AJA IPTR-10G2 Series Operating instructions

IPTR-10G2-Series Mini-Converters
SMPTE 2110 IP Tx/Rx
Version 2.5r1
Published July 24, 2023
Installation and Operation Guide

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 2 www.aja.com
Notices
Trademarks
AJA® and Because it matters.® are registered trademarks of AJA Video Systems, Inc.
for use with most AJA products. AJA™ is a trademark of AJA Video Systems, Inc. for
use with recorder, router, software and camera products. Because it matters.™ is a
trademark of AJA Video Systems, Inc. for use with camera products.
Corvid Ultra®, lo®, Ki Pro®, KONA®, KUMO®, ROI® and T-Tap® are registered trademarks of
AJA Video Systems, Inc.
AJA Control Room™, KiStor™, Science of the Beautiful™, TruScale™, V2Analog™ and
V2Digital™ are trademarks of AJA Video Systems, Inc.
All other trademarks are the property of their respective owners.
Copyright
Copyright © 2023 AJA Video Systems, Inc. All rights reserved. All information in
this manual is subject to change without notice. No part of the document may be
reproduced or transmitted in any form, or by any means, electronic or mechanical,
including photocopying or recording, without the express written permission of AJA
Video Systems, Inc.
Contacting AJA Technical Support or Sales
Please have all pertinent information at hand prior to contacting AJA support or sales.
Support Telephone: [phone]
Support Website: https://www.aja.com/support/contact
Support Email: suppor[email protected]
Sales Email: [email protected]
Shipping Address: AJA Video Systems
180 Litton Drive
Grass Valley, CA 95945, USA

Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Contacting AJA Technical Support or Sales . . . . . . . . . . . . . . . . . . . . . . . 2
Chapter 1 – Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Pre-Built System Conguration Modes for IPR-10G2. . . . . . . . . . . . . . . .6
IPTR-10G2-Series Mini-Converters Features . . . . . . . . . . . . . . . . . . . . . . .7
IPT-10G2-SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
IPT-10G2-HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
IPR-10G2-SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
IPR-10G2-HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Abbreviated Feature Comparison Chart . . . . . . . . . . . . . . . . . . . . . . 10
Workow Diagrams and I/O Connections . . . . . . . . . . . . . . . . . . . . . . . 10
Simplied Block Diagrams and Logic Diagrams . . . . . . . . . . . . . . . . . . . 14
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Control LAN, Ready, Link/Act, and Lock LED Behavior. . . . . . . . . . . . . . 15
Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Initial Setup By Web Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Initial Setup By AJA eMini-Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Settings Retained. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
REST API Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Chapter 2 – eMini-Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Acquiring eMini-Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
eMini-Setup Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Installing eMini-Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
PC Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Mac Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Running eMini-Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
PC Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Mac Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Operating eMini-Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Control LAN Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Media LAN 1 Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Media LAN 2 Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Update Tab Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Firmware Update Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Info Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Chapter 3 – IPTR-10G2-Series Mini-Converters Web Interface . . . 27
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Remote Control Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Networking Option – Using Only the Media LAN Port for Control and Media
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Web Browser via Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
General Screen Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Status Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
IPT-10G2-SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
IPR-10G2-HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Cong Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
IPT-10G2-SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
IPR-10G2-HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Presets Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Contents

