aireRyder F0048 Instruction Manual

PAGE: 1 / 9
Model No.: F0048
181128

A
D
B
C
9V
PAGE: 2 / 9
11
10 X10
12 13
5
7
6
9
8
34
Unpack your fan and check the contents. You should have the following items.
1.) Hanger Bracket
2.) Canopy
3.) Decorative Cap
4.) Downrod Stand Cover
5.) Downrod Set (Included Hanger Ball, 6” Downrod, Hanger Pin & Lock Pin)
6.) Fan Motor Assembly
7.) Fan Blades (3PCS)
8.) Blade Holder (3PCS)
9.) Fan Light Kit
10.) Remote Control Set (Includes Transmitter & Receiver & Wire Connectors & Battery )
11.) Assembly Kit
12.) Blade Balancing Kit
13.) Installation Instructions
Package Contents:
2
1
Installation Instruction
Dimension Reference (Installed with 6” Downrod):
A. 16-7/8 in. B. 12-1/2 in. C. 52 in. D. 5 in.
181128

Downrod Mount
Slope Ceiling Mount (Up to 23 degrees)
Exploded View Detail
PAGE: 3 / 9
Dual Mount Drawing
Collar
Housing
Fan Light
Blade Holder
Switch Box Screw
Switch Box
Blade
Hanger Bracket
Canopy
Downrod
Downrod Stand Cover
Hanger Ball
Hanger Pin
Lock Pin
Decorative Cap
181128

PAGE: 4 / 9
Safety Instructions
READ ALL SAFETY INFORMATION AND INSTALLATION INSTRUCTIONS BEFORE YOU BEGIN TO
INSTALL THE FAN AND SAVE INSTRUCTIONS.
All set screws of the fan must be checked and retightened where necessary before installation.
To reduce the risk of personal injury, do not bend the blade brackets when installing the brackets,
balancing the blades or cleaning the fan. Do not insert foreign objects between rotating fan blades.
Before changing the fan direction, turn off the fan and wait for the fan blades to stop completely.
The safeguards provided by these safety instructions and by the separate installation
instructions are not meant to cover all possible conditions and situations that may occur. It must be
understood that common sense, caution and care are factors which can not be built into this product.
These factors must be supplied by the person(s) installing, caring for and operating the fan.
TO AVOID RISK OF ELECTRIC SHOCK, BE SURE TO SHUT OFF POWER AT THE MAIN
FUSE OR CIRCUIT BREAKER BOX BEFORE INSTALLING OR SERVICING THIS
FIXTURE. TURNING OFF THE ELECTRICAL POWER BY USING THE LIGHT SWITCH
IS NOT SUFFICIENT TO PREVENT ELECTRICAL SHOCK.
TO REDUCE THE RISK OF INJURY, INSTALL THE FAN SO THAT THE BLADES ARE
AT LEAST 7 FEET (2.1 METERS) ABOVE THE FLOOR AND AT LEAST 18 INCHES
(0.5 METERS) FROM THE TIP OF THE BLADES TO THE WALL.
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY, MOUNT
TO OUTLET BOX MARKED "ACCEPTABLE FOR FAN SUPPORT" AND USE MOUNTING
SCREWS PROVIDED WITH THE OUTLET BOX.
THE INSTALLATION HAS TO BE IN ACCORDANCE WITH THE NATIONAL ELECTRICAL
CODE, ANSI/NFPA 70-1999 AND LOCAL CODES. IF YOU ARE UNFAMILIAR WITH THE
METHODS OF INSTALLING ELECTRICAL WIRING, SEEK THE SERVICES OF A
QUALIFIED LICENSED ELECTRICIAN.
WARNING
181128

