About This Guide
Related Documentation
The following related documents can found at enterprise.alcatel-lucent.com/userguides:
• OmniSwitch CLI Reference Guide
• OmniSwitch AOS Switch Management Guide
• OmniSwitch AOS Network Configuration Guide
• OmniSwitch AOS Advanced Routing Configuration Guide
• OmniSwitch AOS Data Center Guide
• OmniSwitch Transceivers Guide
Product Release Notes
Release Notes can be downloaded from the Customer Support website (account login required).
Customer Support
Web: support.esd.alcatel-lucent.com
Email: [email protected]

2
1 Chassis and Power

3
OmniSwitch 9900 Series
The Alcatel-Lucent Enterprise OmniSwitch 9907 11 RU modular LAN chassis.
OS9907 Chassis Specifications
Slots 7
Chassis Management Module (CMM) Slots 2
Chassis Fabric Module (CFM) Slots 4 (Slots CFM 3 and CFM 4 are currently inactive and are
reserved for future use.)
Network Interface (NI) Slots 5
Fan Trays 3
Power Supplies 4
Rack Unit Dimensions 11 RU
Dimensions (HxWxD) 49.02 x 44.2 x 58.42 cm (19.3 x 17.4 x 23 in)
Weight (RCB) 32.83 kg (72.24 lb)

4
Operating Temperature 0°C to 45°C (32°F to 113°F)
Storage Temperature 10°C to 70°C (14°F to 158°F)
Operating and Storage Humidity 10% to 90% (non-condensing)
Altitude 4000m/13,000 feet
OS9907 Chassis Specifications

5
Chassis Front Panel
OS9907 Front Panel Components
Slot 1 Supports Chassis Management Module (CMM) only
Slot 2 Supports a CMM (for 1+1 CMM redundancy) or NI module
(to maximize port count)
Slots 3 through 7 Support NI modules only
Slots PS1 through PS4 Support up to four load-sharing chassis power supplies,
offering N+1 redundancy
Wrist Strap Grounding Connector Location shown in diagram above

6
Chassis Rear Panel
Fan tray slot numbers are printed along the top-rear of the chassis.
OS9907 Rear Panel Components
Fan Tray Slots 1 through 3 Support three fan trays, with three fans per tray for N+1
fan redundancy
Grounding Block Location shown in diagram above
Wrist Strap Grounding Connector Location shown in diagram above

7
Chassis Rear Panel (Fan Trays Removed)
CFMs are located behind the chassis fan trays. To access a CFM, remove the fan tray in front of the
module. See “Removing Fan Trays” on page 50 for more information.
CFM slot numbers are printed along the top-rear of the chassis.
OS9907 CFM Location
Slots CFM1 through CFM4 For CFM module use only. Slots CFM1 and CFM2 are
currently supported; slots CFM 3 and CFM 4 are inactive
and reserved for future use

8
Chassis Management
OS99-CMM
The CMM manages system functions in the chassis. This includes controlling and monitoring NIs, fabric
modules (CFMs) and power distribution. The CMM also provides two (2) 40G QSFP+ uplink ports.
*Note. A driver is required for Micro-USB port operation. For information
on downloading the driver, refer to the OmniSwitch AOS Switch
Management Guide.
CMM Specifications
Port Types (pictured from left to right) • USB Type A: For storage devices that can download
code or save configuration information, such as flash-
based pen drives or external hard drives
• EMP (RJ45): 10/100/1000 Base-T with auto-
negotiation for out-of-band management (e.g.,
Telnet connection, diagnostics, downloading
software, etc.)
• Console (RJ45): For console or modem
• Console (Micro-USB*): For console or modem
• QSFP+ (Qty 2): 40G QSFP+ uplink ports
Power Consumption 64W
Number of Slots 2 (Slot positions 1 and/or 2. The slot 2 position may be
used for an NI module in lieu of a secondary CMM. Note
that, when an NI is installed in slot 2, CMM redundancy
is not provided.)
090992-10 C
40G
OS99-CMM
PRI VC FAB PS TEMP
USB
CONSOLE VFL / UPLINK
ABCD
12
ABCD
CLASS 1 LASER PRODUCT
EMP
0909
0909
0909
0909
909
0909
0909
0909
0909
0909
0
92 1
92 1
92 1
92 1
92-1
92-1
92-1
92 1
92 1
92 1
0 C
C
0 C
0 C
0 C
0 C
0 C
0
0
0
0
CLASS 1 LASER PRODUCT

