Alacron FAST SERIES User manual

FASTSERIES
DIGITAL VIDEO RECORDER & PLAYER (DVRP)
USER’S MANUAL
30002-00396

ii
COPYRIGHT NOTICE
Copyright  2004 by Alacron Inc.
All rights reserved. This document, in whole or in part, may not be copied, photocopied,
reproduced, translated, or reduced to any other electronic medium or machine-readable form
without the express written consent of Alacron Inc.
Alacron makes no warranty for the use of its products, assumes no responsibility for any error,
which may appear in this document, and makes no commitment to update the information
contained herein. Alacron Inc. retains the right to make changes to this manual at any time
without notice.
Document Name: DVRP User’s Manual
Document Number: 30002-00396
Revision History: 1.0 Feb 23, 2004
Trademarks:
Alacronis a registered trademark of Alacron Inc.
AltiVecis a trademark of Motorola Inc.
Channel Linkis a trademark of National Semiconductor
CodeWarrioris a registered trademark of Metrowerks Corp.
FastChannelis a registered trademark of Alacron Inc.
FastSeriesis a registered trademark of Alacron Inc.
Fast4, FastFrame 1300, FastImage, FastI/O, and FastVisionare registered
Trademarks of Alacron Inc.
FireWireis a registered trademark of Apple Computer Inc.
3Mis a trademark of 3M Company
MS DOSis a registered trademark of Microsoft Corporation
SelectRAMis a trademark of Xilinx Inc.
Solarisis a trademark of Sun Microsystems Inc.
TriMediais a trademark of Philips Electronics North America Corp.
Unixis a registered trademark of Sun Microsystems Inc.
Virtexis a trademark of Xilinx Inc.
Windows, Windows 95, Windows 98, Windows 2000, Windows NT, and
Windows XPare trademarks of Microsoft
All trademarks are the property of their respective holders.
Alacron Inc.
71 Spit Brook Road, Suite 200
Nashua, NH 03060
USA
Telephone: [phone]
Fax: [phone]
Web Site:
http://www.alacron.com/
Email:
[email protected], or [email protected]

iii
TABLE OF CONTENTS
Copyright Notice ………………………………………………………………………………….. ii
Table of Contents ………………………………………………………………………………… iii
Manual Figures & Tables ………………………………………………………………..………. iii
Other Alacron Manual ……………………………………………………………………………. iv
I. INTRODUCTION ___________________________________________________ 1
II. Installation _______________________________________________________ 2
III. USER’S GUIDE ___________________________________________________ 3
A. Operating Modes ______________________________________________________ 3
B. Main Screen __________________________________________________________ 3
C. Video Mode Selection __________________________________________________ 3
D. Selecting Files for Record or Replay ______________________________________ 4
E. Recording and Playback Controls ________________________________________ 5
1. Record Mode _________________________________________________________________ 5
2. PlayBack / VideoOut Mode______________________________________________________ 5
F. Frame Converter ______________________________________________________ 6
G. Display Indicators _____________________________________________________ 7
1. Host Buffer __________________________________________________________________ 7
2. Board Buffer _________________________________________________________________ 7
3. Speed _______________________________________________________________________ 7
4. Time Elapsed _________________________________________________________________ 7
5. Time Remaining ______________________________________________________________ 8
III. TROUBLESHOOTING _____________________________________________ 9
IV. ALACRON TECHNICAL SUPPORT_________________________________ 10
A. Contacting Technical Support __________________________________________ 10
B. Returning Products for Repair or Replacements ___________________________ 11
C. Reporting Bugs_______________________________________________________ 12
LIST OF FIGURES
Figure 1: DVRP main screen........................................................................................................... 3
Figure 2: Select Mode dialog box................................................................................................... 4
Figure 3: Select Files dialog box ..................................................................................................... 5
Figure 4: Frame Converter dialog box............................................................................................. 7

iv
OTHER ALACRON MANUALS
Alacron manuals cover all aspects of FastSeries hardware and software installation and
operation. Call Alacron at 603-891-2750 and ask for the appropriate manuals from the list below
if they did not come in your FastSeries shipment.
• 30002-00148 ALFAST Runtime Software Programmer’s Guide & Reference
• 30002-00150 FastSeries Library User’s Manual
• 30002-00153 Fast I/O Hardware User’s Manual
• 30002-00155 FastMem Hardware User’s Manual
• 30002-00162 FOIL – F astSeries O bject I maging L ibrary User’s Manual
• 30002-00169 ALRT Runtime Software Programmer’s Guide & Reference
• 30002-00170 ALRT, ALFAST & FASTLIB Software Installation Manual for Linux
• 30002-00171 ALRT, ALFAST, & FASTLIB Software Installation for Windows NT
• 30002-00173 FastMem Programmer’s Guide & Reference
• 30002-00176 FastImage 1300 Hardware User’s Manual
• 30002-00180 Fast4 1300 Hardware User’s Manual
• 30002-00184 FastSeries Getting Started Manual
• 30002-00183 FastImage 1300 Camera Integration User’s Manual
• 30002-00185 FastVision Hardware User’s Manual
• 30002-00186 FastVision Software User’s Manual
• 30002-00187 FastFrame 1300 Hardware User’s Manual

1
I. INTRODUCTION
DVRP is a digital recording system that is based on the Alacron FastFrame1300 family of
frame grabbers. The application works under Windows 2000/NT/XP operating systems. The
DVRP system enables recording of video from a variety of digital and analog sources.
DVRP enables recording of high frame rate images to system disk files. The Frame rate to
the disk files depends on the hardware configuration.

