Operating Manual
T-300
Equipped With Perkins 404D.22T or Kubota V2403-TE Series Diesel Engine
Model Year 2016/2017
Air Curtain Burner
Trailer Mounted Trench Burner
“Better Economically - Better Environmentally”
Factory and Main Office
Air Burners, Inc.
4390 SW Cargo Way
Palm City, FL 34990
Phone: [phone] or 888-566-3900
FAX: [phone]
E-mail: [e-mail]
© 1998-2016, Air Burners, Inc.
The words Air Burners and the Air Burners Logo are Registered Trademarks of Air Burners, Inc.
All Rights Reserved. Subject to change without notice. Metric conversions rounded.
Rev. 09.16.0716 ( Vers. 09.16Pr )
Visit Our Web Site at:
www.AirBurners.com

This Page intentionally left blank.

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
(Vers. 08.16)
INDEX
THE PRINCIPLE OF AIR CURTAIN INCINERATION.....................................Page 1
GENERAL DESCRIPTION T-300 MODEL .....................................................Page 2
SAFETY CONSIDERATIONS.........................................................................Page 4
T-300 COMPONENTS ....................................................................................Page 7
HOW TO SET UP THE MACHINE T-300 UNIT ..............................................Page 8
T-300 WINCH OPERATION ...........................................................................Page 11
HOW TO BUILD A PIT....................................................................................Page 12
HOW TO OPERATE THE MACHINE..............................................................Page 14
SITE PREPARATION .....................................................................................Page 16
LOADING AND STARTING THE FIRE ...........................................................Page 19
HOW TO FEED THE FIRE .............................................................................Page 22
HOW TO BURN FIRE DOWN FOR SHUTDOWN ..........................................Page 23
HOW TO CLEAN OUT THE PIT .....................................................................Page 24
HOW TO PREPARE THE MACHINE FOR TRANSPORT ..............................Page 25
TROUBLESHOOTING ....................................................................................Page 26
MAINTENANCE AND CARE OF THE T-300 UNIT.........................................Page 27
INSTALLATION OF AIR FAN V-BELTS ………………………………………. Page 28
MAINTENANCE AND CARE OF THE MANIFOLD .........................................Page 29
OPENING COWLING FOR MAJOR MAINTENANCE ....................................Page 30
SERVICING SPECIFICATIONS — PERKINS ENGINE..................................Page 31
SERVICING SPECIFICATIONS — KUBOTA ENGINE...................................Page 32
TRAILER TOWING CHECKLIST ....................................................................Page 33
TRAILER WIRING DIAGRAM ........................................................................Page 34
i

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
(Vers. 08.16)
ii
T-Series Trench Burner 2016/2017
T-Series Trench Burners

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 1 of 34 (Vers. 08.16)
PRINCIPLE OF AIR CURTAIN INCINERATION
Air curtain incinerators are designed primarily as a pollution control device. Using a
Diesel engine driven fan, these machines generate a curtain of air with a very particu-
lar mass flow and velocity. This curtain of air acts as a trap over the top of an earthen
trench or thermo-ceramic lined pit. The wood debris is dumped into the trench or pit
and then ignited (usually with a propane torch or with a small amount of Diesel fuel)
just as you would light any other pile of wood you intended to burn. Once the fire has
gained strength the air curtain is turned on. The air curtain traps most of the smoke
particles and causes them to re-burn under the air curtain where the temperatures ex-
ceed 1,800º F. These machines do not inject any fuels into the fire, the fire is sustained
only by adding more wood debris. The air from the air curtain is not heated. The only
fuel used in the continuous operation is that of the Diesel engine driven fan.
1. Manifold and nozzles that create the air curtain over the refractory lined pit.
2. Wall of earthen pit.
3. Material to be burned.
4. High velocity “air curtain” over fire.
5. Continued air flow over-oxygenates fire keeping temperatures high.

