optimum route around all of them. It is possible to create and save up to eight Multi-stop routes in total.
Create a Multi-stop route
Press the middle of the screen to access the “Navigate” menu. Then press the “Multi-stop” icon. At this point the unit allows you to create a new
Multi-stop, use or amend a saved Multi-stop or delete a Multi-stop.
Next press “Create Multi-stop” and the screen will display the following options;
“Edit name” – This is where you can name your Multi-stop.
“Change start” – This is where you have the option to change the start point of the Multi-stop.
“Add” – This is where you add your destination.
“Save” – This is where you save your destination.
“Calculate” – This is where your Multi-stop is calculated.
Next press “Edit name”. You can then name your new Multi-stop (up to a maximum of sixteen characters). Then press the “Arrow” key to delete the
current name of your Multi-stop and then type in the new name of your Multi-stop and press “Save”.
If you are happy with the start position you can then enter the details of your first destination. If you want to change your start position then press
“Change Start”. You can then select how to find your start position.
Now press “Add”. You are then provided with various options to enable you to find your destination;
“Find using address”
“Find address by Postcode”
“Find using POI”
“Find using recent routes”
“Find by favourites”
Once you have entered the details press “Set” and the destination will appear on the screen. Press “Add” to enter additional destinations and once
finished press “Save”.

17.
Edit a Multi-stop route.
You are able to change the order or delete any stage of a Multi-stop route as follows:-
Press the middle of the screen to access the “Navigate” menu. Then press the “Multi-stop” icon and then press the name of the Multi-stop route
you want to edit. Press one of the stages listed and further options appear on the screen as below.
1. Delete the selected destination.
2. Change the destination. You can choose between final destination and stops.
3. Move the selected destination up.
4. Move the selected destination down.
5. Change the route option for that section of your journey.
Once you have made your changes press “Save”.
Use a Multi-stop route.
To use a saved Multi-stop route press the middle of the screen to access the “Navigate” menu. Press the “Multi-stop” icon, and then press the
name of the Multi-stop destination you want and press “Calculate”.
The unit will then calculate the route to each destination and display a new summary screen with the distance to each destination along with the
estimated duration of the journey to each destination stage. If you want to view the calculated route at this stage, press “Map”. If you wish to use
the Multi-stop route created, press “Go”.
If you press one of the stages listed before pressing “Go”, you will see a summary screen where you have various options as listed below.
Press “Go” to start navigation
Press “Simulation” to see the route calculated in detail.
Press “Route Option” to change the parameters of the route.
Press “Guide” to see turn by turn details of the route.

18.
The Multi-stop “Summary Screen” will display the distances between each destination as well as the time it is estimated it will take you to travel
between each destination.
Once you press “Go” the unit will return to the Map Navigation View showing your current position along with a mini summary screen.
If during your journey you want to cancel a current stage and go to the next stage then press the mini summary box and the message “Delete current
stage ?” will appear. Press “OK” and the unit will calculate the route to the next stage in the Multi-stop from your current position.
If the unit is turned off and then on again during a Multi-stop journey it will retain the current route and ask you if you want to continue with the
current destination or with the next stage of the Multi-stop route or if you want to cancel the Multi-stop route completely.

Auto-arrange a Multi-stop route.
Once you have created a Multi-stop route you can arrange the destinations into the most optimum order by using the “Auto-arrange” function.
1. Add an additional destination to your Multi-stop route.
2. Save the Multi-stop
3. Rearrange the Multi-stop into the most efficient/logical order
4. OK –this will be greyed out if no changes have been made
5. Return to previous screen
Once the route has been arranged press “Save” then “OK” and then “Calculate”. The unit will then calculate the Multi-stop route with estimated
times and distances. The route summary is then displayed and you can use the up and down arrows to view additional stops or the final destination.
Press “Go” to continue or “Map” to display the route on screen. You can use the + and – buttons to zoom in and out of the map view.
19.
Auto-arrange

20.
Recent routes
The unit can store details of the last 40 routes that have been calculated so that if you want to return to an address you do not have to enter all the
details again.
To calculate a route using this feature press the middle of the screen to access the “Navigate” menu and scroll until you see the “Recent routes”
icon and press it once. Next, select the destination/route you want to navigate to, from the list displayed and follow the on-screen instructions.
A list of your ‘Recent routes’ will be displayed in chronological order. Use the arrows on the right hand side of the screen to scroll through the list.
To start your journey press “Calculate”
To change the route parameters press “Route Option”
To view the location of the ‘Recent route’ press “Map”
To return to the previous page press the “Return” arrow.
Once the calculation is complete the following options are available.
Press “Go” to start navigation
Press “Simulation” to see the route calculated in detail.
Press “Route Option” to change the parameters of the route.
Press “Guide” to see turn by turn details of the route.
The “Summary Screen” will give you the distance to your destination along with the estimated time the journey will take and the estimated time of
arrival. The summary screen will be displayed for approximately 10 seconds and then your device will automatically proceed to the navigation map
view so you can begin navigating. If you want to manually proceed to the navigation map view before the 10 second period has elapsed, press the
“Go” button.
If you would like to clear the list press the ‘Delete all’ button.
Please note that once you have deleted this list you will not be able to retrieve it.
