AJA HI5-PLUS-R0 Operating instructions

®
Installation and Operation Guide
Version 1.0
Published: March 31, 2014
Mini-Converter
Hi5-Plus

Hi5-Plus v1.0 www.aja.com
2
Table of Contents
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Contacting Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
I/O Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
User Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
MiniConfig Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Chapter 2: Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
USB Control and Setup—Using AJA MiniConfig . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing MiniConfig on a Mac. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing MiniConfig on a PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Running MiniConfig. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
PC Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Mac Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Saving Setups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operating MiniConfig . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Tabbed Screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Input Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Input Video Selections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Output Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Output Video Selections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Audio Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Audio Selections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Update Tab Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Software Update Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Info Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Appendix A: Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Physical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Appendix B: Safety and Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Federal Communications Commission (FCC) Compliance Notices . . . . . . . . . . . . . . . . . . 16
Class B Interference Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
FCC Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Canadian ICES Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
European Union and European Free Trade Association (EFTA)
Regulatory Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Korea KCC Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Taiwan Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Japanese Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Hi5-Plus v1.0 www.aja.com
3
Translated Warning and Caution Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Before Operation Please Read These Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Hi5-Plus v1.0 www.aja.com
4
Notices
Trademarks
AJA®, KONA®, Ki Pro®, KUMO® and XENA® are registered trademarks of AJA Video, Inc.,
TruZoom™, TruScale™, Ki Pro Mini™, Io Express™, Io HD™, Io™ and “Work. Flow.” are
trademarks of AJA Video, Inc. AirPort, Apple, the Apple logo, AppleShare, AppleTalk,
FireWire, iPod, iPod Touch, Mac, and Macintosh are registered trademarks of Apple
Computer, Inc. Final Cut Pro, QuickTime and the QuickTime Logo are trademarks of Apple
Computer, Inc. Avid, Avid Media Composer and Avid DNxHD are trademarks of Avid
Technology, Inc. All other trademarks are the property of their respective holders.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC. DVI is a registered trademark of DDWG. All
other trademarks are the property of their respective holders.
Copyright
Copyright © 2014 AJA Video, Inc. All rights reserved. All information in this manual is
subject to change without notice. No part of the document may be reproduced or
transmitted in any form, or by any means, electronic or mechanical, including
photocopying or recording, without the express written permission of AJA Inc.
Contacting Support
When calling for support, have all information at hand prior to calling.
To contact AJA Video for sales or support, use any of the following methods:
Telephone: [phone]
FAX: [phone]
Web: http://www.aja.com
Support Email: [email protected]
Sales Email: [email protected]

Hi5-Plus v1.0 www.aja.com
5
Chapter 1: Introduction
Overview
The Hi5-Plus converts 3G/HD/SD-SDI to HDMI for driving HDMI monitors. Embedded SDI
audio is supported in the HDMI output allowing a convenient single cable audio/video
connection. The Hi5-Plus provides 2 RCA style audio outputs for separate audio
monitoring if needed.
Features • 3G/HD/SD-SDI to HDMI (see "Appendix A: Specifications on page 15" for a complete list of
supported inputs).
• Full HDMI support including 10-bit video and 8 channels of embedded audio
• Additional 2 Channel RCA jack audio output (selectable channel pairs)
• HDMI cable supplied
• Uses universal input +5V power supply AJA model DWP-U-R1 (included)
• No configuration necessary
Block Diagram Figure 1. Hi5-Plus Converter, Simplified Block Diagram
3G/HD/SD-SDI
Input
Audio
D/A
Audio
Delay
SDI
Equalizer
psf to p
Conversion
Video
Audio
HDMI
Transmitter
2-Channel
Analog Audio
Monitor Output
HDMI Output
with Embedded
Audio
USB Port
(connect to
PC or Mac)
MiniCong Control
SDI
Processing