PAGE: 5 / 9
Installation Steps :
Fig.1
Turn OFF the electric circuit at the
main fuse or circuit breaker box.
Lock Pin
Hang the fan on Hanger Bracket, and
make sure the slot of hanger ball is
snapped into the chip of Hanger
Bracket exactly.
Note: For slope ceiling installation,
make sure the slot of hanger ball and
the chip of hanger bracket face down.
Insert and tighten the two Collar
Screws. Slide Lock Pin into Hanger
Pin until it is locked into position.
Fig.6
Collar Screws
Fig.7
Slot
Chip
Hanger Bracket
NOTE: The fan weight is 17.28 lbs (7.84 kgs). Be sure the outlet box you are using is securely attached to the building
structure and can support the full weight of the fan. Failing to do so can result in serious injury.
INSTALLATION INSTRUCTIONS
IMPORTANT:
BEFORE YOU BEGIN INSTALLING THE FAN, CAREFULLY READ ALL INFORMATION ON THE SEPARATE
SHEET "SAFETY INSTRUCTIONS" AS WELL AS THE FOLLOWING "INSTALLATION INSTRUCTIONS". IF IN
DOUBT, CONSULT A QUALIFIED ELECTRICIAN.
SAVE ALL INSTRUCTIONS.
Collar
Collar Hanger Pin
Fig.4
Motor Wires
Downrod
Downrod Stand
Cover
Canopy
Downrod
Canopy
Downrod Stand
Cover
Fig.5
Decorative Cap Decorative Cap
Thread the motor wires through the
downrod stand cover, decorative
cap, canopy and downrod.
Remove the Lock Pin and take off
the Hanger Pin. Loosen the collar screws in part way.
Insert the Downrod into the Collar.
Slide Hanger Pin through holes of
Collar and Downrod.
Hanger Pin
Lock Pin
Fig.3
Tighten the hanger bracket to the outlet box with two mounting screws.(Make sure
the outlet box is securely installed so that it will be able to support at least the
fan weight.) Attach the safety cable hook to the ceiling with the dry wall screw and
washer, and make sure the safety cable hook is covered by the fan canopy.
WARNING: MOUNT ONLY TO AN OUTLET BOX MARKED "ACCEPTABLE FOR
FAN SUPPORT"!
Fig.5.Fig.2.
Ceiling
Hanger Bracket
Ceiling Joist
Wood Member
(2" x 4" Approx.)
Junction Box Washer
Safety Cable Hook
Dry Wall Screw
Ceiling
Hanger Bracket
Ceiling Joist
Wood Member
(2" x 4" Approx.)
Junction Box
181128

PAGE: 6 / 9
Move Ground Wires (a), Outlet Box wires (b), and
Motor Wires (c) away from the center of the Hanger
Bracket. Then slide Receiver through Hanger
Bracket as shown, Antenna end first, until it is
centered. Finally, cut Motor Wires (c) to length
needed for connections.
Hang the safety cable into the safety cable hook.
Fig.11
Safety Cable Hook
Safety
Cable
Fig.12
Canopy Screw
Key Hole
Slot
Hanger Bracket
Canopy
Decorative Cap
Fig.10
Hanger
Bracket
Hanger
Ball
Receiver
1. 5. 6.
7.
2.
4. 3.
Antenna:
DO NOT CUT
OR SPLICE
Connect wires:
1) The white (neutral) wire from motor to the white (neutral)
"TO MOTOR N" wire from Receiver with a wire connector.
2) The black (hot) wire from motor to the black (hot)
"TO MOTOR L" wire from Receiver with a wire connector.
3) The blue wire from motor to the blue for "Main Light L" wire
from Receiver with a wire connector.
4) The organge wire from motor to the organge for "Accent
Light L" wire from Receiver with a wire connector.
5) The white (neutral) wire from Outlet Box to the white "AC in
N" wire from Receiver with a wire connector.
6) The black (hot) wire from Outlet Box to the black "AC in L"
wire from Receiver with a wire connector.
7) The ground wire from Outlet Box to the green ground wire
from the Hanger Ball and the green ground wire from the
Hanger Bracket with a wire connector.
Make sure all of wire connectors are connected firmly.
*** Put all wire connectors and wires carefully up into the
Outlet Box.
There is a code switch in the transmitter and
receiver. This "DIP Switch" is a 4 key units
(Fig.8). All keys were set at "ON" position in
the beginning. Set the keys to a different
code. Make sure the same numbered keys
are switched "ON" for both DIP switches
(Fig.8a). If the remote controlled fans are
installed than one or the frequency is
interfered, the fan may function abnormally.
Code example:
1-ON 2-OFF 3-ON 4-OFF on both DIP
Switches.
Note: If you have two ceiling fans with 2
remote control units, set 2 different
codes for each set of transmitter / Receiver.
Fig. 8
Antenna
DIP Switch
Transmitter
Receiver
Fig.8a
Loose canopy screw
and do not remove it ,
push the canopy
upwards to cover
hanger bracket by
inserting canopy screw
into key hole slot, then
rotate the canopy till it
fixed on the hanger
bracket. finally, Attach
the decorative cap to
canopy, rotate it
clockwise until tight.
Antenna
Receiver
Hanger
Bracket
a. b.
c.
Fig.9
181128

