Airspan AirSpeed 1050 Series User manual

AirSpeed 1050 Installation Guide
Part Number: DUG01545
System Release: 16.0
Revision: A
Published: June 2019

© Copyright by Airspan Networks Inc., 2019 - 2019. All rights reserved worldwide.
Legal Notices
The information contained within this document is proprietary, privileged and intended only for the recipient. As such, the
information is subject to all relevant copyright, patent and other laws protecting intellectual property, as well as any spec ific
agreements protecting Airspan Networks Ltd. rights in the aforesaid information. Neither this document nor the information
contained herein may be published, reproduced, transmitted or disclosed to third parties, in whole or in part, without the
express, prior, written permission of Airspan Networks Ltd. In addition, any use of this document or the information contained
herein for the purposes other than those for which it is disclosed is strictly forbidden.
Airspan Networks Inc. reserves the right, without prior notice or liability, to make changes in equipment design or specifications.
Information supplied by Airspan Networks Ltd. is believed in good faith to be accurate and reliable, while every care has been
taken in preparing these documents. However, Airspan Networks Ltd. does not make any representations and gives no
warranties of whatever nature in respect of these documents, including without limitation, the accuracy or completeness of any
information, facts and/or opinions contained therein. No responsibility is assumed by Airspan Networks Ltd. for the use of the
documents nor for the rights of third parties which may be effected in any way by the use thereof. The provision of these
documents (and the documents themselves) does not constitute professional advice of any kind. Any representation(s) in these
documents concerning performance of Airspan Networks Ltd. product(s) are for informational purposes only and are not
warranties of future performance, either expressed or implied. Airspan Networks Ltd., its affiliates, directors, employees and
agents shall not be held liable for any damages or losses, of any nature whatsoever, arising from any use of and/or reliance on
the documents.
These documents may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed in relation
thereto unless specifically undertaken in Airspan Networks Ltd. sales contract or order confirmation. Information contained
herein is periodically updated and changes will be incorporated into subsequent editions. If you have encountered an error,
please notify Airspan Networks Ltd.
Product performance figures quoted within this document are indicative and for information purposes only.

DUG01285-SP Airspan Commercial and Internal Use i
Table of Contents
Document Information ............................................................................... 1
Document Approvals .............................................................................................. 1
Revision History ..................................................................................................... 1
Warnings and Cautions ............................................................................. 2
Human Exposure to Radio Frequencies ................................................................ 2
Avertissement et Precautions d’Utilisation ................................................ 2
Radio Interference.................................................................................................. 2
Modifications .......................................................................................................... 2
General .................................................................................................................. 2
Général .................................................................................................................. 3
Important Safety Instructions ............................................................................ 3
Safety ..................................................................................................................... 3
Securite .................................................................................................................. 4
Warning of Hazardous Voltages ............................................................................ 4
Attention aux Voltages Hasardeux ......................................................................... 5
Adherence to European Directive 1999/5/EC ........................................................ 5
Warning Symbols ................................................................................................... 5
Service Information ................................................................................................ 5
UL Information ....................................................................................................... 6
Lightning Protection ............................................................................................... 6
Outdoor Cabling ..................................................................................................... 7
DECLARATION OF CONFORMITY....................................................................... 7
GPS Compliance.................................................................................................... 8
Maximum Output TX Total Power ............................................................. 9
Power Consumption ............................................................................................... 9
Product Variants .................................................................................................... 9
Antenna System ................................................................................................... 10
About This Document .............................................................................. 11
Purpose ................................................................................................................ 11

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use ii
Intended Audience ............................................................................................... 11
Related Reading .................................................................................................. 11
Customer Care Help Desk ...................................................................... 12
Airspan Encourages Comments .......................................................................... 12
1Introduction .......................................................................................... 13
1.1 AirSpeed 1050 .............................................................................................. 13
1.1.1 Deployment .................................................................................................. 13
2Verifying Prerequisites ......................................................................... 15
2.1 Verify the Tools ............................................................................................. 15
2.2 Verify the Parts and Kits ................................................................................ 15
3Physical Description ............................................................................ 17
3.1 AirSpeed 1050 Physical Dimensions............................................................. 17
3.2 Bottom View .................................................................................................. 18
3.3 Power 18
3.3.1 Environmental .............................................................................................. 18
4Installation of AirSpeed 1050 .............................................................. 20
4.1 Mounting ....................................................................................................... 20
4.1.1 Pole Mount Assembly ................................................................................... 21
4.1.2 Wall Mount Assembly ................................................................................... 22
4.1.3 Securing the Unit to the Mounting Clamp Bracket ........................................ 23
5Connect and Manage Cables .............................................................. 25
5.1 Connecting the Ground Cable ....................................................................... 25
5.2 Cable Connection .......................................................................................... 25
5.2.1 AC Cable Preparation .................................................................................. 26
5.2.2 DC Cable Preparation .................................................................................. 30
5.2.3 Fiber Ethernet (SFP) Cable Preparation ....................................................... 34
5.2.4 Copper Ethernet Cable Preparation.............................................................. 38
AJob Sheet ............................................................................................. 42
BAbbreviations ....................................................................................... 43