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 2 of 34 (Vers. 08.16)
GENERAL DESCRIPTION T-300 SERIES
The T-300 is a mobile air curtain burner which is used in combination with an earthen
pit or trench made to function as the combustion chamber. The T-300 unit is a fully self
-contained, trailer mounted system that includes a power plant, mechanical drive sys-
tem, blower fan, manifolds, carrier pipe and fuel tanks.
This unit does not require assembly on site, as the carrier pipe and manifolds deploy
and unfold. The Diesel engine drives a fan which produces high velocity air. This high
velocity air is directed down the carrier pipe to the manifold. The carrier pipe is an im-
portant safety element, as it gives the machine the required “set-back” from the fire.
This set-back will help protect the machine, if the fire gets too high or if the wind
changes direction.
Once in the manifold, the air is evenly distributed across the burning trench through
the manifold nozzles. Air is directed across the top and down into the combustion
zone. The curtain of air acts as a top over the pit, trapping particulates (PM or small air
-born particles) and adding oxygen to the combustion zone, thereby generating a hot-
ter more complete fire.
Temperature achieved by this unit while burning clean wood and other vegetative
waste can range between 1,600º F and 1,800º F.
The air flow coupled with the recommended dimensions of the pit, creates an after-
burner effect. By re-circulating the air under the curtain, residence time of the particu-
lates is increased long enough for their effective combustion with very little smoke es-
caping.
T-300 Carrier pipe fully extendedT-300 Carrier pipe with manifolds folded

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 3 of 34 (Vers. 08.16)
All of this is carefully engineered to provide the correct amount of air at the correct
velocity. It is sometimes thought that more air flow will actually increase the burn
rate. This is INCORRECT. Modifying the air flow will actually have the opposite
effect and reduce the machine’s through-put. Additionally it will reduce the ma-
chine’s ability to meet air quality minimum standards. There is a maximum rate at
which wood can burn. Trying to exceed that rate by adding more air to an air cur-
tain burner causes two major problems:
1) It will cool the fire reducing combustion efficiency creating more smoke (carbon
dioxide and nitrogen enriched). This will begin a circular effect of further reduc-
ing the oxygen and further reducing combustion efficiency. The result is your
through-put drops and smoke increases.
2) Increasing the air flow beyond design standards will over pressurize the pit
causing larger sized particles to be ejected from the pit. Besides violating the
EPA limits for PM (particulate matter) the larger hotter embers ejected will
pose a much greater fire hazard.
T-300 Specifications
Model Overall Size
L × W × H
Trench Size
L × W × D
Weight
(Tongue)*
Fuel
Consumption**
gal/hr
T-300 28' × 8' 3" × 6' 10" 30' × 10' × 10’ 6,500 lbs.
(750 lbs.) 2.5
*) Hitch Select Appropriate Class Hitch for Trailer Towing
**) Diesel Engine Version: Perkins 404D.22T or Kubota V2403-TE (Tier 4 compliant). Diesel fuel consumption rated at aver-
age operating RPM and is approximate.
Drive System: PTO & multi-belt drive.
NOTE: All weights and dimensions are approximate. Subject to change without notice.

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 4 of 34 (Vers. 08.16)
The Air Curtain Burner operator is dealing with fire on a daily basis; it is very im-
portant that each and every individual involved with the machine be aware of and
practice very rigid safety precautions.
When you are running the machine, you are responsible for assuring that it is operat-
ed in the safest possible manner at all times. During the burning operations there
may not be any signs of smoke from the trench, but small hot embers will always be
coming out. These embers rise up on the hot gases from the fire. Operators must be
aware of the area around the unit to insure “spot fires” do not ignite. If you notice
something wrong, correct it immediately, and if you cannot correct it, find someone
who can and/or shut down the machine.
The T-300 is very safe as long as it is used and operated in the manner for which it
was designed; however, it will be no safer than an open fire burning above ground
when it is not being used and operated properly.
Basic Safety Points:
1. Personnel should not enter the pit while building it.
There is always the danger of the pit collapsing. Personnel should not enter the pit.
The pit should be secured and marked to prevent anyone from falling in.
2. Once the pit is in use the area should be restricted.
The area around the pit should be controlled by the trained operators. If the pit is to
be re-used the next day, then a security guard and secure fencing should be used
around the pit to insure no animals or humans will fall in. If the pit is not to be reused
then the fire should be extinguished and the pit filled in with dirt. The operators must
monitor the activities around the pit at all times.
3. The Machine must only be operated with the cowling closed and secured.
The top cowling provides a guard for the drive belts and fan inlet. There is a risk of
serious injury, if the machine is run with the cowling open.
SAFETY CONSIDERATIONS
READ ALL SECTIONS OF THIS MANUAL BEFORE YOU BEGIN BURNING OPERATIONS
DANGER: Falling into the fire pit will cause serious injury or death.
DANGER: Watch for DANGER NOTICES throughout this manual.

