Alcolock LR max User manual

Installation manual
ALCOHOL INTERLOCK

Alcohol Countermeasure Systems Corp
60 International Boulevard
Toronto, Ontario M9W 6J2 CANADA
T [phone]
F [phone]
[email protected]
acs-corp.com
ACS, ALCOHOL COUNTERMEASURE SYSTEMS, ALCOLOCK, INTERTRACK and the “Molly” are
trademarks of Alcohol Countermeasure Systems (International) Inc. and are used under license. Alcohol
Countermeasure Systems is the trading style of Alcohol Countermeasure Systems (International) Inc.
© 2015 Alcohol Countermeasure Systems
The information disclosed in this document is the valuable property of Alcohol Countermeasure Systems and
all copyright and other proprietary rights to this document are reserved. No reproduction of this document is
permitted without the prior written consent of Alcohol Countermeasure Systems.

ALCOLOCK LR HANDSET COMPONENTS
*The navigation
buttons permit the
selection of
options shown on
the display.
Press the left,
right, or bottom
button to select
options, based on
the location on
the display.
Display
Cable input
HDMI port
Sampling
port
Navigation
buttons*
Mouthpiece Indicator light Air vent
FRONT VIEW
SIDE VIEW

TABLE OF CONTENTS
1.0 ALCOLOCKLRmaxalcoholinterlockproductprole 1
2.0 The ALCOLOCK LR max device installation manual 1
3.0 How to read this manual 2
4.0 Other required manuals 2
5.0 Parts and equipment supplied by ACS (the service provider) 3
6.0 Tools and equipment supplied by the service centre (service facility) 5
6.1 Power tools 5
6.2 Hand tools and test equipment 5
6.3 Other material 5
7.0 Installation overview 6
8.0 Inspecting the vehicle electrical system 6
8.1 Inspecting the vehicle battery 6
8.2 Inspecting the vehicle charging system 7
8.3 Inspecting the vehicle starting system 7
9.0 Mounting the ECU and antenna 7
10.0 Mounting the alarm horn 8
11.0 Mountingthealarmasher(ifrequired) 8
12.0 Mounting the retest alarm (for hearing- impaired) 9
13.0 Locating the tachometer signal wire 9
14.0 Connecting the alcohol interlock ECU cable 9
14.1 ECU cable-wire summary 10
14.2 ECU wire-connection steps 11
14.3 Alarm horn wire connection steps 13
14.4 Alarmasherwire-connectionsteps(ifrequired) 13
14.5 Retest alarm wire-connection step (install for hearing-impaired) 14
14.6 Tachometer wire-connection steps 14
14.7 OBD-II wire-connection steps 15
15.0 Attaching the HS and ECU 16
16.0 HS install procedure and ITE install transaction 17
16.1 Performing the HS install procedure 18
16.2 OBD-II Select 22
16.2.1 OBD / TACH 23
16.2.2 OBD speed 25
16.2.3 No OBD 26

16.3 Input odometer reading 27
16.4 Performing an ITE install transaction 28
17.0 Post-installation testing 29
18.0 Attaching the security enclosure 29
19.0 Sealing connections and restoring the vehicle 30
20.0 HS monitor procedure, ITE calibration and monitor transactions 31
20.1 Performing the HS monitor procedure 32
20.2 OBD-II Select 36
20.2.1 OBD / TACH 37
20.2.2 OBD speed 39
20.2.3 No OBD 40
20.3 Input odometer reading 41
20.4 Performing the ITE calibration and monitor transactions 42
21.0 Device removal overview 43
21.1 Running an HS removal procedure and ITE removal transaction 43
21.2 Performing the HS removal procedure 44
21.3 OBD-II Select 47
21.3.1 OBD / TACH 49
21.3.2 OBD speed 51
21.3.3 No OBD 51
21.4 Input odometer reading 53
21.5 Performing an ITE removal transaction 53
21.6 Removing ECU and restoring the vehicle 54
22.0 Recycling the ALCOLOCK LR max device 56
23.0 Tampering 56
23.1 Signs of tampering 56
23.2 Examples of tampering – before and after 56
23.3 Signs of tampering -- event log 58
23.4 Tamper Report Procedure 59
Appendixes 60
Appendix 1: Tamper report 60
Appendix 2: Glossary 61
Appendix 3: LR max circuit diagram (low-current vehicles) 64

