Akko 3098 User manual

用户手册
User Manual

382 x 134 x 40mm
Approximately 1.05KG
China
Mechanical Keyboard
PBT Material
Type-C To USB
YES
YES
YES (use Akko Marco V1.0)
3098 Technical Specifications
11
Dimensions
Weight
Country of Origin
Type
Keycap
Interface
Multimedia Keys
N-Key Rollover
Custom Keys

3098 HotKeys
12
Hold down FN and press right Ctrl Revert Ctrl into Menu (APP) key
File Explorer
E-mail
Windows Search
Browser Homepage
Media
Fn+
F1
F2
F3
F4
F5
=
Pause/Playback
Previous Song
Next Song
Print Screen
Calculator
Fn+
F6
F7
F8
P
C
=
Mute
Decrease Volume
Increase Volume
M
<
>
W
Fn+ =
Swap W A S D
with ↑↓ ← →
Cal
PrtSc
Menu
Fn
W
C M < >
Ctrl
P
F1 F2 F3 F4 F5 F6 F7 F8

3098 System Commands
13
Press Fn and left Win key
Lock Windows Key
Hold down Fn and press ～ keyRestore Factory Settings
Win
~
Fn

3098S Single-Color Backlight
14
*Backlight function is only available on the backlight version of 3098s.
Lighting Effect 1
Lighting Effect 2
Lighting Effect 3
Lighting Effect 4
Del
Ins
PgUp
PgDn
Bright
Dim
Slower Animation
Faster Animation
“↑”
“↓”
“-”
“+”
Fn+ Fn+ ==
The adjustments on the left is for generic
lighting effects. Some lighting effects
cannot be tweaked.
For example, effects with constant light
can only adjust brightness as they don’t
have animation speed and direction.
Fn
Del Ins PgUp PgDn
+
↑
↑

Fn+ =
3098S Custom Backlight
15
1. The keyboard provides 4 groups of Fn + (F9 ~ F12) customizable lighting effects.
The system has 4 groups of default pre-loaded lighting effects that can be triggered.
2. Press Fn + (F9 ~ F12) to trigger custom lighting effects.
3. Edit custom lighting effects:
Step 1. Press Fn + (F9 ~ F12) to enter the custom lighting mode.
Step 2. Press Fn + (F9 ~ F12) again to start editing. Press to specify the desired illuminated keys for the
specific lighting effect group.
Step 3. Continue to press Fn + (F9 ~ F12) to save the changes.
Fn
F9 F10 F11 F12

Akko Macro V1.0
Macro Setup Instruction 1
16
1. Akko Macro V1.0 is hardware-based and works without software-driven.
2. The following keys cannot be programmed: "Esc", "Fn" and "Left Win".
3. Press and hold Fn + Win for 3 seconds to switch to the Macro mode. When the keyboard is re-connected or the
system is restarted, the Macro mode will be exited. You need to switch to the Macro mode again to use
programmed keys.
4. Akko Macro V1.0 does not support simultaneous trigger, that is, pressing "AB" at the same time will trigger the
two keys in the order of A followed by B.
5. Akko Macro V1.0 does not support customized interval time, that is, the trigger interval between key A and key
B cannot be defined and will follow the system's default trigger time.

Akko Macro V1.0
Macro Setup Instruction 2
17
Enter Macro Mode Start Macro Editor Macro Recording Fn + Custom Key
Exit Macro EditorExit Macro Mode
Fn + Custom Key
Record the next Key
Back to Default Mode Fn+Esc
Long Press Fn +Left Win Fn+Esc (End Recording)(Press Keys to Store)
Clear Macro：
If a key has been defined, after entering the Macro editor, you can press “FN + the key” to
clear its definition.
If you want to re-customize that key, press “FN + the key”again to start the new Macro
recording after clearing its old definition.

Akko Macro V1.0
Macro Setup Instruction 3
Step 1: Press Fn + left Win for 3 seconds to enter the Macro mode.
Step 2: Press Fn + ESC to launch Macro editor.
Step 3: Press Fn + A. This means we choose key “A” to record.
Step 4: Press A, K, K, O, G, E, A, R in order as replacement definition of “A”.
Step 5: Press Fn + A again to end the Macro recording of key “A”.
At this point, pressing “A” in notepad will display “AKKOGEAR”.
If you want to create a Macro for key “B”, press Fn + B to start the Macro recording.
Step 6: Press Fn + Esc to exit Macro editor.
Under the Macro mode, you can configure the keys and Macros you set.
Step 7: Press and hold Fn + Left Win for 3 seconds to exit the Macro mode and return to the default key definition.
Macro Recording Example: Define “A” as “AKKOGEAR”
18

19
Akko Macro V1.0 Calling Macros
Method A:
Enter the Macro mode by long pressing Fn+left Win. Then all keys will turn to pre-configured definitions with
locked Win key. Press Fn+Win to unlock Win key if necessary. In the Macro mode, you can use keys with
customized definitions.
Note, everytime you reboot or re-plugged the cable of the keyboard, the Macro mode will be turned off by
default and all keys will return to default definitions until you re-enter the Macro mode.
Method B:
Under the default key definition, you can also quickly call the customized content of specific keys through
“Fn+right Alt+the key that has been defined through Macro”. Note that you must first press Fn and then press
Alt to call the Macro.
