AIRINNOVATIONS RevitaSpa RS-L305A Instruction Manual

Instruction Manual and Warranty Information - Read and Save These Instructions.
Ultrasonic
Aromatherapy Diffuser
with Color Changing
LED Lights
RevitaSpa™

Contents
Safety Instructions ................................................................................................1
How It Works / Specifications ...............................................................................2
Parts & Contents .................................................................................................. 3
Filling & Operating Instructions............................................................................4
Weekly Cleaning & Care...................................................................................... 5
Storage / About White Dust.................................................................................6
Other Great Products............................................................................................7
Warranty ................................................................................................................8
If you have a respiratory condition, please contact your physician prior to use.
FCC Statement
Potential for Radio/Television interference
This device complies with Part 18 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.This product has been tested and
found to comply with the limits for a Class B digital device, pursuant to Part 18 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. The product generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that the interference will not occur in a particular installation. If the
product does cause harmful interference to radio or television reception, which can be determined by
turning the product on or off, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
• Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.

SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
1
When using electrical appliances, basic safety precautions should always be taken including
the following:
• This product is for household use only; DO NOT use outdoors.
• WARNING: NEVER operate in the presence of explosive or flammable gases.
• Operate diffuser only when fully assembled.
• Close supervision is necessary when any appliance is used near children.
• Always use on an elevated firm, level surface where it is not easily knocked over.
• WARNING: DO NOT place the appliance directly on the floor, near
computers or sensitive electronic equipment.
• Only use Power Adaptor and accessories provided by the manufacturer for this
product.
• Before use, extend the cord and inspect for any signs of damage.
WARNING: DO NOT use if cord has been damaged.
• Keep cord away from heated surfaces and arrange cord away from traffic areas
and where it will not be tripped on.
• WARNING: DO NOT block any air outlets or intakes.
• WARNING: NEVER use the diffuser after a malfunction, after it has been
dropped or damaged in any way.
• WARNING: DO NOT operate if Water Reservoir is empty.
• Always fill Water Reservoir with water before adding essential oils. Only fill the
Water Reservoir to the suggested capacity (165ml); do not use hot water in the unit.
• Empty Water Reservoir when not in use.
• Unplug diffuser when not in use, when moving location, or before cleaning.
• WARNING: ALWAYS unplug the Power Adaptor by grasping the adaptor
itself; never pull on cord. Ensure that hands are dry.
• WARNING: To protect against electrical shock, DO NOT immerse unit,
plug or cord in water or spray with liquids and plug the appliance directly into a
120V AC electrical outlet.
• Always unplug and empty the Water Reservoir when not in use for a long period
of time.
• Clean the Water Reservoir every week and perform regular maintenance of the
Ultrasonic Nebulizer. WARNING: NEVER scrape the Ultrasonic Nebulizer with
a hard or sharp object.
• WARNING: DO NOT rinse Base under faucet or immerse the Base in water.

How It Works
Thank you for choosing RevitaSpa™Ultrasonic Aromatherapy Diffuser with Color
Changing LED Lights. This product comes with a 1-YEAR WARRANTY, as your
satisfaction is our primary concern.
RevitaSpa™Ultrasonic Aromatherapy Diffuser with Color Changing LED Lights uses
Ultrasonic Cool Mist Technology to create humidity instantaneously, working silently
to erase the discomforts of dry air. The RevitaSpa™Fragrance Oil fills your space
with a soothing, aromatic fragrance while color changing lights cycle through the
spectrum.
Specifications
2
Product Model
RS-L305A 12W 165ml .64 lbs.
DC 24V/500mA D 4.9” x H 6.1”
Power Consumption Rating Voltage / Current Water Capacity Dimensions Weight

Parts & Contents
Inside Base View
3
1. Exterior Base Cover
2. Base
3. Power Button
4. Water Reservoir
5. Ultrasonic Nebulizer
6. Air Outlet
7. Power Adaptor
8. (2) 5ml bottles of RevitaSpa™Fragrance Oil Blends
2
3
4
8
5
6
7
1

