Alba Fiber Systems AFS6514 User manual

Series AFS6514
Alba Fiber Systems Inc. Specifications are subject to change without notice. Page 1 11/21/13
www.albafiber.net [e-mail]
5 Ports Modular 10/100/1000BaseT(X) to 1000BaseFX Ethernet/Fiber Switch
4 x 10/100/1000BaseT(X) Ports, 1 x 1000M SFP Port
Installation/Operation Instructions
Fiber Optic 10/100/1000Mbps Ethernet Transmission System
Part Number: AFS6514
4-ch 10/100Mbps Ethernet Fiber Switch
Alba Fiber Systems, Inc.
265 E. Merrick Rd., Valley Stream, NY 11580
Tel: [phone] Fax: [phone]
E-mail: [email protected]
Web: www.albafiber.net
Document Version 1.0

Series AFS6514
Alba Fiber Systems Inc. Specifications are subject to change without notice. Page 2 11/21/13
www.albafiber.net [e-mail]
5 Ports Modular 10/100/1000BaseT(X) to 1000BaseFX Ethernet/Fiber Switch
4 x 10/100/1000BaseT(X) Ports, 1 x 1000M SFP Port
Table of Contents
1.0 Safety Instructions..................................................................................3
2.0 Fiber Installation Hints.................................................................................4
3.0 Product Description...................................................................................5
4.0 Product Features......................................................................................5
5.0 Installation.............................................................................................6
6.0 Product Signal Format & Specifications.......................................................6
7.0 Front Panel Pin-out Assignment Diagram....................................................7
8.0 Front Panel and Rear Panel LED Indicators..................................................8
9.0 Product Part Number Variations.................................................................8
10.0 Warranty................................................................................................9

Series AFS6514
Alba Fiber Systems Inc. Specifications are subject to change without notice. Page 3 11/21/13
www.albafiber.net [e-mail]
5 Ports Modular 10/100/1000BaseT(X) to 1000BaseFX Ethernet/Fiber Switch
4 x 10/100/1000BaseT(X) Ports, 1 x 1000M SFP Port
1.0 Safety Instructions
The optical devices used in this equipment are Hazard Level 1M. As required by IEC60825-1, the
installer is responsible for insuring that the label depicted below is present in the restricted locations
where this equipment is installed.
This assembly contains parts sensitive to damage by electrostatic discharge (ESD).
Use ESD precaution procedures when touching, removing or inserting parts or
assemblies.
Units are not waterproof; please install in an appropriate NEMA Enclosure.
When units are installed in extremely hot environments, the metal enclosures
may become hot to the touch. Please install is restricted areas where properly
trained personnel have access.
The safety information contained in this section, and on other pages of this manual,
must be observed whenever this unit is operated, serviced, or repaired. Failure to
comply with any precaution, warning, or instruction noted in the manual is in violation
of the standards of manufacture, warranty and intended use of the unit. ALBA assumes
no liability for the customer’s failure to comply with any of these safety requirements.
LASER RADIATION CAUTION:
DISCONNECTED OPTICAL CONNECTORS MAY EMIT OPTICAL ENERGY.
DO NOT VIEW BEAM WITH OPTICAL INSTRUMENTS (MAGNIFIERS).
This product contains Class 1M lasers
•Class 1M laser product according to IEC60825-1:1993+A1+A2
•CAUTION: Use of controls or adjustments or procedures other than those specified
herein may result in hazardous radiation exposure.
•Precautions should be taken to prevent exposure to optical radiation if the internal PCB removed
from its enclosure or when the fiber is disconnected from the unit.
•Laser radiation may be present on a fiber connection to this unit even when the power has been
removed from the unit.
•This unit is intended for installation in locations where only trained service personnel have
access to the fiber connections.
•The optical connectors are listed in the Connection Diagrams and Function section of this
manual.
•Optical outputs and wavelengths are listed in the Specifications section of this manual.

