AirTurn BT500 User manual

BT500 Manual
Support for:
AirTurn DIGIT 500
AirTurn DUO 500

CONTENTS
Contents 2
Before Turning on Your AirTurn 4
BT500 Controls 5
Power 6
Connecting and Pairing 6
Open and Closed Pairing 6
Open Pairing 6
Closed Pairing 7
Reset Pairing 7
Switching Between Pairing Methods 8
Pairing in AirDIRECT MODE 1 8
Pairing in MODE 2-6 (Keyboard/Mouse) 9
Pairing in MODE 7 (MIDI) 9
MIDI Mode 10
MODES for BT500 11
2

Changing the MODE 12
Virtual Keyboard in iOS 12
Power Consumption 13
Recharging the Battery 13
LED Indications 13
AirTurn Manager 14
Unit Identification 14
Care of Your AirTurn 15
Warranty 15
Radio Information 16
Recycling and Disposal 18
Battery Information 18
Battery Disposal 19
Trademarks 19
3

Thank you for purchasing an AirTurn BT500
Bluetooth controller. We hope you enjoy many years of
use from it. From page turning, to effects management
and presentation control, the AirTurn provides a
myriad of uses.
BEFORE TURNING ON YOUR AirTurn
The BT500 works with most Bluetooth 4 and 5 devices. This
includes iPad 3 and later, iPhone 4S and later, and most devices
running Android 4.3 or later with Bluetooth 4 or 5.
Most PCs and Macs equipped with Bluetooth 4.x or 5 and HID
(keyboard) support are compatible. For older PCs you can use
Bluetooth 4.1 or 5 USB dongles that can connect to the AirTurn.
A compatible app is required. Apps are listed on the AirTurn
website: https://AirTurn.com/apps
There are three compatibility modes: AirTurn Direct, HID,
(keyboard), and MIDI. Not all compatible apps will function in
every mode. See the MODES section for additional information.
4

BT500 CONTROLS
The BT500 series uses the same transceiver for each model. The
controls consist of a power button, a membrane pad with 5
buttons, a dedicated Mode button, two stereo ports for use with
up to four pedals, two LED indicators, and a USB-C port for
charging. The function of each button is explained on page 12.
5

POWER
ON - Press and hold the Power Button for one second and the
LEDs flash.
The blue LED will begin to blink 2 times per second until pairing
is started.
OFF - Press and hold the Power Button until the red and blue
LEDs turn off.
CONNECTING AND PAIRING
Once the AirTurn is selected for pairing, the blue LED will
blink 5 times per second until pairing is completed.
OPEN AND CLOSED PAIRING
AirTurn devices have the ability to pair to your tablet or
computer two different ways. We call them Open and Closed
pairing. Open pairing is the default method.
OPEN PAIRING
AirTurn devices pair in the same way that almost all Bluetooth
devices pair. In Open Pairing you do not need to delete the
pairing to connect to another device so you can easily connect
your AirTurn to your iPad, smartphone or computer. In fact, you
6

can connect up to 8 Bluetooth devices. (In MODE 1 (AirDirect)
you can connect to an unlimited number of devices).
Bear in mind you can only be connected to one device at a
time. If two of your devices have Bluetooth turned on, you
must turn off the Bluetooth of the one you do not wish to
connect to while you connect to the other device. No reset is
required with Open Pairing.
If you connect to more than 8 devices, the next pairing will
delete the pairing that you haven’t used recently. If you delete or
“forget” the pairing of the AirTurn on a device, restart the
Bluetooth and attempt to re-pair with the AirTurn – It may
require two attempts to connect.
CLOSED PAIRING
This method locks one AirTurn to one tablet, phone or computer.
Use this method if you only intend to be connected to one
tablet, phone or computer. Also, use this method if you are in
an ensemble with other players using AirTurn devices. It will
ensure that you don’t inadvertently connect to each other’s
devices. Pairing is required in all MODES.
RESET PAIRING
To delete all pairings, or if you would like to connect to another
device, or you are having connection problems, you can pair
again by removing all the existing pairing connections.
7

