Aiper P1111 User manual
P1111
HANDHELD POOL VACUUMS
User Manual
Thank you for choosing AIPER handheld pool vacuum
You have joined millions of people to enjoy the convenience of robotic
pool cleaning.
This user manual helps you to keep your vacuum performing at its best.
Please take a few moments to read through it.
If you have any questions, please contact our customer service for assistance
or visit www.aiper.com for more information.
US Toll Free: 1-866-850-0666
Email: service@aiper.com
Facebook: @AiperOfficial
Aiper Customer Service:
1.1 Charger
1.2 Batter disposal
2. How to use?
2.1 How to connect with charger ?
2.2 How to assemble the cleaner ?
2.3 How to clear the filters?
2.4 How to assemble the batteries?
2.5 Trouble shooting
2.6 Environmental Programmes
1. Safety warnings
CONTENTS
1
3
3
4
4
4
6
7
----------------------------------
---------------------------------------
--------------------------------------
3. Warranty 9
9
8
-----------------------------------------
3.1 Statement 9
-----------------------------------
-------------------------------
-------------
-------------
--------------------
---------------
---------------------------
------------
1
The cleaner is not a toy, and is operated by people older than 8 years age.Any
people who operates the cleaner, has to read the manual carefully before work it.
(1) The cleaner is designed to clean the swimming pool, SPA.
(2) Please use the original batteries and charger when using.
(3) Only charging it when the cleaner is power off.
(4) Put the cleaner into a clean and dry place. Do not expose it under the sun,
or close to explosive.
(5) The filter bag is easy to be broken when there is sharp substances under water.
(6) Do not work it when out of water.
(7) Do not close to the vacuum head when it is working, due to its suction power,
especially for the human body, animals, hairs or clothes.
(8) Do not disassemble the cleaner without professional guidance or notice from
the authorized distributor or manufacturer.
(9) Do not leak the lubricant oil, and it causes water polluted.
(10) Stop to work the cleaner when there is anything wrong; Please contact with
the authorized distributor or replace it to the original parts/accesso ries.
(11) Cleaner working conditions:
(11)-1 Water depth from 30cm to 300cm
(11)-2 Water temperature: 4°C( 39.2°F )-35°C( 95°F )
1. Safety Warning
2
1. Vac head
2. Front filter
3. Cleaner body
4. Switch
5. Charging position
6. Poles fitting
7. Portable handle
8. Filter basket
9. Large mesh filter bag
10. Charger
Battery: lithium battery, 11.1V DC, 2000mAh
Charging power: 12.6V DC, 1000mAh
Motor voltage: 12V DC
9
3
(1) Use the original charger provided only.
(2) For indoor use only. The charger should not be used outdoor and not be
exposed to rain, humidity, any liquid or heat.
(3) Keep the charger out of children.
(4) Never use the charger if any damage is found.
(5) Do not handle the cleaner and charger with wet hands and bare feet,when
charging the cleaner.
(6) Disconnect the charger from power when not in use.
(7) If the wire is damaged, it must be replaced by a new charger to avoid danger.
(8) Make sure the cleaner and charger are totally dry before charging.
(9) Charge the cleaner 3 hours prior to the first use.Normally cleaner can be
operated about 60 minutes after fully charged.
1.1 Charger
1.2 Battery disposal
(1) The cleaner battery is a lithium battery, it must be disposed properly, please
contact with your local authority for more information.
(2) Never attempt to disassemble the lithium battery.
(3) Remove all personal items such as rings, bracelets, necklaces and watches
when unwiring a lithium battery from the vacuum unit.
(4) The battery causes short curcuit current, as well as severe burning when
it is high enough.
(5) Wear complete eye protection, gloves and protective clothing when removing
the battery pack.
(6) No smoking or sparkling flame near the cleaner, or, it may causes unknow
gases.
(7) If acid comes in contact with skin and clothing, wash immediately with
plenty of soap and water.
(8) If acid comes in contact with eyes, immediately flood eye with running cool
water for at least 15 minutes.Get medical attention immediately.