Series AFS6514
Alba Fiber Systems Inc. Specifications are subject to change without notice. Page 4 11/21/13
www.albafiber.net [e-mail]
5 Ports Modular 10/100/1000BaseT(X) to 1000BaseFX Ethernet/Fiber Switch
4 x 10/100/1000BaseT(X) Ports, 1 x 1000M SFP Port
2.0 Fiber Installation Hints
Fiber Information
Alba Fiber Transmission Systems are manufactured with optical connector covers to keep them
from accumulating dirt. In addition to safety precautions, our manual also provides the following
guidelines when working with optical fibers.
Please maintain optical fiber connectors as clean as possible to reduce loss of optical
transmission output. Cleanliness is extremely important to proper operations.
1. Protect optical connectors by leaving the connector covers in place on unused fiber
connections and on the fiber tips themselves.
a. Personnel who remove and replace fiber connectors or fiber pigtails should be equipped
with a fiber cleaning kit. These are available as off-the-shelf items from a supplier of fiber
optic accessories.
b. Propyl Alcohol and lint-free tissue or cloth may be used to clean fiber connector tips.
c. Do not use rubbing alcohol mixed with water. This can cause additional spots.
d. Clean the fiber by pulling the connector tip across the tissue, then turn the connector 90
degrees and repeat it in a different spot on the tissue.
e. Don’t pull the fiber across and then push it back. This will put the dirt that was cleaned off
back on again.
f. Repeat the process on a dry, folded tissue.
2. When removing fiber cables from fiber system ports, it is good practice to clean them again.
3. Installer must pay attention to the bend radius of the fibers. A general rule is to have a 3-
inch (8cm) bend radius. A bend radius less than 3 inches may cause attenuation also known
as optical signal loss.
4. Installers of fiber equipment should be equipped with an Optical Light Source an Optical
Power Meter to measure the optical inputs and outputs in a system. These instruments are
available from Alba at great savings, especially to our customers. The use of these tools will
save much time and effort in getting optical communications links up and running. Properly
equipped and trained installers can quickly determine the source of any problems that occur.

Series AFS6514
Alba Fiber Systems Inc. Specifications are subject to change without notice. Page 5 11/21/13
www.albafiber.net [e-mail]
5 Ports Modular 10/100/1000BaseT(X) to 1000BaseFX Ethernet/Fiber Switch
4 x 10/100/1000BaseT(X) Ports, 1 x 1000M SFP Port
3.0 Product Description
The ALBA FIBER SYSTEMS Series AFS6514 is Ethernet/Fiber Switch designed to transmit and
receive 4-ch 10/100/1000Mbps data over one user selectable SFP options. Available in
commercial temperature grade, units feature half or full duplex mode and Auto-Negotiation to
10/100/1000Mbps Ethernet rate without adjustments. The optical interfaces operate at a
1000Mbps rate. Plug-and-play design ensures ease of installation and no user electrical or
optical adjustments required. Features included are low power consumption, LED indicators for
monitoring equipment link and performance operating status and auto resettable voltage
transient fuses. With 12-48VDC input voltage on standalone, industry highest density15 card
slots, 1 PSU or 13 slots and 2 PSU per19"Lx4U Rackmount Chassis, the Series AFS6514 are
outstanding products for transmission of 4-ch 10/100/1000Mbps Ethernet signals.
4.0 Product Features

4 x 10/100/1000Mbps Ethernet Ports
1 x 1000BASE-FX SFP Port (SC or LC)
Copper port supports Auto-Negotiation for 10Mbps or
100Mbps or 1000Mbps, full or half duplex mode
Optical port supports 1000 Mbps full duplex data
Automatic MDI/MDI-X crossover cables
Transparent to data encoding/compatible with
major data protocols; IEEE 802.3 compliant
No Electrical or Optical User Adjustments
Performance and Link Status Indicator LEDs
Voltage Transient Protection on Power/Signals
Auto Resettable Fuses on Power Lines
Hot-Swappable Rackmount Cards
Designed with Lowest Power Consumption
Highest Density - 15 Slots and Power Supply
12-48VDC Input Voltage (Standalone)
90-130VAC or 180-264VAC (19" Chassis)
PoE or PoE+ selectable
Compliance with CE, FCC, ROHS

