ALDI HARBOUR HBRTLWRC120W User manual

12kg Top Load
Washing Machine
INSTRUCTION MANUAL
IM VERSION: V1.6 |MODEL: HBRTLWRC120W |PRODUCT CODE: 704357 |ISSUE DATE: 07/2021
SUPPORT: 1300 11 4357 |WWW.HARBOUR-APPLIANCES.COM.AU

02
Congratulations on purchasing your new Washing Machine.
All products brought to you by Harbour are manufactured to the highest standards
of performance and safety and, as part of our philosophy of customer service and
satisfaction, are backed by our comprehensive 3 Year In Home Warranty.
We hope you will enjoy using your purchase for many years to come.
Welcome

03
Contents
2 Welcome
4 Warranty Details
5 General Safety Instructions
8 Product Overview
9 Installation Instructions
13 Operation Instructions
20 Maintenance and Cleaning
22 FAQs and Troubleshooting
25 Specifications
26 Repair and Refurbished Goods or Parts Notice
27 Warranty Returns

04
The product is guaranteed to be free from defects in workmanship and parts for a period
of 36 months from the date of purchase. Defects that occur within this warranty period,
under normal use and care, will be repaired, replaced or refunded at our discretion. The
benets conferred by this warranty are in addition to all rights and remedies in respect of
the product that the consumer has under the Competition and Consumer Act 2010 and
similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage. You are also entitled to have the
goods repaired or replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
12kg Top Load Washing Machine
Congratulations!
REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION
You have made an excellent choice of this quality product. Our commitment to quality also includes our service. Should you, contrary to
expectations, experience defects due to manufacturing faults, ALDI will provide you with a warranty against defects as follows:
Warranty
The product is guaranteed to be free from defects in workmanship and parts for a period of 36 months from the date of purchase. Defects that occur within this
warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion. The benefits conferred by this warranty are in addition to
all rights and remedies in respect of the product that the consumer has under the Competition and Consumer Act 2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure
and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
Proof of Purchase
This warranty is valid for the original purchase and is not transferable. Please keep your purchase docket, tax invoice or receipt as the best proof of purchase, and
as proof of date on which the purchase was made.
Extent of Warranty
This warranty is limited to defects in workmanship or parts. All defective products or parts will be repaired or replaced.
Normal Wear and Tear
This warranty does not cover normal wear and tear to the products or parts.
118 Campbell Street, Collingwood, VIC 3066
Exclusions
This warranty does not cover:
• Any defects caused by an accident, misuse, abuse, improper installation or operation, lack of reasonable care, unauthorised modification, loss of parts,
tampering or attempted repair by a person not authorised by the distributor.
• Any product that has not been installed, operated or maintained in accordance with the manufacturer’s operating instructions provided with the product.
• Any product that has been used for purposes other than domestic use.
• Any damage caused by improper power input or improper cable connection.
To Make a Claim
This warranty against defects is provided by ALDI Stores, Locked Bag 56, St Marys Delivery Centre, NSW 2760, Phone [phone]. If a defect in the goods
appears within 36 months, you are entitled to claim a warranty, please contact or send all warranty claims to:
When making a return, please ensure the product is properly packaged so as to ensure that no damage occurs to the product during transit.
Please provide the original or a copy of the proof of purchase. Also please make sure you have included an explanation of the problem.
Please note that the costs of making a warranty claim, including any return postage, will be covered by the supplier identified above.
Please note upon receiving your warranty claim, the supplier will send, via the post or email, a repair and refurbished goods
or parts notice.
Please provide your email address and advise the supplier, if you wish to obtain a repair and refurbished goods or
parts notice via email.
AFTER SALES SUPPORT:
1300 11 4357
AUS
3
Hotline number: 1300 11 4357
Residentia Group Pty Ltd
Email: [email protected]
[email protected]
MODEL: SUC54EEW PRODUCT CODE: 62878 11/2018
IN HOME

