A-1
Catalyst 3750-X and 3560-X Switch Hardware Installation Guide
OL-19593-01
APPENDIX
A
Technical Specifications
•Switch Specifications, page A-1
•Power Supply Module Specifications, page A-2
•Fan Module Specifications, page A-4
Switch Specifications
Table A-1 Environmental and Physical Specifications
Environmental Ranges
Operating temperature 32 to 113° F (0 to 45° C)
Storage temperature –13 to 158° F (–25 to 70° C)
Relative humidity 10 to 85% (noncondensing)
Operating altitude Up to 10,000 ft (3049 m)
Storage altitude Up to 15,000 ft (4573 m), NEBS up to 13,000 ft (4000 m)
Physical Specifications

A-2
Catalyst 3750-X and 3560-X Switch Hardware Installation Guide
OL-19593-01
Appendix A Technical Specifications
Power Supply Module Specifications
Power Supply Module Specifications
Weight
Catalyst 3750-X-24T
Catalyst 3750-X-24P
Catalyst 3750-X-48T
Catalyst 3750-X-48P
Catalyst 3750-X-48PF
Catalyst 3560-X-24T
Catalyst 3560-X-24P
Catalyst 3560-X-48T
Catalyst 3560-X-48P
Catalyst 3560-X-48PF
15.6 lb (7.1 kg)1
15.8 lb (7.2 kg)2
16.3 lb (7.4 kg)1
16.5 lb (7.5 kg)2
16.7 lb (7.6 kg)3
15.4 lb (7.0 kg)1
15.7 lb (7.1 kg)2
16.1 lb (7.3 kg)1
16.4 lb (7.4 kg)2
16.6 lb (7.5 kg)3
Dimensions (H x W x D)
Catalyst 3750-X and 3560-X-24T
Catalyst 3750-X and 3560-X-24P
Catalyst 3750-X and 3560-X-48T
Catalyst 3750-X and 3560-X-48P
Catalyst 3750-X and 3560-X-48PF
1.75 x 17.5 x 18.0 in. (4.45 x 44.5 x 46.0 cm)
1.75 x 17.5 x 18.0 in. (4.45 x 44.5 x 46.0 cm)
1.75 x 17.5 x 18.0 in. (4.45 x 44.5 x 46.0 cm)
1.75 x 17.5 x 18.0 in. (4.45 x 44.5 x 46.0 cm)
1.75 x 17.5 x 19.5 in. (4.45 x 44.5 x 49.5 cm)
Note The C3KX-PWR-1100 W AC power supply extends
1.5 in. (3.8 cm) beyond the switch chassis.
1. With C3KX-PWR-350-W AC power supply
2. With C3KX-PWR-715-W AC power supply
3. With C3KX-PWR-1100-W AC power supply
Table A-2 Environmental and Physical Specifications for the AC- and DC-Power Supply
Modules
Environmental Ranges
Operating temperature 23 to 113° F (–5 to 45° C)
Storage temperature –40 to 158° F (–40 to 70° C)
Relative humidity 10 to 95% (noncondensing)
Altitude Up to 10,000 ft (3049 m)
Physical Specifications
Table A-1 Environmental and Physical Specifications (continued)

