User Guide
AIR-SW8P
8-Port 10/100Mbps Mini Desktop
Switch
February, 2013

FCC STATEMENT
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to pro-vide reasonable
protection against harmful interference in a residential
installation. This equipment generates and can radiate radio
frequency energy and, if not in-stalled and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/ TV technician
for help.
This device complies with part 15 of the FCC Rules. Operation

is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority
to operate the equipment.
CE Mark Warning
This is a class B product. In a domestic environment, this
product may cause radio interference, in which case the user
may be required to take adequate measures.

Package Contents
The following items should be found in your box:
One AIR-SW8P 8-Port 10/100Mbps Desktop Switch
One Power Adapter
This User Guide
Note:
Make sure that the box contains the above items. If any of the
listed items are damaged or missing, please contact with your
distributor.
Safety Notices
Do not use this product near water. Avoid using this product
during an electrical storm. Do not place heavy objects on the
switch.

Chapter 1. Introduction of the Product
Thank you for choosing the AIR-SW8P 8-Port 10/100Mbps
Desktop Switch.
1.1 Overview of the Product
AIR-SW8P 8-Port 10/100Mbps Desktop Switch provides 8
10/100Mbps Auto-Negotiation RJ45 ports. All ports support
Auto MDI/MDIX function, eliminating the need for crossover
cables or Uplink ports. The Switch is Plug-and-Play and each
port can be used as general ports or Uplink ports and can be
simply plugged into a server, a hub, a switch or a router and so
on, using straight cable or crossover cable.
The AIR-SW8P 8-Port 10/100Mbps Desktop Switch provides
you with a low-cost, easy-to-use, high-performance, seamless
and standard upgrade to improve your old network to a
100Mbps network. It will boost your network performance up to
full duplex data transfer. Its wire-speed switching that forwards
packets can be as fast as the speed that your network delivers
those packets to them.
1.2 EEE Power Saving Features
The switch supports EEE Power Saving Features to help make
your network environmentally friendly without compromising
performance. The switch automatically powers down ports that
have no link, and reduce the power consumption in idle mode or

with low traffic mode. In Low Power Idle mode, up to 59.7% of
the power can be saved.
Chapter 2. Installation
1.3 Mounting the Switch on a Desk
To install the Switch, please follow the steps:
1) You can place the Switch on a flat desk.
2) Please inspect the Power Adapter carefully and make
sure that it is properly connected to a power source.
3) Ensure adequate ventilation space around the switch for
dissipating heat and air.
Note:
Please keep the switch horizontal on the desktop, with its top
cover facing up. And avoid anything heavy placed on the switch.
1.4 Power On
Powering on the Switch, it will automatically initialize and its
LED indicators will respond as follows:
1) All of the Link/Act LED indicators will flash momentarily,
which represent a resetting of the system.
2) The Power LED indicator will light all the time.
Note:

If the LED indicators don’t respond as described above, please
check the power supply and its connection.
Chapter 3. Identifying External Components
This Chapter describes the front panel, rear panel and LED
indicators of the Switch.
1.5 Front Panel
Figure 3-1 AIR-SW8P Front Panel
The Switch’s LEDs are located on the front panel.
Power LED:
This indicator will light up when the Switch
powers up.
LEDs (1-8):
One LED indicator will light green when a
device is connected to the corresponding
port. It flashes when data is being
transmitted or received on the connection.
1.6 Rear Panel
Figure 3-2 AIR-SW8P Rear Panel

The following parts are located on the rear panel:
Port (1-8):
The AIR-SW8P Switch is equipped with 8
10/100Mbps Auto-Sensing RJ45 ports where
you will connect your network devices. The
working status can be indicated by the
corresponding LEDs on the front panel.

Appendix: Specifications
Specifications
Standards
IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
Data Transfer Rate
Ethernet: 10Mbps (Half Duplex), 20Mbps (Full
Duplex)
Fast Ethernet: 100Mbps (Half Duplex), 200Mbps
(Full Duplex)
Network
Media(Cable)
10BASE-T: UTP category 3, 4, 5 cable (maximum
100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-Tx: UTP category 5, 5e cable (maximum
100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Number of Ports
8 10/100Mbps Auto-Negotiation ports
LED indicators
Power, LEDs (1,2,3,4,5,6,7,8)
Environmental and Physical
Power Supply Output
9V- 0.6A
Size
140mm*85mm*30mm
Operating Temperature
0°C~40°C (32°F~104°F)
Storage Temperature
-40°C~70°C (-40°F~158°F)
Operating Humidity
10%~90% non-condensing
Storage Humidity
5%~90% non-condensing
