RGBLE S00203 User manual

Stock Code 873117 en.rgble.com 400-1661-021
P/N: S00203
4K HDMI 4×1
Quad Multi-Viewer
User Manual
VER 1.0

Stock Code 873117 en.rgble.com 400-1661-021
P/N: S00203
Thank you for purchasing RGBLE product
For optimum performance and safety, please read these instructions carefully before
connecting, operating or adjusting this product. Please keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical spikes,
surges, electric shock, lighting strikes, etc. Use of surge protection systems is highly
recommended in order to protect and extend the life of your equipment.
1. Introduction
The high-performance 4×1 quad multi-viewer supports four routes HDMI high-definition input
contents be displayed on one HDMI screen and one VGA screen simultaneously. It supports
analog audio output that can be selected different input source. Supports five multi-view display
modes. Output resolution can be adjusted and supports the maximum up to 4K30Hz. The
product can be controlled via the front panel button and remote control.
2. Features
◆HDMI 1.4b, HDCP 1.4 compliant
◆Input resolution can automate recognition. (480p~4K30Hz, 800x600~4K30Hz)
◆Output resolution can be selected by on-panel button and remote control.
◆HDMI supports resolution the maximum up to 4K30Hz. (3840x2160@30Hz,
1920x1080@50/60Hz, 1280x720@50/60Hz, 1920x1200@60Hz,
1024x768@60Hz)
◆VGA supports resolution the maximum up to 1920x1200@60Hz.
(1920x1080@50/60Hz, 1280x720@50/60Hz,1920x1200@60Hz,
1024x768@60Hz)
Note: If output resolution selects the 4K30Hz, the VGA port will not support.
◆Audio supports LPCM 2CH.
◆Supports 1/2/4 windows multi-view modes.
◆Control is via on-panel button and remote control.
3. Package
① 1× 4K HDMI 4×1 Quad Multi-Viewer
② 1× 12V/1A DC Power Adapter
③ 1× Remote Control
④ 2× Mounting Ears
⑤ 1× User Manual

Stock Code 873117 en.rgble.com 400-1661-021
P/N: S00203
4. Specifications
Technical
HDMI Compliance
HDMI 1.4b
HDCP Compliance
HDCP 1.4
Video Bandwidth
10.2Gbps
Video Resolutions
3840x2160@30Hz,1920x1080@50/60Hz,1280x720@
50/60Hz,1920x1200@60Hz,1024x768@60Hz
Color Depth
8-bit
Color Space
RGB, YCbCr 4:4:4, YCbCr 4:2:2
Analog Audio Formats
LPCM2.0, 44.1KHz, 48KHz
ESD Protection
Human-body Model:
±8kV (Air-gap discharge) , ±4kV (Contact discharge)
Connections
Inputs ports
4x HDMI Type A [19-pin female]
1x SERVICE [Micro USB, Update port]
Outputs ports
1x HDMI Type A [19-pin female]
1x VGA [VGA-D]
1x Audio [3.5mm Stereo Mini-jack]
Mechanical
Housing
Metal Enclosure
Color
Black
Dimensions
185mm (W)×128mm (D)×20mm (H)
Weight
595g
Power Supply
Input: AC100~240V 50/60Hz, Output: DC12V/1A (US/EU
standards, CE/FCC/UL certified)
Power Consumption
7.68W (max)
Operating Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature
-20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity
20~90% RH (non-condensing)

Stock Code 873117 en.rgble.com 400-1661-021
P/N: S00203
5. Operation Controls and Functions
Front Panel:
Number
Name
Function Description
POWER LED
The LED will illuminate green when the unit is working, red when the unit is
in standby mode.
IR
IR receiver window. It accepts the remote-control signal of this device only.
CH1/CH2/CH3/
CH4 button
Input channel select button (Please refer to “6. Display Modes” for details).
MODE button
Press this button to cyclical selection display mode output (Please refer to
“6. Display Modes” for detail description). Press this button up to 5s, the
output screen is full screen and equal proportion display.
RESO button
Cycling selects different output resolution. Press this button up to 5s to
opening or closing window display frame.
SERVICE port
Fireware update port. (Manufacture use only.)
Rear Panel:
Number
Name
Function Description
HDMI INPUT
Connect to HDMI source device such as DVD player or PS4 with a HDMI cable.
HDMI OUTPUT
Connect to HDMI display device such as TV or projector with a HDMI cable.
VGA OUTPUT
VGA output port, this port output signal is the same as the HDMI output port.
AUDIO
OUTPUT
Analog audio output port. (Note: If the HDMI output is MODE 1, the audio output
follows the video content. If the HDMI output is MODE 2/3/4/5, press
CH1/CH2/CH3/CH4 up to 5s to selecting audio output or using remote control to
cyclical selection audio output. The default status is CH1 screen audio output.)
DC 12V
Plug the 12V/1A DC power supply into the unit and connect the adapter to an AC
outlet

Stock Code 873117 en.rgble.com 400-1661-021
P/N: S00203
6. Display Modes
The quad multi-viewer has 5 display modes. Detailed description is as follows.
MODE 1 MODE 2 MODE 3 MODE 4 MODE 5
MODE 1: The quad multi-viewer will display separately four HDMI inputs. Press the
CH1/CH2/CH3/CH4 buttons on-panel or using IR remote control the Source 1/2/3/4 buttons to
selecting input source, corresponding on-panel light is on.
MODE 2: The quad multi-viewer divides four HD inputs with same size and display on a screen.
The on-panel four lights is on. In the CH1 window, you can press the CH1 button on-panel or
using IR remote control the Source 1 button to cyclical selection four inputs source. In the CH2
window, you can press the CH2 button on-panel or using IR remote control the Source 2 button
to cyclical selection four inputs source...etc.
The rest can be done in the same manner.
MODE 3: The quad multi-viewer divides four HD inputs and display on a screen. The on-panel
four lights are on. Operation method is the same as MODE 2.
MODE 4: The quad multi-viewer divides two HD inputs with same size and display on a screen.
The on-panel CH1/CH2 lights is on. In the CH1 window, you can press the CH1 button on-panel
or using IR remote control the Source 1 button to cyclical selection four inputs source. On the
CH2 window, you can press the CH2 button on-panel or using IR remote control the Source 2
button to cyclical selection four inputs source.
MODE 5: The quad multi-viewer divides four HD inputs and display on a screen. The on-panel
four lights is on. Operation method is the same as MODE 2.

Stock Code 873117 en.rgble.com 400-1661-021
P/N: S00203
7. IR Remote
: Press this button to setting standby mode, press this button
again to power on the unit.
: Press this button to opening or closing display window frame.
: Press this button to cyclically select output resolution.
Mode: Press these buttons to select output
display mode.
: Press this button to cyclically select output display mode.
Source:
1/2/3/4: Press these buttons to select input source.
: Press this button to cyclically select input source (This button can
be used only at the MODE 1).
Audio:
Mute button.
Press this button to select audio output cyclically.
8. Application Example
