AKT BLSD-D-02-S User manual

BRUSHLESS DC MOTOR DRIVERS
Low Voltage BLDC Driver
Manual 1.6-0915
BLSD-D-02-S
AKT AUTOMATION TECHNOLOGY

AKT Automation Technology
www.aktmotor.com [e-mail]
1
1. System Characteristic:
Input voltage: 24VDC 36VDC 48VDC
Continuous current: 30A 25A 20A
Max. output power: 750W 750W 750W
Working temp.: 0~+45°C
Storage temp.:-20~+85°C
Working & storage humidity: <85% (no frosting)
Structure: wall-mountable box type
2. Basic Characteristic
Cooling: Radiator
Control terminals: Isolation
Protection: Over load, over heat, over speed, over voltage, lost voltage will cause the power abnormal.
Panel: 6 digit LED display, 4 digit keypad operation
--------------------------------------------------------------------------------------------------------------------------------------------
3. Installation attention
* Do not measuring or touch any components without housing while operating.
* Should check soleplate or change fuse 1minute later after power off.
* Operating without housing is forbidden.
* Make sure to connect the ground terminal, otherwise the brushless motor will working unsteadily
* Sudden damage while drives working, our company only affords the service and replace in guarantee.
Personal injury and motor damage caused by the accident will invalidate the guarantee.
----------------------------------------------------------------------------------------------------------------------------

AKT Automation Technology
www.aktmotor.com [e-mail]
2
Mounting Dimension: 166x102x67mm
4. Terminal and Signal
Control Terminal
No. Terminal Name Description
8 COM COM terminal
7 F/R CW/CCW terminal
6 EN Stop/Start terminal
5 BK Brake terminal
4 SV Analogy signal input terminal
3 PG Speed output terminal
2 ALARM Alarm output terminal
1 +5V +5V power output terminal
Hall Signal Terminal
No. Name Description
1 GND Hall sensor Negative
2 HA Hall sensor A phase
3 HB Hall sensor B phase
4 HC Hall sensor C phase
5 +5V Hall sensor Positive

AKT Automation Technology
www.aktmotor.com [e-mail]
3
Motor Connection Terminal
No. Name Description
1 DC+ DC+
2 DC- DC-
3 FG For the ground
4 U BLDC winding U phase(A)
5 V BLDC winding V phase(B)
6 W BLDC winding W phase(C)
5. Function and Usage
Choose any of the below speed command:
Build-in potentiometer: Speed reduced while CCW potentiometer, otherwise speed increased. Set the
potentiometer at minimum while use the external speed command.
External potentiometer: Connect on the GND and +5V of the drives, speed can be adjusted on external
potentiometer ((5K~100K) when connect SV terminal. Input simulate voltage through other control command (e.x. PLC,
SCM etc.) to SV terminal to achieve the speed adjust as well (relative GND). The range of the SV terminal is DC
0V~+5V, the relevant motor speed is 0~rated speed.
External digital signal speed regulation: Add 5V between SV and GND, speed can be adjusted by PWM control
between the 1KHz~2KHz, motor speed is influenced by duty. At this time, by adjusting the R-SV potentiometer, SV
digital signal amplitude can be 0~1.0 ratio attenuation processing. Generally, adjust R-SV to 1.0, SV input digital signal
without attenuation processing.
Motor running/stop control (EN)
Control the brushless motor to run or stop by controlling the terminal “EN” and “GND” connecting. The motor will
running when we connect the terminal “EN” to “GND”; if shut down, the motor will stop, and the stopping time will
decided by the motor inertia and load adding on the motor.
Motor rotation direction control (F/R)
Control the motor rotation direction by controlling the terminal “F/R” and “GND” connecting. When shut off terminal
“F/R” to terminal “GND”, the motor will run at CW (view from motor output side), and when connect on, the motor will
run at another direction. For avoiding to damage the driver, please stop the motor running and then change the motor
rotation direction.
Brake the motor to stop (BK)
Motor stop can be controlled by connect BK and GND terminal. When shut off the BK and GND terminal, motor
running, otherwise motor will fast stop. Motor stopping time is decided by the motor inertia and load adding on the

