ahead RC Crawler Cat 1
Expedition Cab
Assembly Manual!
of 117
ahead RC

Requiredtoolsandhardware
Tools
-1.5mmHexDriver
-2.0mmHexDriver
-2.5mmHexDriver
-NeedleNosedPliers
-InstantGlue
-HotGlue
Electronics
-3mmOrangeLEDx6
-5mmWhiteLEDx2
-5mmRedLEDx2
-5mmOrangeLEDx2
Hardware
Hardware
Quantity
Check
󲰬
M2*5Sockethead
1
M2*10Sockethead
26
M3*10Sockethead
19
M3*15Sockethead
18
M3*15Buttonhead(BH)
12
M3*10Countersunk(CS)
31
M3*3Grubscrew(GS)
1
M3locknut
24
of 217
ahead RC

Beforeyoubegin
-Besuretoreadthroughthemanualandfamiliariseyourself
withtheinstructions
-Visualiseaplantoassembleallthepieces
-Makesureyouhaveallofthehardwareandtools
-Besuretohaveenoughinstantglue
-Dryfitallpartsbeforepaintingandassembling
Tip:Itwillhelptopaintallofthepartsbeforefinalassembly!
of 317
ahead RC

!
of 417
ahead RC
Combiningandassemblingthesplitcab
M3x15mmBH
x12
1.
2.
Repeatonthe
otherside
M3locknutx12
Repeatonthe
otherside
M3x10mmCS
x12
M3locknutx12
3mm
orange
LEDx6
Repeatonthe
otherside

!
of 517
ahead RC
M3locknutx12
M2x10mm
x1
OPTIONAL:
Eitherhardmountwithglue
oruseyourownhinges

!
of 617
ahead RC
M3x10mm
x18
Mountingthefenders
Ifusingwidetrackfenders:Use
M3x15mmx18

!
of 717
ahead RC
Assemblingtherearofthecab
M2x10mm
x8
Repeatonthe
otherside
Repeatforall
6lenses
5mm
OrangeLEDx2
5mm
RedLEDx2
5mm
WhiteLEDx2

!
of 817
ahead RC
M3x10mm
x6CS
M2x10mm
x3

!
of 917
ahead RC
M3x10mm
x2CS

!
of 10 17
ahead RC
Addingaccessories
Holdinplace
M2x5mmx1

!
of 11 17
ahead RC
M3x10mm
x1
M3x3mmGS
x1
M2x10mm
x2
M2x10mm
x2

!
of 12 17
ahead RC
M2x10mm
x2
M2x10mm
x4

of 13 17
ahead RC
M2x10mm
x2
Repeatonthe
otherside

!
of 14 17
ahead RC
Closegate
M2x10mm
x2
Repeatonthe
otherside
Repeatforall
6lenses
Repeatforall8
cabsidehinges
Repeatfor12
sidewindow
hinges

!
of 15 17
ahead RC
Repeatfor3rear
windowhinges

!
of 16 17
ahead RC
Mountingthefrontpanelofthecab
M3x10mm
x11CS

of 17 17
ahead RC
Bodyisnowfullycomplete.Thankyouforselectingahead
RCproducts.
Ifyouhaveanyquestionsorneedhelpwiththeassembly,
pleasedonothesitatetocontactusat:
[email protected]
orvisitusat:
www.aheadrc.com
Bestofluckwithyourbuild!