ALCOLOCK LR max1
1.0 ALCOLOCK LR MAX ALCOHOL INTERLOCK PRODUCT
PROFILE
The ALCOLOCK LR max alcohol interlock controls the normal operation of a
vehicle through connection with the power, starter and control systems. To start
the vehicle engine, the driver must provide an accepted breath test with a breath
alcohol concentration (BrAC) below the preset limit. During operation of the
vehicle, the driver will be requested to provide additional breath tests to maintain
compliance with program requirements. The ALCOLOCK LR max device will
never cause the vehicle engine to stop.
The ALCOLOCK LR max device consists of a Handset (HS) to conduct breath
alcohol tests, and an Electronic Control Unit (ECU) that is connected with
the power and control circuits of the vehicle. The ALCOLOCK LR max device
includes a GPS/GPRS patch antenna–connected separately–for the real-time
transfer of critical log events.
The ALCOLOCK LR max device is used in alcohol interlock programs under the
direction of a jurisdictional authority and conforms to international regulations for
alcohol interlocks being used in compliance programs.
2.0 THE ALCOLOCK LR MAX DEVICE INSTALLATION
MANUAL
This manual contains procedures for the installation, monitoring and removal of
the ALCOLOCK LR max device, as well as wiring diagrams and a glossary of
terms.
ATTENTION!
•Failure to follow safety instructions can result in damage to the device and
personal injury
•This manual is intended for authorized service technicians only
•Before starting the engine, ensure that there is sufcient ventilation for vehicle
exhaust fumes. Failure to do so may cause injury
•Before starting the vehicle engine, ensure that the vehicle is in the park / neutral
position (with parking brake engaged) to prevent the vehicle from moving
•Before beginning the installation, ensure that the vehicle is functioning properly
(Refer to section 8.0 “Inspecting the vehicle electrical system” in this manual)
•If any vehicle components are not functioning, it is the client’s responsibility to
have the vehicle repaired before beginning the installation
•This device is intended for installation in vehicles with +12 volt or +24 volt
electrical systems
•The ALCOLOCK LR max alcohol interlock is a low current device. Use a
supplied external relay on vehicles with high-current starter circuits (above 2
amps)

INSTALLATION MANUAL 2
•Do not connect the alcohol interlock ECU to the ECU cable (13-001151) until
after the cable has been installed and visually inspected. Failure to do so may
result in damage to the ECU
•Read entire manual before operating the Automotive Diagnostic Tool
3.0 HOW TO READ THIS MANUAL
•For installation of the ALCOLOCK LR max device, read sections 5.0 to 20.0
of this manual in the order provided
•For wiring diagrams (with and without the external relay), refer to Appendices
3 and 4 of this manual
•For the HS install procedure (completed by following the steps on the HS
display), read section 16.0 of this manual
•For the HS monitor procedure (completed by following the steps on the HS
display), read section 21.0 of this manual
•For information about the tamper report procedure, refer to section 24.3 of
this manual
•Fortechnicaldenitionsandtermsrelatedtothealcoholinterlockprogram,
refer to the glossary in Appendix 2 of this manual
•For removal of the ALCOLOCK LR max device, read section 22.0 of this
manual in the order provided
4.0 OTHER REQUIRED MANUALS
•The ALCOLOCK LR device instruction manual provides information about
the general usage of the device
•TheALCOLOCKLRdevicecompliancemanualprovidesspecicprogram
requirements
•The INTERTRACKTM Enterprise (ITE) application manual provides
procedures for ITE transactions and is for authorized technicians only
•The ALCOLOCK LR device troubleshooting manual provides device error
and recall codes and is for authorized technicians only