05
General Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety
precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to.
Make sure you understand all instructions and warnings.
Keep the manual in a safe place for future reference, along with the completed warranty card and
purchase receipt. If you sell or transfer ownership of this product, pass on these instructions to the
new owner.
Always follow basic safety precautions and accident prevention measures when using an electrical
appliance, including the following:
IMPORTANT: Pay particular attention to messages that contain the words DANGER, WARNING or
CAUTION. These words are used to alert you to a potential hazard that can seriously injure you and
others. The instructions will tell you how to reduce the chance of injury and let you know what can
happen if the instructions are not followed.
USAGE CONDITIONS AND RESTRICTIONS
• Domestic use only: This appliance is intended for indoor household use only. It is not intended for
commercial, industrial or outdoor use. It is not intended for use in a recreational vehicle.
• Purpose: Do not use this appliance for anything other than its intended purpose. Other uses are not
recommended and may cause fire, electric shock or personal injury.
• Attachments: The use of attachments is not recommended by the appliance manufacturer and
distributor as they may be hazardous.
• Improper use: Damage due to improper use, or repairs made by unqualified personnel will void
your warranty. We assume no liability for any eventual damages caused by misuse of the product or
noncompliance with these instructions.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities or lack of experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
•The new hose-sets supplied with the appliance are to be used and that old hose-sets should not
be reused.
•The openings must not be obstructed by a carpet.
•This appliance is intended for indoor domestic (or household) use only, and is not intended for
commercial, trade or industrial use.
Model: HBRTLWRC120W
Washing Capacity: 12.0kg of dry clothes
Standard Water Pressure: 0.03-0.8MPa

06
GENERAL SAFETY INSTRUCTIONS CONT.
WARNING POTENTIAL ELECTRIC SHOCK
•This appliance is for indoor use only.
•Do not position washing machine in a humid place.
•Do not insert your hands into running spin-dry tub.
•If the spin-dry tub does not stop within 15 seconds after opening the cover, please stop using the
machine and have it repaired.
•Before performing any maintenance on the device, unplug the appliance from the mains.
•Always unplug the machine and turn off the water supply after use.
•The maximum inlet water pressure is 0.8MPa. The minimum inlet water pressure is 0.03MPa.
•To ensure your safety, power plug must be inserted into an earthed three-pole socket. Check carefully
and make sure that your socket is properly and reliably earthed.
•Make sure that the water and electrical devices must be connected by a qualified technician in
accordance with the manufacturer’s instructions and local safety regulations.
WARNING RISK TO CHILDREN
•The appliance can be used by children aged from 8 years an d above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
•Animals and children may climb into the machine. Check the machine before every operation.
•Young children should be supervised that they do not play with the appliance.
•Machine may be very hot during the operation. Keep kids and pets far away from the machine during
the operation very wet rooms as well as in the rooms with explosive or caustic gas.
•Remove all packaging before using the appliance. Otherwise, serious damage may result.
•The washing machine with single inlet valve only can be connected to the cold water supply. The
product with double inlet valves should be correctly connected to the hot water and cold water supply.
•Plug must be accessible after installation.
WARNING RISK OF EXPLOSION
•Do not wash or dry articles that have been cleaned in, washed in, soaked in, or dabbed with
combustible or explosive substances( such as wax, oil, paint, gasoline, degreasers, dry-cleaning
solvents, kerosene, etc.) This may result in fire or explosion.
•Before hand thoroughly rinse items of washing by hand.
CAUTION INSTALLING THE APPLIANCE
•This washing machine is for indoor use only.
•The appliance is not intended to for built-in use.
•The openings must not be obstructed by a carpet.
•Washing machine shall not be installed in bath room or very wet rooms as well as in the rooms with
explosive or caustic gases.
•Remove all packaging and transport bolts before using the appliance. Otherwise, serious damage
may result.
•Washing machines with single inlet valve only can be connected to the cold water supply. Models with
double inlet valves should be correctly connected to the hot water and cold water supply.
•Both the cold and hot water inlet hoses must be connected. If you only use one hose, some water may
be expressed through the other outlet.
•Plug must be accessible after installation.