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 4 www.aja.com
Presets Screen Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Network Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Firmware Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Downloading and Installing Updated Firmware . . . . . . . . . . . . . . . . . 52
Booting the IPTR-10G2-Series Mini-Converters from the Safeboot Firmware53
Appendix A – Specications . . . . . . . . . . . . . . . . . . . . . . . . 55
IPT-10G2-SDI Tech Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
IPT-10G2-HDMI Tech Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
IPR-10G2-SDI Tech Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
IPR-10G2-HDMI Tech Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Appendix B – Safety and Compliance . . . . . . . . . . . . . . . . . . 63
Warranty and Liability Information . . . . . . . . . . . . . . . . . . . .71
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 5 www.aja.com
Chapter 1 – Introduction
Overview
AJA IPTR-10G2-Series Mini-Converters are designed for point of use applications
for encoding, transport, reception and decoding of IP based video sources.
Rugged, compact and fanless, the IPTR-10G2-Series Mini-Converters provide
the bridge between Baseband and IP video for a range of applications,
such as sending and receiving video over IP from remote facilities in
post production, source monitoring, digital signage, and video walls.
IPTR-10G2-Series Mini-Converters ease the cost of extensive monitoring
distribution in a facility.
The 10 GigE IP Mini-Converter Transmitters take baseband HDMI or SDI input
and encode the data as SMPTE 2110. The embedded audio associated with the
video stream is also encoded to SMPTE 2110. Alternatively, analog audio can be
encoded and sent with the video stream instead.
The 10 GigE IP Mini-Converter Receivers decode SMPTE 2110 and format the data
for either HDMI or SDI output. The audio associated with the video stream is
extracted, synchronized, and then embedded into the HDMI or SDI signal as well
as output on a stereo analog RCA audio output.
All UltraHD rates (23.98, 24, 25, 29.97, 30, 50) can be received only by the IPR-10G2-
HDMI.
The IPR-10G2-HDMI can provide RGB (rather than YCbCr) to a compatible monitor
if the monitor or other sink device indicates this availability via EDID.

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 6 www.aja.com
Pre-Built System Configuration Modes for IPR-10G2
There is a set of pre-built system configuration modes, or "system modes,"
available from the System Mode control on the Config page of the IPR-10G2 web
UI. These pre-built System Modes are designed to save you time so that you can
get your unit up and running quickly.
Each System Mode is built for a specific type of use case, taking into account
factors such as network conditions, protection requirements, timing, and latency
considerations.
Please see "System Modes" on page 40 for more detailed information.
NOTE: The System Modes are available only for the IPR-10G2-SDI and IPR-10G2-HDMI
units; they are not needed on the IPT-10G2-SDI and IPT-10G2-HDMI units since the
transmitter's functionality is simpler.
On a high level, the five pre-built System Modes are described as follows:
PTP Low Latency
• Appropriate under ideal network conditions
• Fastest method of moving data through the device (does not require signal
processing)
• Provides the least amount of packet-level and frame-level protection
• Remote sender and AJA IPR-10G2 receiver are locked to PTP
PTP Protected
• Provides the highest amount of packet-level and frame-level protection,
including redundancy support with ST 2022-7
• Maximum latency due to longer signal processing chain
• Remote sender and AJA IPR-10G2 receiver are locked to PTP
Gateway
• Bridges between PTP and Reference Video timed domains
• Provides frame-level protection
• Moderate latency due to signal processing chain
Gateway Protected
• Bridges between PTP and Reference Video timed domains
• Provides the highest amount of packet-level and frame-level protection,
including redundancy support with ST 2022-7
• Maximum latency due to longer signal processing chain
Asynchronous
• Intended as a setup environment or troubleshooting and demo tool
• Not for production
• When unable to lock to PTP or when experiencing problems with Reference
In, uses Video In to verify that video is being received from source address
• Provides frame-level protection (no packet-level protection)
• Moderate latency due to signal processing chain
Advanced
Unlike the five pre-built System Modes just described, each of which are "safe,"
Advanced Mode does not guard against a user applying contradictory settings
that could provide unpredictable results.

