ALC AMR300N User manual

QUICK START GUIDE
Wi-Fi Extender
Please read these instructions completely
before operating this product.
Model: AMR300N
Quick
Quick Simple
Set Up
ACCESSORY
®
Connecting- Option 2
uPlug Extender into standard wall outlet having 120V. After installation you can
change the location of the Extender.
vOn a cell phone, go
to your Wi-Fi
settings and
select ALC
Wireless-N.
You may get
a message
stating
Internet is not
available, this
is normal.
No password is required.
wOpen a browser
and enter
ap.setup.
The login
screen will
appear. Enter
the default
password,
“admin” and
click Login.
xThe Wireless page will appear.
Click Wizard at
the bottom of
the page. At the
Wizard page,
click Repeater.
ySelect your Wi-Fi network
and enter its
password. Name
your Extender
in the Extender
SSID field. Click
Connect.
Go back to your phone’s Wi-
Fi setting and
select your new
Extender’s SSID.
If asked after the
Extender reboots,
enter your main
Wi-Fi password.
UGo back to the web browser
and click Back.
Enter admin as
password again
to go back to the
Extender web
page. Select
Setup at the
bottom of the
page. Select
Time Zone and
click Apply. The
Extender is now
ready to use.
Configuring the Extender Wirelessly

1. Power On/Off Button: Press to turn the unit on
or off.
2. LAN Port: Connect Ethernet cable here to
connect devices to your router.
3. WPS/Reset Button: Press and hold for six
seconds to reset this Extender. Press and hold for
one to two seconds to connect to your AP Router.
WPS for client connection is not supported.
4. Status LED
ON: The Extender is powered on and working properly.
OFF: The Extender is not receiving power.
Blinking Slow: The network is disconnected.
Blinking Fast: The Extender’s WPS is connecting to your AP/Router.
Introduction
Hardware Default Parameters
Location Of Controls
Connecting- Option 1
CONNECTION TIP: If you want to keep the stable connection between your router and
this Extender while utilizing the Extender mode, make sure to install this Extender in the
most suitable position. A great way to do this is by checking the Wi-Fi signal on your
smartphone after this Extender is installed. If signal is below 2 bars, we recommend
changing the location.
IMPORTANT: This Wi-Fi Extender requires a 2.4GHz Wi-Fi router to connect to.
FCC: This device complies with Part 15 of the FCC rules. Operation is subjected to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any in-
terference that may cause undesired operation. Privacy of communications may not be ensured when
using this device. FCC ID: 2ACMYAMR300N - MODEL NUMBER AMR300N
uPlug Extender into standard wall outlet having 120V. After completing installation
you can change the location of the
Extender.
vPress and hold the WPS/Reset button for two seconds until the Status LED
starts blinking fast.
wWithin two minutes, press the WPS button on your wireless router for two to
three seconds. See your wireless router’s
owner’s manual for details.
This Extender will reboot and then
connect to your wireless router. Note the
Extender’s name (SSID) will be the same
as your home Wi-Fi plus “_EXT” on the
end. Ex. homewifi_EXT.
This ALC Wi-Fi Extender can be used in a number of ways with ALC devices:
• It extends the range of your Wi-Fi router to areas of your home or office where the signal is weak.
You can connect your ALC SightHD cameras to it to allow better positioning of them to cover
areas you may not have been able to before. You can even connect your phones, tablets and
laptops.
• It will allow you to add a wired Ethernet connection in locations that do not have one. After setting
up the Extender, you can then plug in an ALC Connect Hub or ALC Observer Monitor using
the Ethernet cable that came with it. This will allow you to place your Hub or Monitor in a more
convenient location that is more accessible to you.
Default IP.....................................192.168.10.1
Login Password...................................... admin
Wi-Fi SSID............................... ALC Wireless-N
URL...........................................http://ap.setup
Wi-Fi Key..................................................... No
Configuring using the WPS Button
The easiest method of connecting the unit is using the WPS button. Your wireless router must be
able to do this, see your wireless router’s owner’s manual for details.
RESET: If the WPS function is not working
or the Status LED does not blink, reset the
unit by pressing the WPS/Reset button
for six seconds.
This product includes software developed by third parties. These software codes are subject to either
the GNU General Public License (GPL), Version 2, June 1991 or the GNU Lesser General Public License
(LGPL), Version 2.1, February 1999. You can copy, distribute, and/or modify in accordance with the terms
and conditions of GPL or LGPL.
The source code should be complete, if you want us to provide any additional source code files under
GNU General Public License (GPL), please contact us. We are committed to meeting the requirements
of the GPU General Public License (GPL). You are welcome to contact our local office to get the
corresponding software and licenses. Please inform us your contact details (full address) and the product
code. We will send the CD with the software and license for free.
Please refer to the GNU GPL web site for further information.
http://www.gnu.org/licenses/licenses.en.html