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use iii
Figures
Figure 1: AirSpeed 1050 .................................................................................................................. 10
Figure 2: AirSpeed 1050 .................................................................................................................. 14
Figure 3: AirSpeed 1050 Overall Dimensions ................................................................................... 17
Figure 4: AirSpeed 1050 Bottom ...................................................................................................... 18
Figure 5: Positioning Overview ........................................................................................................ 20
Figure 6: Mounting Bracket on Wall ................................................................................................. 22
Figure 7: Assembly on Pole ............................................................................................................. 23
Figure 8: AirSpeed 1050 on Pole (Shown Wired) ............................................................................. 23
Figure 9: AirSpeed 1050 on Top Pole - Example (Shown Wired) ...................................................... 24
Figure 10: AirSpeed 1050 on Wall ................................................................................................... 24
Figure 11: Ground Connection ......................................................................................................... 25
Figure 12: Stripping Dimensions (AC Cable) .................................................................................... 26
Figure 13: Open Housing Lock ........................................................................................................ 26
Figure 14: Seperate into Sections .................................................................................................... 27
Figure 15: Insert Gland Nut .............................................................................................................. 27
Figure 16: Pass Cable Through ....................................................................................................... 27
Figure 17: Insert Wire to Housing ..................................................................................................... 27
Figure 18: AC Wire Placement ......................................................................................................... 28
Figure 19: Tighten Three (3) Set Screws .......................................................................................... 28
Figure 20: Cable Click in Place ........................................................................................................ 28
Figure 21: Place Split Rubber Gland ................................................................................................ 28
Figure 22: Gland Size on Edge ........................................................................................................ 29
Figure 23: Place Tightening Cone on Split Gland ............................................................................. 29
Figure 24: Tighten Gland Nut ........................................................................................................... 29
Figure 25: Close the Lever ............................................................................................................... 30
Figure 26: Secure Lock .................................................................................................................... 30
Figure 27: Stripping Dimensions (DC Cable) .................................................................................... 30
Figure 28: Open Housing Lock ........................................................................................................ 31
Figure 29: Seperate into Sections .................................................................................................... 31
Figure 30: Insert Gland Nut .............................................................................................................. 31
Figure 31: Pass DC Cable Thru ....................................................................................................... 31
Figure 32: Tighten Two (2) Set Screws ............................................................................................ 32
Figure 33: Tighten the Strap Clamp ................................................................................................. 32
Figure 34: Align Marks + Click in Place ............................................................................................ 32
Figure 35: Place Split Rubber Gland ................................................................................................ 32
Figure 36: Gland Size on Edge ........................................................................................................ 33