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 7 www.aja.com
Characteristics of Advanced Mode include the following:
• For custom configurations
• Has no native default settings
• Can be used to iterate and expand upon the five pre-built System Modes
described above
• Provides free-range access to:
• Video Clock Mode
• Packet Protection Mode
• Frame Sync Mode
• System Mode
• Audio Sample Rate Converter
• When selected, Advanced Mode will retain the settings of the previously
selected System Mode, and the user may proceed to customize settings as
desired. This means that any of the System Modes can be modified using
Advanced Mode and then saved as a Preset on the Presets screen.
NOTE: When working with Advanced Mode, if the configuration settings become
problematic, you can always "revert" to one of the five pre-built System Modes to
get the unit running again with established internally compatible settings.
IPTR-10G2-Series Mini-Converters Features
IPT-10G2-SDI
• SMPTE ST 2110 audio, video transmitter including support for ST 2022-7
• Essence support: SMPTE 2110-10, 2110-20, 2110-30
• Rugged, quiet, fanless design
• 2x 10 GigE SFP+ cages for media LAN with status light (for media transport,
control, and timing input), SFP+ modules not included)
• 1x 1 GigE RJ45 socket for control LAN with status light
• Complete control interface on any web browser from a built-in web server
• Customizable control with AJA REST API
• Control supported over dedicated management Ethernet port and in-band
over media ports
• NMOS Rx discovery and control according to standards IS-04 v1.3 and IS-05
v1.1
• Ember+ control (no discovery, control only)
• AJA REST API control (discovery via SSDP or MDNS)
• LLDP (Link Layer Discovery Protocol)
• 1x 3G-SDI Input
• 1x 3G-SDI Loop Out
• Support for HD up to 1080 60p, YCbCr 4:2:2
• Concealment of errors due to packet loss
• Full 10-bit pixel processing pipeline
• Embedded SDI audio input (up to 16 channels)
• 2x RCA analog audio input
• 1x BNC Reference Out, allowing incoming baseband sources to be locked to
PTP timing
• Frame Sync
• 1x mini-USB port for initial network configuration with AJA eMini-Setup
software (alternative setup method)

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 8 www.aja.com
• 5-year international warranty and support
IPT-10G2-HDMI
• SMPTE ST 2110 audio, video transmitter including support for ST 2022-7
• Essence support: SMPTE 2110-10, 2110-20, 2110-30
• Rugged, quiet, fanless design
• 2x 10 GigE SFP+ cages for media LAN with status light (for media transport,
control, and timing input), SFP+ modules not included)
• 1x 1 GigE RJ45 socket for control LAN with status light
• Complete control interface on any web browser from a built-in web server
• Customizable control with AJA REST API
• Control supported over dedicated management Ethernet port and in-band
over media ports
• NMOS Rx discovery and control according to standards IS-04 v1.3 and IS-05
v1.1
• Ember+ control (no discovery, control only)
• AJA REST API control (discovery via SSDP or MDNS)
• LLDP (Link Layer Discovery Protocol)
• Dedicated HDMI transmitter/output with full size (standard type A) HDMI 1.4b
(24/30-bits per pixel) input up to HD 60p, 4:2:2, 10-bit, YCbCr
• Concealment of errors due to packet loss
• Full 10-bit pixel processing pipeline
• Embedded SDI audio input (up to eight channels)
• 2x RCA analog audio input
• 1x BNC Reference Out, allowing incoming baseband sources to be locked to
PTP timing
• Frame Sync
• 1x mini-USB port for initial network configuration with AJA eMini-Setup
software (alternative setup method)
• 5-year international warranty and support
IPR-10G2-SDI
• SMPTE ST 2110 audio, video receiver including support for ST 2022-7
• Essence support: SMPTE 2110-10, 2110-20, 2110-30
• Rugged, quiet, fanless design
• 2x 10 GigE SFP+ cages for media LAN with status light (for media transport,
control, and timing input), SFP+ modules not included)
• 1x 1 GigE RJ45 socket for control LAN with status light
• Complete control interface on any web browser from a built-in web server
• Customizable control with AJA REST API
• Control supported over dedicated management Ethernet port and in-band
over media ports
• NMOS Rx discovery and control according to standards IS-04 v1.3 and IS-05
v1.1
• Ember+ control (no discovery, control only)
• AJA REST API control (discovery via SSDP or MDNS)
• USB Keyboard Control for Recalling Presets
• 2x 3G-SDI Output (mirrored)
• Support for HD up to 1080 60p, YCbCr 4:2:2
• Concealment of errors due to packet loss
• Full 10-bit pixel processing pipeline