Hi5-Plus v1.0 www.aja.com
6
I/O Connections Figure 2. Hi5-Plus Converter Connections
User Controls
MiniConfig Control Auto controls configures the unit automatically to match the input and output video
parameters. Advanced MiniConfig control supports color space and bit depth
adjustments, and audio channel selection.
Configuration set via MiniConfig is stored in the Hi5-Plus unit through subsequent power
cycles.
Installation
Typically, Hi5-Plus installation consists of the following steps:
1. Ensure the Hi5-Plus is disconnected from power.
2. Connect video equipment to the converter BNC and HDMI connector.
3. Connect audio equipment to RCA connectors (optional)
4. Apply power to the converter (AJA power supply included).
5. The converter will now run using the default factory settings. If you wish to alter the
factory settings, you’ll need to:
• Install the AJA MiniConfig software (supplied on CD) on your computer
• Attach the converter via USB
• Make your changes using MiniConfig setup screens.
• This process is detailed in "USB Control and Setup—Using AJA MiniConfig".
USB
Port
3G/HD/SD-SDI
Input BNC
Signal
Presence
Lock LED 2 Channel
Unbalanced
Analog Audio
Out (RCA Jacks)
DC
Power
Input
Power
LED
HDMI
Output
Connector

Hi5-Plus v1.0 www.aja.com
7
Chapter 2: Operation
USB Control and Setup—Using AJA MiniConfig
The Hi5-Plus can usually be used right out of the box for most applications since it is
designed to recognize inputs and perform standard actions automatically by default.
However you can also manually configure the Hi5-Plus using a supplied software
application for PCs and Macs called “MiniConfig.” This same application can be used to
update Mini-Converter firmware released by AJA.
Installing
MiniConfig on a Mac
To install the application on a Mac, insert the CD supplied with the
Mini-Converter into the computer, drag the “AJA MiniConfig”
application for your platform (Mac or PC) to your desktop or an
applications folder.
NOTE: Macintosh computers must be Intel-based (G5, G4 and earlier models will not work with
MiniConfig).
Installing
MiniConfig on a PC
To install the application on a Windows PC, insert the CD supplied with the Mini-
Converter into the computer, locate the “MiniInstaller” application, and then double-
click it.
Figure 3. MiniConfig Setup Wizard on PC
A Setup Wizard will guide you through the installation. Just click Next to begin.
Answer all questions in the subsequent dialogues; when done, you will be able to locate
the MiniConfig application in the AJA folder in the Programs listing.
Running MiniConfig Connect the Mini-Converter to the PC or Mac via the supplied USB cable. Connect the
external power supply (supplied) to the Mini-Converter.

Hi5-Plus v1.0 www.aja.com
8
PC Startup To run MiniConfig on a PC, find the AJA MiniConfig in the program list and locate the AJA
MiniConfig application.
Figure 4. PC MiniConfig Startup
Mac Startup To run MiniConfig on a Mac, double-click the Applications folder and locate the AJA
MiniConfig application. Double-click the application to launch it.
Figure 5. Mac MiniConfig Startup
NOTE: On a Mac, when the Mini-Converter is connected to the USB port, you may see an alert like
that shown below. If you do, press Cancel—this alert can be ignored.
Figure 6. Mac Network Message (ignore)
Saving Setups A File menu at the top of the MiniConfig application menu bar allows you to Save the
state of the Mini-Converter, with your current settings, to a file for later recall. This allows
you to set up the converter for different applications, storing each (with Save) to a unique
name for easy recall—using the Open menu item. A Revert to Factory Settings menu item
similarly allows you to change the settings back to AJA’s factory defaults. An Edit menu
allows you to cut and paste values to/from fields, just as in other applications.
Operating
MiniConfig
The MiniConfig application provides a graphic interface for viewing settings and
updating software. It consists of an information area at the top that shows the available
Mini-Converters attached to the computer via USB, with a graphical rendering of the
selected Mini-Converter showing all the connectors and their current state.
Colored text next to the connectors indicates the signal type and what the Mini-
Converter is doing:
•Blue text indicates the values automatically selected