First, delete the pairing from the host device and turn off the
Bluetooth. Then, hold the power button on the AirTurn for 6
seconds. The LEDs will turn off, but don’t release until they
blink 3 more times. You are now ready to pair again.
SWITCHING BETWEEN PAIRING METHODS
You can easily switch between Open and Closed pairing
methods. With your AirTurn powered off, hold down the MODE
button and hold the power button to turn on as usual. Both LEDs
will flash to confirm – twice for open pairing, three times for
closed pairing. You can also change the Pairing method using the
AirTurn Manager App, in Advanced settings.
PAIRING IN AIRDIRECT MODE 1
Note: This MODE is for AirDirect specific apps only. AirDirect
MODE was created to prevent conflicts with the virtual
keyboard.
1. Power on the AirTurn
2. Be sure the AirTurn is in MODE 1 (Hold down the MODE
button for 1 blink of the red light)
3. Turn on your device’s Bluetooth then
a. On iOS, go to the app you want to use and find the
Bluetooth setup screen
b. On Android, go to the AirTurn manager App
4. Find the AirTurn in the device list and tap on it
5. If required, tap on the Pair button in the dialog box
8

PAIRING IN MODE 2-6 (KEYBOARD/MOUSE)
iOS – Select Settings > Bluetooth and turn on Bluetooth if it is
off. When the AirTurn is discovered, tap on the selection. A
dialog box will then appear. Tap on Pair.
Android – Select Settings > Bluetooth, and turn it on if it is off.
Make sure your device is set to discoverable, tap the SCAN
button. When the AirTurn appears, tap to pair. If asked to verify a
passcode, click OK.
PC – Select Control Panel > My Bluetooth Devices > Select
“Add a device” > Click next and complete pairing.
Mac – Select Apple > System Preferences > Bluetooth and turn
on Bluetooth.
PAIRING IN MODE 7 (MIDI)
With all devices, ensure Bluetooth is turned on and switch your
AirTurn to Mode 7.
iOS –Go to the MIDI App you wish to use and find the
Bluetooth MIDI connection settings. Select your AirTurn in the
list. If requested, tap Pair.
Android –Select Settings > Bluetooth. Tap the SCAN button.
When the AirTurn appears, tap to pair. If you are asked to verify
the passcode, click on OK.
PC – Select Control Panel > My Bluetooth Devices > Select
“Add a device” > Click next and complete pairing. (Middleware
may be required)
9

Mac – Select File > New Finder Window > Applications >
Utilities > Audio MIDI Setup > Select “Bluetooth” > Next to the
AirTurn click “Connect”
MIDI MODE
MIDI Mode is for sending basic MIDI commands to your app.
Support for Bluetooth MIDI is required, and special setup for
your tablet or computer may be required. MIDI commands may
be setup using the AirTurn Manager. More detailed instructions
available online (AirTurn.com/support/midi) or reach out to
our support team at [e-mail] for further assistance.
10

MODES FOR BT500
There are seven modes available on your AirTurn. Each mode
sends a different signal for each pedal. The AirTurn is set to
MODE 2 by default. You can also customize MODES 2-6 with
the AirTurn Manager App. (See page 12 for instructions on mode
changes)
Switch 1
Switch 2
Switch 3
Switch 4
Switch 5
Mode 1
AirDirect
Mode 2
Up Arrow
Left Arrow
Down
Arrow
Right
Arrow
Enter
Mode 3
Page Up
Left Arrow
Page Down
Right
Arrow
Enter
Mode 4
Volume Up
Previous
Track
Volume
Down
Next Track
Play/Pause
Mode 5
Space
Left Click
Enter
Right Click
Home
Mode 6
3
p
m
Shift +R
Space
Mode 7
Damper
Portamento
Sostenuto
Soft Pedal
Legato
11