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 9 www.aja.com
• Embedded SDI audio output (up to 16 channels)
• 2x RCA analog audio output
• 1x BNC Reference for analog/tri-level reference input, allowing baseband
output to be locked to the facility baseband clock (instead of PTP)
• 1x mini-USB port for initial network configuration with AJA eMini-Setup
software (alternative setup method)
• 5-year international warranty and support
IPR-10G2-HDMI
• SMPTE ST 2110 audio, video receiver including support for ST 2022-7
• Essence support: SMPTE 2110-10, 2110-20, 2110-30
• Rugged, quiet, fanless design
• 2x 10 GigE SFP+ cages for media LAN with status light (for media transport,
control, and timing input), SFP+ modules not included)
• 1x 1 GigE RJ45 socket for control LAN with status light
• Complete control interface on any web browser from a built-in web server
• Customizable control with AJA REST API
• Control supported over dedicated management Ethernet port and in-band
over media ports
• NMOS Rx discovery and control according to standards IS-04 v1.3 and IS-05
v1.1
• Ember+ control (no discovery, control only)
• AJA REST API control (discovery via SSDP or MDNS)
• USB Keyboard Control for Recalling Presets
• Dedicated HDMI receiver/input with full size (standard type A) HDMI 1.4b
(24/30-bits per pixel) output up to HD 60p, 4:2:2, 10-bit, YCbCr/RGB, or 2K up
to 2048 60p, YCbCr 4:2:2 or UltraHD 30p,4:2:2, 10-bit, YCbCr, or UltraHD 50p,
4:2:0, 8-bit, YCbCr
• ST 2022-7 is supported up to HD 1080p (UltraHD not supported)
• Concealment of errors due to packet loss (error concealment functionality
supported up to 1080p 60, UltraHD not supported)
• Full 10-bit pixel processing pipeline (except for UHD p50)
• Embedded HDMI audio output (up to eight channels)
• 2x RCA analog audio output
• 1x BNC Reference for analog/tri-level reference input, allowing baseband
output to be locked to the facility baseband clock (instead of PTP)
• 1x mini-USB port for initial network configuration with AJA eMini-Setup
software (alternative setup method)
• 5-year international warranty and support

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 10 www.aja.com
Abbreviated Feature Comparison Chart
Model UltraHD
Support
2K
Support
Reference
Functions
System
Modes
2022-7
support
RGB 4:4:4
10-bit
IPT-10G2-SDI Up to
2048 p60
Ref Out Up to
1080 p60
IPT-10G2-HDMI Ref Out Up to
1080 p60
IPR-10G2-SDI Up to
2048 p60
Ref In Supported Up to
2048 p60
IPR-10G2-HDMI Up to
UHD p50
Up to
2048 p60
Ref In Supported Up to
2048 p60
Up to 1080
p60
Workflow Diagrams and I/O Connections
Figure 1. Example Workflow Diagram for the IPT-10G2-SDI
10 GigE Switch
1x 3G-SDI
3G-SDI Recorder/Player
or other SDI source
PTP Generator
10 GigE
Input/Output HD (up to 60p) Input/Output
redundant IP feeds
IPR-10G2-SDI
1x
SDI
Media Server HD SDI
Remote Monitor
Ref Out
Ref In
Black Burst/
Tri-level Sync
based on
PTP Clock
HD (up to 60p)
Redundant
IP feeds