ALCOLOCK LR max3
5.0 PARTS AND EQUIPMENT SUPPLIED BY ACS (THE
SERVICE PROVIDER)
This section lists parts supplied by ACS, which are required by the Service
Centre for the alcohol interlock program; including installation, monitoring,
calibration and removal of the ALCOLOCK LR max device.
Contact ACS to order the following parts (for contact information, refer to
acs-corp.com).
PART # PART QTY DESCRIPTION
79-007308 LR handset 1 To take a breath test
13-001100 LR handset cable 1 To connect the handset to the ECU
60-000251 LR instruction manual 1 Reference material
13-001151 LR max vehicle ECU
cable
1 To connect the ECU to vehicle circuits
04-000009 GPS/GPRS
glassmount antennae
1 For log and picture real-time
transmission
79-009130 LR max ECU 1 Prevents starting of the vehicle
79-008968 LR handset holder
assembly
1 In-vehicle handset holder
93-002334 LR max kit 1 LR max device hardware
95-000528 L install kit 1 L device hardware
21-000022 Terminal crimp ring 2 To mount wires
27-000026 Tie wrap 20 Securing wires / mounting hardware
27-000075 Tie wrap 5 Securing wires / mounting hardware
45-000054 Screw 2 Connecting ground wire to vehicle
59-000007 Plastic poly bag 1 Protective packaging
59-000017 Plastic poly bag 1 Protective packaging
79-000251 Heat shrink 7 To secure wiring, anti-tampering
79-009132 LR max security
enclosure assembly
1 Securing the ECU connector opening,
for anti-tampering
58-000730 LR max ECU security
enclosure top
1 Top of the security enclosure
58-000731 LR max ECU security
enclosure bottom
1 Bottom of the security enclosure
45-000143 Screw #2-56 x
½”, machine, pan,
Phillips, SS
2 To fasten the rear and front clips
58-000528 LR max security
enclosure plug
2 To cover screws (front clip)

INSTALLATION MANUAL 4
Accessories and consumable items for alcohol interlock program:
PART # PART DESCRIPTION
79-008953 External relay (12V) Additional relay (high-current starter
circuit)
79-008961 External relay (24V) Additional relay (high-current starter
circuit)
94-001960 Lampashermodule
(12V negative)
Visual alarm, vehicle indicators
94-001961 Lampashermodule
(12V positive)
Visual alarm, vehicle indicators
79-000300 Alarmasher Exterior visual alarm or interior retest
alarm for hearing-impaired
79-000916 Alarm horn Audible alarm
95-000145 Mouthpiece (bag of
25)
Inserting into HS, taking breath test
95-000305 Alcohol reference
solution (50 mg/dL)
Calibration
Other equipment for alcohol interlock program:
PART # PART DESCRIPTION
94-001950 Automotive
Diagnostic Tool
Testing wires and tach readings
94-001890 Digital tach sensor
(DTS)
Providing tach (rpm) signal to ECU
79-007302 Universal Calibration
Station (UCS)
Calibration and ITE transactions
79-008952 Download Station
(DS)
ITE transactions
93-002355 Presentation stand Product demonstration
13-001105 USB cable Connecting UCS to PC
79-008958 HS/UCS cable Connecting HS to UCS

ALCOLOCK LR max5
6.0 TOOLS AND EQUIPMENT SUPPLIED BY THE SERVICE
CENTRE (SERVICE FACILITY)
This section lists parts supplied by the Service Centre, which are required for the
installation, monitoring and removal of the ALCOLOCK LR max device.
6.1 POWER TOOLS
•Portable reversible battery operated drill with bits
•Electric soldering gun and spool of rosin core solder
•Portable butane soldering gun
•Heat-shrink gun
•Industrial-strength battery charger
6.2 HAND TOOLS AND TEST EQUIPMENT
•Automotivetachnder(forlocatingtach/rpmsignal)
•Digital multimeter with 10Mohm resistance
•Automotive battery load tester
•Wire stripper (16 to 28 gauge)
•Diagonal side-cutters
•Scissors
•Computer-safe test probe
•Mechanic’s trouble light with receptacles
•Setofscrewdrivers(Phillips,athead,Robertson)
•Socket / ratchet set (metric and imperial)
•Utility knife
•Needle-nose pliers
•Extension cord
6.3 OTHER MATERIAL
•Fender cover
•Electrical tape
•Shop towels
•Hand cleaner
•Eight 6” tie straps (for restoring the vehicle at end of program)
•Heat-shrink tubing: 3/16”, 1/4”, 3/32” and 3/8” sizes as required (for restoring
the vehicle at end of program)
•Fire wall probe
•Methyl hydrate cleaner