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use iv
Figure 37: Place Tightening Cone on Split Gland ............................................................................. 33
Figure 38: Tighten gland Nut............................................................................................................ 33
Figure 39: Close the Lever ............................................................................................................... 33
Figure 40: Secure Housing Lock ...................................................................................................... 34
Figure 41: Pre-assembled LC Duplex Cable .................................................................................... 34
Figure 42: Open Housing Lock ........................................................................................................ 34
Figure 43: Gland Nut on Cable ........................................................................................................ 35
Figure 44: Insert Tightening Cone on Cable ..................................................................................... 35
Figure 45: Insert Rubber Gland on Cable ......................................................................................... 35
Figure 46: Pass Cable thru Housing................................................................................................. 35
Figure 47: Insert Cable into Transceiver........................................................................................... 36
Figure 48: Insert Holder over theTransceiver ................................................................................... 36
Figure 49: Holder into Housing Base................................................................................................ 36
Figure 50: Holder into Transceiver ................................................................................................... 36
Figure 51: Lift Lever ......................................................................................................................... 37
Figure 52: Insert Gland .................................................................................................................... 37
Figure 53: Insert Cone ..................................................................................................................... 37
Figure 54: Tighten Gland Nut ........................................................................................................... 37
Figure 55: Secure Housing Lock ...................................................................................................... 38
Figure 56: Pre-assembled RJ45 Cable ............................................................................................ 38
Figure 57: Gland Nut on Cable ........................................................................................................ 38
Figure 58: Insert Tightening Cone on Cable ..................................................................................... 38
Figure 59: Insert Rubber Gland on Cable ......................................................................................... 39
Figure 60: Insert Housing onto Cable ............................................................................................... 39
Figure 61: Insert Holder onto RJ45 .................................................................................................. 39
Figure 62: Holder into Housing Base................................................................................................ 39
Figure 63: Align RJ45 into Holder .................................................................................................... 40
Figure 64: Lift Lever ......................................................................................................................... 40
Figure 65: Insert Gland .................................................................................................................... 40
Figure 66: Tighten Gland Nut ........................................................................................................... 40
Figure 67: Secure Housing Lock ...................................................................................................... 41
Figure 68: AC Housing Lock Secured .............................................................................................. 41
Tables
Table 1: AirSpeed 1050 ETSI Maximum Output TX Total Power ........................................................ 9
Table 2: Power Consumption ............................................................................................................. 9
Table 3: Variants ............................................................................................................................... 9
Table 4. Hardware Requirements - Mounting ................................................................................... 15
Table 5: AirSpeed 1050 Components .............................................................................................. 15

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use v
Table 6. AirSpeed 1050 Physical Dimensions .................................................................................. 17
Table 7. AirSpeed 1050 Environment Compliance ........................................................................... 18
Table 8: Outdoor Power Cable Requirements .................................................................................. 25
Table 9: Recommended Gland Size................................................................................................. 29

AirSpeed 1050 Installation guide
DUG01545 Airspan Commercial and Internal Use 1
Document Information
This document details procedures for installing the Airspan’s AirSpeed 1050 Pico-class LTE eNodeB
variant.
Document Approvals
Department
Name
Role
Approval date
Product Management
STS
Product Line Manager
R&D
EPI
Digital HW Group Manager
Revision History
Document owner: Shlomi Tsur, PLM
Revision
Date
Summary of Changes
Created by
0.1 - 0.3
January 2019
Initial document & comments
MSF
0.4
February 2019
Additions from comments
MSF
A
February 2019
 Additions from comments
 Publish
MSF
A1
May 2019
 Additions from comments
MSF
A2
June 2019
 Additions from comments
MSF

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use 2
Warnings and Cautions
Human Exposure to Radio Frequencies
The AirSpeed 1050 when operational should be operated from a minimum safe distance of 2ft (64cm).
Avertissement et Precautions d’Utilisation
Exposition des personnes aux fréquences radioélectriques
Les antennes d’AirSpeed 1050 quand opérationnel doivent être installée et utilisée de façon à garantir
la distance minimale de sécurité de 2ft. (60cm).
Radio Interference
This AirSpeed 1050 generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment on and off, the technician is encouraged to try to correct the interference by
performing one or more of the following measures:
 Re-orientate or relocate the unit
 Increase separation between the units and/or End Device
 Connect the equipment to a circuit different from that to which the power source is connected
Modifications
Any changes and modifications to this device that are not expressly approved by Airspan Networks
may void the user's authority to operate the equipment.
General
 Only qualified personnel should be allowed to install, replace, and service the equipment.
 The device cannot be sold retail, to the general public or by mail order. It must be sold to
operators.
 Installation must be controlled.
 Installation must be performed by licensed professionals.
 Installation requires special training. The AirSpeed 1050 radio and antenna should be
installed ONLY by experienced installation professionals who are familiar with local building
and safety codes and, wherever applicable, are licensed by the appropriate government
regulatory authorities. Failure to do so may void Airspan's product warranty and may expose
the end user or the service provider to legal and financial liabilities. Airspan and its resellers
or distributors are not liable for injury, damage or violation of regulations associated with the
installation of outdoor units or antennas.
 The device is to be installed in a Restricted Access Location.