CHANGING THE MODE
1. Turn on the AirTurn.
2. Press and hold the MODE button. The red LED will
flash once per second from 1 to 7 flashes. The
number of flashes corresponds to the MODE
number. Be sure to count the flashes.
3. Release the MODE button following the number of
flashes that reflects the desired MODE. The blue and
red LED will flash together the number of times
indicating which MODE has been set.
Example: To set MODE 2, hold the MODE button for 2
flashes of the red LED, release, and both LEDs will flash 2
times to confirm the MODE 2 setting.
Note: Once the MODE has been set, it will remain the same
until it is changed following the above steps.
VIRTUAL KEYBOARD IN iOS
To turn on the virtual keyboard in iOS, put the cursor into a text
box and press the Power Button. Both LEDs will flash once to
signify that the button was pressed. The button will only work in
Modes 2-6. Virtual keyboard support for MODE 1 is automatic.
This is not available for Android except when using MODE 1.
12

POWER CONSUMPTION
The AirTurn uses an idle timeout function to conserve power.
After two hours of inactivity when powered on and connected,
the AirTurn will power down automatically. The timer is reset
when any button is pressed. You can change this time out period
or turn it off completely using the AirTurn Manager software.
The AirTurn averages a usage of 1160 μA when powered on and
5 μA when off.
RECHARGING THE BATTERY AND BATTERY SAFETY
To charge the battery, insert the charging cable into the
port and plug the other end into any USB source. The Red
LED will slowly blink to indicate charging, and turn solid
when complete. A charge will last for about 250 hours.
The BT500 series includes several battery safety features to help
maintain battery life and health. The battery will stop providing
power if it is too low, and stop charging when full. Charging is
disabled when the unit is above 45°C, or below 0°C (113°f and
32°f). Charging resumes when the unit is back within operating
range.
13

LED INDICATIONS
LED indication
State
3 red flashes when attempting to power on
Battery is too low to operate
Red flash every 3 seconds
Battery is low
Red flash once a second
Charging
Solid red
Fully charged
Blue flashing rapidly (twice a second)
Ready to connect
Blue flashing very rapidly (5 times a
second)
Connecting
Blue flash every 3 seconds
Connected
Solid blue
Pedal pressed
Rapid red flash
Temperature too high/low
AIRTURN MANAGER
To change the configuration of your AirTurn and update its
firmware to the latest available, download the AirTurn Manager
App from the Apple App Store or Google Play Store. It is
available for iPad, iPhone, most Android devices and Mac
computers.
The App allows you to configure the key repeat rate, power
saving settings, select pairing method and configure the signals
for each of the pedals in each mode.
If any firmware updates are available, you will be notified after
the App has connected. After performing the update, the AirTurn
will install it and shut down. Remove the pairing from your
iOS/Android/PC/Mac device, power on the AirTurn, and
reconnect. It is recommended to check for updates quarterly.
14

UNIT IDENTIFICATION
The unit name in your Bluetooth host consists of several codes to
help with support and identifying your specific device. For
example:
BT500 v3.0.2 ABCD
V2.1.0 refers to the firmware number.
ABCD refers to the MAC address.
This is helpful if there are many AirTurn units in the same
location. Your MAC address will always be the same so you can
easily identify your unit. You will find your specific MAC
address labeled on the bottom of your AirTurn at the end of the
serial number.
RESET TO FACTORY DEFAULTS
To reset the AirTurn to factory defaults, hold the first two
switches while powering on the device. Both LEDs will flash 3
times and then the AirTurn will power off.
There is also a reset option through the AirTurn Manager.
15