INSTALLATION MANUAL 6
7.0 INSTALLATION OVERVIEW
To install the ALCOLOCK LR max device, complete the following steps in the
order provided in this manual.
•Inspecting the vehicle electrical system
•MountingtheECU,alarmhorn,and(ifrequired)alarmasher
•(Skip if using OBD-II) Locating the tach signal (using DTS, if applicable)
•Connecting the ECU cable assembly, alarm horn and (if required) alarm
asher
•Attaching the GPS/GPRS antenna
•Connecting the tach wire or OBD-II assembly
•Running the HS install procedure and ITE install transaction
•Post-installation device testing
•Assembling the ECU security enclosure
•Sealing connections and restoring the vehicle
ATTENTION!
•If any vehicle components are not functioning, it is the client’s responsibility
to have the vehicle repaired before beginning the installation
•At end of program, the vehicle must be returned to the same condition as before
installation
•Install the device in a vehicle location that allows the least amount of drilling or
modication
•Use existing hardware and holes to minimize vehicle modication
•Before beginning installation ensure that there is sufcient ventilation for
vehicle exhaust fumes. Failure to do so may cause injury
•Before starting the engine, ensure that the vehicle is in the park or neutral
position, with parking brake engaged, to prevent the vehicle from moving
8.0 INSPECTING THE VEHICLE ELECTRICAL SYSTEM
Ensure that the vehicle electrical system is properly functioning by checking the
battery, starting and charging systems.
8.1 INSPECTING THE VEHICLE BATTERY
1. Visually inspect the battery for corrosion, cracks, holes, leakage, and other
damage.
2. Visually inspect the cleanliness of the battery case and posts.
3. Perform a battery load test on the vehicle battery and observe the battery
voltage. If the battery is detected to be fully discharged (dead), the client
must have the battery replaced elsewhere before continuing with the
installation.

ALCOLOCK LR max7
8.2 INSPECTING THE VEHICLE CHARGING SYSTEM
1. Visually inspect the condition of all wires and belts that connect to the starter,
alternator, and battery.
2. Check if the battery warning light on the dashboard is on, or observe the
voltmeter in the dashboard for at least 14 volts (for the 12 volt device), or at
least 26 volts (for the 24 volt device).
8.3 INSPECTING THE VEHICLE STARTING SYSTEM
If a vehicle starting problem is detected, attach a digital multimeter to the battery
terminals and observe the voltage as the vehicle engine cranks.
If the voltage is below 9 volts (for the 12 volt device), or below 19 volts (for the
24 volt device), or there is no cranking, it is the client’s responsibility to have the
vehicle repaired elsewhere before continuing the installation.
9.0 MOUNTING THE ECU AND ANTENNA
1. Locate an ECU mounting position that is convenient and accessible –
preferablyunderthedashboard.Ensurethatthereissufcientspaceforthe
ECU cable wires to be securely incorporated into the vehicle wire loom.
ATTENTION!
•The ECU and cabling must not obstruct the physical operation of the vehicle
•Do not install the ECU near the vehicle brake and accelerator pedals
2. Position the ECU so that it is elevated, with the cable connector opening
facing downwards. This is to protect the open side of the ECU from
contaminants, such as water leakage and dust.
3. Fasten the ECU to the mounting position with the supplied tie wraps.
NOTE: Always use existing hardware and holes to minimize vehicle
modication.
4. Ensure that the connection is tight and secure.
5. On the back of the antenna, there is double-sided tape. Peel the plastic
backingoffthetapeandafxtheantennatotheinsideofthewindshield.