Hi5-Plus v1.0 www.aja.com
9
•Black text indicates values that you have manually selected
•Red text indicates the Mini-Converter is not detecting a signal or cannot negotiate with
the attached device
NOTE: Even if no output device is detected, it still shows the signal it is outputting.
NOTE: Configuration settings in red will change based on the attached output device as well as input
signals. For improved accuracy and reliability, you should configure the Mini-Converter only
when the target output device is attached and input signals are supplied at the inputs.
Screens are virtually the same on both PC and Mac, with subtle differences that reflect
the general look of the platform environment.
Running Multiple Mini-
Converters:
MiniConfig can manage multiple AJA Mini-Converters connected via USB—even when
they are of differing types. However it only connects to one at a time. You can choose
which Mini-Converter you wish to control using the pulldown menu in the upper right
hand corner. If you want to configure and update multiple Mini-Converters in parallel,
you can do it by running multiple instances of the MiniConfig application and have each
control a different Mini-Converter.
Figure 7. MiniConfig, Video Screen
Selecting a Mini-Converter with the dropdown menu causes this application to connect
to the selected converter. The graphic of Mini-Converter and text below it provides:
• Type of converter
• Firmware version
• Serial number of the unit
A status field at the bottom of the screen shows if your application is connected and
communicating with the Mini-Converter.
Tabbed
screens
Message
showing
status
Firmware
version
and serial
number
Each connector is labeled with
the signals currently detected: Select a USB
port and an
attached
Mini-Converter
(name in
parentheses)

Hi5-Plus v1.0 www.aja.com
10
When configuring the Mini-Converter, select it from the top pulldown, view the current
settings and change any values. Making a change communicates that new value to the
Mini-Converter’s non-volatile memory.
Tabbed Screens The Tabs delineate control screens with groups of controls for each type of task to be
performed. The controls for the actual configuration parameters are specific to each
Mini-Converter type. Click on any of the tab buttons and the screen below will change to
match. Each of these screens are described on the following pages.
Input Tab Screen With your Mini-Converter connected and selected, you’ll click on the Input tab to view
and make changes to the converter’s input settings.
Any changes you make are immediately implemented and are saved, overwriting
previous settings.
Figure 8. MiniConfig, Input Tab Screen
Input Video Selections
Color Space: Selects the Input Video Color Space. Choose Auto, 422 YCbCr, or 444 RGB, or 444 YCbCr.
Choosing “Auto” will automatically select color mode based on the input video
parameters and the payload ID.
RGB Range: Selects the Input Video Color Range. Choose SMPTE or Full color range.
Bit Depth: Selects the input video bit depth. Choose Auto, 8-bit, 10-bit, or 12-bit. Choosing “Auto”
automatically selects the bit depth based on the input video parameters and payload ID.
Video Format: Selects the Input Video Format. Choose from Auto, Progressive (P), Interlaced, or PsF
(progressive segmented frame). Choosing “Auto” automatically selects the format based
on the input video parameters and the payload ID.

Hi5-Plus v1.0 www.aja.com
11
3G-B Mode: Selects the 3G level B Video Mode. Choose from the following:
• Auto - automatically selects the format based on the input video parameters.
• Dual Link - select this when your 3G signal is carrying 444 information or 12 bit data.
NOTE: The following two settings only apply to 3G-B video in Dual Stream mode.
• 1 x HD DS1 - use only Data Stream 1 as a single video.
• 1 x HD DS2 - use only Data Stream 2 as a single video.
Output Tab Screen Click on the Output tab to view and make changes to the Hi5-Plus Output settings.
Figure 9. MiniConfig, Output Tab Screen
Output Video
Selections
Color Space: Selects the desired output video format. Choose from the following:
• Auto - selects the video format based on the input video and the attached device's
capabilities.
• 4:2:2 YCbCr
• 4:4:4 RGB
• 4:4:4 YCbCr
Bit Depth: Choose from Auto, 8-bit, 10-bit, or 12-bit. Choosing “Auto” automatically selects the bit
depth based on the input video and the attached device's capabilities.
RGB Range: Choose Auto, SMPTE or Full. Choosing “Auto” automatically selects the input color range
setting.

