Airwell AWSI-DED076-N11 User manual

DED 076/095
Indoor Units
Outdoor Units
AWSI-DED076-N11
AWAU-YED076-H13
AWSI-DED095-N11
AWAU-YED095-H13
REFRIGERANT
R410A
HEAT PUMP
SM DED 1-A.1 GB
FEB-2017
Version:1

LIST OF EFFECTIVE PAGES
SM DED 1-A.1 GB A
LIST OF EFFECTIVE PAGES
Note: Changes in the pages are indicated by a “Revision#” in the footer of each effected page
(when none indicates no changes in the relevant page). All pages in the following list represent
effected/ non effected pages divided by chapters.
Dates of issue for original and changed pages are:
Original ....... 01 ........ 15-FEB-2017
Total number of pages in this publication is 45 consisting of the following:
Page
No.
Revision
No. #
Page
No.
Revision
No. #
Page
No.
Revision
No. #
* Zero in this column indicates an original page.

TABLE ODEDONTENTS
SM DED 1-A.1 G P i
Table of Contents
1. INTRODUCTION............................................................................................................................. 1-1
2. PRODUCT DATA SHEET............................................................................................................... 2-1
3. RATING CONDITIONS ................................................................................................................... 3-1
4. OUTLINE DIMENSION ................................................................................................................... 4-1
5. PERFORMANCE DATA ................................................................................................................. 5-1
6. AIRFLOW CURVES........................................................................................................................ 6-1
7. SOUND LEVEL CHARACTERISTICS ........................................................................................... 7-1
8. ELECTRICAL DATA....................................................................................................................... 8-1
9. WIRING DIAGRAM......................................................................................................................... 9-1
10. REFRIGERATION DIAGRAMS...................................................................................................... 10-1
11. TUBING CONNECTIONS............................................................................................................... 11-1
12. CONTROL SYSTEM(TO BE FINISHED)........................................................................................ 12-1
13. TROUBLESHOOTING.................................................................................................................... 13-1
14. CHARACTERISTICS OF SENSOR................................................................................................ 14-1
15. EXPLODED VIEW & SPARE PART LIST...................................................................................... 15-1

INTRODUCTION
SM DED 1-A.1 GB 1-1
1. INTRODUCTION
1.1 General
DED series is a monosplit DCI inverter air conditioner. The indoor is high static
pressure ducted type which is very suitable for larger space air conditioning.
The outdoor is front discharge ourdoor designed for easy installation and saving
installation space. The outdoor has two DC inverter compressors and the operation
is for better efficiency of partial load and reliability.
The whole series includes two models DED076 (8HP) and DED095(10HP)
1.2 Main Features
The unit benefits from the most advanced technological innovations, namely:
DC inverter technology
R410A models
EEV for refrigerant control
High static up to 200Pa
Max allowing tubing distance of 120m.
Heating operation at outdoor temperature down to -20ºC.
Easy installation and service.
Integrated condensate water pump
Compatible for BMS

INTRODUCTION
1-2 SM DED 1-A.1 GB
1.3 Indoor Unit
The indoor unit is high static ducted type indoor, and can be easily fitted to many types
of commercial buildings. It includes:
Variable speeds DC fan
Integrated condesate water pump
High efficiency filtration to ensure a best Air Quality
1.4 Control
Wired control RCW17 as standard control including functions (ON/OFF, mode,
temperature, fan, swing, sleep mode,fresh air settings, turbo mode, error display)
RCW18 is optional wired control suitable for the case of dry contact on-off needed.
For detail of functions, please refer to wired control manual.
1.5 Outdoor Unit
The outdoor units are front discharge outdoor. The metal sheets are protected by anti-
corrosion paint work allowing long life resistance. All outdoor units are pre-charged. For
further information please refer to the Product Data Sheet, Chapter 2.
It includes :
Two DC Compressors mounted in a soundproofed compartment :
Two Axial fan operated by DC motor
Outdoor coil with hydrophilic louver fins for RC units.
Outlet air fan grill.
Interconnecting wiring terminal block.
1.6 Tubing Connections
Soldering type interconnecting tubing to be produced on site.
For further details please refer to the Installation Manual.
1.7 Inbox Documentation
Each unit is supplied with its own installation, operation and remote control manuals.