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 5 of 34 (Vers. 08.16)
4. The Machine should be placed on cleared, level ground.
The placement or positioning of the machine on the job site can be very important.
The machine should be placed in a manner to give the greatest clearance on the
downwind side of the pit. The unit should be placed on level ground to facilitate proper
positioning of the manifold alongside the pit.
5. The Machine should be placed such that no combustible material is within a
minimum of 100 foot clearance in any direction.
The machine should not be located over combustibles, such as dry grass, brush or
peat moss. In addition, hot embers will escape from the pit and, depending on the
wind, will land on the ground around the unit. The unit should not be located within 100
feet of any combustible material.
The waste material to be burned during the day’s operation can be staged within the
100 foot perimeter to facilitate loading. The operator must monitor the loading pile to
insure embers do not ignite the loading pile. The combustible materials to be stored for
burning at a later date must be stored outside the 100 foot perimeter or in accordance
with the chart below which suggests adjustments for wind speed.
DANGER: The above distances serve as a GUIDELINE ONLY! You MUST
ALWAYS observe the down range area regardless of the wind speed. You
must always observe local fire ordinances and directives from the local fire
department or other authorities.
WIND SPEED VS. SAFE DISTANCE
Approximate Safe Distance for:
Wind Speed
(MPH)
Structures
(Houses, etc.)
Woods/Trees
Stored Brush Piles
10 300' 150' 100'
12 300' 150' 100'
14 300' 200' 150'
16 400' 250' 150'
18 400' 250' 200'
20 500' 250' 200'

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 6 of 34 (Vers. 08.16)
6. The Machine should not be operated when the wind speeds reach 20 MPH.
As an operator you should always be aware of wind speed and direction. Increased
wind speed will affect the integrity of the “air curtain” and will cause hot embers to trav-
el farther. See the wind speed chart on Page 5 regarding the suggested set back.
7. NEVER use highly combustible materials to light the pit.
Highly combustible materials such as gasoline, refined spirits, etc. ignite at an explo-
sive rate which may cause serious injury or death. The safest method to start the fire
in the pit is to use materials, such as paper and kindling wood. In the absence of these
materials or when starting materials with a high moisture content, Diesel fuel oil is an
acceptable option.
8. Shut the unit down in an emergency.
Stop loading the pit, stop the air flow by either disengaging the PTO or by shutting
down the engine. Dump dirt, sand or water into the fire pit.
9. Personal Safety
Operators need to be aware of the following
potential hazards:
A) Flying hot embers being released from
the fire. Operators or anyone within the
100 foot radius of the fire should wear ap-
propriate fire resistant clothing. The ideal
outwear for an operator would include a
Nomex jacket, leather gloves, eye protec-
tion, hard hat, cotton work jeans and steel
toe boots. Operators should never wear
synthetic material (i.e. polyester) around
the fire as this type of material can melt
and cause injury. Additionally, some syn-
thetic materials will support combustion
and could be very dangerous around fire.
One hundred percent cotton materials would be the minimum, cotton treated with a
fire retardant would be better and fire proof materials, like “Nomex”, would be best.
B) Noise, ear protection is recommended around the machines. It is a good
practice to wear approved ear protection when working in close proximity to the fan
and engine.
C) Ash and dust can be released during the operation and during cleaning. Op-
erators should wear appropriate breathing masks to protect themselves from inhal-
ing the dust and ash.

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 7 of 34 (Vers. 08.16)
T-300 COMPONENTS
T-300 positioned at trench
T-300, manifold assembly retracted
T-300 Manifold Extended

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 8 of 34 (Vers. 08.16)
DANGER: THE MACHINE MUST ONLY BE OPERATED WITH THE WHEELS
CHOCKED AND THE COWLING CLOSED AND SECURED.
IF THE MACHINE IS OPERATED WITH THE COWLING OPEN, THEN THE DRIVE
BELTS AND FAN INLET ARE UN-GUARDED, AND THERE IS THE RISK OF SERIOUS
INJURY.
HOW TO SET UP THE MACHINE
Cowling Latches
1. Once the machine is in the correct loca-
tion, first chock the wheels with suitable
blocks or wedges to keep the trailer from
moving, disconnect your tow vehicle.
Next remove the two jacks from the stor-
age box under the top cowling and fit
them to the jack points at the rear and
front of the trailer. Using the three jack
stands, level the trailer.
2. Lift the cowling of the machine and se-
cure it with an appropriate cowling sup-
port prop rod / device.
3. Check engine fluid levels, top up as nec-
essary.
4. Check drive belts (see Page 29).
5. Check PTO and fan bearings for grease,
re-grease per maintenance schedule.
6. Check engine for leaks, check for any
loose components and any obstructions
at the fan inlet.
7. Close the top cowling and secure all
latches (See Photo on right). Lock “D” lift
latch.
“D” lift latch