4
Above warning and cautions are not intended to incorporate all possible
instances for risks and/or severe injury. Pool/spa owners should always
exercise intensive caution and common sense when operating the cleaner.
(1) Before connection to the cleaner, firstly connecting the charger with socket
to check the charger quality, when the light is green, the charger is ok;Then,
connecting to the cleaner, if the light is red, it means the cleaner is charging.
(2) Around 3 hours later, the light turns to green, it means the machine is full
of power now.
2. How to use ?
2.1 How to connect with charger ?
2.2 How to assemble the cleaner ?
2.2.1 Component installation
Please assemble the machine by arrows, especially the signs ON/OFF , OPEN /
CLOSE at the body.
5
The cleaner can either connect with portable handle A, or standard telescopic
poles B ( B is not with shipment, needs to extra purchase )
2.2.2 Handle assembly
2.2.3 Suction head assembly
Please take the correct way to assemble the vacuum head and front filter,
please be sure the front filter way is right, otherwise, the cleaner can not work
efficiently.(See,Fig“A” and “B”)
AB
AB
6
2.2.4 Filter bag assembly
How to choose the correct filter bag?
(1) Large mesh filter bag
It is used for dirty pools, or plenty of rubbish into the pools, such as begin
ning of season, after big shower or rainning.
2.3 How to clear the filters?
2.3.1 Wash the front filter
Please follow the pics, and take care of machine sign OPEN/ CLOSE .
How to assemble filter bag?
Please take the steps per arrows:
DCBA
7
2.3.2 Wash the back filter
Please follow the arrows:
2.4 How to assemble the batteries?
DCBA
(1) Please follow the pics to get the batteries out.
(2) Please follow the pics to put the batteries into.
A B
b1 b3b2
C D
c1 c3c2
8
2.5 Trouble shooting
Problem Possible Cause Action
Battery is running
out
Impeller is jammed
Impeller is broken
Detach the filter basket and filter bag,
and clean them.
Replace a new filter sock.
Power off the cleaner and visually
check the gap in middle of the cleaner
to see if the impeller is jammed. you
can use your hand to rotate the
impeller two circles to make the
impeller rotation looser.
WARNING! Make sure cleaner is power
off when servicing the cleaner.
Charge the battery again. Normally
cleaner can operate about 60 minutes
after fully charged.
When the filter bag
is full
Filter sock is
damaged
Garbage flowing out
from the Transparent
Suction Head part
Garbage flow out from
the rear filter bag
Cleaner does not
capture the debris
Side pin broken Using the new V-Shape clip
Contact your dealer for impeller
replacement.
Handle/pole connector
cannot be secured in
assembly
The charger is out
of order WARNING! Using wrong charger will
result in damaging the cleaner
/battery and void the warranty.
Contact dealer for proper transformer.
Cleaner cannot be
recharged
Battery is dead
WARNING! When you replace the
battery, please contact the local
dealers to purchase the original
lithium battery in case that the electric
cleaner is destroyed.
Contact dealer for battery replacement.
The soft rubber of rear impeller is like
a door in case the garbage in the filter
bag will flow backwards into impeller
and the cover of transparent suction
head part.
The soft rubber of
the rear impeller is
broken
9
We reserve the right to change all or part of the features of the articles or contents
of this document, without prior notice.
2.6 Environmental Programmes
Please respect the local regulations and help to protect
the environment.
Return non-working electrical equipment to a facility
appointed by your municipality that properly recycles
electrical and electronic equipment, Do not dispose
them in unsorted waste bins.
For items containing removable batteries, remove
batteries before disposing of the product.
This product is covered by Aiper warranty for 12 months from the date of its
original purchase. If the product fails due to manufacturer defects, please contact
us by the following ways to launch a warranty. We will instruct you on how to
return the products for repair/replacement.
3. Warranty
We can only provide after sale services for products that are sold by Aiper, if
you have purchased your unit from a different place,please contact the seller
for return and warranty issues.
3.1 Statement
US Toll Free: 1-866-850-0666
Email: service@aiper.com
Facebook: @AiperOfficial
Aiper Customer Service:
