Danfoss VLT CDS 803 User manual

Operating Guide
VLT® Compressor Drive CDS 803

Contents
1 Introduction 5
1.1 Purpose of this Operating Guide 5
1.2 Trademarks 5
1.3 Additional Resources 5
1.4 Manual and Software Version 5
1.5 Type Approvals and Certifications 5
1.6 Disposal 6
2 Safety 7
2.1 Safety Symbols 7
2.2 Qualified Personnel 7
2.3 Safety Precautions 7
2.4 Motor Thermal Protection 9
3 Installation 10
3.1 Mechanical Installation 10
3.1.1 Cooling Capacity 10
3.1.2 Side-by-side Installation 10
3.1.3 Drive Dimensions 11
3.2 Electrical Installation 12
3.2.1 Electrical Installation in General 12
3.2.2 IT Grid 12
3.2.3 Mains and Motor Connection 13
3.2.3.1 Introduction 13
3.2.3.2 Connecting to Mains and Motor 14
3.2.3.3 Relays and Terminals on Enclosure Sizes H3–H5 17
3.2.3.4 Relays and Terminals on Enclosure Size H6 18
3.2.4 Fuses and Circuit Breakers 18
3.2.4.1 Branch Circuit Protection 18
3.2.4.2 Short-circuit Protection 18
3.2.4.3 Overcurrent Protection 18
3.2.4.4 UL/Non-UL Compliance 19
3.2.4.5 Recommendation of Fuses 19
3.2.5 EMC-correct Electrical Installation 19
3.2.6 Control Terminals 21
3.2.6.1 Accessing the Control Terminals 21
3.2.6.2 Setting the Control Terminals to Run the Compressor 21
3.2.7 Electrical Wiring 22
ContentsOperating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / | 3Danfoss A/S © 2019.12

4 Programming 24
4.1 Local Control Panel (LCP) 24
4.2 Start-up Quick Guide for Open-loop Applications 26
4.3 Start-up Quick Guide for Compressor Functions 30
4.4 Start-up Quick Guide for Compressor Closed-loop Applications 31
4.5 Changes Made 36
4.6 Changing Parameter Settings 37
4.7 Accessing All Parameter via the Main Menu 37
4.8 Main Menu Structure 38
5 Troubleshooting 40
5.1 Acoustic Noise or Vibration 40
5.2 List of Warnings and Alarms 40
6 Specifications 43
6.1 Mains Supply 3x200–240 V AC 43
6.2 Mains Supply 3x380–480 V AC 43
6.3 EMC Emission Test Results 44
6.4 Special Conditions 45
6.4.1 Derating for Ambient Temperature and Switching Frequency 45
6.4.2 Derating for Low Air Pressure and High Altitudes 45
6.5 General Technical Data 46
6.5.1 Protection and Features 46
6.5.2 Mains Supply (L1, L2, L3) 46
6.5.3 Compressor Output (U, V, W) 46
6.5.4 Cable Lengths and Cross-sections 46
6.5.5 Digital Inputs 47
6.5.6 Analog Inputs 47
6.5.7 Analog Outputs 47
6.5.8 Digital Outputs 48
6.5.9 Control Card, RS485 Serial Communication 48
6.5.10 Control Card, 24 V DC Output 48
6.5.11 Relay Outputs, Enclosure Sizes H3–H5 48
6.5.12 Relay Outputs, Enclosure Size H6 49
6.5.13 Control Card, 10 V DC Output 49
6.5.14 Ambient Conditions 49
6.6 Options for VLT® Compressor Drive CDS 803 50
ContentsOperating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 /4 | Danfoss A/S © 2019.12

1 Introduction
1.1 Purpose of this Operating Guide
This operating guide provides information for safe installation and commissioning of the AC drive. It is intended for use by qualified
personnel. Read and follow the instructions to use the drive safely and professionally. Pay particular attention to the safety instructions
and general warnings. Always keep this operating guide available with the drive.
1.2 Trademarks
VLT® is a registered trademark for Danfoss A/S.
1.3 Additional Resources
Other resources are available to understand advanced drive functions and programming.
• The programming guide provides greater detail on working with parameters and shows many application examples.
• The design guide provides detailed information about capabilities and functionality to design motor control systems.
• Supplementary publications and manuals are available from Danfoss.
See www.danfoss.com for supplementary documentation.
VLT® Motion Control Tool MCT 10 software support
Download the software from the Service and Support download page on www.danfoss.com.
During the installation process of the software, enter CD-key 34544400 to activate the CDS 803 functionality. An activation key is not
required for using the CDS 803 functionality.
The latest software does not always contain the latest updates for the drive. Contact the local sales office for the latest drive updates (in
the form of *.upd files), or download the drive updates from the Service and Support download page on www.danfoss.com.
1.4 Manual and Software Version
This manual is regularly reviewed and updated. All suggestions for improvement are welcome.
Table 1: Manual and Software Version
Edition Remarks Software version
AQ321748767627xx-xx0101 New power sizes added to product range. 6.0–10 kW (8–15 hp): Version 2.0
18–30 kW (25–40 hp): Version 1.00
1.5 Type Approvals and Certifications
The following list is a selection of possible type approvals and certifications for VLT® Compressor Drive CDS 803 drives:
Introduction
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570| 5
Danfoss A/S © 2019.12

Name of certification Certification logo IP20
EC Declaration of Conformity ✓
UL listed ✓
UL recognized (only valid for CDS 803 - S096) ✓
RCM ✓
EAC ✓
UkrSEPRO
089
✓
VLT® Compressor Drive CDS 803 drives having S096 in the type code (400 V AC, 18.5–30 kW (25–40 hp)) are certified to UL/EN/IEC
60730-1. The drive is also designed for systems that have to be compliant with UL/IEC/EN 60335.
For more information on UL 508C thermal memory retention requirements, refer to the section Motor Thermal Protection in the
product-specific design guide.
1.6 Disposal
Do not dispose of equipment containing electrical components together with domestic waste.
Collect it separately in accordance with local and currently valid legislation.
Introduction
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570
6 | Danfoss A/S © 2019.12

2 Safety
2.1 Safety Symbols
The following symbols are used in this manual:
DANGER
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTICE
Indicates information considered important, but not hazard-related (for example, messages relating to property damage).
2.2 Qualified Personnel
To allow trouble-free and safe operation of the unit, only qualified personnel with proven skills are allowed to transport, store,
assemble, install, program, commission, maintain, and decommission this equipment.
Persons with proven skills:
• Are qualified electrical engineers, or persons who have received training from qualified electrical engineers and are suitably
experienced to operate devices, systems, plant, and machinery in accordance with pertinent laws and regulations.
• Are familiar with the basic regulations concerning health and safety/accident prevention.
• Have read and understood the safety guidelines given in all manuals provided with the unit, especially the instructions given in the
Operating Guide.
• Have good knowledge of the generic and specialist standards applicable to the specific application.
2.3 Safety Precautions
WARNING
HIGH VOLTAGE
AC drives contain high voltage when connected to AC mains input, DC supply, or load sharing. Failure to perform installation,
start-up, and maintenance by qualified personnel can result in death or serious injury.
-Only qualified personnel must perform installation, start-up, and maintenance.
Safety
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570| 7
Danfoss A/S © 2019.12

WARNING
UNINTENDED START
When the drive is connected to AC mains, DC supply, or load sharing, the motor may start at any time. Unintended start during
programming, service, or repair work can result in death, serious injury, or property damage. Start the motor with an external
switch, a fieldbus command, an input reference signal from the local control panel (LCP), via remote operation using MCT 10
software, or after a cleared fault condition.
-Disconnect the drive from the mains.
-Press [Off/Reset] on the LCP before programming parameters.
-Ensure that the drive is fully wired and assembled when it is connected to AC mains, DC supply, or load sharing.
WARNING
DISCHARGE TIME
The drive contains DC-link capacitors, which can remain charged even when the drive is not powered. High voltage can be
present even when the warning indicator lights are off.
Failure to wait the specified time after power has been removed before performing service or repair work could result in death
or serious injury.
-Stop the motor.
-Disconnect AC mains, permanent magnet type motors, and remote DC-link supplies, including battery back-ups, UPS, and
DC-link connections to other drives.
-Wait for the capacitors to discharge fully. The minimum waiting time is specified in the table Discharge time and is also
visible on the nameplate on top of the drive.
-Before performing any service or repair work, use an appropriate voltage measuring device to make sure that the capacitors
are fully discharged.
Table 2: Discharge Time
Voltage [V] Power range [kW (hp)] Minimum waiting time (minutes)
3x200 6.0–10 (8.0–15) 15
3x400 6.0–7.5 (8.0–10) 4
3x400 10–30 (15–40) 15
WARNING
LEAKAGE CURRENT HAZARD
Leakage currents exceed 3.5 mA. Failure to ground the drive properly can result in death or serious injury.
-Ensure the correct grounding of the equipment by a certified electrical installer.
Safety
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570
8 | Danfoss A/S © 2019.12

WARNING
EQUIPMENT HAZARD
Contact with rotating shafts and electrical equipment can result in death or serious injury.
-Ensure that only trained and qualified personnel perform installation, start-up, and maintenance.
-Ensure that electrical work conforms to national and local electrical codes.
-Follow the procedures in this manual.
CAUTION
INTERNAL FAILURE HAZARD
An internal failure in the drive can result in serious injury when the drive is not properly closed.
-Ensure that all safety covers are in place and securely fastened before applying power.
2.4 Motor Thermal Protection
Context:
This procedure is only valid for VLT® Compressor Drive CDS 803 - S096 (18.2–30 kW/VZH088–VZH170))
Procedure
1. Set parameter 1-90 Motor Thermal Protection to [4] ETR trip 1 to enable the motor thermal protection function.
Safety
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570| 9
Danfoss A/S © 2019.12

3 Installation
3.1 Mechanical Installation
3.1.1 Cooling Capacity
Table 3: H3–H4, 400 V
Cooling capacity 400 V IP20 enclosure
4 TR/VZH028 H3
5 TR/VZH035 H3
6.5 TR/VZH044 H4
Table 4: H4–H5, 200 V
Cooling capacity 200 V IP20 enclosure
4 TR/VZH028 H4
5 TR/VZH035 H4
6.5 TR/VZH044 H5
Table 5: H5–H6, 400 V
Cooling capacity 400 V IP20 enclosure
13 TR/VZH088 H5
17 TR/VZH117 H5
26 TRVZH170 H6
3.1.2 Side-by-side Installation
The drive can be mounted side by side but requires the clearance specified in table 6 above and below for cooling.
Table 6: Clearance Required for Cooling
Power [kW (hp)] Clearance above/below [mm (in)]
Size IP protection rating 3x200–240 V 3x380–480 V
H3 IP20 – 6.0–7.5 (8.0–10) 100 (4)
H4 IP20 6.0–7.5 (8.0–10) 10 (15) 100 (4)
H5 IP20 10 (15) 18.5–22 (25–30) 100 (4)
H6 IP20 – 30(40) 200 (7.9)
Installation
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570
10 | Danfoss A/S © 2019.12

NOTICE
With IP21/NEMA Type1 option kit mounted, a distance of 50 mm (2 in) between the units is required.
3.1.3 Drive Dimensions
e
f
a
e
e
f
a
d
e
A
a
b
B
C
D
e30bf984.10
Illustration 1: Dimensions
Table 7: Dimensions, Enclosure Sizes H3–H6
Enclosure Power [kW (hp)] Height [mm (in)] Width [mm (in)]
Size IP protection
rating
3x200–240 V 3x380–480 V A A (1) a B b
H3 IP20 – 6.0–7.5 (8.0–10) 255 (10.0) 329 (13.0) 240 (9.4) 100 (3.9) 74 (2.9)
H4 IP20 6.0–7.5
(8.0–10)
10 (15) 296 (11.7) 359 (14.1) 275 (10.8) 135 (5.3) 105 (4.1)
H5 IP20 10 (15) 18.5–22
(25–30)
334 (13.1) 402 (15.8) 314 (12.4) 150 (5.9) 120 (4.7)
H6 IP20 – 30 (40) 518 (20.4) 595 (23.4)/635 (25),
45 kW
495 (19.5) 239 (9.4) 200 (7.9)
1Including decoupling plate.
Table 8: Dimensions, Enclosure Sizes H3–H6
Enclosure Power [kW (hp)] Depth
[mm (in)]
Mounting hole [mm (in)] Maximum weight
Size IP protection
rating
3x200–240 V 3x380–480 V C d e f kg (lb)
H3 IP20 – 6.0–7.5 (8.0–10) 206 (8.1) 11 (0.43) 5.5 (0.22) 8.1 (0.32) 4.5 (9.9)
Installation
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570| 11
Danfoss A/S © 2019.12