Connect the female terminals from motor to male terminals
from fan light kit.
secure the fan light kit to the motor by fan screws.
Note: 1). The blue fixture wire to blue motor wire;
2). The orange fixture wire to orange motor wire;
3). The white fixture wire to white motor wire;
Align holes and fasten blade holder to the
motor with screws.Then align holes and
fasten blade to the blade holder with blade
screws.Repeat for remaining blades and blade
holders (Fig.12a).
Suggest: Using magnetic Philips screwdriver.
NOTE: The blade outside edge angle and
blade holder outside edge angle
must be same(Fig.12b).
PAGE: 7 / 9
1. Install the battery (9V) to the transmitter.
2. OPERATING TRANSMITTER:
* Press "HI" to turn on the fan at high speed.
* Press "MED" button to turn the fan in medium speed.
* Press "LOW" button to turn the fan in low speed.
* Press "OFF" button to turn off the fan.
* Press and release the "Accent" button quickly to turn
on or turn off the accent light.
* Press and hold the "Main" button to dim or brighten lights
to the desired level and release, and the brightness level
will be memorized. Turn on the main light again, then fan
light will restore on of the brightness level which was
dimmed last time.
Note:
This remote control has memory function setting. The fan will
operate at the same speed and the fan light will stay at the same
brightness as the last time the power supply was turned off.
This remote control can not be worked along with other solid-state
speed control or dimmer at the same time
Fig.17
Battery Cover
Battery
Fig.16
Turn ON the electric circuit at the
main fuse or circuit breaker box.
CAUTION :Handle the light kit gently during installing. In order
to avoid noise please keep crystalls tightly.
NOTE: Accent light is non-dimmable. Main light is
dimmable.
The slide switch on motor
assembly sets direction of
fan rotation. Select the
desired direction of fan
rotation. Push the slide
switch left for " Forward"
and right for "Reverse".
Note: Wait for fan to
stop before reversing
the direction of blade
rotation.
Fig.14
Motor
Fan Light Kit
Fan Screw
Male terminal
Female terminal
Blade Screw
Screw
Fan Blade
Fig.13a
Motor
Motor
Blade Holder
Fig.15
Slide Switch
Reverse
Forward
Motor
Fig.13b
Blade Angle Edge
Blade Holder Edge Angle
181128

