Aircare Tower User manual

Read and save these instructions
TOWER
Everything you need to know about your
ALL D46720 MODELS 1B73370
8/2020

1
2

a. Base
b. Two 1040 Super Wicks® (inside base)
ALL 1040 WICKS
c. Two water bottles
#1B71663
d. Two bottle caps
#1B71664
e. Front grille
#1B71665
f. Back grille
#1B71666
g. Two bottle release latches (attached to bottles)
#1B72089
h. Two wick grille clips (attached to front grille)
#1B71877
i. Owner’s manual
#1B73370
LET’S GET YOU UP AND RUNNING
Remove the Tower from its packaging. You
should have:
1
Prefer to see a video?
Watch the Tower set-up at
aircareproducts.com/support.
SCAN THE CODE TO THE RIGHT
WITH YOUR PHONE’S CAMERA
a
a
b
b
i
i
e
e
f
f
c
c
c
c
d
d
d
d
g
g
h
h
h
h
g
g
If you are missing any parts, or need
replacement parts, call us at 800.547.3888 or
visit our website aircareproducts.com.
♥We hope you love your Tower. 
1
2

Remove the water bottles by pressing the
latches on top of the bottles. Remove the
foam blocks and throw them away.
Remove the tape from the front and back
grilles. Open the covers by pressing the
clips on the side of the base. Make sure there are
two wicks in your unit, then close the covers.
Fill the water bottles. Each bottle holds 1
gallon of water.
2
3
4
About water additives:
• Do not use essential oils in your Tower.
• Do not use water softeners.
• We recommend our Essick Air Bacteriostat to help inhibit
mold growth.
3

5Put your Tower in the most centrally-
located room of your home. It should
be on a level surface against an interior wall.
Make sure it’s at least two inches from the wall
so the humidistat (on the cord) can accurately
read your humidity.
Wait 20 minutes for the filters to
become fully saturated, then proceed
to step 8.
Put the bottles back on the base. Hold
the bottle at an angle, then seat the
bottom end first, so the plunger sits directly on
the peg in the base.
Press the latch on the top of the bottle, then
tilt the top end of the bottle toward the unit.
Release the latch, and let the bottle click into
place.
7
6
More about positioning:
• To maximize humidity circulation, put your unit near a cold air return.
• If you prefer to put your unit in the room where humidity is most
needed, you can! But the humidity won’t circulate as well with this
method.
• Don’t put your humidifier under a window, as condensation may
occur.
• Put the unit on the bottom floor of a multi-story home.

F– The F code means your unit is empty and needs to be FILLED with water.
CL – Your CONTROLS ARE LOCKED on the current setting. Activate the control lock by holding the power button for five
seconds, until CL appears. Your Tower will lock on the current fan and humidity settings. Release the lock by pressing the
power button again for five seconds until the display flashes CL three times, letting you know the lock is o.
CF – The CF code triggers after 720 hours of use and means it’s time to CHECK YOUR FILTER (wick). Unplug your unit and
check your wicks. If your wicks are still in good shape, simply clear the code by plugging your humidifier back in. If your wicks
need replacing, follow these quick steps:
1. Remove the water bottles, then remove the front and back grilles. Do not discard your grilles.
2. Remove your old wicks and replace them with two new 1040 Super Wicks®.
3. Replace the grilles, then reattach your water bottles.
ABOUT THE CODES
Plug in your unit and set your desired fan
speed by pressing the fan button .
Your Tower has four fan speeds that are displayed
by F1 (the lowest speed) through F4 (the highest
speed). F0 indicates your Tower is in standby
mode.
Press the humidity control button
to set your humidity level from 25% to
65%. The humidistat on your cord will read your
home’s humidity and turn your fan o when the
set level is reached. When set to 65%, your unit
will run continuously.
That’s it! Your Tower is ready to use.
8
9
6

Regular cleaning is important for preventing mold,
mildew, and other bacterial growth in your humidifier.
It also keeps your Tower working its best.
1. Let the unit run until it’s empty, then turn it o and
unplug it.
2. Remove the water bottles and grilles.
3. Remove the wicks. Throw the wicks away if it is time to
replace them. Otherwise, put them in a sink while you
finish cleaning your Tower.
4. Fill each bottle with water and ½ cup of white vinegar,
then put the bottle cap back on. Gently shake the
bottles, then lay them flat for 20 minutes. To disinfect,
replace the vinegar with 1 teaspoon of bleach in each
bottle. Do not mix vinegar and bleach.
5. After 20 minutes, empty the water bottles.
6. Dampen a sponge with white vinegar and wipe out the
base. To disinfect, replace the vinegar with bleach.
7. Rinse the base and bottles thoroughly.
8. Wipe everything dry and replace the wick, if needed.
Then reassemble.
When storing your Tower, discard the used filter and clean the unit
using either method above. Dry the unit thoroughly, and store in a
temperature-regulated area. Do not install a new filter until you are
ready to use your humidifier again.
ABOUT THE CODES
HOW TO CLEAN YOUR TOWER
6

Où se trouve mon numéro de série?
Pourquoi mon unité ne
fonctionne-t-elle pas?
Pourquoi l’achage
clignote-t-il «20»?
Pourquoi la bouteille de gauche
ne se vide pas?
Pourquoi mon Tower fait-il
clignoter la lettre «F» alors qu’il
y a de l’eau dedans?
À quelle fréquence dois-je
remplacer mes mèches?
Puis-je commander des pièces
de rechange?
Pourquoi l’achage
clignote-t-il «—»?
Pourquoi mon taux d’humidité
n’augmente-t-il pas?
Votre numéro de série se trouve sur l’autocollant au dos de
votre appareil. Vous pouvez l’écrire ici pour référence future :
__________
Votre niveau d’humidité est inférieur à 20 %. Essayez d’augmenter
la vitesse de votre ventilateur et le niveau de sortie.
Votre Tower videra d’abord la bouteille de droite.
Essayez d’ajuster vos bouteilles. Assurez-vous que le piston
est bien placé sur la cheville.(  6)
La teneur en minéraux de votre eau détermine la fréquence à
laquelle vos mèches doivent être remplacées. Une eau plus
dure implique des changements plus fréquents. L’utilisation de
notre bactériostat (pièce #1970) peut vous aider à garder votre
appareil plus propre et à prolonger la durée de vie de vos mèches.
Changez toujours vos mèches au début de chaque saison.
Oui! Les pièces de rechange Tower et leurs références sont
indiquées à la page 10.
Votre niveau d’humidité est supérieur à 90 %. Essayez de
réduire la vitesse du ventilateur et le niveau de sortie.
Il faut parfois 2 à 3 jours pour que votre nouvel humidificateur
d’air fasse monter le taux d’humidité, surtout s’il fait très sec
dans votre maison.
Si vos mèches sont vieilles, remplacez-les par des mèches neuves.
Q
Q
Q
Q
Q
Q
Q
Q
Q
R
R
R
R
R
R
R
R
R
• Assurez-vous que vos bouteilles sont correctement
installées. ( ’ 6)
• Votre unité a atteint le niveau d’humidité que vous avez fixé.
[e-mail] aircareproducts.com 800.547.3888
TOWER
TOUS LES MODÈLES D46720
FOIRE AUX QUESTIONS
Pour toute autre problème, contactez nos experts en humidification!
Ils sont prêts à vous aider par téléphone, courriel ou chat.
Tout ce que vous devez savoir sur votre
Lisez et conservez ces instructions

TOWER
TOUS LES MODÈLES D46720 1B73370
8/2020
Tout ce que vous devez savoir sur votre
Lisez et conservez ces instructions

9
10
