Airbi MIST User manual

EN
Ultrasonic humidifier
Airbi MIST
Instruction manual
(version 1.3)
Page 1 of 8

EN
1 Before first use
1.1 Why humidify the air
Stay in heated rooms can be not only unpleasant, but also insanitary. One of the main reason is
low humidity. Optimal humidity is between 45% and 55%, while in many of our homes in
winter humidity drops below 20%.
What does low humidity causes Dust particles, bacteria, viruses, dust mite feces are collected
by nasal mucosa are exhaled back in normal state, but due to dry air these particles get into the
lungs and reduce natural defense. This actions overload the immune system and irritate the
mucous membranes, cough, cracked lips and it is very close to any kind of disease.
Ultrasonic humidifiers Airbi are ideal for apartments, offices, everywhere where low humidity
can cause health problems for people. Ultrasound produced vapor is harmless to health. The
biggest advantage of the ultrasonic humidifiers is high performance together with low energy
consumption.
1.2 Principle of ultrasonic humidifier
Ultrasonic Humidifier use the ultrasonic high-frequency oscillator to break up water into tiny
water particles with the diameter of about 1-5µm.The ventilation system blows out this water
into the dry air where they evaporate to give the required humidity. The clearly visible smooth
and even fog can be seen out of the unit.
1.3 Security instructions
Always read the user guide instructions carefully before using the device.
Keep this User's Manual for future reference.
After unpacking, make sure that humidifier wasn't damaged during transport. If you find any
damage, contact your dealer as soon as possible. We recommend you keep the packaging for
possible future use .
Before first use check that the device parameters (electric voltage, etc.) correspond to local
conditions.
Always put the humidifier on a hard, flat horizontal surface, at least 15cm from the walls
and away from any source of heat such as burners, radiators etc. The humidifier cannot
operate on a surface that is not horizontal.
Keep the humidifier out of reach of children. Do not permit children to play with it.
Before using the humidifier, unwind the cord and check if it is not damaged. Do not use it if
the cord is damaged.
Do not plug or unplug the humidifier with wet hands.
Never disassemble the basic unit.
Never operate the humidifier with a defective plug or cord, or after a breakdown or damage
of any kind. In these cases, return the appliance to the nearest approved dealer/repairer for
verification and any necessary repairs or adjustments.
Do not use additives such as perfumes, essences, etc.
Page 2 of 8

EN
Do not shake the humidifier. This could spill water into the base unit and affect its operation.
Do not leave the humidifier in the sun for a long period.
If an unusual odour occurs during normal use, turn off the appliance, unplug it and have it
verified by qualified personnel.
Unplug the humidifier before cleaning or if removing the tank.
Never touch the water or the immersed components when the appliance is in operation.
Never turn on the humidifier when there is no water in the tank.
Never scratch the transducer.
To prevent any damage to the components, do not allow water to splash inside the base unit.
Never wash the entire unit with water; do not immerse it.
The ultrasonic humidifier should be cleaned regularly. To do this, refer to the cleaning
instructions in this manual and respect them.
Do not use the humidifier if the air in the room is already sufficiently moist (more than 50%
relative humidity). Excessive humidity gives rise to condensation on cold surfaces or walls
in the room.
Device is only for indoor use.
This device is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities or lack of experience and knowledge, unless they are
supervised or have the person responsible for their safety.
Clean and dry device according to the following guidelines before storage. Don't store
device when the water is inside. Store device on dry and cool place, out of reach of children.
Page 3 of 8

EN
2 Description
2.1 Technical specifications
Model: SPS-706
Evaporation rate: 250 ml/h
Water tank capacity: 5 litrů
Noise level: < 35 dB (A)
Power supply: 220-240 V
Frequency: 50/60 Hz
Total power: 30W
Dimensions: 26 x 20 x 32 cm
2.2 Humidifier's diagram
1 – output jet
2 – water tank handle
3 – water tank
4 – inlet of water tank
5 – water filter
6 – water tank cover
7 – power control LED
8 – security sensor
9 – transducer
10 – bottom part (base)
11 – main power switch
12 – light on button
2.3 Features
Low energy consumption, save 85-90 percent of electricity of normal stream humidifier.
Automatic control to humidity level, lack-water security protection.
Ceramic filter to soften and purify the water.
Releases abundant anion, promotes cellular metabolism, increases vitality and appetite, purifies
blood and soothes one's nerve.
Easy to refill water into the water tank
Increase and regulate relative humidity of the room air.
Eliminate electrostatic charges.
Prevent different diseases.
Keep your appearance fit and protect your skin.
Night light.
Page 4 of 8

