AJA’s HA5-12G allows users to convert an HDMI 2.0 input to two 12G-SDI single
link outputs. It includes two SDI DA outputs and transmits 12G-SDI on each SDI
link, reducing cable runs when transporting 4K/UltraHD SDI. HA5-12G supports
up to 8-Channels of audio from the HDMI source or 2-Channel analog audio
(RCA), with eight or two channels of digital embedded audio on 12G-SDI.
A Fiber SFP equipped HA5-12G-T single channel trasmitter model is available,
which extends HDMI source 4K signals over long distances (10 km Single Mode).
The fiber output is in addition to the two coax outputs, for a total of three 12G-SDI
outputs.
Default Operation
The HA5-12G auto configures to the connected HDMI input (no dipswitch settings
required). The auto-configure function identifies the connected input and
outputs the equivalent SDI format.
AJA Mini-Config Control
AJA’s Mini-Config application is available for firmware updates and advanced
configuration. Configuration set via Mini-Config is stored in the HA5-12G unit
through subsequent power cycles.

HA5-12G Mini-Converter v1.1r1 5 www.aja.com
Features
• Converts HDMI 2.0 to 12G-SDI, up to 4K 60p (see "Appendix A – Specications"
on page 19 for a complete list of supported inputs).
• Supports up to 60p input at 4:4:4/4:2:2/4:2:0
• Supports 2SI (two sample interleave) 4K/UltraHD SDI mapping
• Two 12G-SDI coax outputs
• Embedded audio can be selected from the HDMI or Analog audio inputs
• Fiber SFP model, HA5-12G-T, includes a 12G-SDI single mode ber output
• Congure via USB port and supplied Mini-Cong software
• Uses 5-16VDC power. The included DWP-U-R1 universal power supply is 5VDC.
• Five year warranty
Block Diagram
Figure 1. HA5-12G/HA5-12G-T Converter, Simplified Block Diagram
12G
SDI Out 1
12G
SDI Out 2
SDI
XMIT
Sample
Rate
Converter
12G Fiber Out
(HA5-12G-T)
Video
Audio
Audio
HDMI v2.0
Input with
Embedded
Audio
USB Bus
(connect to
PC or Mac)
Control
HDMI v2.0
RCVR
Video
Processing
Audio
Disembed
SDI
XMIT
SDI
XMIT
Video
A/D
Converter
Analog
Audio In 2
(RCA)
Analog
Audio In 1
(RCA)
Embed
Audio

HA5-12G Mini-Converter v1.1r1 6 www.aja.com
I/O Connections
Figure 2. HA5-12G/HA5-12G-T Converter Connections
HDMI
Input
Connector
USB
Port
DC Power
Input
SDI
Ouput 1
Fiber Output
(HA5-12G-T
model only)
Analog Audio
Inputs
(2 RCA)
Power LED
Lock LED
SDI
Ouput 2
NOTE: The LOCK LED adjacent to the HDMI input connector indicates by color whether
the HDMI input circuit is locked, and if so, the SDI output data rate. Off is no
signal, Green is SD-SDI, Red is HD-SDI, Amber is 3G-SDI, Purple is 6G-SDI, and Blue
is 12G-SDI.
Installation
Typically, HA5-12G installation consists of the following steps:
1. Ensure the HA5-12G is disconnected from power.
2. Connect video equipment to the converter BNCs and HDMI connector.
3. Apply power to the converter (AJA power supply included).
4. The HA5-12G will now run using the default factory settings. If you wish to
alter the factory settings, you’ll need to:
• Install the AJA Mini-Cong software on your computer
• Attach the HA5-12G via USB
• Make your changes using AJA Mini-Cong setup screens.
This process is detailed in "USB Control and Setup—Using AJA Mini-Config" on page
7.
NOTE: The HA5-12G packs an unprecedented feature set into a mini converter box.
As a result, the unit uses approximately 12 watts of power. It will be very warm
to the touch, which is normal. The unit is engineered to operate across the full
temperature range, from 0 to 40 degrees C.
NOTE: For highest reliability, the mini converter relies on convection cooling instead
of using a built-in fan. Therefore, when installing the unit, mount in a location
where it has access to air for proper cooling. Do not stack the HA5-12G with other
mini converters.