CARE OF YOUR AIRTURN
Wipe down using a damp cloth with a mild detergent or
soap-based cleaner to remove dirt and stains from your AirTurn.
●Do not get the AirTurn wet or place it in direct sunlight for
extended periods of time.
●Do not open the unit, as there are no user serviceable parts.
●Do not put the AirTurn in the trash. Please recycle.
WARRANTY
AirTurn, Inc., (“AirTurn”), warrants to the first consumer purchaser that the AirTurn BT500,
(the “Product”), when shipped in its original container, will be free from defective
workmanship and materials, and agrees that it will, at its option, either repair the defect or
replace the defective Product or part thereof with a new or remanufactured equivalent at no
charge to the purchaser for parts or labor for one year from date of purchase.
This warranty does not apply to any appearance items of the Product nor to any Product the
exterior of which has been damaged or defaced, which has been subjected to misuse,
abnormal service or handling, or which has been altered or modified in design or
construction, nor does it apply to batteries that may be supplied.
In order to enforce the rights under this limited warranty, the purchaser should request a
RMA number via email or phone following the directions on the support page at
www.AirTurn.com/support. The purchaser shall return the product at their expense. The
repaired or replaced product will be returned at the expense of AirTurn.
The limited warranty described herein is in addition to whatever implied warranties may be
granted to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE ARE LIMITED TO
ONE YEAR FROM THE DATE OF THE PURCHASE. Some states do not allow limitations
on how long an implied warranty lasts, so the above limitation may not apply to you.
The warranties described herein shall be the sole and exclusive warranties granted by
AirTurn and shall be the sole and exclusive remedy available to the purchaser. Correction of
16

defects, in the manner and for the period of time described herein, shall constitute complete
fulfillment of all liabilities and responsibilities of AirTurn to the purchaser with respect to the
Product and shall constitute full satisfaction of all claims, whether based on contract,
negligence, strict liability or otherwise. In no event shall AirTurn be liable, or in any way
responsible, for any damages or defects in the Product which were caused by repairs or
attempted repairs performed by anyone other than an authorized servicer, nor shall AirTurn
be liable or in any way responsible for any incidental or consequential economic or property
damage. Some states do not allow the exclusion of incidental or consequential damages, so
the above exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE
OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
RADIO INFORMATION
●Bluetooth 5.0 low energy radio
●Transmit power: -1 dBm peak
●TX peak current: 18.2 mA
●Frequency 2.36GHz to 2.50GHz
Approximate Range: 200 feet (61 Meters) subject to orientation and other factors.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
CAUTION: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy, and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
17

reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
--Consult the dealer or an experienced radio/TV technician for help.
Contains FCC ID: 2AA9B04
Contains transmitter module IC: 12208A-04
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
KCC (Korea) BMD-300 has type certification in Korea with certification number
R-CRM-Rgd-BMD-300
Contains ANATEL approved module # 00820-21-05903
Este equipo contiene el módulo con IFT #: NYCE/CT/0146/17/TS
AirTurn also holds unintended emissions testing on file for FCC/CE
RECYCLING AND DISPOSAL
Electronic components and construction comply
with RoHS and REACH standards.
Packaging is recyclable. Please recycle.
18

Contains Lithium Ion Battery. Battery should be
disposed of according to local law. AirTurn will
recycle returned batteries and electronics. Please
request an RMA from the support desk:
[e-mail]
BATTERY INFORMATION
Contains Lithium-Polymer Battery. Charging with a standard 5V
USB charger with the provided adaptor cable is recommended.
Charging from a laptop or a computer with a sleep setting is not
recommended.
A charge will last for about 250 hours, generally a battery should
last 2-5 years.
Operating temperature of your AirTurn device should be between
-20C and +55C. Charging temperature should be between 0C and
+45C, The temperature sensor inside the case will stop the
charging if temperatures go outside that range.
BATTERY DISPOSAL
— Do not put lithium ion batteries in the trash.
— Recycling is always the best option.
19

— The battery should be disposed of according to local law.
AirTurn will recycle returned batteries and electronics. Please
request an RMA from the support desk: [email protected]
TRADEMARKS
iPhone, iPod, iOS, iPad are trademarks of Apple, Inc.
Android is a trademark of Google, Inc.
Powerpoint, Word are trademarks of Microsoft
AirTurn, BT500, and its respective logos are trademarks of
AirTurn
20
