Air King AK927 User manual

SPECIFICATIONS
HEATER WITH EXHAUST FAN
AK927
Specifications subject to change without notice.
CUS
• Grill
White, polymeric grill (flame retardant ABS UL rated 94-5V)
secured in place with torsion springs; easily removed if
neccessary, dimensions - 161/2" x 10".
• Blower Wheel
One piece polymeric wheel, 37/8"diameter, 21/2"wide with 21 fins.
• Motor
Heavy duty, plug in 2 pole motor. Life time lubrication, thermally
protected. Rated 120 volts, 60 hz., 0.90 amps.
• Fan Housing
23 gauge galvanized steel housing. Dimensions 137/8" x 8" x 57/8".
• Duct Collar
Plastic collar for 4" duct connection, comes complete with built in
non-metallic back draft damper for quiet operation.
• Ventilating Area
For bathrooms up to 70 sq. ft.
• Lamping Information
2 - 250 watt maximum, type R40 bulb, medium base, 850 Btu. with
shaped aluminum socket housing with porcelain socket.
(lamp not included)
• Unit Mounting
The housing will mount in ceilings with at least 6" of
clearance and through drywall thickness up to 3/4", with a
rough-in opening of 137/8" x 8". Rated for ceilings insulated
to R-40. The housing will mount between 16" on center
joists, using the 4 supplied housing mounting rails.
• Single Pack Shipping Info
Box Dim: 18" x 111/2" x 73/4"
UPC: 0-8316227011-5
Shipping Weight: 9 lbs.
PERFORMANCE
HVI Sones Fan Speed Power
Static Pressure (inches of w.g.) @ .1 SP RPM Watts
0 0.05 0.1 0.125 0.15 0.2 0.25 0.3
Air Flow - CFM
CUL/HVI - TYPE IC RATED
PROJECT
LOCATION
CONTRACTOR
ARCHITECT
ENGINEER
SUBMITTED BY DATE
FAN MODEL CFM IN RPM WATTS AMPS SONES QTY OPTIONAL EQUIPMENT
NUMBER NUMBER W.G. & REMARKS
57/8"
4"
137/8"
10"
161/2"
8"
Updated 1-11
U.S.: 820 Lincoln Avenue
West Chester, Pennsylvania 19380-4466
Tel: [phone] • 877-304-3785
Fax: [phone]
Canada: 8 Edvac Drive
Brampton, Ontario L6S 5P2
Tel: [phone]
Fax: [phone]
70 CFM/3.5 Sones @ 0.10" SP., 120 Volts, 4.6 amps, 60 hz.