AKT Automation Technology
www.aktmotor.com [e-mail]
4
motor. If it is unnecessary to fast stop the motor, please don’t use this function since it has some electrical and
mechanical impact on the motor and controller.
Speed signal output (PG)
The speed pulse output port is 0C, output 30V/10mA max. You can connect with a resistance (3K ohm ~10K ohm)
between signal and input power to get the pulse signal, this port will output serial pulses which has fixed extent ( it is
50uS). This output pulse from every rotation of motor is 3 x N, “N” means the total pole number of the magnet. For
example, 2 pair of poles means 4 poles motor, 12 pulses per turning, when the motor speed is 500rpm, the pulses out
from the PG is 6000.
Alarm output
The alarm output port is 0C, output 30V/10mA max. You can connect with a resistance (3K ohm ~10K ohm)
between signal and input power to get the alarm signal. When alarm, this port and the GND is connecting (Low voltage),
and the controller will stop working and keep in alarm status.
Driver failure
Drivers enter to protection status while inner overload or over current, drivers and motor will stop automatic, the
blue led will flashed on the driver. The alarm can be released by reset the enable terminal (shut off EN and GND) or
switched off. Please check the motor connection wires when failure.
6. Display and keyboard

AKT Automation Technology
www.aktmotor.com [e-mail]
5
Display and Keyboard Operation
Remark: “SET”: Start/stop, (backspace)
“△” : “+”，Plus 1
“▽” : “-” , Minus 1
“ENT”: “ENTER” (call out setting parameter)
6.1 Parameter Setting Sequence
Please insure that the motor is under the stop situation when set the parameter. That is, in the case of panel
mode, the motor is in the stop state or an external port mode, the motor is enabled to disconnect
1. In standby condition, press “ENTER” to call out the system parameters, press “ENTER” again, it will call out the
parameter value.
2. Press “△”or “▽” to the parameter number. Press “SET” to return to standby mode if there is no need to change
value.
3. Press “ENTER” to show the parameter setting value. Press “SET” to return to standby mode if there is no need
to change value.
4. Press“△”or “▽” to the value demanded.
5. Press “ENTER” to save the changes, then press “SET” to return to standby mode.
Note: At setting mode, it will return to display interface if there is no press within one minute.
6.2 Working mode
Motor works at two modes. One is the panel mode; the other is external terminal control. The motor runs as the
setting, LED digital display shows the speed of motor. Under the panel mode, Press “SET” to start/stop the motor,
long press “△”or “▽” to acceleration or deceleration speed, press “ENTER” to insure and know the running speed.
The motor runs as setting speed.
6.3 Protect mode
While Motor operates abnormally, display will show ERR×
(1) Err-01: stall
(2) Err-02: over current
(3) Err-04: hall fault
(4) Err-05: stall and hall fault
(5) Err-08: under-voltage
(6) Err-10: over-voltage
(7) Err-20: peak current alarm
(8) Err-40: temperature alarm

AKT Automation Technology
www.aktmotor.com [e-mail]
6
6.4 Drives parameter setting:
P00X: Operating Parameter
Function
Code Function Name Setting Range Unit Default
value Change
P000 Control mode
00 External port mode
18 Panel control mode
485 communication control mode
00
External
port mod
P001 Pair of Pole 1~255 Pairs 2
P002 Rated Speed 1~65535
(external port mode effective ) RPM 3000
P003 Display mode
00: speed display
01: PWN speed adjustment
02:segmental speed adjustment
80:current display
00
P004
No sense starting
torque
1~255 16
P005
Initial speed w/o sensor
start
1~255 04
P006 Acceleration time 1~255 0.1S 0
P007 Deceleration time 1~255 0.1S 0
P008 Current setting 1~255 44
P009 Temperature alarm 1~255 34
P010 Panel speed setting 1~65535
only external port mode effective RPM 2000
P011 Brake force 0-1023 1023
P012 Site address 0~250 1
P013 Reserved
P014
Current adjusting
parameter
0-FF Hexadeci
mal 3A
P015 Reserved
P016
Per speed at Segmental
speed adjusting