EN
3 How to use
Before first use, allow the device to adjust room temperature at least half an hour. The device is
recommended for use in the temperature range 5-40 °C and relative humidity less than 80%.
Remove the water tank, unscrew the cover from the bottom of the tank and fill the tank with
clean water (water temperature should be under 40°C). After filling water tank close it.
Check the bottom part of the humidifier and make sure that this part is clean. Carefully place
the water tank on the base and wait a few seconds before the water gets into the basin. Plug the
cord into the outlet (NEVER SWITCH ON DEVICE WITHOUT WATER IN BASIN) and
power on humidifier – turn main power switch clockwise. Power control LED should light on.
There is main power switch and light button on front side. Light button activates/deactivates
night light – useful for children. Use main power switch to control mist output and switch
on/off humidifier.
Page 5 of 8

EN
4 Troubleshooting
Trouble Possible reason Solution
Power lamp off, humidifier
does not work
No power supply Connect power supply,
switch on
Power lamp on, no mist
outlet with wind
No water in water tank Fill water into water tank
Abnormal smell mist New unit Take out water tank, open
cover, let it stay 12 hours in
cool position
Dirty water or long time
staying water
Cleaning water tank, fill in
clear water
Power lamp on, unit doesn’t
work
Security switch is too slight Make the switch tight
Water tank is broken Contact authorized service
Mist fog is too small Too much scum in the water
basin
Clean transducer
Water is too dirty or water
kept too long in the tank
Clean water tank, change to
fresh clear water
Abnormal noise Resonant in water tank
when water is too less
Fill water into water tank
Unit is on an unstable
surface
Move the unit to a stable flat
surface
Mist coming out from
around nozzle
There are apertures between
the nozzle and water tank
Dip the nozzle in water for a
while and then fix it to the
socket on water tank
As fault y is not considered the following :
If use too hard water in humidifier white coating of sediment may appear in the room. This
is not malfunction. Please use soft water.
Gurgle of water which can be heard close to humidifier is a normal sound.
The device operates quietly, but not completely noiseless. Noise less than 35 db is not
considered as defect.
WARNIN !
Should up mentioned solutions do not work please contact the manufacturer or agent. Do
never arbitrarily disassemble, repair or restructure the apparatus.
Page 6 of 8

EN
5 Maintenance
In case when the water is hard which means water contains too much calcium and magnesium,
they can cause “white powder” problem and give heavy scum on the surface of water basin,
transducer and inner surface of the water tank. Scum on the surface of transducer will make the
unit work improperly.
We recommend :
1. Use cold boiled water or distilled water.
2. Clean the transducer, water tank and basin unit every week.
3. Change the water in water tank more often to keep it fresh.
4. Clean the whole unit, and make sure to keep all parts of the unit dry completely when the
unit is not in use.
How to clean the transducer:
1. Put 5-10 drops of vinegar on the surface of the transducer, wait for 2-5 minutes.
2. Brush out the scum on the surface.
3. Rinse the transducer with clean water.
4. Never use sharp and solid objects for cleaning of transducer
How to clean the basin unit:
1. Clean the water basin with soft cloth and the vinegar if there is scum in it
2. If the scum is covered on the security switch, drop the vinegar on the scum and clean it out
with the brush.
3. Rinse the water basin with clean water.
How to clean water filte r:
Take the filter system away from the tank cover.
Put the filter system into the white vinegar for about 10 minutes.
Take the filter system away from the white vinegar; shake for several times, clean it with
clear water.
How to replace water filter :
1. Take the filter system away from the tank cover.
2. Fix new water filter.
3. Replacement is finished.
If you don't plan to use humidifier longer time remove the water filter and let it dry thoroughly.
Then wrap it in protective packaging and keep it dry and dark place.
Page 7 of 8

EN
6 Disposal of the device (environment)
At the end of the product lifecycle, you should not throw this product into the
normal household garbage but bring the product to a collection point for the
recycling of electrical and electronic equipments. The symbol on the product, user
guide and/or box indicate this. Some of the product materials can be re-used if you
bring them to a recycling point. By reusing some parts or raw materials from used
products you make an important contribution to the protection of the environment. Please
contact your local authorities in case you need more information on the collection points in
your area.
This product is in compliance with the essential requirements and other relevant provisions of
Directive 89/336/EEC. The device was approved for use in EU countries, therefore, bear the
CE. All necessary documentation is available at the importer address.
Changes in technical parameters, properties, printing errors in the instruction manual reserved.
Importer address:
Bibetus s.r.o.
Loosova 262/1
Brno 638 00
Czech republic
E-mail: [email protected]
Tel: [phone]
Page 8 of 8