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use 3
Général
 Seul le personnel qualifié peut être autorisé pour installer ou remplacer l’équipement ainsi
qu’effectuer les opérations de maintenance pour cet équipement.
 L’équipement ne peut pas être vendu en grande distribution ou par commande via email à
destination du public. Il doit être vendu aux opérateurs de télécommunications.
 Son installation doit être contrôlée
 Son Installation doit être effectuée par des professionnels autorises.
 Son installation requiert une formation spécifique du personnel. L’AirSpeed 1050, radio et
antenne doit être installe UNIQUEMENT par des installateurs professionnels expérimentés et
ayant une connaissance des constructions locales et règles de sécurité, ainsi que, dès que
nécessaire, disposant d’un agreement des autorités gouvernementales de régulation. Toute
enfreinte a ces obligations peut annuler la garantie délivrée par Airspan pour ces produits et
peut exposer l’utilisateur final ou le fournisseur de services a des dommages légaux et
financiers.
 Airspan et ses revendeurs ou ses distributeurs ne sont pas responsables des blessures,
dommages ou violations de la régulation en vigueur lies a l’installation du système extérieur
ou des antennes.
 L’Equipment doit être installe dans une zone a accès réduit et contrôle.
Important Safety Instructions
 Read and Save these instructions
 This Installation Guide contains instructions and warnings that should be followed during
installation, and operation.
 Failure to follow these instructions could cause bodily injury and/or product failure.
Safety
1. Read this guide and follow all operating and safety instructions.
2. Supply cord is not shipped with the unit and is to be provided by user. Installation is to be
performed by a qualified electrician according to local codes. Installation to be done in
accordance with the National Electrical Code (NEC), ANSI/NFPA 70, the Canadian
Electrical Code (CEC), Part I, CAN/CSA C22.1, and when applicable, the National
Electrical Safety Code, IEEE C2.
3. Static sensitive components inside - do not remove the lid or base: No user serviceable
parts inside.
4. The ground connection should be made before connecting to supply connections.
5. Position the power cord to avoid possible damage; do not overload circuits.
6. Do not place this product on or near a direct heat source, and avoid placing objects on
the terminal.
7. To avoid electrical shock do not install this device during adverse conditions such as rain
or inclement weather.
8. Use only a damp cloth for cleaning. Do not use liquid or aerosol cleaners. Disconnect the
power before cleaning.
9. The units should not be located too near power lines or other electrical power circuits,
where it can come into contact with such power lines or circuits.
10. The unit must be properly grounded to protect against power surges and accumulated
static electricity. It is the user’s responsibility to install this device in accordance with the
local electrical codes.
11. Installation of the unit must be contracted to a professional installer.

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use 4
12. The circuit breaker should be easily accessible in case you have to disconnect the
device.
13. When installed in the final configuration, the product must comply with the applicable
Safety Standards and regulatory requirements of the country in which it is installed. If
necessary, consult with the appropriate regulatory agencies and inspection authorities to
ensure compliance.
Securite
1. Lire attentivement ce guide et suivre les instructions d’utilisation et de sécurité.
2. Le cordon d’alimentation n’est pas livré avec l'appareil et doit être fourni par l'utilisateur.
L’installation doit être effectuée par un électricien qualifié conformément aux règles et
standards locaux. L’installation doit être effectuée en conformité avec le Code national de
l'électricité ( NEC ), ANSI / NFPA 70, le Code canadien de l'électricité (CCE ), Partie I,
CAN / CSA C22.1, et le cas échéant, le Code national de sécurité électrique, IEEE C2.
3. Des composants sensibles a électricité statique sont utilisés à l’intérieur. Ne pas retirer le
coffre ou la base. Aucune pièce a l’intérieur est d’utilité pour l’utilisateur.
4. La connexion "terre" doit être effectuée en priorité et avant d'effectuer les connexions à la
source d'alimentation (phase et neutre).
5. Positionner le cordon d’alimentation de façon à éviter des dommages potentiels. Ne pas
surcharger les circuits.
6. Ne pas placer ce produit sur ou à proximité d’une source directe de chaleur et éviter de
placer des objets sur le terminal.
7. Afin d’éviter des problèmes électriques, ne pas installer cet équipement au cours
d’évènements climatiques difficiles comme averses ou météo non clémente.
8. Utiliser uniquement chiffon de coton pour nettoyage. Ne pas utiliser de produits liquides
ou d’aérosols. Déconnecter le produit de la source d’alimentation avant nettoyage.
9. L’unité ne doit pas être située trop près de lignes électriques ou autres circuits de
puissance, avec lesquels il pourrait entrer en contact.
10. L’émetteur radio doit être correctement relie a la terre afin de le protéger contre les
surtensions ou accumulation d’électricité statique. L’utilisateur est tenu responsable de
l’installation du produit conformément aux règles électrique en vigueur localement.
11. L’installation de unité doit être contractualisée avec un installateur professionnel.
12. L’interrupteur de circuit électrique doit être facilement accessible afin de pouvoir
déconnecter l’équipement.
13. Lors de l’installation de la configuration finale, le produit doit être conforme aux Standards
de Sécurité en vigueur ainsi qu’aux exigences réglementaires du pays dans lequel il est
installé. Si nécessaire, consulter les agences règlementaires appropriées, ainsi que les
autorités chargées de l’inspection afin de garantir la conformité.
Warning of Hazardous Voltages
On AC installations, hazardous voltages exist. Use caution when verifying or working with AC power.
Remove metal jewellery that could come into contact with AC power.
On DC sections, short-circuiting the low voltage, low impedance circuits can cause severe arcing that
may result in burns or eye damage. Remove rings, watches etc. to avoid shorting DC circuits.
Note: Airspan products do not contain hazardous substances (as defined in UK Control of
Substances Hazardous to Health Regulations 1989 and the Dangerous Substances Regulations
1990). At the end of any Airspan products life cycle, the customer should consult with Airspan to
ensure that the product is disposed of in conformance with the relevant regulatory requirements.