9
LEDs
Backlit Status LED Located at the module product name at the upper-left corner of
the front panel
• Solid Blue: HW OK
• Blinking Blue HW Bootup or HW Failure
Speed LED (40G) • Solid Green: HW OK
• Solid Red: HW Failure
• Blinking Green: SW OK (Heartbeat); the module is booted
and operating normally
• Solid Yellow: SW System Failure
PRI • Solid Green: CMM has Primary status
• Blinking Green: CMM has Secondary status
• Solid Yellow: CMM not operating
• Blinking Yellow: Software upgrade in progress
VC Virtual Chassis (reserved for future use)
FAB • Solid Green: Fabric modules (CFMs) operating normally
• Solid Yellow: Fabric module (CFM) error
PS • Solid Green: Power supplies are operating normally
• Solid Yellow: Power supply error
TEMP • Solid Green: System temperature is normal
• Solid Yellow: System temperature error (e.g., overtemp)
• Blinking Yellow: Fan error
USB • Solid Green: USB device/drive connected
• Blinking Green:USB device/drive transferring data
EMP • Solid Green: USB Port Link
• Blinking Green: USB Port Link and Activity
VFL/UPLINK Refer to “QSFP+ LED Display” below.
QSFP+
LED Display Admin Status Link Status Transceiver Traffic VFL Port Speed 1G/10G (SFP+)
40G/4X10G
(QSFP+)
Off Down Down N/A N/A N/A N/A
Off Up Down No N/A N/A N/A
Solid Green Up Up Yes No No 10G (SFP+)
40G (QSFP+)

10
Note. Because OS99-CMMs provide splitter cable support on QSFP+ ports, port
LED behavior for these switches differs from other OS9900 modules. To manually
configure network LED colors, refer to the interfaces beacon command in the
OmniSwitch AOS Release 8 CLI Reference Guide.
Solid Yellow Up Up Yes No No 1G (SFP+)
4X10G (QSFP+)
SolidBlueUpUpYesNoYesN/A
Blinking
Green Up Up Yes Yes No 10G (SFP+) 40G (QSFP+)
Blinking
Yellow Up Up Yes Yes No 1G (SFP+) 4X10G (QSFP+)
Blinking
Blue Up Up Yes Yes Yes N/A
White N/A N/A Yes N/A N/A 4X10G
QSFP+
LED Display Admin Status Link Status Transceiver Traffic VFL Port Speed 1G/10G (SFP+)
40G/4X10G
(QSFP+)

11
Switch Fabric
OS9907-CFM
Each OS9907-CFM installed provides 1280Gbps of switch fabric bandwidth to chassis management and
the Network Interface (NI) modules. The chassis provides four (4) OS9907-CFM slots. The modules
connect to the chassis mid-plane and are located just behind the system fan trays.
CFM Specifications
Switch Fabric Bandwidth 1280Gbps
Number of Slots 4 (Slots CFM 3 and CFM 4 are currently inactive
and are reserved for future use.)
Power Consumption 119W