Series AFS6514
Alba Fiber Systems Inc. Specifications are subject to change without notice. Page 6 11/21/13
www.albafiber.net [e-mail]
5 Ports Modular 10/100/1000BaseT(X) to 1000BaseFX Ethernet/Fiber Switch
4 x 10/100/1000BaseT(X) Ports, 1 x 1000M SFP Port
5.0 Installation
The ALBA FIBER SYSTEMS Series AFS6514 products are interchangeable between Standalone
and Rackmount. Cards units occupy one slot in Alba’s standard 19"x4U chassis series AFS945-1
with one power supply (total 15 cards) or ASF945-2 with 2 power supplies. To install card and
power supply, keep the orientation of Alba logo on top and slide onto the top and bottom card
guides in the chassis. Press securely on the top and bottom of the card to ensure that it is fully
seated so that the electrical connector mates with the chassis-mounted motherboard. Once
installed, manually tighten the two thumbscrews located at the top and bottom of the card. Do
not use tools to secure these and do not over tighten.
6.0 Product Signal Format & Specifications
The tables below identify the specifications for the various signals that these fiber switches.
.
CONNECTORS
Optical
SC or LC (SFP)
Power
Terminal Block
Ethernet
4 x RJ-45
OPTICAL PARAMETERS
Fiber
SFP Dependent
Wavelengths (MM)
850/1310nm
Wavelengths (SM)
1310/1550nm
DATA
Data Interface
4 x 10/100/1000BaseT(X)
RJ45 ports
Data Rate
10/100/1000Mbps
IEEE 802.3 Compliant
Full Duplex or Half Duplex Electrical
Port / Full Duplex Optical Port

Series AFS6514
Alba Fiber Systems Inc. Specifications are subject to change without notice. Page 7 11/21/13
www.albafiber.net [e-mail]
5 Ports Modular 10/100/1000BaseT(X) to 1000BaseFX Ethernet/Fiber Switch
4 x 10/100/1000BaseT(X) Ports, 1 x 1000M SFP Port
7.0 Panels Layout and Pin out Assignment Diagrams
Figures 7.1 and 7.2 below show the front panel layout; Figures 7.3 below show the connector
diagrams of rear panel layout;
Figure 7.3: the connection diagram of rear panel
Figure 7.1: the layout of front
panel
Figure 7.2: the layout of front panel
in Card (rackmount) version

Series AFS6514
Alba Fiber Systems Inc. Specifications are subject to change without notice. Page 8 11/21/13
www.albafiber.net [e-mail]
5 Ports Modular 10/100/1000BaseT(X) to 1000BaseFX Ethernet/Fiber Switch
4 x 10/100/1000BaseT(X) Ports, 1 x 1000M SFP Port
8.0 Front Panel LED Indicators
Front panel mounted indicators to provide visual operational status of the card and each of the
channels. Below are listed and described the functions of the various LED indicators.
9.0 Product Part Number Variations
The table below lists the various part numbers associated with different versions of the products.
Figure 8.1: LED indicators of rear panel
AFS6514
LED STATUS INDICATORS
LED
indicator
lamp
Status
Explanation
Link/Act
On
Active Optic Signal
Blink
Active data connection
Power
On
Power is on and normal
ORDER INFORMATION
MODEL
DESCRIPTION
# FIBER
PORT
# COPPER
PORT
DISTANCE
AFS6514
4 x 10/100/1000BaseT(X)
Ports,
1 x 1000M SFP Port
1
4
See SFP options
for optional
distances, fiber
type and connector
type.
AFS6514-PoE
4 x 10/100/1000BaseT(X)
Ports PoE, 1 x 1000M SFP
Port
1
4 with PoE
AFS6514-PoE+
4 x 10/100/1000BaseT(X)
Ports PoE+,1 x 1000M SFP
Port
1
4 with PoE+

Series AFS6514
Alba Fiber Systems Inc. Specifications are subject to change without notice. Page 9 11/21/13
www.albafiber.net [e-mail]
5 Ports Modular 10/100/1000BaseT(X) to 1000BaseFX Ethernet/Fiber Switch
4 x 10/100/1000BaseT(X) Ports, 1 x 1000M SFP Port
10.0 Warranty
3 years warranty for product - please refer to Alba Fiber Systems warranty document.
Repair
If product is found to be defective, and user must contact a local distributors or re-
seller. In order to return any items for repair or credit, buyer must receive a dated Return
Materials Authorization form (RMA #), assigned by Alba Fiber Systems Customer Service
department. Please contact [e-mail] must be shipped prepaid, fully insured,
door to door service and clearly identified with RMA on package exterior or it will not be
accepted. Alba reserves the right to apply repair charges to any products that have been
dismantled or modified by anyone other than an Authorized Alba Security engineer.
Please attach a statement clearly describing the problem.
Alba will repair defective product under warranty free of charge to our customers.
Any unauthorized modification of hardware and software voids the warranty.
Warranty does not cover mishandling and/or abuse of the product.
Products comply with the following Safety Label for International Fiber Communication
Equipment.
NOTE: This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates uses and can radiate radiofrequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
Interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at this own expense.
Alba Fiber Systems
265 E. Merrick Rd.
Valley Stream, NY 11580, USA
www.albafiber.net
