Air Monitor Corporation S.A.P./ B Operating and maintenance manual

S.A.P. / B,P,S,R
INSTALLATIONPROCEDURE
WARRANTY
AirMonitorCorporation(hereinafterreferredtoas"Seller")warrantsthatatthetimeofshipment,productssold
pursuant to this contract will be free from defects in materials and workmanship, and will conform to the
specificationsfurnishedorapprovedinwritingbySeller.Nowarrantyisgiventhatdeliveredproductswillconform
to catalog sheets, data sheets, and the like, which are subject to change without notice.
Seller will repair or replace, at its option, any products listed under this warranty which is returned freight pre-
paidtoSellerandwithintheearlierofone(1)yearafterstart-uporfifteen(15)monthsaftershipment,proveupon
testandexaminationbySellertobedefectivewithinthetermsofthiswarranty. Thewarrantyperiodforanyitem
repairedorreplacedshallbeforthetimeremainingonthewarrantyperiodfortheoriginalcomponents. Purchaser
shall notify Seller in writing of such defect within sixty (60) days of discovery of the defect.
This warranty does not extend to any product sold by Seller which has been the subject of misuse, neglect,
accident,damageormalfunctioncausedbyinterconnectionwithequipmentmanufacturedbyothers,improper
installationorstorage,orusedinviolationofinstructionsfurnishedbySeller,nordoesitextendtoanyproduct
which has been repaired or altered by persons not expressly approved by Seller. Nor does Seller warrant
equipmentagainstnormaldeteriorationduetoenvironment;noritemssuchasthermocouples,electrodes,and
similaritemssubjecttowearorburnoutthroughusage. Adjustmentsforitemsorequipmentnotmanufactured
by Seller shall be made to the extent of any warranty of the manufacturer or supplier thereof.
Seller shall not be liable for any special or consequential damages or for loss of damage directly or indirectly
arising from the use of the products.
Thewarrantysetforthaboveisinlieuofallotherwarrantieseitherexpressorimpliedandconstitutesthefullextent
ofAirMonitorCorporation'sliabilitytothecustomer,oranyotherpartyforbreachofwarranty. THEREARENO
EXPRESSWARRANTIESEXCEPTASSETFORTHHEREIN. THEREARENOIMPLIEDWARRANTIESOF
MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE, WHICH ARE PARTICULARLY
DISCLAIMED.
INSPECTION & HANDLING. S.A.P.s should be carefully inspected for damagepriortoinstallation.Reportdamage to
yourFreight Department, or contact thedelivery carrier.
S.A.P.s may be handled while in any position. However, it is important not to drop or mishandle the probes such
that damage is done to sensing holes or the static signal connections.

S.A.P. / B,P,S&R– Installation Procedure
- 2 -
INSTALLATION OF PROBES. The S.A.P./S and S.A.P./R are furnished with a predrilled mounting plate for bolting
orscrewing to mountingsurfaces, using threefasteners.
S.A.P./R – Recessed Flush Mount
S.A.P./R – External Flush Mount
S.A.P./S – Surface Mount

S.A.P. / B,P,S&R– Installation Procedure
-3-
INSTALLATION OF PROBES.
S.A.P./P – Pipe Mount
S.A.P./B – Electrical Junction Box Mount
The S.A.P./P is furnished with a 1/2" FPT signal connection which is also used for mounting.
The S.A.P./B is mounted into a standard 2x4 electrical junction box (provided by others).
SIGNAL TUBING. Signal tubing may be 1/4" O.D. if the distance from the S.A.P. to the transmitter is 200' or less.

S.A.P. / B,P,S&R– Installation Procedure
-4-
1050 Hopper Avenue • Santa Rosa, CA 95403 • 707-544-2706 • www.airmonitor.com
INSTALL40A(06/06)
CUSTOMER SERVICE.AirMonitor Corporation provides in-house technical support forall our products:
Monday through Friday, 7 am to 5 pm (pst)
Phone:[phone]or1-800-AIRFLOW / Fax:[phone]
If after contacting the Customer Service Department it is determined that equipment will require return toAir Monitor
Corporationforfurtherrepair,a ReturnAuthorization number willbeissued.AConfirmationofReturnAuthorizationwith
shippinginstructionswill be sent via facsimile.Equipmenttobe returned toAirMonitor should be returnedin its original
shipping container if possible. If this is not possible, ensure equipment is packaged sufficiently to protect it during
shipment.
Caution: All damage occurring during transit is the Customer’s responsibility.
List the Return Authorization (R/A) number on the packing list and clearly mark this number on the outside of each
shipping container. Costs associated with the return of equipment to Air Monitor Corporation are the customer’s
responsibilityregardless whethertherepair/returnisunderwarranty.Oncethe CustomerServiceDepartmentdetermines
that the equipment repair is under warranty, the item will be repaired and returned to the customer at no charge. If the
equipment is not under warranty, customer will need to approve a repair quote which will be invoiced along with return
shippingcharges.
