AirTouch U250 User manual

Android ver. 1.3.1 (v39)
U250
U250 Owner’s Manual
Android™
(V39)
(Subject to change without notice)
OneSmartConnect

2
Included Items
1. U250 base unit
2. AC Adapter (Base)
3. TEL Cord 1.8 meter (RJ11)
4. LAN Cable 1.0 meter (RJ45)
5. Quick Start Guide English & Spanish

3
Table of Contents
Included Items 2
Opening Box and Connecting U250_____ 4
Download OneSmartConnect App 5
Pair SmartPhone to the base 6
Android App Icons and Indicators 9
Feature Location and Screens
Dialer 10
History 11
Contacts 12
Active Call 13
OneSmartConnect U250 Features
Make a call on the Android 14
End a call 15
Receiving a landline call 16
Make a Quick Connect “Intercom” call 17
Transfer or Adding a caller 17
On Hold Notification 20
Advanced Features
“More” Feature 21
Prefix Settings 22
Troubleshooting 24
Q & A 25
Warranty Information 26
Precautions 27
Installation Considerations 28
General Information 30
FCC Rules 31

4
Opening Box and Preparing Android Device
1. Remove the U250 from the box.
2. There are only 4 (four) connections to make:
a. Connect the RJ45 (supplied LAN cable) to #6 on the back of the U250 and the
other end of cable to your Wireless Router.
b. Connect your RJ11 (supplied phone cord) to #8 on the back of the U250 and plug the
other end into your existing Landline wall outlet or the back of your VoIP box.
c. Optional - Connect an extension telephone to #9 on the back of the U250 (corded
or cordless telephone).
d. Connect the power adapter to #7 on the back of the U250 and to your
AC wall outlet. For proper operation, connect the power adapter last.

5
Download the OneSmartConnect App for Android
1. Download the OneSmartConnect (search as one word) App from the Google Play
Store.
The App should look similar to the picture below:

6
Pairing your Android to U250
1. On the U250 Base Unit, LED (#2) “TEL Line”should be solid (Not flashing) before
proceeding.
2. On your Android, turn on Wi-Fi. Make sure this is the same wireless network connected
to the U250.
3 . Enter the OneSmartConnect App by pressing the OneSmartConnect App Icon. The
following screen should appear:
4. Press and release the PAIR Button (#3) on the U250 Base Unit. The Power LED (#1) on the base
unit will flash.
5. On the OneSmartConnect App Screen, press “Pair”.
6. The Android display should say “Register”.
7. and then display the OneSmartConnect dial screen.
Wi-Fi Icon Must be ON
Enter Name of Device

7
8. L o c a l Extension # (1-8) appears just below Registration. This indicates that the phone is ready
to use and shows this Android ext. #. (Note: In the event of a power outage or if you go outside
the Wi-Fi range, you do not need to re-pair your Android.)
9. Repeat steps 2-7 to pair up to 7 additional Androids.
MAC address of U250
populates when paired
The “more” menu
Rotating icon while
paring

8
Updating U-250 Firmware
1. Use the “More menu” (three vertical dots) on the dialer screen and select “Update device FW”.
2. Your mobile phone and u2-250 have to be on the same network
3. Select “Udate_20161214”
4. You will see the light on the U-250 cycle through the update. The update is complete when all
four lights are lit again.
5. Return to the dialer screen. The phone is ready for use.
Select Update

9
Android App Icons and Indicators
Notify a party to join a call
Deletes one number at a time
Press to place a call
Gives you access to your Android contact list
Allows you to dial and place a call
Allows you to join all parties to a conference call
Press to terminate a call
Allows you to view previous calls, incoming and outgoing
Rejoin your landline call after completing a cell call or place on hold
Turns off the mic so the other party cannot hear you
Add a prefix to a phone number (area code, 011, etc.)
Activates the speakerphone

10
Press to Backspace
Feature Location and Screens
Dialer
Green Shows
Phone is
registered
Device
Extension #
Dial out, VOIP or landline
Press to make
call
Press for call
History
Press for
Contacts
Press for
configuration
settings
Use Dialer to
manually enter
phone number
Wi-Fi signal
Office Connect Plan

11
History
Clears History
out going Call
Incoming Call

12
Contacts
Phone’s Contact
list
Name Search
Press to call
a Contact

13
Active Call
Number or
Name Called
Duration of Call
Speaker Phone
Mute
Transfer call
Add second party
to call
Hold/Rejoin
Keypad to
send DTMF
Press to END
call

14
OneSmartConnectU250
Features
Make a Call Using Your Android
1. Access your OneSmartConnect App on your Android.
2. The dialer will appear. You can manually enter the phone number or press the Contacts Icon on the
bottom menu bar, to pick the desired contact.
3. Move the OSC/Tel Switch to send call by VOIP or landline
4. Press Green Phone icon to initiate the call.
Press CALL after dialing the number or picking a contact from your list.
Press Phone Icon after dialing the number or picking a contact from your Phone list

15
End a Call on the Android
1. Press END on the Android to end the call.
Press to END

16
Receiving a landline call on your Android
1. The landline extension phone(s) may ring first. All paired Androids will ring by the second ring.
2. The incoming call on the landline will create an alert on paired Androids. One of three screens will
appear. Slide or press to connect to the call.
3. If the Android has a security code turned on, then you will have to enter the code to answer the call.
Incoming caller
phone number
Press to
answer call

17
Make a Quick Connect “Intercom” call
1. Press the “#”sign on the OSC app and select the Android extension you wish to connect with (1-8),
then press Green Phone icon. The phone that you are calling will ring.
2. Press the Green Phone icon on the Android being called and the two parties will be connected.
3. To end the call, press The Red Phone icon.
#2, Press to
make call

18
Transferring or Adding a second Caller
1. While on an existing call, Press the ADD sign on the OneSmartConnect App.
2. This will bring up the Call Options window, select your option
3. This will bring up the Dialer. Press “#” and the extension (1-8) you wish to reach and press
CALL.
4. To create a conference call, press the conference Call Button.
5. After dialing the second caller, push the two heads icon will connect the callers.
Current Call
Transfer Call
Options
Select option
Hang UP
Conference call

19
First call is placed on
hold while caller is being
announce to third party
Joins all callers
In Conference
Disconnect from
conference

20
On Hold Notification
1. If you receive a cellular call during a landline call, you can choose to answer or reject the incoming call.
2. The landline call will hear a peep while on
3. After the cellular call is terminated, you will be given the choice to return to the landline call or
reject it. Tap the “on hold” to return to your OSC call
4. If you return to the call, the on hold party will hear a chime and you will be reconnected.
HOLD