Hi5-Plus v1.0 www.aja.com
12
2K Crop: Choose Auto, Off, or On. Provides the option of center cutting 2Kx1080 video signals to
make 1920x1080. This function is only enabled in the hardware when the input bit depth
is less than the output bit depth.
Color Dithering: Choose Off or On.
HDMI/DVI: Choose Auto, HDMI, or DVI. When DVI is selected, any audio signals present are not
passed. Choosing “Auto” automatically selects the output mode based on the attached
device's capabilities.
Audio Tab Screen Click on the Audio tab to view and make changes to the Hi5-Plus audio settings.
Figure 10. MiniConfig, Audio Tab Screen
Audio Selections
NOTE: When using the DVI video protocol no audio is output, since that protocol is video only.
Input Source: Choose which embedded audio channels are routed to the HDMI output. Eight channels
are routed at a time. You can choose Ch 1-8 or Ch 9-16 from the SDI input.
Output Channel Count: Choose Auto, 2 of 8 channels or 8-channel embedded audio. Choosing “Auto”
automatically selects the audio channels based on the attached device's capabilities.
Analog Audio Select: Permits selecting the pair of audio channels to be sent to the analog audio RCA
connectors. The audio pairs routed depend on the Input Source (1-8 or 9-16) setting
above. Choose Ch 1-2 (or 9-10), through Ch 7-8 (or 15-16).
Audio Offset In Frames: Permits time shifting the embedded audio in relationship to the video (for example, to
correct for lip sync problems), in 1/16 of a frame increments. Range is from 0 video frame
to +7.0 video frames. The actual time duration of delay will vary depending on the frame
rate of the format being converted.

Hi5-Plus v1.0 www.aja.com
13
NOTE: One frame of delay is automatically added when the input video is Psf.
Update Tab Screen Use this Update screen to view the software version currently installed on the converter
or install new software.
Figure 11. MiniConfig, Update Screen
NOTE: When discussing Mini-Converters, “Firmware” is software that will be stored in the Mini-
Converter’s non-volatile memory and used when it is powered up. This is something different
than the MiniConfig application software. The version numbers shown in the Update screen
refer only to the firmware.
The following fields and control are present in this screen:
Installed: This field shows the version of the firmware currently installed inside the Mini-Converter.
Desired: This field shows the version of firmware embedded in the MiniConfig application which
you can install into the Mini-Converter by clicking the Update button.
Update: This button initiates a software update operation loading the “Desired” version of
firmware into the Mini-Converter’s non-volatile memory.
Progress: This indicator bar shows the progress of software being installed.
Software Update
Procedure
1. Check the AJA website for new MiniConfig software for your Mini-Converter. If new
software is found, download it and uncompress the file archive (zip). Here is the URL
to use when checking:
http://www.aja.com/en/products/mini-converters/mini-config-software
2. Connect the Mini-Converter to a Mac or PC via a USB port on the computer and run
the new MiniConfig software just downloaded.
3. Click on the Update tab screen.

Hi5-Plus v1.0 www.aja.com
14
4. Check the Installed version level against the Desired version level. If the Desired is
newer, then click the Update button to download the new firmware to the Mini-
Converter.
Progress will be shown via the Progress thermometer bar, and when completed an
“Update Succeeded” message appears.
Info Tab Screen This screen provides basic information about the Mini-Converter. This information is
mostly useful when calling AJA Support for service or technical support.
Figure 12. MiniConfig, Info Screen
Name: This field allows you to give your Mini-Converter a name. This may be useful if you have
several Mini-Converters attached to a Mac/PC via USB so you can distinguish one of them
easily (especially if they’re the same model).
Type: This is the factory set model name of the Mini-Converter (Hi5-Plus).
Assembly: This is the factory assembly number.
Serial Number: This is the factory set unique serial number of your Hi5-Plus. If you ever call AJA Support
for service, you may be asked for this number.