12
NI Modules
OS99-XNI-48
OS99-XNI-U48
OS99-GNI-48
Port Type Number of Ports Power Consumption
1/10 GigE Base-T 48 402W
Port Type Number of Ports Power Consumption
1/10 GigE SFP+ 48 305W
Port Type Number of Ports Power Consumption
10/100/1000 Base-T 48 56W
10G
2090990-10 C
24
25
13
12
37
36
48
OS99-XNI-48
0
0909
0909
0909
0909
0909
09
0909
0909
0909
0
90 1
90 1
90 1
90 1
90-1
90-1
90 1
90 1
C
C
C
0C
0C
0C
0 C
0 C
0
0
0
0
0
10G
2123 47
5689 10 11 12 13 14 15 16 17 18 19 20 21 23
22 24 25 26 27 28 29 33
30 31 32 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 090989-10 C
24
25
13
12
37
36
48
OS99-XNI-U48
0909
0909
0909
0909
0909
0909
0909
0909
0909
0909
0
89 1
89 1
89 1
89 1
89 1
89-1
89-1
89-1
89 1
89 1
0 C
C
C
0 C
0 C
0 C
0 C
0
0
0
0
0
CLASS 1 LASER PRODUCT
1G
2123 47
5689 10 11 12 13 14 15 16 17 18 19 20 21 23
22 24 25 26 27 28 29 33 30 31 32 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 090985-10 C
24
25
13
12
37
36
48
OS99-GNI-48
HPoE
0909
0909
0909
0909
0909
0909
0909
0909
0909
0909
0
85 1
85 1
85 1
85 1
85 1
85-1
85-1
85-1
85 1
85 1
0 C
C
C
0 C
0 C
0 C
0 C
0
0
0
0
0

13
OS99-GNI-P48
OS99-GNI-U48
Port Type Number of Ports Power Consumption
10/100/1000Base-T PoE 48 54W, excluding any attached
Powered Devices (PDs)
HPoE Ports Ports 1 through 8 support HPoE (75W). These ports are labeled
“HPoE” on the chassis front panel.
Port Type Number of Ports Power Consumption
1 GigE SFP 48 70W
1G
2123 47
5689 10 11 12 13 14 15 16 17 18 19 20 21 23
22 24 25 26 27 28 29 33
30 31 32 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 090986-10 C
24
25
13
12
37
36
48
OS99-GNI-P48
HPoE
0909
0909
0909
0909
0909
0909
0909
0909
0909
0909
0
86 1
86 1
86 1
86 1
86 1
86-1
86-1
86-1
86 1
86 1
0 C
C
C
0 C
0 C
0 C
0 C
0
0
0
0
0
CLASS 1 LASER PRODUCT
CLASS 1 LASER PRODUCT

14
NI Module LEDs
NI Module LEDs
Backlight Status LED Located at the module product name at the upper-left corner of
the front panel
• Solid Blue: HW OK
• Blinking Blue HW Bootup or HW Failure
Speed LED Located at the left side of the front panel and indicates the
maximum port speed for the module (e.g., 10G)
• Solid Green: HW OK
• Solid Red: HW Failure
• Blinking Green: SW OK (Heartbeat); the module is booted
and operating normally
• Solid Yellow: SW System Failure
Power Save LED Reserved for future use
Port Status LEDs • Solid Green: Non-PoE Port Link
• Blinking Green: Non-PoE Port Link and Activity
• Solid Yellow: PoE Port Link (PoE modules only)
• Blinking Yellow: PoE Port Link and Activity (PoE modules only)

15
Fan Trays
The chassis provides three (3) fan tray slots for chassis air and temperature control.
Fan Tray Specifications
Number of Fan Tray Slots 3 (with three fans per tray for N+1 fan redundancy)
Airflow Direction Front-to-back only
Hot Swapping Supported (Three fan trays are required at all times; removal of a
fan tray is allowed for fan tray or CFM field replacement only.)
Power Consumption 112W

16
Power Supplies
Note: Mixing of AC and DC power supplies is not supported. Mixing of Hi
(240VAC) and Low (110VAC) input is not supported.
OS99-PS-A (AC Power Supply)
OS99-PS-D (DC Power Supply)
OS99-PS-A Specifications
Input Voltage/Current 100 VAC (13.8A) to 240V AC (16.5 A)
Max Output Power/Current 1200 W/21.4 A
3000 W/53.5 A
Dimensions 1.63 in x 4 in x 17.2 in
Weight 4.8 lb (2.18 kg)
Hot Swapping Supported
Provides Power for System and PoE
OS99-PS-D Specifications
Input Voltage/Current -40 VDC to -72 VDC / 75 ADC (At input voltages > 40 VDC)
Max Output Power 2500 W (44 - 58 VDC)
Max Output Current 44.6 A @ 56 VDC
Dimensions 1.63 in x 4 in x 17.2 in