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use 5
Attention aux Voltages Hasardeux
Sur les installations de réseau électrique de type courant alternatif (CA) , des voltages hasardeux
peuvent survenir. Garder une Attention particulière lors d’une vérification ou de travaux sur réseau
électrique CA. Retirer tous bijoux en métal qui pourraient entrer en contact avec l’alimentation ou le
réseau CA.
Sur les portions de réseau électrique de type courant continu (CC), un circuit basse impédance peut
causer de sérieux arcs électriques qui pourraient bruler ou endommager les yeux. Retirer bagues,
anneaux, montres etc… afin d’éviter les court-circuit sur le réseau CC.
Adherence to European Directive 1999/5/EC
European Council Recommendation 1999/5/EC details basic restrictions and reference levels on
human exposure to electromagnetic fields as advised by the ICNIRP. Adherence to these
recommended restrictions and reference levels should provide a high level of protection as regards
the established health effects that may result from exposure to electromagnetic fields.
Airspan equipment is compliant with CE and R&TTE regulations and can be operated in all EU
(European Union) locations listed below:
Country Code
BE
EL
LT
PT
BG
ES
LU
RO
CZ
FR
HU
SI
DK
HR
MT
SK
DE
IT
NL
FI
EE
CY
AT
SE
IE
LV
PL
UK
Warning Symbols
The following symbols may be encountered during installation or troubleshooting. These warning
symbols mean danger. Bodily injury may result if you are not aware of the safety hazards involved in
working with electrical equipment and radio transmitters. Familiarize yourself with standard safety
practices before continuing.
Caution, hot
surface
Caution
Electro-Magnetic
Radiation
High Voltage (AC)
DC
Service Information
Refer all repairs to qualified service personnel. Do not modify any part of this device, as this will void
the warranty.
Disconnect the power to this product and return it for service if the following conditions apply:

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use 6
a. The terminal does not function after following the operating instructions outlined in this
manual.
b. The product has been dropped or the housing is damaged.
Locate the serial number of the terminal and record this on your registration card for future reference.
Also record the MAC address, located on the product sticker.
UL Information
- The equipment must be properly grounded according with NEC and other local safety code
requirements.
- Reminder to system installers: Attention to Section 820-40 of the NEC which provides guidelines for
proper grounding and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as is practical.
- AirSpeed 1050 is designed to operate in environmental conditions complying with IP66 and relevant
standards.
Lightning Protection
WARNING: The following notes are general recommendations for the system. The wireless equipment
should be installed by a qualified professional installer and must follow local and national codes for
electrical grounding and safety. Failure to meet safety requirements and/or use of non-standard
practices and procedures could result in personal injury and damage to equipment. A direct lightning
strike may cause serious damage even if these guidelines are followed.
All outdoor wireless equipment is susceptible to lightning damage from a direct hit or induced current
from a near strike. Lightning protection and grounding practices in local and national electrical codes
serve to minimize equipment damage, service outages, and serious injury. The antennas are to be DC
grounded, so surge protection may not be required. Reasons for lightning damage are summarized as:
- Poorly grounded tower/antenna sites that can conduct high lightning strike energy into equipment.
- Lack of properly installed lightning protection equipment that can cause equipment failures from
lightning induced currents.
A lighting protection system provides a means by which the energy may enter earth without passing
through and damaging parts of a structure. A lightning protection system does not prevent lightning
from striking; it provides a means for controlling it and preventing damage by providing a low resistance
path for the discharge of energy to travel safely to ground. Improperly grounded connections are also a
source of noise that can cause sensitive equipment to malfunction.
A good tower grounding system disperses most of the surge energy from a tower strike away from the
building and equipment.
To limit the equipment damage due to a lightning strike, the following practices are recommended for
the wireless system:
- Provide direct grounding from the antenna mounting bracket, the radio and antenna and the
lightning/surge protectors to the same ground point at the base of the tower or a ground bus on the
building. Use the grounding screws on the antenna bracket and the radio and antenna for terminating
the ground wires.
- The circuit ground must be connected to the same grounding system as the unit.