Hi5-Plus v1.0 www.aja.com
15
Appendix A: Specifications
Video
Video Input 3G/HD/SD-SDI, SMPTE-259/292/424 (with embedded audio) 1 x BNC
Input Formats: •525i,625i,
• 720p 50/59.94/60,
• 1080i 50/59.94/60,
• 1080p23.98/24/25/29.97/30/50/59.94/60
• 1080psf23.98/24/25/29.97/30
• 2Kx1080p23.98/24/25/29.97/30/50/59.94/60
• 2Kx1080psf23.98/24/25/29.97/30
Video Output HDMI (with embedded audio)
HDMI Standard Type A connector
• Video (selectable by MiniConfig):
• 8-bit RGB 4:4:4 or
• 10-bit YCbCr 4:2:2
•12-bit
HDCP The Hi5-Plus does not encode the HDMI output with HDCP encryption.
Audio
SDI Audio Input Eight channels (4 pairs) of embedded audio supported
• Select Ch 1-8 or Ch 9-16
•24-bit/48KHz
HDMI Audio Output Up to eight channels (4 pairs) of embedded audio supported, selectable by MiniConfig:
• Two embedded channels, or 8 embedded channels
•24-bit/48KHz
Analog Audio Output Unbalanced, -10dBV (nominal), 2 x RCA
Routing of incoming embedded audio channel pairs to the analog outputs selectable by
MiniConfig:
• Ch 1-2 (or 9-10), through Ch 7-8 (or 15-16)
Physical
Size 4.6" x 2.4" x 1" (117mm x 61mm x 25mm.)
Power • Uses AJA Power Supply model DWP-U-R1 (included)
• 100-240V, 50/60Hz Universal Input
• +5V DC regulated, 3 watt capacity

Hi5-Plus v1.0 www.aja.com
16
Appendix B: Safety and Compliance
Federal Communications Commission (FCC) Compliance Notices
Class B Interference
Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15, Subpart B of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Canadian ICES Statement
Canadian Department of Communications Radio Interference Regulations
This digital apparatus does not exceed the Class B limits for radio-noise emissions from a
digital apparatus as set out in the Radio Interference Regulations of the Canadian
Department of Communications. This Class B digital apparatus complies with Canadian
ICES-003.
Règlement sur le brouillage radioélectrique du ministère des Communications
Cet appareil numérique respecte les limites de bruits radioélectriques visant les appareils
numériques de classe B prescrites dans le Règlement sur le brouillage radioélectrique du
ministère des Communications du Canada. Cet appareil numérique de la Classe B est
conforme à la norme NMB-003 du Canada.

Hi5-Plus v1.0 www.aja.com
17
European Union and European Free Trade Association (EFTA)
Regulatory Compliance
This equipment may be operated in the countries that comprise the member countries
of the European Union and the European Free Trade Association. These countries, listed
in the following paragraph, are referred to as The European Community throughout this
document:
AUSTRIA, BELGIUM, BULGARIA, CYPRUS, CZECH REPUBLIC, DENMARK, ESTONIA,
FINLAND, FRANCE, GERMANY, GREECE, HUNGARY, IRELAND, ITALY, LATVIA, LITHUANIA,
LUXEMBOURG, MALTA, NETHERLANDS, POLAND, PORTUGAL, ROMANIA, SLOVAKIA,
SLOVENIA, SPAIN, SWEDEN, UNITED KINGDOM, ICELAND, LICHTENSTEIN, NORWAY,
SWITZERLAND
Declaration of
Conformity
Marking by this symbol indicates compliance with the Essential Requirements of the EMC
Directive of the European Union 2004/108/EC.
This equipment meets the following conformance standards:
Safety: CB- IEC 60065:2001 + A1:2005
NRTL - UL 60065:2003 R11.06, CSA C22.2 NO. 60065:2003 + A1:06
GS - EN 60065:2002 + A1
Additional licenses issued for specific countries available on request.
Emissions: EN 55103-1: 1996
EN61000-3-2:2006, EN61000-3-3:1995 +A1:2001 +A2:2005
Immunity: EN 55103-2: 1996
EN61000-4-2:1995 + A1:1999 + A2:2001, EN61000-4-3:2006, EN61000-4-4:2004,
EN 61000-4-5: 2005, EN 610004-6:2007, EN61000-4-11:2004
The product is also licensed for additional country specific standards as required for the
International Marketplace.
Warning!
This is a Class B product. In a domestic environment, this product may cause radio
interference, in which case, the user may be required to take appropriate measures.
Achtung! Dieses ist ein Gerät der Funkstörgrenzwertklasse B. In Wohnbereichen
können bei Betrieb dieses Gerätes Rundfunkstörungen auftreten, in welchen Fällen
der Benutzer für entsprechende Gegenmaßnahmen verantwortlich ist.
Attention! Ceci est un produit de Classe B. Dans un environnement domestique, ce
produit risque de créer des interférences radioélectriques, il appartiendra alors à
l?utilisateur de prendre les mesures spécifiques appropriées.