Enclosure Power [kW (hp)] Depth
[mm (in)]
Mounting hole [mm (in)] Maximum weight
H4 IP20 6.0–7.5
(8.0–10)
11 (15) 241 (9.5) 12.6 (0.50) 7 (0.28) 8.4 (0.33) 7.9 (17.4)
H5 IP20 11 (15) 18.5–22
(25–30)
255 (10) 12.6 (0.50) 7 (0.28) 8.5 (0.33) 9.5 (20.9)
H6 IP20 – 30 (40) 242 (9.5) – 8.5 (0.33) 15 (0.6) 24.5 (54)
3.2 Electrical Installation
3.2.1 Electrical Installation in General
All cabling must comply with national and local regulations on cable cross-sections and ambient temperature. Copper conductors are
required. 75 °C (167 °F) is recommended.
Table 9: Tightening Torques for Enclosure Sizes H3–H6, 3x200–240 V & 3x380–480 V
Power [kW (hp)] Torque [Nm (in-lb)]
Enclo‐
sure size
IP protec‐
tion rat‐
ing
3x200–240 V 3x380–480 V Mains Motor DC con‐
nection
Control ter‐
minals
Ground Relay
H3 IP20 – 6.0–7.5 (8.0–10) 0.8 (7) 0.8 (7) 0.8 (7) 0.5 (4) 0.8 (7) 0.5 (4)
H4 IP20 6.0–7.5 (8.0–
10)
10–15 (15–20) 1.2 (11) 1.2 (11) 1.2 (11) 0.5 (4) 0.8 (7) 0.5 (4)
H5 IP20 10 (15) 18.5–22 (25–30) 1.2 (11) 1.2 (11) 1.2 (11) 0.5 (4) 0.8 (7) 0.5 (4)
H6 IP20 – 30 (40) 4.5 (40) 4.5 (40) – 0.5 (4) 3 (27) 0.5 (4)
3.2.2 IT Grid
CAUTION
IT Grid
Installation on isolated mains source, that is, IT mains.
-Ensure that the supply voltage does not exceed 440 V (3x380–480 V units) when connected to mains.
NOTICE
This is only relevant for 200–240 V and 380–400 V drives in power sizes 6.0–10 kW (8.0–15 hp).
Open the RFI switch by removing the screw on the side of the drive when at IT grid.
Installation
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570
12 | Danfoss A/S © 2019.12

e30bb612.10
1
1EMC screw
Illustration 2: IP20, 200–240 V, 380–480 V, 6.0–10 kW (8.0–15 hp)
On 380–480 V, 18.5–30 kW (25–40 hp) units, the RFI filter cannot be switched off.
3.2.3 Mains and Motor Connection
3.2.3.1 Introduction
The drive is designed to operate Danfoss VZH Compressors.
• Use a shielded/armored motor cable to comply with EMC emission specifications and connect this cable to both the decoupling
plate and the motor.
• Keep the motor cable as short as possible to reduce the noise level and leakage currents.
• For further details on mounting the decoupling plate, see VLT® Compressor Drive CDS 803 Decoupling Plate Installation
Instruction.
• Also see EMC-correct Installation in the 3.2.5 EMC-correct Electrical Installation
Installation
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570| 13
Danfoss A/S © 2019.12

3.2.3.2 Connecting to Mains and Motor
1. Mount the 2 screws in the mounting plate, slide the plate into place, and tighten fully.
-DC+DC
BR- BR+ U
V
W
99
M A I N S
95
RELA
Y 1 RELA
Y 2
- L
C +
e30ba261.10
2. Mount the ground cables to the ground terminal before mounting other cables.
Installation
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570
14 | Danfoss A/S © 2019.12

e30ba262.10
M
I N S
+DC
BR-
BR+
U
V
W
RELAY 1 RELAY 2
95
3. Connect the compressor to terminals U, V, and W, and then tighten the screws according to the torques described in 3.2.1 Electrical
Installation in General.
MOTOR
MO
T
OR
U
V
W
99
e30bt302.12
Installation
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570| 15
Danfoss A/S © 2019.12

Table 10: Connection of Compressor to Terminals
Drive terminals Compressor
U T1
V T2
W T3
4. Connect the mains supply to terminals L1, L2, and L3, and then tighten the screws according to the torques.
e30ba263.10
95
M
A
INS
+DC
BR-
BR+
U V
W
91
92
93
L1
L2
L3
RELA
Y 1 RELA
Y 2
5. Tighten support bracket on mains wires.
Installation
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570
16 | Danfoss A/S © 2019.12