2
II. INSTALLATION
Follow these instructions to install the DVRP software:
Insert the DVRP installation CD-ROM into your CD-ROM drive. Access your CD-ROM drive, go
to ”\Setup” directory and double click “DVRP-win2k-obj-x.y.z.exe” to run the DVRP installation.
Follow the “InstallShield Wizard” on screen instructions. After the installation is complete, reboot
the PC System to complete the software installation and the environment setup.

3
III. USER’S GUIDE
A. Operating Modes
The DVRP system operates as a dual-channel high-speed digital recording and playback
system. It can record continuous stream of images (frames) from two separate synchronized
digital cameras, each providing 40-60 Mpixels/sec. The DVRP system can be configured to
accept Camera Link, parallel LVDS, analog and all other input and output formats supported
by Alacron’s FastFrame FF1300 board.
The DVRP system controls are very simple and intuitive, similar in function to controls of a
typical Digital Camcorder, DVD player or VCR.
B. Main Screen
After starting the DVRP application user will see large main screen that can be positioned
anywhere in the system window. This screen combines two horizontal image display
windows, recording and playback indicators, and essential application controls.
Figure 1: DVRP main screen
During DVRP operations the main canvas will be horizontally split into 1024x512 pixels
windows to display each of the video channels in a separate window.
C. Video Mode Selection

4
The first step to start using the DVRP software is to select the camera type by opening the
“Select Mode” Dialog (Figure 2). This dialog enables you to select camera type to be used
for digital recording, configure system for visual playback of pre-stored video recordings, or
initiate video-out mode sending pre-recorded image stream over Camera Link or other type
of video interconnect. The “Demo Record” mode is available for self-diagnostic purposes. It
generates image stream using TriMedia processor on the FastFrame boards and exercises
DVRP system recording capabilities.
After selecting operating mode, the system loads appropriate software to frame grabber
boards and allocates buffers in the host system memory. Completion of the initialization
phase is signaled by highlighting / enabling the “Select Files” button, which was grayed-out
and not selectable before.
Figure 2: Select Mode dialog box
All cameras which will be used with the DVRP system must have corresponding camera
description file camera_name.cap stored in the %DVRP%\Capture folder. See appendix for
more details regarding relevant entries in the capture file.
D. Selecting Files for Record or Replay
This dialog enables you to select and/or create Folder on the RAID storage system for each
of the recording or playback channels. In addition, this dialog box provides optional Timer
selection to control operation during unattended recording.

5
Figure 3: Select Files dialog box
E. Recording and Playback Controls
1. Record Mode
a) RECORD button
Pressing the Record button starts image capture operation. Video frames captured from
the camera are stored first in the system memory in a circular buffer. An independent
execution thread stores video frames from the buffer on the RAID disks. During DVRP
operations, the image area at the main application window is continuously updated with
the latest video image from the camera at a refresh rate that depends on camera
characteristics and system configuration. The refresh rate might be lower then the
camera frame rate to prevent disturbance to system performance.
The capture operation continues until the user presses the Stop/Pause button or until
expiration of the predefined time period - if timer check-out box was selected in the
“Select Files” dialog
b) PAUSE button
Pressing the Pause button pauses the capturing operation until Record/stop button is
pressed.
c) STOP button
Once a recording command is initiated, the Stop button stops the acquisition process of
the images and storing of images to the buffer.
2. Playback / Video Out Mode
a) PLAY / PLAY-REVERSE button /

6
Pressing the Play button starts image playback operation. An independent execution
thread fetches frames from the disk and refills the buffer. During DVRP operations, the
image area at the main application window is continuously updated with the latest video
image. In playback mode, the video frame rate is user defined using rate controls on the
main windows. In Video Out mode, the video output frame rate is according to recorded
rate from the camera in Video Out mode. Changing the frame rate parameter in the
output configuration file (output. cap), allows playing video out in reduced rate.
The playback operation continues until the user presses the Stop/Pause button or until
the end of file/s.
The play operation is enabled after choosing files, going to first/last frame or stepping
one frame.
b) PAUSE button .
Pressing the Pause button pause the video playing and enables the step by step
buttons.
c) STOP button
Pressing the Stop button stops the video playing/output and enables the First/Last
buttons.
d) First button
Pressing the First button jumps to the first frame in video stream. The system is ready to
play in either forward or backward directions.
e) Last button
Pressing the Last button move to the last frame and the system is ready to play in either
forward or backwards.
f) Next Frame button
Move to the next frame. The system is ready to play in either forward or backwards or
continuing stepping forward or backwards.
g) Previous Frame button
Move to the previous frame. The system is ready to play in either forward or backwards
or continuing stepping forward or backwards.
F. Frame Converter
DVRP Frame converter converts frames from internal DVRP unique file format into separate
file per frame in TIFF file format or into single multi page TIFF file.
To operate the converter, type the source file name in the Source Edit Box and press the
Load button. If the Source Edit Box left empty, a standard Windows Open File Dialog will
opened allow the user to select the desired file. After loading the file, several properties are
shown, including number of frames stored in the file and time stamps of beginning and end of
record. The converter allows converting partial selection of frames. The default is from the
first frame to the last available frame. In case of recording from more then one camera, the
conversion process should be performed per camera.