INTRODUCTION
SM DED 1-A.1 GB 1-3
1.8 Matching Table
OUTDOOR UNITS
INDOOR UNITS
AWSI-DED076-N11
AWSI-DED095-N11
AWAU-YED076-H13
V
AWAU-YED095-H13
V

PRODUCT DATA SHEET
SM DED 1-A.1 GB 2-1
2. PRODUCT DATA SHEET
2.1 AWSI-DED076-N11 / AWAU-YED076-H13
Model Indoor Unit
AWSI-DED076-N11
Model Outdoor Unit
AWAU-YED076-H13
Installation Method of Pipe
Soldering
Characteristics
Units
Cooling
Heating
Capacity (1)
kW
22.4
25.0
Power input
kW
6.7
6.54
SEER /SCOP (2)
W/W
3.34
3.82
Energy efficiency class
A
A
Power supply
V/Ph/Hz
380-415V/3N~/50Hz
Circuit breaker rating
A
20
INDOOR
Fan type & quantity
Centrifugal x 2
Fan speeds
H/M/L/VL
RPM
-
Air flow (3)
H/M/L/VL
m3/hr
4000
External static pressure
Min-Max
Pa
150(0-200)
Sound power level (4)
H/M/L
dB(A)
64
Sound pressure level(5)
H/M/L/VL
dB(A)
54
Moisture removal
l/hr
7.5
Condensate drain tube O.D / I.D
mm
OD30 (ID 28.5)
Dimensions
WxHxD
mm
1483x385x791
Weight
kg
82
Package dimensions
WxHxD
mm
1578x472x883
Packaged weight
kg
104
Stacking height
units
OUTDOOR
Refrigerant control
EEV
Compressor type, model
Rotary DC Inverter QXAS-D32zX050 x 2
Fan type & quantity
Axial x 2
Fan speeds
H/L
RPM
820
Air flow
H/L
m3/hr
9000
Sound power level(4)
H/L
dB(A)
70
Sound pressure level(5)
H/L
dB(A)
60
Dimensions
WxHxD
mm
1098x1584x399
Weight
kg
175
Package dimensions
WxHxD
mm
1183x1785x505
Packaged weight
kg
180
Stacking height
Units
1
Refrigerant type
R410A
Refrigerant charge (standard connecting tubing length)
kg(5m)
7.2
Additional charge per 1 meter
gr / 1m
20
Connections between units
Liquid line
In.(mm)
3/8”
Suction line
In.(mm)
7/8”
Max.tubing length
m.
120
Max.height difference
m.
13
Operation control type
Wired Remote control

PRODUCT DATA SHEET
2-2 SM DED 1-A.1 GB
2.2 AWSI-DED095-N11 / AWAU-YED095-H13
Model Indoor Unit
AWSI-DED095-N11
Model Outdoor Unit
AWAU-YED095-H13
Installation Method of Pipe
Soldering
Characteristics
Units
Cooling
Heating
Capacity (1)
kW
28.0
30.0
Power input
kW
8.3
8.15
SEER /SCOP (2)
W/W
3.37
3.68
Energy efficiency class
A
A
Power supply
V/Ph/Hz
380-415V/3N~/50Hz
Circuit breaker rating
A
20
INDOOR
Fan type & quantity
Centrifugal x 2
Fan speeds
H/M/L/VL
RPM
-
Air flow (3)
H/M/L/VL
m3/hr
4400
External static pressure
Min-Max
Pa
150(0-200)
Sound power level (4)
H/M/L
dB(A)
65
Sound pressure level(5)
H/M/L/VL
dB(A)
55
Moisture removal
l/hr
8.5
Condensate drain tube O.D / I.D
mm
OD30 (ID 28.5)
Dimensions
WxHxD
mm
1686x450x870
Weight
kg
105
Package dimensions
WxHxD
mm
1788x580x988
Packaged weight
kg
140
Stacking height
units
OUTDOOR
Refrigerant control
EEV
Compressor type, model
Rotary DC Inverter QXAS-F428zX050B x 2
Fan type & quantity
Axial x 2
Fan speeds
H/L
RPM
820
Air flow
H/L
m3/hr
9000
Sound power level(4)
H/L
dB(A)
71
Sound pressure level(5)
H/L
dB(A)
61
Dimensions
WxHxD
mm
1098x1584x399
Weight
kg
185
Package dimensions
WxHxD
mm
1183x1785x505
Packaged weight
kg
190
Stacking height
Units
1
Refrigerant type
R410A
Refrigerant charge (standard connecting tubing length)
kg
7.6 (50m)
Additional charge per 1 meter
gr / 1m
20
Connections between units
Liquid line
In.(mm)
3/8”
Suction line
In.(mm)
7/8”
Max.tubing length
m.
120
Max.height difference
m.
16
Operation control type
Wired Remote control