3.2.3.3 Relays and Terminals on Enclosure Sizes H3–H5
e30bb634.10
1
2
2
3
4
M
ot
or
U
V W -DC
+DC
M
AINS
1Mains
3Compressor
2Ground
4Relays
Illustration 7: Enclosure Sizes H3–H5, IP20, 200–240 V, 6.0–10 kW (8.0–15 hp), IP20, 380–480 V, 6.0–22 kW (8.0–30 hp)
Installation
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570| 17
Danfoss A/S © 2019.12

3.2.3.4 Relays and Terminals on Enclosure Size H6
1
95
99
L1 91 / L2 92 / L3 93
U 96 /
V 97 /
W 98
03 02 01
06 05 04
2
3
4
e30bb762.11
1Mains
3Ground
2Motor
4Relays
Illustration 8: Enclosure Size H6, IP20, 380–480 V, 30 kW (40 hp)
3.2.4 Fuses and Circuit Breakers
3.2.4.1 Branch Circuit Protection
To prevent fire hazards, protect the branch circuits in an installation - switch gear, machines, and so on - against short circuits and
overcurrent. Follow national and local regulations.
3.2.4.2 Short-circuit Protection
Danfoss recommends using the fuses and circuit breakers listed in this chapter to protect service personnel or other equipment in case
of an internal failure in the unit or a short circuit on the DC link. The drive provides full short-circuit protection in case of a short circuit
on the motor.
3.2.4.3 Overcurrent Protection
Provide overload protection to avoid overheating of the cables in the installation. Overcurrent protection must always be carried out
according to local and national regulations. Design circuit breakers and fuses for protection in a circuit capable of supplying a
maximum of 100000 Arms (symmetrical), 480 V maximum.
Installation
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570
18 | Danfoss A/S © 2019.12

3.2.4.4 UL/Non-UL Compliance
To ensure compliance with UL or IEC 61800-5-1, use the circuit breakers or fuses listed in this chapter. Circuit breakers must be
designed for protection in a circuit capable of supplying a maximum of 10000 Arms (symmetrical), 480 V maximum.
3.2.4.5 Recommendation of Fuses
NOTICE
If malfunction occurs, failure to follow the protection recommendation may result in damage to the drive.
Table 11: Fuses
Fuse
UL Non-UL
Bussmann Bussmann Bussmann Bussmann Maximum fuse
Power [kW (hp)] Type RK5 Type RK1 Type J Type T Type G
3x200–240 V IP20
6.0 (8.0) FRS-R-50 KTN-R50 JKS-50 JJN-50 50
7.5 (10) FRS-R-50 KTN-R50 JKS-50 JJN-50 50
10 (15) FRS-R-80 KTN-R80 JKS-80 JJN-80 65
3x380–480 V IP20
6.0 (8.0) FRS-R-25 KTS-R25 JKS-25 JJS-25 25
7.5 (10) FRS-R-25 KTS-R25 JKS-25 JJS-25 25
10 (15) FRS-R-50 KTS-R50 JKS-50 JJS-50 50
18.5 (25) FRS-R-80 KTS-R80 JKS-80 JJS-80 63
22 (30) FRS-R-80 KTS-R80 JKS-80 JJS-80 63
30 (40) FRS-R-125 KTS-R125 JKS-R125 JJS-R125 80
3.2.5 EMC-correct Electrical Installation
General points to be observed to ensure EMC-correct electrical installation:
• Use only shielded/armored motor cables and shielded/armored control cables.
• Ground the shield at both ends.
• Avoid installation with twisted shield ends (pigtails), because it reduces the shielding effect at high frequencies. Use the cable
clamps provided.
• Ensure the same potential between the drive and the ground potential of PLC.
• Use star washers and galvanically conductive installation plates.
Installation
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570| 19
Danfoss A/S © 2019.12

B
a
c
k
OK
Com.
On
Warn.
Alarm
Hand
On Reset Auto
On
Menu Status Quick
Menu Main
Menu
L1
L2
L3
PE
Minimum 16 mm2
equalizing cable
Control cables
All cable entries in
one side of panel
Grounding rail
Cable insula-
tion stripped
Output con-
tactor
Motor cable
Motor, 3 phases and
PLC Panel
Mains-supply
Minimum 200 mm (7.87 in)
between control
cable, mains cable
and between mains
motor cable
PLC
protective earth
Reinforced protective earth
e30bb761.12
(6 AWG)
Illustration 9: EMC-correct Electrical Installation
Installation
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570
20 | Danfoss A/S © 2019.12
