Assembly Manual
of 123
ahead RC

Requiredtoolsandhardware
Tools
-2.0mmHexDriver
-2.5mmHexDriver
-NeedleNosedPliers
-InstantGlue
-HotGlue
Electronics
-5mmWhiteLEDx2
-5mmOrangeLEDx2
-5mmRedLEDx2
Hardware
Hardware
Quantity
Check
󲰬
M3x10Countersunk(CS)Screw
20
M3x10SocketHead(SH)Screw
12
M3x15Countersunk(CS)Screw
17
M3x15SocketHead(SH)Screw
8
M3x20Countersunk(CS)Screw
4
M3x20SocketHead(SH)Screw
2
M3Locknut
4
M3Washer(8-10mmouterdiameter)
2
M4x20grubscrew
13
Batterystrap(20-25mmwidth,
150-200mmlength)
1
of 223
ahead RC

Beforeyoubegin
-Besuretoreadthroughthemanualandfamiliariseyourself
withtheinstructions
-Visualiseaplantoassembleallthepieces
-Makesureyouhaveallofthehardwareandtools
-Besuretohaveenoughinstantglue
-Dryfitallpartsbeforepaintingandassembling
Tip:Itwillhelptopaintallofthepartsbeforefinalassembly!
of 323
ahead RC

"
of 423
ahead RC
M4x20mmGSx5
Combiningthehalfsplitbed
2.Apply
instantglue
andpushfit
ontogrub
screws
1.Tightenthegrub
screwsasmuchas
possible
ORfollowquartersplit
bedinstructionsbelow

"
of 523
ahead RC
Combiningthequartersplitbed
2.Apply
instantglue
andpushfit
ontogrub
screws
1.Tightenthegrub
screwsasmuchas
possible
M4x20mmGSx2
M4x20mmGSx5
M4x20mmGSx2

"
of 623
ahead RC
CombiningthesplitTALLHeadacherack
M4x20mmGSx4
2.Apply
instantglue
andpushfit
ontogrub
screws
1.Tightenthegrub
screwsasmuchas
possible
ORfollowSMALLheadache
rackinstructionsbelow

"
of 723
ahead RC
M4x20mmGSx4
2.Apply
instantglue
andpushfit
ontogrub
screws
1.Tightenthegrub
screwsasmuchas
possible
CombiningthesplitSMALLHeadacherack

"
of 823
ahead RC
MountingtheTALLheadacherack
M3x20mmCSx4
M3x15mmCSx4

"
of 923
ahead RC
MountingtheSMALLheadacherack
M3x20mmCSx4

"
of 10 23
ahead RC
Mountingthefrontcover
M3x10mmSHx2

"
of 11 23
ahead RC
M3x10mmCSx4
Repeatonthe
otherside
Mountingthefendersandsidecovers
M3x10mmCSx12
M3x10mmSHx6
Repeatonthe
otherside

"
of 12 23
ahead RC
Installingthefrontchassismount
Lineupholesto
preparefor
mounting
M3x15mmCSx4

"
of 13 23
ahead RC
M3x20mmSHx2
Assemblingthebumper
M3x10mmSHx2
ORfollowadjustablebumper
mountinstructionsbelow
Simplyinsertscrews
first,noneedto
tightenyet.

"
of 14 23
ahead RC
Mountingthebumper
M3washerx2
M3nylonlocknutx2
ORfollowadjustablebumper
mountinstructionsbelow
M3x10mmSHx2

"
of 15 23
ahead RC
Installingthebumperaccessories
5mmOrange
LED
5mmRed
LED
5mmWhite
LED
Repeatonthe
otherside

"
of 16 23
ahead RC
Installingthebumperassemblyontothechassis
1.slidebumper
mountintochassis
rails
2.slidechassismount
ontotheoutsideof
thechassisrailsand
lineupslotwith
bumpermountholes.
3.Drivescrews
throughchassis
mountslotinto
bumpermount
M3x15mmSHx6
Repeatonthe
otherside

"
of 17 23
ahead RC
Installingthebumperassemblyontothechassis
M3x15mmCSx4

"
of 18 23
ahead RC
Flatbediscomplete!
Toinstalltheincludedbatterybox,followtheinstructionsbelow!

"
of 19 23
ahead RC
BatteryBoxassembly
Threadbatterystrap
through.(recommended
20-25mmwidth
150-200mmlength)

"
of 20 23
ahead RC
BatteryBoxlidassembly
M3x15mmSHx2
Repeatonthe
otherside
M3nylonlocknutx2
1.Restlidontobox
compartmentandalign
slotswithholes
2.insertscrews
andlightly
tightennutson
insideofbox
compartment