07
GENERAL SAFETY INSTRUCTIONS CONT.
CAUTION RISK OF DAMAGING THE APPLIANCE
•Your product is only for home use and is only designed for the textiles suitable for machine washing.
•Do not climb up and sit on top cover of the machine.
•Do not lean against machine door.
•Please do not close the door with excessive force.
•Do not wash carpets.
CAUTION HANDLING THE APPLIANCE
•Transport bolts shall be reinstalled to the machine by a specialised person.
•The accumulated water shall be drained out of the machine.
•Handle the machine carefully. Never hold each protruded part on the machine while lifting.
•Machine door can not be used as the handle during the conveyance.
•This appliance is heavy. Transport with care.
CAUTION OPERATING THE APPLIANCE
•Before washing the clothes at first time, the product should be operated in one round of the whole
procedures without the clothes inside.
•Do not wash flammable and explosive or toxic solvents.
•Do not use gasoline and alcohol etc. as detergents.
•Please only select the detergents suitable for machine washing, especially for drum.
•Make sure that all pockets are emptied. Sharp and rigid items such as coin, brooch, nail, screw
or stone etc. may cause serious damages to this machine.
•Please check whether the water inside the drum has been drained before opening its door.
Please do not open the door if there is any water visible.
•Be careful of burning when the product drains hot washing water.
•Never refill the water by hand during washing.
•After the program is completed, please wait for two minutes to open the door.
RESPONSIBLE DISPOSAL
Note: At the end of its working life, do not throw this appliance out with your household rubbish. Electrical
and electronic products contain substances that can have a detrimental effect on the environment and
human health if disposed of inappropriately. Observe any local regulations regarding the disposal of
electrical consumer goods and dispose of it appropriately for recycling. Contact your municipal authorities
for advice on recycling facilities in your area. When the appliance is scrapped, disassemble the door to
prevent entrapment of any children.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such
waste separately for special treatment is necessary.
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse
of material resources. To return your used device, please use the return and collection
systems or contact the retailer where the product was purchased. They can take this
product for environmental
safe recycling.
For more detailed information about treatment, recovery and recycling of this product,
please contact your local city office, your household waste disposal service or the shop
where you purchased the product.

08
Product Overview
THE WASHING MACHINE
ACCESSORIES INCLUDED
1. Powder & liquid detergent box
2. Wash & Spin barrel
3. Impeller
4. Cabinet exterior
5. Adjustable feet
6. Handle
7. Glass lid
8. Program dial
9. Water inlet valve
10. Filter holder
11. Power cord and plug
12. Cabinet handle
13. Drain hose
14. Supply hose (cold water)
15. Supply hose (hot water)
16. Cabinet baseboard
Not shown but also included:
°1 × Instruction manual
°1 × Quick start guide
°1 × Warranty certificate
Key:
Note: The images in this user manual
are for reference only. Your appliance
may appear differently.
3
4
5
2
1
6
7
8
9
11
10
12
13
14 15 16

09
Installation Instructions
INSTALLATION INSTRUCTIONS
It’s recommended to use the washing machine on its own dedicated power
outlet for both convenience and safety. The power outlet must be grounded.
IMPORTANT
If the power cord (11) is damaged, it must be replaced by Residentia Group
or one of its authorised service representatives.
Please contact 1300 11 HELP (4357) and ensure the appliance is completely
disconnected from the power supply.
WARNING
Stability is important to prevent the product from moving!
Make sure that the product should not stand on the power cord (11).
Before installing the machine, the location must be:
•Rigid, dry, and a level surface
•Avoiding direct sunlight
•Sufficient ventilation
•Room temperature is above 0 °C
•Kept far away from the heat resources such as coal or gas.
UNPACKING THE WASHING MACHINE
WARNING
Packaging material (e.g. Films, Styrofoam) can be dangerous for children.
There is a risk of suffocation! Keep all packaging well away from children.
•Remove the cardboard box and styrofoam packing.
•Lift the washing machine and remove the base packing.
•Remove the tape securing the power supply cord and drain hose.
•Remove the inlet hoses (14 & 15) from the drum.

10
INSTALLATION INSTRUCTIONS CONT.
WARNING
To prevent leakage or water damage, follow the instructions in this chapter carefully:
•Do not kink, crush, modify, sever or protract the inlet hoses (14 & 15) or drain hose (13).
•Position drain hose properly, otherwise damage might result of water leakage.
•If drain hose is too long, do not force it into washing machine as it will cause abnormal noises.
There are two ways to place the end of drain hose:
1. For lower drain system
2. For upper drain system
LEVELLING THE WASHING MACHINE
WARNING
The lock nuts on all four feet must be screwed tightly against the housing.
1. Check if the legs are closely attached to the cabinet. If not, please turn them to their original positions
tighten the nuts.
2. Check alignment of the product with a spirit level and if required, correct.
3. Loosen the lock nut and turn the feet until it closely contacts with to the floor.
4. After being locked properly, press four corners again to make sure that they has been
adjusted properly.
Under 3m
Lock nut
Correct
Incorrect
Foot
Water
trough
Trough
Min. 86cm
Max. 100cm
Min. 86cm Max. 100cm
Hose
Retainer
Bind
Loosen
Raise Lower
Lock
Under 15cm
