ahead RC Crawler G3308
“Adventurer”
Assembly Manual
of 118
ahead RC

Requiredtoolsandhardware
Tools
-1.5mmHexDriver
-2.0mmHexDriver
-2.5mmHexDriver
-NeedleNosedPliers
-InstantGlue
-HotGlue
Electronics
-5mmWhiteLEDx2
-3mmOrangeLEDx6
Hardware!
of 218
ahead RC
Hardware
Quantity
Check
󲰬
M2*5Sockethead
12
M2*10Sockethead
17
M3*8Sockethead
4
M3*10Sockethead
1
M3*15Sockethead
4
M3*20Buttonhead(BH)
2
M3*10Grubscrew(GS)
2
M3*20Grubscrew(GS)
1

Beforeyoubegin
-Besuretoreadthroughthemanualandfamiliariseyourself
withtheinstructions
-Visualiseaplantoassembleallthepieces
-Makesureyouhaveallofthehardwareandtools
-Besuretohaveenoughinstantglue
-Dryfitallpartsbeforepaintingandassembling
Tip:Itwillhelptopaintallofthepartsbeforefinalassembly!
of 318
ahead RC

"
of 418
ahead RC
Combiningandassemblingthesplitcabandfenders
M2x10mmx4

"
of 518
ahead RC
M3x10mmGSx2

"
of 618
ahead RC
3mmOrange
LEDx2
3mm
Orange
LEDx2
Repeaton
theother
side
5mm
White
LEDx2
M2.5x10mm
x12

"
of 718
ahead RC
M2x10mm
x4
Repeaton
theother
side

"
of 818
ahead RC
Assemblingthedashboard
M3x10mm
x1
M2x10mm
x2
M3x20mm
GSx1

"
of 918
ahead RC
Assemblingthedashboard
M2x10mm
x1
M2x10mm
x2
M3x8mm
x4

"
of 10 18
ahead RC
Assemblingthedoorandmirrors
M2x5mm
x4
Repeaton
theother
door
M2x10mm
x4
Repeaton
theother
door

"
of 11 18
ahead RC
M2x5mm
x8
Repeaton
theother
door
Repeaton
theother
door

"
of 12 18
ahead RC
Repeaton
theother
side
Useglueor
hinges

"
of 13 18
ahead RC
Addingthedetails
Repeatonthe
otherside,totalof
6nuts

"
of 14 18
ahead RC
Repeatonthe
otherwiper

"
of 15 18
ahead RC
M3x20mm
BHx2
Assemblingandmountingthebumper
Slotinto
bumpermount

"
of 16 18
ahead RC
Mountingthebonnet
Useglueor
hinges

"
of 17 18
ahead RC
M3x15mm
x4
Repeatonthe
otherbody
mount
Installingthebodymounts

of 18 18
ahead RC
Bodyisnowfullycomplete.ThankyouforselectingaheadRCproducts.
Ifyouhaveanyquestionsorneedhelpwiththeassembly,pleasedonot
hesitatetocontactusat:
[email protected]
orvisitusat:
www.aheadrc.com
Bestofluckwithyourbuild!