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 9 of 34 (Vers. 08.16)
8. Use the jacks to set the trailer level.
9. Remove the carrier pipe locking bolt,
use this bolt to secure the manifold in
step 12. NOTE: When the T-300 first
arrives, the locking bolt is replaced with
a “travel bolt assembly” for flatbed truck
transport. Remove this device before
first use and replace it with the locking
bolt shown here. You will find it in a
pouch in the “Black Binder” that con-
tains the Operating Manual (Shipped in
the T-300 tool box).
10. Release the front winch and extend the
carrier pipe manually by pulling the grab
handles. Do not use any equipment or
machinery to accomplish this.
11. Extend the carrier pipe completely until
the yellow/black arrow indicator shows
full extension and you reach a hard stop.
DANGER: IF THE TRAILER IS NOT SET LEVEL THEN THERE IS THE RISK
THAT THE CARRIER PIPE WILL EXTEND OUT OF CONTROL AS SOON AS THE
LOCKING BOLT IS REMOVED. THIS COULD CAUSE SERIOUS INJURY OR
DAMAGE TO THE UNIT.
Carrier pipe locking bolt
Carrier pipe grab handles
DANGER: THE REAR JACK STANDS MUST BE EXTENDED BEFORE PULL-
ING THE MANIFOLD OUT, OR THE MACHINE WILL TIP BACK AND YOU COULD
BE SERIOUSLY INJURED.

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 10 of 34 (Vers. 08.16)
12.Swing the manifolds out and secure
them by fitting the locking bolt from
Step 8.
13.Lower the two rear jacks so that the
manifold rests squarely on the ground.
14.With the machine and manifold posi-
tioned, you can now mark-out the di-
mensions for the pit.
NOTE: THE FRONT OF THE TRAILER
WILL RISE. THIS IS NORMAL.
Locking bolt at center of the manifold
Rear Jack stands
T-300 Carrier pipe fully extended
and manifold on the ground
T-300 Carrier pipe fully extended,
Manifolds partially extended

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 11 of 34 (Vers. 08.16)
A. WINCH OPERATION FOR PULLING OUT
MANIFOLD/CARRIER PIPE ASSEMBLY
1. Level trailer.
2. Release ratchet by pushing the ratchet release lever
forward-down (See Photo on right).
3. Proceed with manifold extraction following the in-
structions on Pages 8 through 10.
DANGER: Be sure to keep hands clear off
handle, as it will be spinning during manifold ex-
traction. A spinning handle can cause severe in-
jury.
B. WINCH OPERATION FOR RETRACTING MANIFOLD/
CARRIER PIPE ASSEMBLY BACK IN THE TRAILER
1. Level trailer.
2. Follow instructions for transport and storage on
Page 26.
3. Engage the ratchet by pushing it up .
4. Crank the handle.
5. Crank the manifold in until the safety bolt hole lines
up with the bracket.
6. Install the safety bolt and secure it with nut and
cotter pin (see Photo on right).
7. For added security, leave the nylon strap tension
tight.
DANGER: The trailer must be level to prevent
the manifold from sliding in or out unintentional-
ly. Do not operate the winch or release the Ratch-
et, if the manifold will slide out unattended.
MANIFOLD ASSEMBLY WINCH OPERATION
Ball hitch adapter (optional),
safety chains, pigtail,

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 12 of 34 (Vers. 08.16)
HOW TO BUILD A PIT
1. The pit needs to be constructed with straight, vertical walls to the dimensions shown
on Page 13.
2. With the manifold resting on the ground, mark the outline of the pit. Leave the trailer
and manifold in position, if possible as it will save time in relocating the trailer.
3. Excavate as close to the manifold without damaging it (see the photo on the next
page). This will give you the proper manifold position to ensure that the manifold
does not protrude over the edge of the pit which may lead to excessive tem-
perature build-up in the manifold which will cause damage to the manifold.
4. The ground under the machine needs to be as close to level as practical. If the
ground slopes down from the pit this will cause the air curtain to be too high and if
the ground slopes up from the pit this will cause the angle to be too low.
NOTE: IF YOU HAVE TO BUILD UP THE GRADE IT IS IMPORTANT THAT THE
FILL IS WELL COMPACTED, SUCH THAT A STABLE PIT MAY BE FORMED.
5. After the pit has been used for several days, it may need some re-construction due
to partial collapse. After the pit becomes wider that 10 feet and the walls are less
than vertical, the unit will begin to lose its effectiveness and may start to emit more
smoke and particles than desired. At this point you should either repair the pit or re-
locate and construct a new pit.
DANGER: THE PIT SHOULD BE PROTECTED AT ALL TIMES, USING A
SUITABLE FENCE, BARRIER OR ENCLOSURE TO PREVENT PERSONNEL
OR ANIMALS FROM FALLING IN.