INSTALLATION MANUAL 8
10.0 MOUNTING THE ALARM HORN
The alarm horn (79-000916) is installed under the hood and is wired to the
alcohol interlock ECU cable. It is programmed to activate when the client has
failed to respond to a retest request past the set limit.
ATTENTION! The alarm horn is intended for installation on vehicles with +12 volt
electrical systems only.
1. Locate an alarm horn mounting position under the hood. Ensure that there
issufcientclearancesothatclosingthehooddoesnotdamagethehoodor
the alarm horn.
2. Position the alarm horn facing downwards. This is to protect the alarm horn
opening from contaminants, such as water leakage and dust.
3. Mount the alarm horn bracket to the vehicle.
NOTE: Always use existing hardware and holes to minimize vehicle
modication.
4. Ensure that the connection is tight and secure.
5. Attach the alarm horn wires to a probe. Feed the wires through the vehicle
rewallandleavesufcientwireclearanceunderthedashboard.
11.0 MOUNTING THE ALARM FLASHER (IF REQUIRED)
Thealarmasher(79-000300)isinstalledtotheexteriorofthevehicle–usually
thefrontlicenseplate--andiswiredtothealcoholinterlockECUcable.Itashes
when the client has failed to respond to a retest request past the set limit.
NOTE: Skip this section if a retest alarm is not required.
ATTENTION! The alarm asher and cabling must not obstruct the normal operation
of the vehicle.
1. Locateanalarmashermountingposition–preferablyunderthefront
licence plate.
2. Mountthealarmasherbracketusingscrewsortiewraps.
NOTE: Always use existing hardware and holes to minimize vehicle
modication.
3. Ensure that the connection is tight and secure.
4. Attachthealarmasherwirestoaprobe.Feedthewiresthroughthevehicle
rewallandleavesufcientwireclearanceunderthedashboard.
NOTE: If possible, use existing wiring harness grommets.

ALCOLOCK LR max9
12.0 MOUNTING THE RETEST ALARM (FOR HEARING-
IMPAIRED)
Analarmasher(79-000300)maybeseparatelyusedasaretestalarmfor
hearing-impaired drivers. It is connected to the vehicle interior and is wired to the
alcoholinterlockECUcable.Itasheswhenaretestisrequired.Whenanalarm
asherisusedasaretestalarm,itusesadifferentECUwireconnectionthanthe
exterioralarmasher.
NOTE: Skip this section if a retest alarm is not required.
ATTENTION! The retest alarm (alarm asher) and cabling must not obstruct the
normal operation of the vehicle.
1. Locate a mounting position in the vehicle interior, within the driver’s view –
preferably on the dashboard.
2. Mountthealarmasherbracketusinganautomotivefasteningsystem
(27-000028).
3. Ensure that the connection is tight and secure.
4. Run the wires neatly to the ECU location under the dashboard.
13.0 LOCATING THE TACHOMETER SIGNAL WIRE
NOTE: Skip this section if the vehicle tach reading will be obtained using vehicle
OBD-II.
ATTENTION! Never use an individual coil pack or fuel injector as a tach source.
Doing so may damage the vehicle fuel injector.
Usethetachnderorthedigitalmultimetertolocateandverifythetachometer
signal wire.
To verify the rpm, (with the vehicle in park / neutral) press the accelerator pedal
and steadily increase the engine rpm.
NOTE: If a tachometer signal is not located, use a permanent Digital Tach Sensor
(DTS) (94-001890) on the alternator. Refer to the Automotive Diagnostic Tool
Instruction Manual (94-000196) and the Tach Sensor Installation Manual (60-000469).
14.0 CONNECTING THE ALCOHOL INTERLOCK ECU CABLE
Connect the ECU cable (13-001151) only after doing the following:
•Inspecting the vehicle electrical system
•MountingtheECU,alarmhorn,andalarmasher(ifrequired)
•Locating the tach signal (if OBD-II is not being used)
This section will provide an overview and steps for the connection of ECU cable,
alarmhornand(ifrequired)thealarmasher.