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use 7
Outdoor Cabling
- Connected cables should be outdoor grade with UV protection.
- Use shielded out CAT6 cabled terminated with metallic RJ45 connectors.
- Surge protection circuit must use a minimum 14AWG grounding cable.
DECLARATION OF CONFORMITY
European Community, Switzerland, Norway, Iceland, and Liechtenstein
Declaration of Conformity with Regard to the R&TTE Directive 1999/5/EC
English:
This equipment is in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
Deutsch:
Dieses Gerät entspricht den grundlegenden Anforderungen und den weiteren entsprecheneden
Vorgaben der Richtlinie 1999/5/EU.
Dansk:
Dette udstyr er i overensstemmelse med de væsentlige krav og andre relevante bestemmelser i Directiv
1999/5/EF.
Español:
Este equipo cumple con los requisitos esenciales asi como con otras disposiciones de la Directive
1999/5/EC.
Greek:
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Airspan ΔΗΛΩΝΕΙ ΟΤΙ Ο ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ
ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Français:
Cet appareil est conforme aux exigencies essentialles et aux autres dispositions pertinantes de la
Directive 1999/5/EC.
Íslenska:
Þessi búnaður samrýmist lögboðnum kröfum og öðrum ákvæðum tilskipunar 1999/5/ESB.
Italiano:
Questo apparato é conforme ai requisiti essenziali ed agli altri principi sanciti dalla Direttiva 1999/5/EC.
Nederlands:
Deze apparatuur voldoet aan de belangrijkste eisen en andere voorzieningen van richtlijn 1999/5/EC.
Norsk:
Dette utstyret er i samsvar med de grunnleggende krav og andre relevante bestemmelser i EU-directiv
1999/5/EC.
Português:
Este equipamento satisfaz os requisitos essenciais e outras provisões da Directiva 1999/5/EC.
Suomalainen:
Tämä laite täyttää direktiivin 1999/5/EY oleelliset vaatimukset ja on siinä asetettujen muidenkin ehtojen
mukainen.
Svenska:
Denna utrustning är i överensstämmelse med de väsentliga kraven och andra relevanta bestämmelser
i Direktiv 1999/5/EC.

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use 8
Român:
Acest echipament este în conformitate cu cerinţele esenţiale şi alte prevederi relevante ale Directivei
1999/5/CE.
The Declaration of Conformity related to this product can be obtained from [e-mail].
GPS Compliance
The GPS is in compliance with the essential requirements and other relevant provisions of Directive
1999/5/EC."
The GPS complies with the following EMC Common Regulatory Testing standards:
 EN55022: Radiated and Conducted Emissions
 CISPR 22: Class B
 EN 50081-1: Generic Emissions Class B
 EN 50082-1: Generic Immunity Class B
 EN 61000-4-2: Electrostatic Discharge Immunity
 EN 61000-4-3: Radiated RF EM Field Immunity Test
 EN 61000-4-4: Electrical Fast Transient/Burst Test
 EN 61000-4-6: Conducted Immunity
 EN 61000-4-8: Magnetic Field Immunity
Note: A GPS is recommended for synchronizing between sectors.
Note: An optional GPS Lightning/Surge protector is available from Airspan when installing the GPS
antenna in a remote location for lightning prone deployments.