A-3
Catalyst 3750-X and 3560-X Switch Hardware Installation Guide
OL-19593-01
Appendix A Technical Specifications
Power Supply Module Specifications
Weight
C3KX-PWR-1100WAC
C3KX-PWR-715WAC
C3KX-PWR-350WAC
C3KX-PWR-440WDC
3 lb (1.4 kg)
2.8 lb (1.3 kg)
2.7 lb (1.2 kg)
3.5 lb (1.6 kg)
Dimensions (H x D x W)
C3KX-PWR-1100WAC
C3KX-PWR-715WAC
C3KX-PWR-350WAC
C3KX-PWR-440WDC
1.38 x 11.72 x 3.25 in. (3.5 x 29.8 x 8.3 cm)
1.38 x 10.22 x 3.25 in. (3.5 x 26 x 8.3 cm)
1.38 x 10.22 x 3.25 in. (3.5 x 26 x 8.3 cm)
1.38 x 10.22 x 3.25 in. (3.5 x 26 x 8.3 cm)
Note Dimensions shown exclude the attached power cord
retainer (AC power supplies) or the extraction handle
(DC power supplies), which measures 1.55 in.
(3.9 cm).
Table A-3 Power Specifications for AC Power 24- and 48-Port Switches
Power Specifications
Maximum output power C3KX-PWR-1100WAC: 1100 W
C3KX-PWR-715WAC: 715 W
C3KX-PWR-350WAC: 350 W
Input voltage range and frequency C3KX-PWR-1100WAC: 1100-W, 115 to 240 VAC (autoranging)
50 to 60 Hz
C3KX-PWR-715WAC: 715 W, C3KX-PWR-350WAC: 350 W,
100 to 240 VAC (autoranging), 50 to 60 Hz
Input current C3KX-PWR-1100WAC:12–6 A
C3KX-PWR-715WAC: 10–5 A
C3KX-PWR-350WAC: 4–2 A
Output ratings C3KX-PWR-1100WAC: –56 [email protected] A
C3KX-PWR-715WAC: –56 [email protected] A
C3KX-PWR-350WAC: –56 [email protected] A
Total input BTU1
1. The total input and total output BTU ratings refer to input power to the power supply and output power to the switch. The
BTU ratings are based on 100 VAC for the 350-W and 715-W power supplies and 115 VAC for the 1100-W power supply.
C3KX-PWR-1100WAC: 4263 Btus per hour, 1250 W
C3KX-PWR-715WAC: 2742 Btus per hour, 804 W
C3KX-PWR-350WAC: 1357 Btus per hour, 398 W
Total output BTU1C3KX-PWR-1100WAC: 3751 Btus per hour, 1100 W
C3KX-PWR-715WAC: 2438 Btus per hour, 765 W
C3KX-PWR-350WAC: 1194 Btus per hour, 350 W
Table A-2 Environmental and Physical Specifications for the AC- and DC-Power Supply Modules
(continued)

A-4
Catalyst 3750-X and 3560-X Switch Hardware Installation Guide
OL-19593-01
Appendix A Technical Specifications
Fan Module Specifications
Fan Module Specifications
Table A-4 Power Specifications for DC-Power 24- and 48-Port Switches
Power Specifications
Maximum output power C3KX-PWR-440WDC: 440 W
Input current C3KX-PWR-440WDC: 16 – 8 A
DC input voltage C3KX-PWR-440WDC: –36 to –72 VDC
Output ratings C3KX-PWR-440WDC: –56 [email protected] A
Voltage range domestic C3KX-PWR-440WDC: –36 VDC (minimum)
–48 VDC (nominal), –72 VDC (maximum)
Voltage range international C3KX-PWR-440WDC: –36 VDC (minimum)
–60 VDC (nominal), –72 VDC (maximum)
Total input BTU1
1. The total input and total output BTU ratings refer to input power to the power supply and output power to the switch. The
BTU ratings are based on –36 VDC.
C3KX-PWR-440WDC: 1841 Btus per hour, 540 W
Total output BTU1C3KX-PWR-440WDC: 1502 Btus per hour, 440 W
Wire gauge for ground connection C3KX-PWR-440WDC: 12 AWG or 8 AWG
Branch circuit protection C3KX-PWR-440WDC: 20 A
Table A-5 Fan Module Environmental and Physical Specifications
Environmental Ranges
Operating temperature 23 to 113° F (–5 to 45° C)
Storage temperature –40 to 158° F (–40 to 70° C)
Relative humidity 10 to 95% (noncondensing)
Altitude Up to 10,000 ft (3049 m)
Physical Specification
Dimensions (H x D x W) 1.68 x 6.8 x 5.74 in. (4.27 x 17.27 x 14.58 cm)
Weight 0.24 lb. (0.1 kg)
Operating Specification
Airflow 60 cfm

A-5
Catalyst 3750-X and 3560-X Switch Hardware Installation Guide
OL-19593-01
Appendix A Technical Specifications
Fan Module Specifications
Table A-6 Standards and Certifications
Description Specification
Electromagnetic compatibility
certifications
FCC Part 15 Class A
EN55022 Class A (CISPR22)
EN55024 (CISPR24)
CE
VCCI Class A
AS/NZS CISPR22 Class A
MIC
China EMC certifications
GOST
Environmental Reduction of Hazardous Substances (ROHS) 5
Noise specifications Office product spec: 48 dBA at 86º F (30º C)