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 11 www.aja.com
Figure 2. IPT-10G2-SDI Connections
2 Channel
Unbalanced
Analog Audio
Input
(RCA Jacks)
Input SDI
Connector 1
Control
LAN
SFP+ Cage for
10 Gbps Ethernet
Lock LED
Ready LED
Link/Act
LED 1
Link/Act
LED 2
SFP+ Cage for
10 Gbps Ethernet
Output SDI
Connector 2
USB Port
+5-16 VDC
Power Input
Reference
Out BNC
Figure 3. Example Workflow Diagram for the IPT-10G2-HDMI
HD Camera or Other
HDMI Source*
10 GigE Switch
PTP Generator
1x HDMI
Ref Out
Ref In
IPR-10G2-HDMI
1x
HDMI
Media Server HD HDMI
Remote Monitor
Black Burst/
Tri-level sync
based on
PTP clock
HD (up to 60p) Input/Output
Redundant IP feeds
10 GigE
Input/Output
HD (up to 60p)
Redundant
IP Feeds
Figure 4. IPT-10G2-HDMI Connections
2 Channel
Unbalanced
Analog Audio
Input
(RCA Jacks)
Input HDMI
Connector
USB Port
+5-16 VDC
Power Input
Control
LAN
SFP+ Cage for
10 Gbps Ethernet
Lock LED
Ready LED
Link/Act
LED 1
Link/Act
LED 2
SFP+ Cage for
10 Gbps Ethernet
Reference
Out BNC

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 12 www.aja.com
Figure 5. Example Workflow Diagram for the IPR-10G2-SDI
PTP Generator
HD SDI Monitor
Recorder/Player
or other SDI destination
Media Server
HD (up to 60p)
Redundant
IP feeds
10 GigE Switch
10 GigE
Input/Output
1x SDI
3G-SDI
1x SDI
3G-SDI
Black Burst/
Tri-level sync
generator
Figure 6. IPR-10G2-SDI Connections
2 Channel
Unbalanced
Analog Audio
Output
(RCA Jacks)
Output SDI
Connector 1
Control
LAN
SFP+ Cage for
10 Gbps Ethernet
Lock LED
Ready LED
Link/Act
LED 1
Link/Act
LED 2
SFP+ Cage for
10 Gbps Ethernet
Output SDI
Connector 2
USB Port
+5-16 VDC
Power Input
Analog/Tri-Level
Reference Input BNC

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 13 www.aja.com
Figure 7. Example Workflow Diagram for the IPR-10G2-HDMI
10 GigE Switch
PTP Generator
1x HDMI
Media Server
HDMI Recorder/Player
or other HDMI destination
Black Burst or
Tri-level sync
generator*
NOTE: HDMI monitors won’t re-
quire reference
UltraHD (up to 50p)
Redundant IP feeds
up to HD 60p
10 GigE
Input/Output
Figure 8. IPR-10G2-HDMI Connections
2 Channel
Unbalanced
Analog Audio
Output
(RCA Jacks)
Output HDMI
Connector
USB Port
+5-16 VDC
Power Input
Control
LAN
SFP+ Cage for
10 Gbps Ethernet
Lock LED
Ready LED
Link/Act
LED 1
Link/Act
LED 2
Analog/Tri-Level
Reference Input BNC SFP+ Cage for
10 Gbps Ethernet