INSTALLATION MANUAL 10
ATTENTION!
•Do not solder or apply heat shrinks or tamper proof labels until all wires have
been attached, and post-installation testing has been performed
•The ALCOLOCK LR max alcohol interlock is a low current device. Use a
supplied external relay on vehicles with high-current starter circuits (above 2
amps)
•Do not connect the ECU cable to the ECU until instructed. This may result in
damage to the ECU
•Do not use the vehicle fuse panel for the wire connections. In most cases, it is
easily accessible and vulnerable to tampering
•To avoid damaging the ECU, always connect the ground wires to the
vehicle rst
•Each connection must be as neat and secure as possible – use solder point
connections and supplied heat shrinks
•Do not use clip or butt connectors to seal wiring, as this may lead to corrosion
and intermittent power
•Use supplied heat shrinks or tamper resistant labels on all solder connections.
Refer to section 20.0 of this manual
•Use supplied tie wraps to neatly incorporate wires into the vehicle wire
loom. Keep wires away from vehicle components that move, or that become
excessively hot
14.1 ECU CABLE-WIRE SUMMARY
The following table lists the wires from the ECU cable (13-001151), for basic
reference.
NOTE: Refer to Appendices 3 and 4 at the back of this manual for wiring diagrams
(with and without the external relay).
WIRE # COLOR CONNECTED TO:
12 Red +12 volt or +24 volt (main power)
1 Black Ground
3 White Ignition (+12 volt or +24 volt, switched on position
only)
2 Green Tachometer
4 Blue-White CAN-Low (CAN-)
5 Yellow-Red CAN-High (CAN+)
10 Blue-Yellow Starter (coming from the ignition switch)
9 Light Blue Starter (going to the starter)
20 Orange Alarm horn + (positive)

ALCOLOCK LR max11
13 Brown +12 volt (main power)
Retestasher(hearing-impaired)
WIRE # COLOR CONNECTED TO:
6 Pink 12 Volt Red wire on alcohol interlock ECU cable
11 Violet Redwireofthealarmasher
CAMERA COLOR CONNECTED TO:
4 Blue-White CAN-Low (CAN-)
8 Yellow-Red CAN-High (CAN+)
2 Black Ground
5 Red-Black VCAM+
14.2 ECU WIRE-CONNECTION STEPS
1. Prepare the ECU wires using the wire strippers, expose 1/2” of the ECU
wires.
2. Place the supplied heat shrinks over all wires in the table below, except ECU
wires 12 (Red), 1 (Black) and 13 (White).
79-000252 •Wire 17 (Light Blue)
•Wire 18 (Blue-Yellow) x2
79-000251
•Wire 7 (Green)
•Wire 20 (Orange)
•Wire 19 (Brown)
3. Fasten a ring terminal (21-000022) to ECU wire 8 (Black). Using the tamper-
proof screw (45-000054), connect the ring terminal to a vehicle ground point.
4. Using the computer-safe test probe, locate a continuous (un-switched)
source wire of +12 or +24 volts, from the vehicle main harness. Test the
source wire by moving the ignition switch through all positions (including
start and accessories). +12 or +24 volts must be present at all times.
NOTE: For vehicles with push-button keyless starters: refer to the vehicle
instruction manual for the ignition switch positions (e.g., start and accessories).
5. Expose 1/2” of the continuous (un-switched) source wire.
6. Twist the end of ECU wire 12 (Red) around the continuous (un-switched)
source wire.
NOTE: Twist the wire as follows:

INSTALLATION MANUAL 12
7. Using the computer-safe test probe, locate a non-continuous (switched)
source wire of +12 or +24 volts from the vehicle main harness. Test the
source wire by moving the ignition switch through all positions. +12 or +24
volts must be present only when the ignition switch is in the on or start
position, and must be absent in all the other positions.
8. Expose 1/2” of the non-continuous (switched) source wire.
9. Twist the end of ECU wire 13 (White) around the non-continuous (switched)
source wire.
10. Using the computer-safe test probe, locate the wire coming from the ignition
switch and going to the starter relay or solenoid (depending on the vehicle
make). This wire supplies the start signal.
11. Cut the wire (that supplies the start signal). Expose 3/4” of wire from each
cut end.
12. Move the vehicle ignition switch to the start position – the starter must not
engage.
ATTENTION!
•The ALCOLOCK LR max alcohol interlock is a low current device. Use an
external relay on vehicles with high-current starter circuits (above 2 amps)
•Refer to Appendix 4 at the back of this manual for the wiring diagram that
includes the external relay
13. Connect ECU wire 18 (Blue-Yellow) to the cut end of the wire coming from
the ignition switch.
14. Connect ECU wire 17 (Light Blue) to the cut end of the wire going to the
starter relay or solenoid (depending on the vehicle make).
NOTE: Step 13 and 14 connections should look as follows: (This illustration
shows a sealed connection – do not seal until the installation is veried. Refer
to section 20.0 of this manual.)
15. Use supplied tie wraps to neatly incorporate ECU wires with the vehicle wire
loom. Keep wires away from vehicle components that move, or that become
excessively hot.