RATING CONDTIONS
SM DED 1-A.1 GB 3-1
3. RATING CONDITIONS
Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units).
Cooling:
Indoor: 27oC DB 19oC WB
Outdoor: 35oC DB
Heating:
Indoor: 20oC DB
Outdoor: 7oC DB 6oC WB
3.1 Operating Limits
R410A
Indoor
Outdoor
Cooling
Upper limit
32oC DB 23oC WB
48oC DB
Lower limit
17oC DB 12oC WB
10oC DB
Heating
Upper limit
30oC DB
27oC DB 24oC WB
Lower limit
0oC DB
-20oC DB -21oC WB
Voltage
3-PH 50Hz 380 –415 V

OUTLINE DIMENSION
SM DED 1-A.1 GB 4-1
4. OUTLINE DIMENSION
4.1 Indoor: DED076 / 095
Model
A
B
C
D
E
F
DED076
1353
632
992
1150
192
327
DED095
1563
706
992
1350
192
402

OUTLINE DIMENSION
4-2 SM DED 1-A.1 GB
4.2 Outdoor: YED076/YED095

PERFORMANCE DATA
SM DED 1-A.1 GB 5-1
5. PERFORMANCE DATA
5.1 Model: AWSI-DED076-N11 / AWAU-YED076-H11
1) Cooling running Capacity
Outdoor
temperature
(℃DB)
Indoor temperature (℃WB/℃DB)
14℃WB
16℃WB
19℃WB
22℃WB
24℃WB
20℃DB
23℃DB
27℃DB
30℃DB
32℃DB
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
10
15.2
11.6
16.4
12.8
22.4
16.8
27.6
17.9
30.0
19.5
12
15.2
11.6
16.4
12.8
22.4
16.8
27.6
17.9
30.0
19.5
14
15.2
11.6
16.4
12.8
22.4
16.8
27.6
17.9
30.0
19.5
16
15.2
11.6
16.4
12.8
22.4
16.8
27.6
17.9
30.0
19.5
18
15.2
11.6
16.4
12.8
22.4
16.8
27.6
17.9
30.0
19.5
20
15.2
11.6
16.4
12.8
22.4
16.8
27.6
17.9
29.8
19.7
21
15.2
11.6
16.4
12.8
22.4
16.8
27.6
17.9
29.1
19.2
23
15.2
11.6
16.4
12.8
22.4
16.8
27.6
17.9
28.7
18.9
25
15.2
11.6
16.4
12.8
22.4
16.8
27.1
18.2
28.2
18.9
27
15.2
11.6
16.4
12.8
22.4
16.8
26.6
18.1
28.0
18.8
29
15.2
11.6
16.4
12.8
22.4
16.8
26.2
18.1
27.6
18.7
31
15.2
11.6
16.4
12.8
22.4
16.8
26.0
18.2
27.1
18.4
33
15.2
11.6
16.4
12.8
22.4
16.8
25.8
18.0
26.7
18.1
35
15.2
11.6
16.4
12.8
22.4
16.8
25.5
18.1
26.4
18.2
37
15.2
11.6
16.4
12.8
22.4
16.8
25.1
18.1
26
17.9
39
15.2
11.6
16.4
12.8
22.4
16.8
24.6
18
25.5
16.9
40
15.2
11.6
16.4
12.8
22.4
16.8
24.4
17.8
25.1
17.6
43
15.2
11.6
16.4
12.8
22.4
16.8
24.2
17.7
24.6
17.2
2) Heating running Capacity
Outdoor
temperature
Indoor temperature℃DB
16.0
18.0
20.0
21.0
22.0
24.0
26.0
TC
TC
TC
TC
TC
TC
TC
℃DB
℃WB
kW
kW
kW
kW
kW
kW
kW
-19.7
-20
14.0
14.0
14.0
14.0
14.0
14.0
13.8
-14.7
-15.0
16.0
16.0
16.0
16.0
16.0
16.0
15.6
-12.6
-13.0
17.0
17.0
17.0
17.0
17.0
17.0
16.4
-10.5
-11.0
18.0
18.0
18.0
18.0
18.0
18.0
17.6
-9.5
-10.0
18.0
18.0
18.0
18.0
18.0
18.0
17.6
-8.5
-9.1
19.0
19.0
19.0
19.0
19.0
19.0
18.4
-7.0
-7.6
19.0
19.0
19.0
19.0
19.0
19.0
18.4
-5.0
-5.6
20.0
20.0
20.0
20.0
20.0
20.0
20.0
-3.0
-3.7
21.0
21.0
21.0
21.0
21.0
21.0
20.0
0.0
-0.7
22.0
22.0
22.0
22.0
22.0
21.0
20.0
3.0
2.2
24.0
24.0
24.0
24.0
23.1
21.0
20.0
5.0
4.1
24.0
24.0
24.0
24.0
23.1
21.0
20.0
7.0
6.0
25.0
25.0
25.0
24.0
23.1
21.0
20.0
9.0
7.9
26.0
26.0
25.0
24.0
23.1
21.0
20.0
11.0
9.8
27.0
27.0
25.0
24.0
23.1
21.0
20.0
13.0
11.8
28.1
27.0
25.0
24.0
23.1
21.0
20.0
15.0
13.7
28.9
27.0
25.0
24.0
23.1
21.0
20.0