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 14 www.aja.com
Simplified Block Diagrams and Logic Diagrams
Figure 9. IPT-10G2-SDI/HDMI Simplified Block Diagram
Reference
Output
Video over IP
Processing
Video
Audio
2-Channel
RCA Analog
Audio Input
Control LAN
Media LAN 1
USB Port
(connect to PC or Mac)
For initial setup of
network interfaces
Media LAN 2
SDI Loop Through
SDI Input with
16 Ch Embedded Audio
HDMI Input with
8 Ch Embedded Audio
(IPT-10G2-SDI only)
(Embeds on Ch 1-8)
(IPT-10G2-HDMI only)
IPT-10G2-SDI / IPT-10G2-HDMI
Video over IP
Transmitter
SDI supports up to 16 Ch. audio
HDMI supports 8 Ch. audio
Figure 10. IPR-10G2-SDI/HDMI Simplified Block Diagram
Video over IP
Processing
Audio
D/A
Video
Audio HDMI
Transmitter
(IPR-10G2-HDMI
only)
2-Channel
RCA Analog Audio
Monitor Output Ch. 1-8
HDMI Output
with 8 Ch. of
Embedded Audio
Control LAN
Media LAN 1
USB Port
(connect to PC or Mac)
For initial setup of
network interfaces
Video over IP
Receiver
Supports up to 16 Ch. Audio
SDI Out 1 with 16 Ch.
of embedded audio
SDI Out 2 with 16 Ch.
of embedded audio
SDI
Transmitter
(IPR-10G2-SDI
only)
IPR-10G2-SDI / IPR-10G2-HDMI
Media LAN 2
Reference
Input Analog/tri-level reference input
Figure 11. IPR-10G2-SDI/HDMI Simplified Logic Diagram
Media LAN 1 Packet Protection
(Supporting ST 2022-7
when dual SFPs in use)
window size applies here
Simplied Logic Diagram
Media LAN 2
Output
Video Clock
Framesync
Bypass Packet Protection
(ST 2022-7 unsupported)
PTP Ref Video In Free Run
Baseband
Output
Bypass Framesync
IPR-10G2-SDI / IPR-10G2-HDMI

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 15 www.aja.com
Frequently Asked Questions
To access responses to freqently asked questions about the
IPTR-10G2-Series Mini-Converters, please use the following links:
• https://www.aja.com/products/ipt-10g2-sdi#support
• https://www.aja.com/products/ipt-10g2-hdmi#support
• https://www.aja.com/products/ipr-10g2-sdi#support
• https://www.aja.com/products/ipr-10g2-hdmi#support
System Requirements
Remote computer configuration and control is accomplished using the
IPTR-10G2-Series Mini-Converters' internal web server. A macOS X or Windows
computer with a web browser installed is all that is required. Additionally, initial
configuration using eMini-Setup will require a USB port between the host
computer and the 10 GigE IP Mini-Converter.
NOTE: Chrome and Firefox are the preferred web browsers for control on Windows.
Safari is the preferred web browser for control on macOS. Other web browsers
may work, but AJA cannot guarantee consistent operation for all web browsers or
web browser versions.
Control LAN, Ready, Link/Act, and Lock LED Behavior
The Control LAN LED illuminates to indicate a link. Blinking indicates activity.
The Ready LED illuminates green when the unit has finished powering up and is
ready to use.
The Link/Act LED 1 and Link/Act LED 2 behavior is as follows:
• Off - No SFP+ module present
• Red - SFP+ module present, no link
• Green - Link is up
• Green flash - Link is up and there is Tx or Rx activity
The Lock LED behavior is as follows:
• Off - No Precision Time Protocol (PTP) is detected
• Red - A PTP error is detected
• Yellow and flashing - Locking Phase 1
• Yellow - Locking Phase 2
• Green and flashing - Locking Phase 3
• Green - Signal is locked
NOTE: Achieving locked status may take 5 or more minutes depending on network jitter
behavior. The output of the unit will still function during the locking period.
Installation Overview
Detailed instructions are provided in "Chapter 2 – eMini-Setup" on page 18 and
"Chapter 3 – IPTR-10G2-Series Mini-Converters Web Interface" on page 27.
As an overview, however, there are two methods available for initial setup for
IPTR-10G2-Series Mini-Converters:
1. Using a web browser on the host computer connected to the same network
as the 10 GigE IP Mini-Converter, or

