ahead RC Crawler V303 4x4 Flatbed
Assembly Manual!
of 110
ahead RC

Requiredtoolsandhardware
Tools
-1.5mmHexDriver
-2.0mmHexDriver
-2.5mmHexDriver
-NeedleNosedPliers
Hardware!
of 210
ahead RC
Hardware
Quantity
Check
󲰬
M3*10Countersunk(CS)
11
M3*10Sockethead
7
M3*15Countersunk(CS)
13
M3*15Sockethead
13
M3*20Grubscrew(GS)
4

Beforeyoubegin
-Besuretoreadthroughthemanualandfamiliariseyourself
withtheinstructions
-Visualiseaplantoassembleallthepieces
-Makesureyouhaveallofthehardwareandtools
-Besuretohaveenoughinstantglue
-Dryfitallpartsbeforepaintingandassembling
Tip:Itwillhelptopaintallofthepartsbeforefinalassembly!
of 310
ahead RC

!
of 410
ahead RC
Assemblingthebed
M3x20mmGS
x4
M3x15mmCS
x4
Skipthisstepifusing
alt.versionofbed

!
of 510
ahead RC
M3x10mmCS
x4
Repeatonthe
otherbrace

!
of 610
ahead RC
M3x15mmx9
Ignorethesideboardsanduse
thesamelengthscrewsbut
countersunktypeifusing
standardversionofflatbed.
M3x10mmx7
Repeatonthe
rightsideboard

!
of 710
ahead RC
Securescrewsintofender
Repeatontheotherfender
M3x15mmx4
Securescrews
throughfront
cab

!
of 810
ahead RC
Securescrewsintorearpanel

!
of 910
ahead RC
Tochassis

of 10 10
ahead RC
Bodyisnowfullycomplete.ThankyouforselectingaheadRC
products.
Ifyouhaveanyquestionsorneedhelpwiththeassembly,
pleasedonothesitatetocontactusat:
[email protected]
orvisitusat:
www.aheadrc.com
Bestofluckwithyourbuild!