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use 9
Maximum Output TX Total Power
Table 1: AirSpeed 1050 FCC Maximum Output TX Total Power
Frequency Band
(MHz)
FCC
TX (dBm) EIRP (dBm)
Antenna Gain (dBi)
Variant
2496 - 2690
35
47
12
1050
Caution: Do not set maximum output TX power to higher than local regulations.
Power Consumption
AirSpeed 1050 has a Max nominal power consumption of 45W. AirSpeed 1050 power consumption is
described in the following table:
Table 2: Power Consumption
Duplex
Tx Power at RF Port (dBm)
Nominal Power Consumption (W)
TDD
4x 33
45
Product Variants
Table 3: Variants
Product Name
Product Code
Description
AirSpeed 1050 B40 Fiber
+ copper BH, DC power
AS105-U40-B08D
AirSpeed 1050, 2.3 - 2.4 GHz (B40), Fiber,
Copper Backhaul, DC
AirSpeed 1050 B40 Fiber
+ copper BH, AC power
AS105-U40-B08A
AirSpeed 1050, 2.3 - 2.4 GHz (B40), Fiber,
Copper Backhaul, AC

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use 10
Antenna System
The AirSpeed 1050 includes embedded antennas: 2x SBA. Each SBA includes two antenna elements
which can be switch on/off.
Figure 1: AirSpeed 1050

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use 11
About This Document
Purpose
This guide provides the workflow and step-by-step procedures for Installing the AirSpeed 1050. These
procedures include:
 Verify prerequisites
 Install the AirSpeed 1050
 Connect and manage cables
Intended Audience
This guide is intended for persons who are responsible for installing the AirSpeed 1050 equipment.
These persons should have a working knowledge of the equipment.
Related Reading
The following documents contain related information:
 AirSpeed 1050 Product Datasheet
 Airspan LTE Commissioning Manual Pending

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use 12
Customer Care Help Desk
Airspan’s Customer Care Help Desk offers prompt and efficient customer support services.
Note: To avail Airspan’s Customer Care Help Desk support, you must be a registered user and must
have a valid support contract. To register, click here and fill the Registration form.
To create and update issue logs, send e-mails to Customer Care Help Desk. Once you submit your
issue, the system generates a new issue and sends an issue number for your reference. The system
uses this issue number to categorize and store e-mails under the appropriate issue.
To help Customer Care Help Desk identify your issue, include the issue number and your Customer
Care Helpdesk account details in all further communications.
Main Operations
Airspan Communications Ltd.
Capital Point
33 Bath Road
Slough, Berkshire
SL1 3UF, United Kingdom
Tel: [phone]
Worldwide Headquarters
Airspan Networks Inc.
777, Yamato Road, Suite 105
Boca Raton, FL 3341-4408, USA
Tel: [phone]
Airspan Encourages Comments
Airspan welcomes any feedback and suggestions that help to improve the quality of the documentation.
Send your feedback to [e-mail].

AirSpeed 1050 Installation Guide
DUG01545 Airspan Commercial and Internal Use 13
1 Introduction
This section provides a descriptive overview of the Airspan’s AirSpeed 1050 variant(s) and its place in
the Airspan product suite. AirSpeed 1050 is a standalone product with fiber and copper backhaul. It
includes dual sector access with SBA antenna. The product is aimed for outdoor deployment, on a
pole top or side as well as wall mounting.
1.1 AirSpeed 1050
AirSpeed 1050 is part of Airspan’s carrier-class LTE advanced outdoor family, a compact outdoor
small cell with dual sector smart beam antennas
All Airspan products, including AirSpeed 1050 B40, are interoperable with a rich portfolio of 3rd party
end user devices, including many handsets, indoor UEs, outdoor UEs and USB dongles from several
ODMs, using various chipsets. For an updated of interoperability list, please contact your nearest
Airspan Sales Representative.
Note: For management please refer to the Airspan LTE Commissioning Manual as well as the
Netspan User Manual.
1.1.1 Deployment
AirSpeed 1050 perfectly fits the requirements of the hard zoning outdoor locations such as city
centers, parks, universities, and hotel facilities all due to its super compact one box form factor.
AirSpeed 1050 creates a single install process for LTE Access and Backhaul, and enables “Just add
Power” plug and play deployment method and along with the easy zoning of the product saving
deployment related costs and time.
Note: The following is for illustration only; actual layout may differ as infrastructure is installation-
specific.
Note: AirSpeed 1050 must be properly grounded according with NEC and other local safety code
requirements.