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 16 www.aja.com
2. Using the AJA eMini-Setup application running on the host computer that is
directly connected to the 10 GigE IP Mini-Converter via USB.
Initial Setup By Web Browser
NOTE: Chrome and Firefox are the preferred web browsers for control on Windows.
Safari is the preferred web browser for control on macOS. Other web browsers
may work, but AJA cannot guarantee consistent operation for all web browsers or
web browser versions.
IPTR-10G2-Series Mini-Converters require a network connection for initial
configuration, control and firmware updates. IPTR-10G2-Series Mini-Converters
are shipped from the factory with DHCP enabled, and support automatic network
discovery via SSDP and MDNS.
To Set Up the Unit with a Web Browser
1. Connect the 10 GigE IP Mini-Converter Control Port to the intended
network with an Ethernet cable.
2. The intended network’s DHCP Server will assign an IP address and the 10
GigE IP Mini-Converter will join that network.
3. Locate and connect to the AJA 10 GigE IP Mini-Converter.
Windows PC Host
A. Open Windows Explorer.
B. Navigate to the Network.
C. Click on the Network to enumerate network devices.
D. Search for either “IPT-10G2,” "IPR-10G2," or the device’s Serial Number.
E. Double-click on the intended 10 GigE IP Mini-Converter. The host machine
web browser will launch and display the web UI for the device.
macOS Host
A. Go to System Preferences > Sharing and turn on File Sharing.
B. Open the Finder Window.
C. Navigate to Shared > All…
D. Click on All… to enumerate network devices.
E. Search for either “IPT-10G2,” "IPR-10G2," or the device’s Serial Number.
F. Double-click on the intended 10 GigE IP Mini-Converter. The host machine
web browser will launch and display the web UI for the device.
NOTE: If the above does not work, then you will need to download and install an MDNS
browser to assist with discovering network devices on a macOS host.
Initial Setup By AJA eMini-Setup
1. Acquire AJA eMini-Setup (version 2.1) from the AJA website for either
macOS or Windows:
https://www.aja.com/family/software#eminisetup
2. Install eMini-Setup:
A. Unzip the Installer.
B. Run the .dmg file on macOS or the .msi file on Windows.
3. Connect Power to your AJA Ethernet equipped Converter.

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 17 www.aja.com
4. Connect the USB cong cable to the computer running eMini-Setup.
5. Open eMini-Setup and congure the device’s network settings.
NOTE: DHCP is enabled by default, and if the device is connected to a DHCP server the IP
address field will populate.
6. Enter the IP address into a browser window. The web UI for your AJA device
will display.
7. Use the web UI to fully congure and control your AJA Device.
Hardware Installation
Temperature of Unit
The 10 GigE IP Mini-Converters pack an unprecedented feature set into the mini
converter box. As a result, the unit uses approximately 13 watts of power. It will be
very warm to the touch, which is normal. The unit is engineered to operate across
the full temperature range, from 0 to 40 degrees C.
Access to Air for Proper Cooling
For highest reliability, the mini converters rely on convection cooling instead
of using a built-in fan. Therefore, when installing the units, mount in a
location where they have access to air for proper cooling. Do not stack the
IPTR-10G2-Series Mini-Converters with other mini converters or other powered
equipment.
Number of LAN Connections
Three LAN connections to the unit are not necessarily required on an ongoing
basis. If it is desirable for your installation, after the 10 GigE IP Mini-Converter is
set up, you can access all control parameters through one of the Media LANs with
the appropriate network configuration. See "Networking Option – Using Only the
Media LAN Port for Control and Media Settings" on page 27 for more information.
Settings Retained
The current 10 GigE IP Mini-Converter's configuration settings are retained even
when powered off, so subsequent installations for an identical decoding or
encoding session can be done with the following simple steps:
1. Apply power to the 10 GigE IP Mini-Converter.
2. Connect the unit to your network using the Control LAN, Media LAN 1 and
Media LAN 2 and connect the unit’s inputs and outputs.
REST API Documentation
AJA’s REST automation API provides a platform from which you can issue
commands to an AJA device’s internal web server, allowing remote systems
the ability to control AJA embedded or networked devices. With this control
framework, you can build integration and automation scripts, using any scripting
language, allowing you to take full advantage of the device’s functionality.
This documentation is available at the following link:
https://gitlab.aja.com/pub/rest_api