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 13 of 34 (Vers. 08.16)
The standard pit dimensions are shown below:
Pit excavation with manifold positioned

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 14 of 34 (Vers. 08.16)
PRE-CHECKS
Check all belts and fluids.
Make sure the top cowling is down and locked and
secured.
Make sure the clutch (PTO) is disengaged (the
lever in the down position).
Make sure the engine speed control is at minimum
by turning the black speed knob clockwise.
STARTING
If preheat is needed, press the PREHEAT switch
for maximum six seconds.
To START
(a) the Perkins engine, push the start button and
hold down the oil pressure override button.
(b) the Kubota engine, turn key clockwise and hold
for three seconds after engine starts (this will
override the oil pressure cut-off sensor, until oil
pressure builds up).
WARM-UP the engine at Idle speed of 1,000 RPM for 5
to 10 minutes before engaging the fan at 1,400 RPM +/-
200 RPM.
Engage the AIR FAN by slowly engaging the
clutch lever to the “up” position until it locks
into place. Engaging the clutch too fast or at
higher RPM may cause the air fan drive belts to
jump the drive pulleys.
DANGER: THE MACHINE MUST
ONLY BE OPERATED WITH THE TOP
COWLING CLOSED AND SECURED.
HOW TO OPERATE THE MACHINE
Perkins 404D Start/Stop
“Murphy” Switch
Clutch (PTO) Lever, Fuel Filler
Perkins 404D Control
Panel Housing

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 15 of 34 (Vers. 08.16)
RUNNING
Engine and fan speed may now be in-
creased as required by turning the speed
control knob counter-clockwise.
See Page 19 “Loading and Starting the
trench burner” for operating RPM sugges-
tions.
SHUT-DOWN
To shut the machine down, first reduce the
engine RPM to approx. 1,400 RPM by turn-
ing the black throttle knob clockwise.
Disengage the clutch by pushing down on
the lever until it unlocks into the disengaged
position.
Turn key to STOP.
Once the fan and engine have stopped then
you should lift the cowling and isolate the
battery by disengaging the battery switch
located on the battery..
Disengaging the AIR FAN with the PTO
abruptly at higher RPM or turning off the
engine with the key switch or STOP But-
ton while the PTO is still engaged may
cause the air fan drive belts to jump the
drive pulleys which may cause damage
to the drive system.
If the engine is stopped suddenly at higher
RPM with the PTO still engaged and the air
fan in fast motion, the fan’s inertia may
cause the belts to jump the pulleys. See
Page 29 for instructions on how to install
the dual drive belts.
Control Panel Housing, PTO Lever,
Throttle and Fuel Tank Filler Neck
Control Panel ( Kubota )
Tachometer, Temperature Gauge, Oil Pres-
sure Gauge, Key Switch, Hour Meter and Fuel
Level Gauge

Air Burners, Inc.
T-300 Air Curtain Trench Burner with Perkins 404D.22T or Kubota V2403-TE Engine
OPERATING MANUAL
Page 16 of 34 (Vers. 08.16)
THE GOALS TO GOOD SITE PREPARATION ARE:
To locate the machine and fire pit for easy access
To sort the waste wood pile
To organize the inflow of new wood waste
When locating the machine and fire pit:
Consider access for your truck and trailer to deliver the machine. Ensure that there is
enough room to maneuver your vehicle. The (optional) ball hitch adapter may be re-
moved to use the pintle hitch in the field for towing by tractor.
Consider where the waste piles will be located. We generally recommend two waste
piles (explained in next section).
Consider the predominate wind direction. Hot embers will be escaping from the fire pit
during all burning operations.
Consider where and how (or if) you will empty the ash from the pit. If you plan to exca-
vate the ash out of the pit to empty it, ensure there is room and the soil conditions are
not too soft. If you are going to excavate the ash out, then consider where you will
dump it. In most cases cold ash can be reapplied to the land. Check your local authori-
ties.
DANGER: This machine DOES NOT prevent hot embers from escaping.
This machine is designed primarily as a pollution control device to reduce
the smoke generated from burning clean wood waste.
SITE PREPARATION