PERFORMANE DATA
5-2 SM DED 1-A.1 GB
5.2 Model: AWSI-DED096-N11 / AWAU-YED096-H11
1) Cooling running Capacity
Outdoor
temperatur
e (℃DB)
Indoor temperature (℃WB/℃DB)
14℃WB
16℃WB
19℃WB
22℃WB
24℃WB
20℃DB
23℃DB
27℃DB
30℃DB
32℃DB
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
10
19
14.5
20.4
15.9
28
21
34.4
22.4
37.5
24.4
12
19
14.5
20.4
15.9
28
21
34.4
22.4
37.5
24.4
14
19
14.5
20.4
15.9
28
21
34.4
22.4
37.5
24.4
16
19
14.5
20.4
15.9
28
21
34.4
22.4
37.5
24.4
18
19
14.5
20.4
15.9
28
21
34.4
22.4
37.5
24.4
20
19
14.5
20.4
15.9
28
21
34.4
22.4
37.2
24.6
21
19
14.5
20.4
15.9
28
21
34.4
22.4
36.4
24
23
19
14.5
20.4
15.9
28
21
34.4
22.4
35.8
23.7
25
19
14.5
20.4
15.9
28
21
33.9
22.7
35.3
23.6
27
19
14.5
20.4
15.9
28
21
33.3
22.6
35
23.5
29
19
14.5
20.4
15.9
28
21
32.8
22.6
34.4
23.4
31
19
14.5
20.4
15.9
28
21
32.5
22.7
33.9
23
33
19
14.5
20.4
15.9
28
21
32.2
22.5
33.3
22.7
35
19
14.5
20.4
15.9
28
21
31.9
22.7
33
22.8
37
19
14.5
20.4
15.9
28
21
31.4
22.6
32.5
22.4
39
19
14.5
20.4
15.9
28
21
30.8
22.5
31.9
21.1
40
19
14.5
20.4
15.9
28
21
30.5
22.3
31.4
22
43
19
14.5
20.4
15.9
28
21
30.2
22.1
30.8
21.6
2) Heating running Capacity
Outdoor
temperature
Indoor temperature℃DB
16.0
18.0
20.0
21.0
22.0
24.0
26.0
TC
TC
TC
TC
TC
TC
TC
℃DB
℃WB
kW
kW
kW
kW
kW
kW
kW
-19.7
-20
17.4
17.4
17.4
17.4
17.4
17.4
17.1
-14.7
-15
19.8
19.8
19.8
19.8
19.8
19.8
19.3
-12.6
-13
21.1
21.1
21.1
21.1
21.1
21.1
20.3
-10.5
-11
22.3
22.3
22.3
22.3
22.3
22.3
21.8
-9.5
-10
22.3
22.3
22.3
22.3
22.3
22.3
21.8
-8.5
-9.1
23.6
23.6
23.6
23.6
23.6
23.6
22.8
-7
-7.6
23.6
23.6
23.6
23.6
23.6
23.6
22.8
-5
-5.6
24.8
24.8
24.8
24.8
24.8
24.8
24.8
-3.0
-3.7
26
26
26
26
26
26.1
24.8
0
-0.7
27.3
27.3
27.3
27.3
27.3
26.1
24.8
3
2.2
29.8
29.8
29.8
29.8
28.6
26.1
24.8
5
4.1
29.8
29.8
29.8
29.8
28.6
26.1
24.8
7
6
31
31
31
29.8
28.6
26.1
24.8
9
7.9
32.2
32.2
31
29.8
28.6
26.1
24.8
11
9.8
33.5
33.5
31
29.8
28.6
26.1
24.8
13
11.8
34.8
33.5
31
29.8
28.6
26.1
24.8
15
13.7
35.8
33.5
31
29.8
28.6
26.1
24.8

