Dormakaba RCI 960 User manual

1. Place the mortise cylinder through the 1-3/16” hole in
the center of the aluminum faceplate.
2. Mount the cylinder/switch bracket on the reverse side
of the faceplate as shown in the profile photos below.
Make sure that the teeth are positioned inside the
grooves along the cylinder.
Attach the cylinder nut to fasten.
3. Insert the switch(es) into the 1/2” holes located on
the bracket below the cylinder. For ideal installation
thread the top nut an 1/8” down and tighten bottom
nut using a 9/16” wrench.
4. Make wire connections per illustrations below.
5. Fasten keyswitch to electrical box with the tamper-
proof 6-32 machine screws and spanner hand tool
supplied.
Rear Profile
Optional DPDT Switch Connection
Side Profile
Instructions
TAMPER-RESISTANT KEYSWITCH
960
INSTALLATION
Red N/C
Black (Common)
Red N/O (Maintained)
Green N/O (Momentary)
(SPDT)
SPDT Wire Connection
IS960 PCN18003
R01-18TG
1-3/4"
(44mm)
1-3/16" (30mm)
2-3/4" (70mm)
3" (76mm)
1-11/16" (Narrow)
(43mm)
Narrow Style = 960N
N/C 1
(Red)
N/O 2
(White)
N/O 1
(White)
Common 2
(Black)
Common 1
(Black)
N/C 2
(Red)
1-1/2"
(38mm)
27/32" (Narrow)
(21.5mm)
1/2" (13mm)
Switch Mounting
Hole
4-3/4"
(120.6mm)
© 2018 dormakaba Canada Inc. | dormakaba Group
www.rutherfordcontrols.com • PHONE: [phone] • FAX: [phone] • E-MAIL: [email protected]

960 Pneumatic Time Delay Installation
1. Follow the same mounting steps 1 thru 3 as the
momentary and maintained switches on the front.
2. Make wire connections as shown below.
3. Fasten keyswitch to electrical box with the
tamperproof 6-32 machine screws and the spanner
hand tool supplied.
Specifications
Time Range: 2 to 60 seconds
Switch Rating: 10AMP @ 125-250VAC
Terminals: Solder type – Flying leads
Temperature Range:+15° to 120°F (-9° to +49°C)
To Decrease Time Delay:
Use slot screwdriver and turn time adjustment knob
counter clockwise.
To Increase Time Delay:
Use slot screwdriver and turn time adjustment knob
clockwise.
N/C (Red)
N/O (White)
960 Keyswitch Wiring Instructions
NOTE: Specifications are subject to change without notice.
Wire to Negative (-) of Power Supply
Black Wire
Green Wire
Red Wire
Wire to Positive (+) of Power Supply
NOTE: To wire LED for green light instead of red light —
disconnect red wire from switch point and connect green wire.
960 Bi-Color LED Installation
Description Switch Mode Switch Configuration Switch Rating Standard Finish
960-MO Key Switch Momentary Action SPDT N/O & N/C 3A @ 125 VAC/VDC & CSA
1A @ 250 VAC/VDC & CSA
28 or 40
28 or 40
960-TD Key Switch 2 to 60 seconds 1 x SPST N/O and 1 x SPST N/C 10A @ 125-250 VAC & CSA 28 or 40
960-MA Key Switch Maintained Action SPDT N/O & N/C 3A @ 125 VAC/VDC & CSA
1A @ 250 VAC/VDC & CSA
28 or 40
28 or 40
2-1/2" (64mm)
1-3/16" (30mm)
2-7/8"
(73mm)
© 2018 dormakaba Canada Inc. | dormakaba Group