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 18 www.aja.com
Chapter 2 – eMini-Setup
Overview
This chapter describes using the eMini-Setup application to initially communicate
with and configure a 10 GigE IP Mini-Converter over a direct USB connection.
Once configured, the IP Mini-Converter can be accessed via an Ethernet network
using a web browser. Subsequently, that device can then be reconfigured over
that network, using its IP address and built-in web server.
NOTE: The eMini-Setup application is only used to setup selected Ethernet capable AJA
devices, and cannot be used to connect to or setup other AJA Mini-Converters.
The general procedure is:
1. Acquire eMini-Setup from the AJA website and install the eMini-Setup
application onto a computer.
2. Connect the IP Mini-Converter to that computer’s USB port.
3. Launch the eMini-Setup application.
4. Go to the Control Network tab and Media Network tabs, where the IP
address settings are displayed. You can use the existing DHCP assigned IP
address, or it can be changed manually.
5. You can also use eMini-Setup to load rmware to the device, although this
can also be done quickly and easily using the web browser interface.
Acquiring eMini-Setup
AJA’s eMini-Setup application is available for download from the AJA website.
To download the latest eMini-Setup package, which includes the eMini-Setup
application and documentation:
1. Go to:
https://www.aja.com/family/software#eminisetup
2. Click the link corresponding to the version you want to download for Mac or
Windows.
NOTE: IPT-10G2-SDI and IPT-10G2-HDMI require eMini-Setup version 2.1 or later.
IPR-10G2-SDI and IPR-10G2-HDMI require eMini-Setup version 2.0 or later.
eMini-Setup Documentation
Included with the eMini-Setup download is the AJA device's Installation and
Operation Guide, which can be accessed from the eMini-Setup UI via the Help/
Manual drop-down menu. This manual includes eMini-Setup information.
Documentation can also be accessed directly from the Mac eMini-Setup installer
in the Documentation folder.
Documentation included with the eMini-Setup application is the version available
at the time of distribution. However, AJA’s documentation can be updated
regularly, so newer versions may exist.

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 19 www.aja.com
To download just the latest documentation, go to:
https://www.aja.com/family/ip-converters
Click the support button and open the Manuals link.
Installing eMini-Setup
PC Installation
To install eMini-Setup on a Windows PC:
1. Download the application from the AJA website. See "Acquiring eMini-Setup"
on page 18.
2. Open the AJA_eMini-Setup_win.zip le.
3. Double-click on the AJA_eMini-Setup.msi le.
4. The Setup Wizard will guide you through the installation.
Figure 12. eMini-Setup PC Wizard
5. Click Next to begin. Answer the questions in the subsequent dialogues,
including device software installation if displayed. When nished, an AJA
eMini-Setup shortcut will be installed on the desktop, and you will be able
to locate the eMini-Setup application in the AJA folder in the Programs
listing.
NOTE: If the eMini-Setup application already exists on the PC, a different Setup Wizard
appears.

IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 20 www.aja.com
Figure 13. eMini-Setup Wizard, Re-installation
With this screen you can Repair (reinstall) or Remove (uninstall) eMini-Setup on
the PC.
Mac Installation
To install the application on a Mac:
NOTE: Mac computers must be Intel-based (G5, G4 and earlier models will not work with
eMini-Setup).
1. Download the application from the AJA website. See "Acquiring eMini-Setup"
on page 18.
2. Unzip the le.
3. Double-click on the AJA eMini-Setup.dmg le.
4. Answer the prompt and a utility program will be launched.
Figure 14. eMini-Setup Mac Installer
5. To complete the installation drag the “AJA eMini-Setup” icon to the
Applications folder.
Running eMini-Setup
Connect your Ethernet capable AJA device to the PC or Mac via the supplied USB
cable, and then connect the external power supply (supplied) to that AJA device.