AKT Automation Technology
www.aktmotor.com [e-mail]
7
7. System usage
Connect on the wires of the motor and driver (motor winding wires, Hall sensor and power supply) strictly as
request. It can not achieve the CW and CCW through changing the wires connection like asynchronous motor. The
motor will run abnormality with the wrong wires connection, like brushless motor will shake much or heat quickly (the
temperature will up to 80 degree in seconds to 2 min.),and will damage the motor and driver.
Please run the motor while connect the power supply, Hall wires and drive power supply. Firstly set the
potentiometer to the minimum, press the start switch, increase the motor potentiometer a little, the motor should run. If
the motor does not run, or shaking, maybe did the wrong wires connection, please recheck the brushless motor wires
till the motor running normally.
8. Communication Mode
This communication model is used standard Mod bus protocol, implement national standards GB/T 19582.1 - 2008.
It is using RS485 two-wire serial link communication, Physical interface uses two 3.81mm spacing 3 core Phoenix
terminals, serial connection is very convenient. Transmission mode is RTU, testing mode is CRC, CRC start word is
FFFFH. Data mode is 8 bit asynchronous serial, 2 is stop bit, without invalid bit, Supports multiple communication rates
(see table of parameters)
Note: if the communication mode is required to control the motor, it must be under the internal speed adjustment mode.
No. address name Setting range Default unit
00 $8000 First byte: control bit state
Second byte: Hall angle and
motor poles
First byte:
Bit0: EN
Bit1: FR
Bit2: BK
Bit3: NW1
Bit4: NW
Bit5: KHX
Bit6: HR60
Bit7: KH
Second byte:
Bit0-7: poles 1-255
00H
02H
01 $8001 Maximum speed in analog
adjustment
0-65535 3000 Rpm
02 $8002 First byte: start torque
Second byte: start speed
without sense start
1-255
1-255
10H
04H
03 $8003 First byte: accelerate time
Second byte: decelerate
time
1-255 0
0
0.1s

AKT Automation Technology
www.aktmotor.com [e-mail]
8
04 $8004 First byte: max. Current
Second byte: temperature
alarm point
38H
30H
05 $8005 External speed setting 0-65535 2000 RPM
06 $8006 Brake force 0-1023 1023
07 $8007 First byte: site address
Second byte: reserved
1-250 1
0
08-0F $8008-$800F Segmental speed
value
10-17 $8010-$8017 reserved
18 $8018 Real speed
19 $8019 First byte: bus voltage
second byte: bus current
1A $801A First byte: control port state
Second: analog port value
Bit0: SW1
Bit1: SW2
Bit2: SW3
Bit3: SW4
1B $801B First byte: fault state
Second byte: motor running
state
Bit0: stall
Bit1: over current
Bit2: hall abnormality
Bit3: low bus voltage
Bit4: over bus voltage
Bit5:peak current
alarm
Bit6: temperature
alarm
Bit7: reserved
1C $801C-$801F Reserved
20 $8020 above illegal
Site address 8000H-8017H Read-write register
Site address 8018H-801FH Read-only register
Other address is illegal
8000: first byte:
EN: when NW=0，0: external EN low level effective 1: external EN high level effective
when NW=1，0: EN ineffective 1: EN effective
FR: when NW=0，0: external FR low level effective 1: external FR high level effective
when NW=1，0: FR ineffective 1: FR effective

AKT Automation Technology
www.aktmotor.com [e-mail]
9
BK: when NW=0，0: external BK low level effective 1: external BK high level effective
when NW=1，0: BK ineffective 1: BK effective
NW1: 0: external control effective （EN,FR,BK） 1: internal effective
NW: 0: Speed external effective, 1:speed internal internal effective(under panel speed adjusting mode, PWN speed
adjusting mode and segmental speed adjusting mode, it must set to 1)
KHX: stall alarm under the open loop w/sense mode. 0: stall alarm 1: NO alarm
HR60: 0: 120° hall control 1: 60° hall control temporarily not supported
KH: 0: closed loop control 1: open loop control
For example:
1. Write 1500 speed
01 06 80 05 DC 05 28 C8
2. Write 2 pair of poles EN start
01 06 80 00 19 02 2A 5B
3. Write EN stop
01 06 80 00 18 02 2B CB
4. Write brake
01 06 80 00 1D 02 28 9B
5. Checking the fault state
01 03 80 1b 00 01 DD CD
6. 01 06 80 00 19 02 2A 5B EN start 2 pair of poles
7. 01 06 80 05 D0 07 AC 09 Write 2000
8. 01 06 80 05 E8 03 BE 0A Write 1000
9. 01 60 80 00 18 02 2B CB EN stop
10. 01 06 80 00 19 01 6A 5A 1 pair of pole EN start
The write message is explained as follows
Message Explain
01 address
10 Function code
00 1B Start address register
00 05 The numbers of register
0A Total byte digits
02 58 Write the first register data
02 58 Write the second register data

AKT Automation Technology
www.aktmotor.com [e-mail]
10
00 F0 Write the third register data
00 03 Write the fourth register data
0D 40 Write the fifth register data
CD 83 CRC testing(from the address to the fifth register data)
The successful feedback message is explained as follows
message 01 10 00 1B 00 05 70 0D
explain address Function code The start register
address
The wrote
register number
CRC testing code
9. Communication wires connection
RS-485 communication can be carried out by using the RJ45 cable connector
The RJ45 connector pins are defined as follows:
Pin Function
8 GND
6 A
3 B