PAGE: 8 / 9
Trouble Shooting Guide
If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation
or wiring. If you experience any faults, please check this Trouble Shooting Guide. If a problem cannot be
remedied or you are experiencing difficulty in installation, please call our Customer Service Department
(1-800-887-6326).
PROBLEM
1. If fan does not start:
2. If fan sounds noisy:
3. If fan wobbles:
4. If light does not work:
5. If accent light does flash:
1. Check main and branch circuit fuses or circuit breakers.
2. Make sure forward/reverse switch is firmly in left or right position. Fan will not
operate when switch is in the middle.
3. Make sure that the wall control is turned "ON".
4. Check line wire connections to fan and switch wire connections in switch box.
CAUTION: Make sure main power is turned off.
1. Check the fixed tightness of crystalls. Open the clips more wide to hold crystalls
tightened.
2. Make sure all screws in motor housing are snug. (not over tightened)
3. Make sure the screws which attach the fan blade bracket to the motor are tight.
4. Make sure wire connectors in switch box are not rattling against each
other or against the interior wall of the switch box.
CAUTION: Make sure main power is turned off before accessing switch box.
5. Check to be sure the light kit is secured on switch box tightly.
6. Some fan motors are sensitive to signals from Solid State variable speed
controls. DO NOT USE a Solid State variable speed control.
7. Allow "break-in" period of 24 hours. Most noises associated with a new fan will
disappear after this period.
All blades are weighed and grouped by weight. Natural woods vary in density
which could cause the fan to wobble even though all blades are weight-matched.
The following procedures should eliminate most of the wobble. Check for wobble
after each step.
1. Check that all blades are screwed firmly into blade brackets.
2. Check that all blade brackets are tightened securely to motor.
3. Make sure that canopy and hanger bracket are tightened securely to ceiling
outlet box and outlet box is mounted firmly to ceiling joist.
4. Most wobble problems of fan are caused when blades are not in equal level. To
check the blade levels, select a point on the ceiling above the tip of any blade.
Measure the distance from the ceiling to the blade tip, to an accuracy of 1/8
inch. Rotate the blades until the next blade is in the measuring position. Repeat
measurement for each blade. If all blade levels are not equal, you can adjust
blade levels by the following procedure. To adjust a blade tip down, insert a
washer (not supplied) between the blade and blade bracket at the screw
closest to the motor. To adjust a blade tip up, insert washer (not supplied)
between the blade and blade bracket at the two screws farthest from the motor.
5. Interchanging two adjacent blades could redistribute the weight and possibly result
in smoother operation.
1. Check connections between female terminals and male terminals are in correct
state. Ensure the contacts between female terminals and male terminals are good
conditions, no looses.
2. Check for loose or disconnected wires in fan switch box.
3. Check for loose or disconnected wires in light kit.
1. Do not connect blue wire from main light to organge wire from accent light.
Make sure wire connections are correct.
SUGGESTEDREMEDY
181128

PREFACE
Your ceiling fan may sometimes have wobbling problems when operating due to irregularity in the
blades or the blade brackets. Improper assembly in the mounting system may cause some additional
problems. This balancing kit can be used to fix wobbling problems.
DYNAMIC BLADE BALANCING KIT FOR CEILING FANS
1. Make sure that all blades are firmly screwed into the blade brackets.
2. Make sure that all blade brackets are firmly secured to the motor housing.
3. By looking up at the fan from below, check and be certain that none of the blade brackets are bent
and that none of the blades are out of position.
4. Use a yardstick to check the blade tracking. Put the yardstick up against the ceiling vertically and
against the outside leading edge of a blade. Note the distance of the edge of blade to the ceiling.
Carefully turn the blades slowly by hand to check the remaining blades. All distances should be
the same.
Operate the fan ten minutes. After following all the steps and if the wobbling problem is not solved, a
dynamic balancing needs to be done with balancing kit. Follow the procedure listed below:
● Turn the fan off. Select one blade and place the plastic clip on it, where the plastic clip locates is
halfway between the blade bracket and the blade tip on the edge of the blade.
Caution: The plastic clip should be placed on the windward edge of the blade for fear of
clip flying off.
● Turn the fan on (set the speed that causes the wobble most). Observe if the wobble is better or
worse. Turn the fan off and move the clip to the next blade. Do the same for all blades and note
on which blade the clip reduces the wobble most. Place the clip on the blade which showed the
most improvement. Move the clip inward and outward on this blade and operate the fan to find
the position where the clip gives the most improvement.
Caution: Stay clear of the blades. If the clip, for any reason, is not secure, injury could result .
● Once the exact position is determined, place a weight on the top of the blade, on its centerline and
as close as possible to the clip. Peel the paper off of the back of the weight and press firmly to ensure
that it is securely attached to the blade. Remove the clip.
Caution: Clean the surface of fan blade before placing the balancing weight so that the
balancing weight can be firmly attached on it.
PAGE: 9 / 9
DYNAMIC BLADE BALANCING KIT
BALANCING WEIGHT
MEASURING
POINT
YARDSTICK
PLASTIC CLIP
CENTERLINE
COUNTER-
CLOCKWISE
1
2
3
4
5
6
7
8
9
181128