4
Filling & Operating Instuctions
WARNING: Always unplug the unit before filling.
WARNING: DO NOT touch the water in the Water Reservoir.
WARNING: NEVER fill the unit from the top, follow the filling directions below.
Filling the Aromatherapy Diffuser
1. Place the Aromatherapy Diffuser on a flat, level surface.
2. Remove the Exterior Base Cover by lifting straight up. (figure 2)
3. Use ONLY clean, cool tap water to fill the Water Reservoir. (figure 3)
WARNING: DO NOT fill the Water Reservoir past the MAX Fill indicator.
WARNING: DO NOT allow water to enter the Air Outlet as this could damage
the Diffuser.
4. Add 1-2 drops of Fragrance Oil to start. If a stronger scent is desired, add up to 6
drops of Fragrance Oil per 165ml of water (to the Max Fill indicator on unit). (figure 4)
5. Replace the Exterior Base Cover.
2
ab
3 4
Operating the Aromatherapy Diffuser
1. Insert the Power Adaptor into to the unit. (figure a)
2. Plug the Power Adaptor into a standard (120V AC) electrical outlet.
3. Power Button
• Pressing the Power Button (figure b) once will start the mist and light function;
the default light function of the diffuser will loop through 5 colors in the
following order: red, green, blue, purple, white.
• Pressing the Power Button twice
will fix the unit on one color.
• Pressing the button a third
time will turn off the light.
• Pressing the button a fourth time will
stop the mist and turn the unit off.
4. Auto Safety Shut Off - When the water
in the Diffuser is low, the unit will
automatically shut off and a red light
will flash for 30 seconds to indicate it
is time to refill.

Base & Surface Cleaning
Gently wipe with a soft damp cloth and a
mild detergent; do not use any solvents or
aggressive cleaning agents.
WARNING: NEVER scrape the Ultrasonic
Nebulizer with a hard or sharp object.
WARNING: When emptying the Water
Reservoir on the base, make sure that the
water is poured away from the air outlet.
If water is poured into the outlet it may
damage the aroma diffuser.
White Dust Cleaning
If mineral deposits “White Dust” are evident
around the Ultrasonic Nebulizer and Water
Sensor, clean these surfaces with a soft cloth
and a small amount of undiluted white vine-
gar. If necessary, mix a solution of 50% white
vinegar and 50% water and fill the Water
Reservoir with enough solution to cover the
Ultrasonic Nebulizer. Allow it to soak for an
hour and then use a cotton swab to gently
loosen buildup. Rinse Reservoir with water
and wipe with a soft cloth.
5
Weekly Cleaning & Care
WARNING: Before cleaning always turn power OFF and unplug the unit.

Storage
1. Follow all cleaning instructions prior to storage.
2. Dry all parts, including the inside of the Water Reservoir. WARNING: NEVER leave
water inside the Water Reservoir for several days.
3. Preferably store in its original box, in a dry place away from high temperatures.
5. Follow all cleaning instructions after long periods of storage.
6
About White Dust
Use of high-mineral content water may cause a white mineral residue to accumulate
on room surfaces near the aroma diffuser. The mineral residue is commonly referred
to as “White Dust”. The higher the mineral content (the harder your water is), the
greater the potential for White Dust. The White Dust is not caused by a defect in the
aroma diffuser, but is due only to minerals suspended in the water from your tap.
WARNING:If you have hard tap water STOP using tap water and use ONLY filtered,
distilled, cold boiled or bottled water to minimize the White Dust residue.

Try These Other Great
Products For Your Life!
Available at: www.ForLifeProducts.com, www.Air-Innovations.com, www.Pursfection.com, www.RejuvenateProducts.com
7

1-YEAR WARRANTY - RS-L305A
RevitaSpa™Ultrasonic Aromatherapy Diffuser with Color Changing LED Lights comes with a
1-year manufacturer’s warranty. If this unit should become defective within 1-year from the date
of purchase, or if you have any questions or comments or regarding replacements for any of our
products, please contact us directly at:
Call us toll free at: 844-600-1370
Monday thru Friday 8:30 AM to 5:00 PM EST.
Visit us on the web at: www.Retiva-Spa.com
e-mail us: [e-mail]
Or write us:
Air Innovations
Att: Quality Assurance Dept.
2301 SW 145th Ave.
Miramar, FL. 33027 USA
Please fill out the warranty card and
mail back to the above address.
Or, register your warranty online today.
Simply go to: http://www.Air-Innovations.com
THIS UNIT COMES WITH A 1-YEAR WARRANTY SUBJECT TO THE FOLLOWING CONDITIONS:
In the first year, all repairs will be performed free of charge or the unit will be replaced. This warranty is not
transferable, it is valid only for the original purchaser. This warranty will be voided if the unit is subjected to
unauthorized repair or impact damage. If you have any questions please call toll free: 844-600-1370.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Please check here if you would not like to receive any solicitations from our company
NAME
ADDRESS
CITY
STATE ZIP
TELEPHONE
E-MAIL
DATE OF PURCHASE
PLACE OF PURCHASE
!

RevitaSpa™

Air Innovations®© Great Innovations, LLC 2016. All Rights Reserved.
US & International Patents Pending. Printed In China. IM0049A
