air sniper Spectrum-800 User manual

Spectrum-800
USER MANUAL

Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca
EPA Facility Registration Number 100516-CAN-1
2
A WORD TO AIR SNIPER OWNERS
At Air Sniper, we design and build air supplemental air sanitization systems with
complete customer satisfaction in mind. To assure trouble-free operation of your
supplemental air sanitization system, please read this manual and follow installation
recommendations.
An authorized Air Sniper representative will know the system best, and if service or
maintenance is needed, the Air Sniper team is here to help. Our team is dedicated
to providing you with the best possible service and assuring your satisfaction with
our product.
For inquiries, questions or concerns regarding the unit, or any other Air Sniper
products contact:
1.866.472.1059
Air Sniper Bay 11
6565 40th Street S.E.
Calgary, AB Canada T2C 2J9
Call, email or fill out the online form and one of our customer service
specialists will get in touch with you.
© AIR ALPINE INNOVATIVE RESEARCH INC. All rights reserved. This document is subject to change without notice.
All Air Sniper trademarks and logos are owned by Air Sniper or one of its affiliates. Unless expressly noted, names and brands of third parties that may be used in this document
are not used to indicate an affiliation or endorsement between the owners of these names and brands and AIR ALPINE INNOVATIVE RESEARCH INC. Those names and
brands may be the trademarks or registered trademarks of those third parties. Because we are continuously improving our products and services, Air Sniper reserves the
right to change specifications without prior notice. Air Sniper is an equal opportunity employer.

Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca
EPA Facility Registration Number 100516-CAN-1
3
TABLE OF CONTENTS
HOME PAGE................................................................................................................1
AWORD TO AIR SNIPER OWNERS................................................................................ 2
TABLE OF CONTENTS...................................................................................................... 3
IMPORTANT SAFETY INSTRUCTIONS .............................................. 4
ABOUT YOUR UNIT ........................................................................................................... 5
DESIGN ................................................................................................................................. 5
FEATURES ........................................................................................................................... 6
SPECIFICATIONS ............................................................................................................... 6
INCLUDED PARTS...............................................................................................................7
DIRECTIONS FOR USE..................................................................................... 8
BULB STATUS.....................................................................................................................11
FILTER REPLACEMENT.....................................................................................................11
TROUBLESHOOTING...................................................................................... 12
ADDITIONAL FACTORS...................................................................................................12
REPLACING YOUR UNIT..................................................................................................13
WARRANTY.............................................................................................................. 14

Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca
EPA Facility Registration Number 100516-CAN-1
4
IMPORTANT SAFETY INSTRUCTIONS
WARNING: NEVER EXPOSE SKIN OR EYES TO UV LAMP WHEN OPERATING
Read and follow all instructions prior to installation. Read the directions and all safety
labels prior to operation. Failure to follow any instructions or labels may result in injury of
the user or damage to the unit. Save this manual for future reference.
1.
The Spectrum-800 unit is intended to be used
for supplemental air sanitization. Do not
attempt to operate the UV-C lamps outside of
the sealed housing.
2.
Electrical shock may cause Injury or possible
death. Ensure that the unit is turned off and
disconnected from the power source prior to
installation or replacement.
3.
Untrained personnel can perform installation
and replacement of the unit as per the
instructions within this manual. Do not attempt
to perform any maintenance on your unit.
Improper maintenance can result in damage
to the unit and injury of the user. If your unit
requires maintenance, please contact Air
Sniper. Replacement of the UV-C lamp by the
user is not allowed.
4.
Do not attempt to modify your unit.
Modification of this unit may result in injuries
to the user or damage to the unit.
5.
Inspect your unit for any abnormalities or
damage prior to installation and use.
Damaged units can result in harmful UV-C
leaks. Do not operate units that are damaged.
6.
If the supply cord is damaged, it must be
replaced by the manufacturer, a service agent
or similarly qualified persons in order to avoid
a hazard.
7.
This appliance contains a UV-C emitter. UV-C
lamps contain small amounts of mercury. If the
lamp is broken or damaged, clean and
dispose of it properly as per your local safety
regulations.
8.
The Spectrum-800 unit is not to be used by
persons (including children) with reduced
physical, sensory or mental capabilities, or a
lack of experience and knowledge, unless
properly supervised. Children shall be
supervised so that they do not to play with the
unit.
9.
It is recommended a minimum of 2 people are
present when installing the unit. Units can be
heavy and require care and precision when
installing.
10.
Air Sniper products are not waterproof. Do not
attempt to use your unit in a wet environment.
11.
Air Sniper products are designed for indoor
use only. Do not attempt to install your unit
outdoors.
12.
The use of this device is a supplement to and
not a substitute for standard infection control
practices; users must continue to follow all
current infection control practices related to
cleaning and disinfection of environmental
surfaces.
13.
The Spectrum-800 unit does not require
cleaning to continue to operate effectively.
14.
FIRST AID INSTRUCTIONS: If Injury occurs,
contact your doctor or appropriate emergency
services.
15.
WARNING: UV RADIATION EMITTED FROM
THIS DEVICE. Unintended use of the
appliance or damage to the housing may
result in the escape of dangerous UV-C
radiation. UV-C radiation may, even in small
doses, cause harm to the skin and eyes

Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca
EPA Facility Registration Number 100516-CAN-1
5
ABOUT YOUR UNIT
Thank you for purchasing the Air Sniper Spectrum-800 supplemental air sanitizing
unit.
For more information on the Spectrum-800 unit and all other Air Sniper products
and services, call (Toll Free) 1-888-338-9549, visit www.airsniper.ca or email Air
Sniper at info@airsniper.ca with any questions, comments or concerns.
DESIGN
The Spectrum-800 is made up of several key components listed below.
The Spectrum-800 unit is designed for supplemental air purification in commercial and
residential spaces such as classrooms, office spaces and communal living areas. The
Spectrum-800 allows for continuous supplemental sanitization of airflow up to 800 CFM. For
greater airflow environments, multiple units may be necessary.
1.
LED Indicators
2.
Display Screen
3.
On/Off Switch
4.
Merv-8 Pre-filter
2
3
1
4

Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca
EPA Facility Registration Number 100516-CAN-1
6
FEATURES
- 300 Watt UV-C Induction Lamp
- 6+ Year Lamp Life (55,200 Hours)
- Bluetooth Enabled
- Control Monitor
- 10x Fan Speeds
- Plug & Play
SPECIFICATIONS
Power Supply
Single Phase, 110v - A/C 50/60 Hz
Energy Consumption
6 Amp Max @ 110v A/C
Operating Temperature Range
-25°C / 100°C
Power Control Systems
Control Monitor, On/Off Switch, Airflow
Differential Pressure Sensor
Bulb Life
55,200 hours (6+ years) of high intensity
UV-C.
CFM
300– 800
Electrical Safety Certification
cETLus, UL & CSA Standards
Ozone Certification
UL867 (Lamp meets UL2998 requirements)
Weight
75 lbs (34.0 kg)
Dimensions
42.5” (H) x 24.5” (W) x 19” (D)
Housing Material
White Powder Coated Aluminum
Noise
21-47 dB (A)

Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca
EPA Facility Registration Number 100516-CAN-1
8
DIRECTIONS FOR USE
CAUTION: Use care when unboxing and handling your unit. Ensure adequate space is
available for unboxing, installation, and operation prior to attempting to handle your unit.
Ensure that the intended placement of your unit allows access to the necessary power
requirements and does not create a hazard once connected.
To operate your Spectrum-800 unit,
1. Connect the supplied 10’ power cable to the unit. The connector end for the cable is
found on the back of the unit.
2. Locate the nearest appropriate 110v A/C receptacle. If required, an extension cable can
be used to extend the distance from the power receptacle. Proceed to plug in the unit.

Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca
EPA Facility Registration Number 100516-CAN-1
9
3. Next, insert the Merv-8 Pre-Filter into the metal brackets on the bottom front
face of the unit. Ensure the direction of the filter is correct by verifying the metal
edges inside the filter are facing upwards.
4. Confirming the power is properly connected, turn the unit on using the On/Off
switch located on the front of the unit.
5. Adjust the fan speed to the desired level, the Spectrum-800 requires a
minimum airflow to begin lamp operation.

Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca
EPA Facility Registration Number 100516-CAN-1
10
6. The “Power On” LED should illuminate, if not turn the unit back off and inspect
the cable connections to verify the unit is properly connected. Verify the fan
speed setting is above 0.
a. If all the connections are correct and the outlet is tested to verify the unit
is receiving power but the “Power On” LED still isn’t illuminated, turn your
unit off and contact an Air Sniper representative.
7. Once the fan speeds are above 0 and airflow is detected, the “Lamp
Operating” LED will illuminate, indicating the UV-C Lamp is on.

Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca
EPA Facility Registration Number 100516-CAN-1
11
BULB STATUS
The “Lamp Operating” LED can illuminate three different colors,
indicating differing bulb status.
The variations are as follows:
Green: Lamp operating, the lamp is operating as intended.
Yellow: Lamp life warning, the lamp is nearing the end of its lifespan,
requires replacement in the near future.
Red: Lamp life exceeded, lamp has reached the end of its lifespan,
requires immediate replacement.
When the “Lamp Operating” LED color is yellow indicating “Lamp Life Warning” please contact
your local distributor or an Air Sniper representative directly for a replacement. The Spectrum-800
is designed as a complete unit, therefore when the lamp expires, the entire unit must be replaced.
FILTER REPLACEMENT
The Air Sniper Spectrum-800 unit uses a Merv-8 Pre-Filter that is sized at 10” x 18” x 1”.
Air Sniper recommends changing this filter once every three (3) months. If using the Spectrum-800
in an excessively dusty/dirty environment, a filter change may be needed sooner, do so at your
own discretion. Merv-8 filters can be purchased locally or ordered online.
The Air Sniper Spectrum-800 warranty and performance specifications are only applicable to
users who consistently use a Merv-8 Pre-Filter in their Spectrum-800. All other air filters are not
capable of filtering the level of particulates required by the Spectrum-800.

Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca
EPA Facility Registration Number 100516-CAN-1
12
TROUBLESHOOTING
If your unit is not operating as expected, there are several steps you can take to attempt to correct
the problem.
If the “Lamp Operating” LED is not illuminating after powering on:
- Inspect the unit and the power cable to verify nothing appears damaged.
- Check that the selected power source is in fact providing power to the unit.
- Check that the On/Off switch is flipped to the on position.
- Once airflow is established with a fan speed from 1-10, the lamp indicator
light will be lit.
- Check that both ends of the 10’ power cable are securely connected to the
unit and the power source.
WARNING: Do not attempt to operate the UV-C lamp outside of the unit
enclosure. UV-C radiation is extremely harmful to unprotected skin and eyes.
ADDITIONAL FACTORS
Given that air pressure can change at differing elevations and differing humidity levels, for
safety reasons the lamp requires a minimum value of airflow to ensure safety.
If the “Lamp Operating” LED is not illuminated and you’ve verified a
correct setup. Try increasing the airflow using the control monitor by
adjusting the fan speed.
If the “Lamp Operating” LED is not able to illuminate at any fan
speed and troubleshooting didn’t solve the issue.
Please contact your Air Sniper representative at 1.888.338.9549 or
email us at service@airsniper.ca

Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca
EPA Facility Registration Number 100516-CAN-1
13
REPLACING YOUR UNIT
The Spectrum-800 unit uses a built in 300w UV-C lamp with a lifetime of 6+ years (55,200
hours, based on 24/7 operation).
To track the life of the lamp on your unit, check the “Lamp Operating” LED colour when the
unit is powered on to determine the state of your unit. It is strongly recommended that the
unit be replaced when the “Lamp Life Warning” yellow LED is illuminated.
When the lamp life has been exceeded, the LED will glow red. The entire unit will need to be
replaced. Contact your local distributor or Air Sniper representative to order replacements.
WARNING: UV-C lamps generate heat during operation, allow 20-30
minutes after unplugging the unit for the lamp to cool down.
1. Disconnect the unit from the power source. The 10’ power cable can also be
disconnected from the unit. Remove the Merv-8 Filter from the bottom of the unit.
2. Connect the 10’ power cable to the newly installed unit. Re-insert the Merv-8 Filter into
the bottom of your new Spectrum-800.
3. Using the On/Off switch, turn the unit on, verify the control monitor is set to “On” and
fan speed is set above 0. The “Lamp Operating” LED will now be illuminated.
4. Once the new unit is operational, carefully package the old unit with all included
equipment (Power Cable & AC Infinity Fan Manual) to ship to your local distributor or
directly to Air Sniper for store credit. The Merv-8 Filter is not required to be returned.

Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca
EPA Facility Registration Number 100516-CAN-1
14
WARRANTY
We take pride in the quality of our products. In the case of a defective piece of equipment,
AIR Alpine Innovative Research Inc. offers a limited five-year warranty on all our products
(excluding bulbs). In case of a discovered defect, we will replace or repair the unit.
Extended Warranty is available.
Limited Warranty Five Year Warranty
Alpine Innovative Research Inc. (AIR) warrants the Air Sniper™ unit to be free from defects in the
workmanship or materials under normal use and service (the “Warranty”) for a period of three (5)
years (the “Warranty Period”) from the date of purchase through an AIR-authorized
dealer/distributor. During the Warranty Period, should an Air Sniper™ unit be determined to be
defective, AIR shall repair or replace the defective Air Sniper™ unit(s) (at AIR or dealer’s option)
within a reasonable period.
Remedy Procedures
If the Air Sniper™ unit proves defective within the Warranty Period, the purchaser may choose one
of the following remedies, after contacting AIR for a Return Authorization Number:
1. Return the defective Air Sniper™ unit to the dealer/distributor from whom it was purchased
together with a copy of the bill of sale, or dated proof of purchase thereof and the Return
Authorization Number; or 2. Ship the defective Air Sniper™ unit directly to Air Alpine Innovative
Research Customer Warranty Department along with the Return Authorization Number.
Limitations
This Warranty is the only representation regarding the Air Sniper™ unit, by Alpine Innovative
Research Inc. of merchantability and fitness for use and shall extend to five (5) years from the date
of purchase. The warranty excludes replaceable UV-C bulbs. If it is determined by either Alpine
Innovative Research Inc. or an authorized dealer/distributor that the defect is the result of damage
caused by the purchaser, the Warranty is null and void.
Contact us with any questions, comments or concerns pertaining to this warranty at Air Sniper by
e-mail, telephone, or in-person at AIR, Alpine Innovative Research.
Customer Warranty Department
(Toll Free): 1.888.338.9549
Air Sniper Bay 11
6565 40th Street S.E.
Calgary, AB Canada T2C 2J9
Other manuals for Spectrum-800
1
Table of contents
Other air sniper Accessories manuals
Popular Accessories manuals by other brands

Fife
Fife Maxcess DSE-45 Series user manual

Stiga
Stiga SNOW RACER Instructions for use

Warn Industries
Warn Industries ATV Winch Multi-Mount 2.5ci Installation and specification guide

Houston Radar
Houston Radar SS300 Series Installation and user manual

PCB Piezotronics
PCB Piezotronics 357C73 Installation and operating manual

THORLABS
THORLABS WFS Series Operation manual