AIRFLOW CURVES
SM DED 1-A.1 GB 6-1
6. AIRFLOW CURVES
6.1 Model: AWSI-DED076-N11
6.2 Model: AWSI-DED095-N11

SOUND LEVEL CHARACTERISTICS
SM DED 1-A.1 GB 7-1
7. SOUND LEVEL CHARACTERISTICS
7.1 Sound Pressure Level
Notes:
1. The noise level is measured in the semi-anechoic room. It will be slightly higher due to
change of the environment during actual operation.
2. The noise level is measured under the standard test condition.
3. The noise level is measured under the condition of rear air return.

SOUND LEVEL CHARACTERISTICS
7-2
7.2 Soud Pressure Level Spectrum (Measured as Figure 1)
Model: AWSI-DED076-N11
Model: AWSI-DED095-N11

ELECTRICAL DATA
SM DED 1-A.1 GB 8-1
8. ELECTRICAL DATA
MODEL
AWSI-DED076-N11
AWAU-YED076-H13
AWSI-DED095-N11
AWAU-YED095-H13
Power Supply
Indoor & Outdoor
Indoor: 1PH-220-240V-50Hz
Outdoor: 3PH-380-415V-50Hz
Max Power (Indoor)
900W
900W
Max power (Outdoor)
8400W
12100W
Circuit Breaker,A (indoor / Outdoor)
6A
20A
6A
20A
Power Supply (Indoor) Wiring No. X Cross
Section mm2
3x1.5 mm2
3x1.5 mm2
Power Supply (Outdoor) Wiring No. X Cross
Section mm2
5x2.5 mm2
5x2.5 mm2
Interconnecting Cable Model No. X Cross
Section mm2
2x0.75 mm2
2x0.75 mm2
NOTE
Power wiring cord should comply with local laws and electrical regulations requirements.

WIRING DIAGRAMS
SM DED 1-A.1 GB 9-1
9. WIRING DIAGRAM
Abbrivation
Symbol
Symbol Color
Symbol
Symbol Color
Symbol
Name
WH
White
GN
Green
CAP
Jumper cap
YE
Yellow
BN
Brown
COMP
Compressor
RD
Red
BU
Blue
Grounding wire
YEGN
Yellow/Green
BK
Black
/
/
VT
Violet
OG
Orange
/
/
9.1 Indoor AWSI-DED076-N11, AWSI-DED095-N11

WIRING DIAGRAM
9-2 SM DED 1-A.1 GB
9.2 Outdoor AWAU-YED076-H13, AWAU-YED095-H13
L RT1 RT4 RT5 Defrosting temperature sensor RT6 RT7 RT8 RT9 RT10 EH1 SP1/SP2 EH2 HP
Oil extractor electrical heat tape
XT1-2 AP1 AP2 AP3 AP4 COMP M YV1 YV2 YV4 YV3 EKV1 EKV2
Wiring board Main board Filter board INV compressor driver board Fan driver board INV compressor Fan 4-Way valve Oil equalizing valve 1 Air by-pass valve Oil equalizing valve 2 EEV for heating Subcooler EEV valve
Electric Reactor Exhoust pipe temperture sensor of INV compressor Liquid-gas seperator inlet temperature sensor Liquid-gas separator outlet temperature sensor Subcooling air temperature sensor Subcooling liquid temperature sensor Environment tempearture sensor Compressor casing-top temperature sensor of inverter compressor Electrical heat tape of INV compressor Low-pressure sensor / High pressure sensor High-pressure circuit breaker of inverter compressor

REFRIGERATION DIAGRAMS
SM DED 1-A.1 GB 10-1
10. REFRIGERATION DIAGRAMS