ALCOLOCK LR max13
14.3 ALARM HORN WIRE CONNECTION STEPS
NOTE: Section 10.0 provides instructions for mounting the alarm horn and feeding
the alarm horn wires through the re wall with a probe.
1. Fasten a ring terminal (21-000022) to the black (ground) alarm horn wire.
Connect the ring terminal to the same vehicle ground connection used by
ECU wire 1 (Black).
NOTE: The ground connection should look as follows: (This illustration shows a
sealed connection – do not seal until the installation is veried. Refer to section
20.0 of this manual.)
2. Connect ECU wire 19 (Brown) to ECU wire 12 (Red).
3. Connect ECU wire 20 (Orange) to the red (positive) alarm horn wire.
4. Use supplied tie wraps to neatly incorporate the alarm horn wires with the
vehicle wire loom. Keep wires away from vehicle components that move, or
that become excessively hot.
14.4 ALARM FLASHER WIRE-CONNECTION STEPS (IF
REQUIRED)
NOTE: Section 11.0 provides instructions for mounting the alarm asher and feeding
the alarm asher wires through the re wall with a probe.
1. Fastenaringterminal(21-000022)totheblack(ground)alarmasherwire.
Connect the ring terminal to the same vehicle ground connection used by
ECU wire 1 (Black).
NOTE: The ground connection should look as follows: (This illustration shows a
sealed connection – do not seal until the installation is veried. Refer to section
20.0 of this manual.)
2. Connect ECU wire 19 (Brown) to ECU wire 12 (Red).
3. ConnectECUwire20(Orange)tothered(positive)alarmasherwire.

INSTALLATION MANUAL 14
14.5 RETEST ALARM WIRE-CONNECTION STEP (INSTALL
FOR HEARING-IMPAIRED)
NOTE:
•Skip this section if a retest alarm (for hearing-impaired drivers) is not required
•Section 12.0 provides instructions for mounting the retest alarm (alarm asher)
and feeding the wires to the ECU cable location
1. Fasten a ring terminal (21-000022) to the black (ground) retest alarm wire.
Connect the ring terminal to the same vehicle ground connection used by
ECU wire 1 (Black).
2. Connect ECU wire 16 (Pink) to the 12 Volt red wire on the alcohol interlock
ECU cable.
3. Connect ECU wire 15 (Violet) to the ECU wire 12 (red wire of the alarm
asher).
4. Use supplied tie wraps to neatly incorporate the retest alarm wires with the
vehicle wire loom. Keep wires away from vehicle components that move, or
that become excessively hot.
14.6 TACHOMETER WIRE-CONNECTION STEPS
NOTE:
•Skip this section if the vehicle tach reading will be obtained using vehicle OBD-II
•Section 13.0 provides instructions for locating the tach signal wire from under
the hood
Attach the vehicle tach signal wire to ECU wire 7 (Green).
Use supplied tie wraps to neatly incorporate the tach connection with the vehicle
wire loom. Keep wires away from vehicle components that move, or that become
excessively hot.

ALCOLOCK LR max15
14.7 OBD-II WIRE-CONNECTION STEPS
NOTE:
•Refer to hybrid installation guide for hybrid vehicles
•Skip this section if vehicle OBD-II was not used or unavailable, and a tach signal
was obtained from under the hood
THE OBD-II cable assembly (79-008959) is interfaced with the ECU and the
vehicle.
1. Locate the vehicle OBD-II connector that is attached to
the vehicle panel – usually located within 2 feet of the
driver’s wheel.
2. Detach the vehicle OBD-II connector from the vehicle
panel, keeping the wires connected.
3. Plug the vehicle OBD-II connector (detached in the
previous step) into the male connector of the OBD-II
cable assembly.
4. Mount the female connector of the OBD-II cable
assembly in place of the connector detached in step two.
To ECU cable
To vehicle OBD-II connector
detached from vehicle panel
To vehicle panel (in place of
vehicle OBD-II connector)