Hi5-Plus v1.0 www.aja.com
18
Korea KCC Compliance Statement
Taiwan Compliance Statement
This is a Class B product based on the standard of the Bureau of Standards, Metrology
and Inspection (BSMI) CNS 13438, Class B.
Japanese Compliance Statement
This is a Class B product based on the standard of the VCCI Council. If this is used near a
radio or television receiver in a domestic environment, it may cause radio interference.
Install and use the equipment according to the instruction manual.
Translated Warning and Caution Messages
The following caution statements, warning conventions, and warning messages apply to
this product and manual.

Hi5-Plus v1.0 www.aja.com
19
Before Operation Please Read These Instructions
Warning!
Read and follow all warning notices and instructions marked on the product or
included in the documentation.
Avertissement ! Lisez et conformez-vous à tous les avis et instructions
d'avertissement indiqués sur le produit ou dans la documentation.
Warnung! Lesen und befolgen Sie die Warnhinweise und Anweisungen, die auf dem
Produkt angebracht oder in der Dokumentation enthalten sind.
¡Advertencia! Lea y siga todas las instrucciones y advertencias marcadas en el
producto o incluidas en la documentación.
Aviso! Leia e siga todos os avisos e instruções assinalados no produto ou incluídos na
documentação.
Avviso! Leggere e seguire tutti gli avvisi e le istruzioni presenti sul prodotto o inclusi
nella documentazione.
Warning!
Do not use this device near water and clean only with a dry cloth.
Avertissement! N'utilisez pas cet appareil près de l'eau et nettoyez-le seulement avec
un tissu sec..
Warnung! Das Gerät nicht in der Nähe von Wasser verwenden und nur mit einem
trockenen Tuch säubern.
¡Advertencia! No utilice este dispositivo cerca del agua y límpielo solamente con un
paño seco.
Aviso! Não utilize este dispositivo perto da água e limpe-o somente com um pano
seco.
Avviso! Non utilizzare questo dispositivo vicino all'acqua e pulirlo soltanto con un
panno asciutto.

Hi5-Plus v1.0 www.aja.com
20
Warning!
Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
Avertissement ! Ne bloquez aucune ouverture de ventilation. Suivez les instructions
du fabricant lors de l'installation.
Warnung! Die Lüftungsöffnungen dürfen nicht blockiert werden. Nur gemäß den
Anweisungen des Herstellers installieren.
¡Advertencia! No bloquee ninguna de las aberturas de la ventilación. Instale de
acuerdo con las instrucciones del fabricante.
Aviso! Não obstrua nenhuma das aberturas de ventilação. Instale de acordo com as
instruções do fabricante.
Avviso! Non ostruire le aperture di ventilazione. Installare in conformità con le
istruzioni del fornitore.
Warning!
Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
Avertissement ! N'installez pas l'appareil près d'une source de chaleur telle que des
radiateurs, des bouches d'air de chauffage, des fourneaux ou d'autres appareils
(amplificateurs compris) qui produisent de la chaleur.
Warnung! Nicht in der Nähe von Wärmequellen wie Heizkörpern, Heizregistern, Öfen
oder anderen Wärme erzeugenden Geräten (einschließlich Verstärkern) aufstellen.
¡Advertencia! No instale cerca de fuentes de calor tales como radiadores, registros de
calor, estufas u otros aparatos (incluidos amplificadores) que generan calor.
Aviso! Não instale perto de nenhuma fonte de calor tal como radiadores, saídas de
calor, fogões ou outros aparelhos (incluindo amplificadores) que produzam calor.
Avviso! Non installare vicino a fonti di calore come termosifoni, diffusori di aria calda,
stufe o altri apparecchi (amplificatori compresi) che emettono calore.
