Alert 550R LCD User manual

1

2
3
TABLE OF CONTENTS
A. TRANSMITTER OPERATION ...................................................................................................... 5
B. 2-WAY LCD REMOTE CONTROL TRANSCEIVER OPERATION ........................................................ 5
C. LED DISPLAY ........................................................................................................................... 6
D. CHIRP INDICATOR .................................................................................................................... 6
E. PARKING LIGHT........................................................................................................................ 6
F. SYSTEM OPERATION CONDITION ............................................................................................ 6
G. ACTIVE ARMING - ARM & LOCK .............................................................................................. 6
Ajar Warning
Silent Arming / Disarming
Shock Sensor By-Pass
Noiseless Mode
Hidden Alarm Function
H. PASSIVE ARMING..................................................................................................................... 7
Passive Arming with Passive Door Locking
Passive Arming By-Pass
I. ACTIVE DISARMING - UNLOCK & DISARM ................................................................................7
Pathway Illumination
Two Steps Door Unlock
Automatic Re-Arm
J. DISARMING WITHOUT A TRANSMITTER ................................................................................... 8
Overrides the Alarm without Password Pin Code
Overrides the AlarmWith Password Pin Code
K. VALET MODE ........................................................................................................................... 8
Enter Valet Mode
Exit Valet Mode
Remote Valet Mode
L. CAR LOCATOR .......................................................................................................................... 9
M. PANIC FUNCTION ..................................................................................................................... 9
N. SYSTEM’T STATUS CHECK ....................................................................................................... 9
O. DRIVER PAGING .................................................................................................................... 10
P. DOME LIGHT CONVENIENCE DELAY & SUPERVISION ........................................................... 10
Q. IGNITION CONTROL POWER LOCK/UNLOCK ......................................................................... 10
R. TRUNK RELEASE CHANNEL 3 OUTPUT .............................................................................. 10
S. CHANNEL 4 TIMMER CONTROL OUTPUT............................................................................... 11
T. CHANNEL 5 TIMER CONTROL OUTPUT.................................................................................. 11
U. CHANNEL 6 TIMER CONTROL OUTPUT ................................................................................. 11
INSTALLATION TIPS AND ACCESSORIES
For most vehicles we have a T-Harness available to make remote starter installation quicker and
easier. To order call 800-659-0764 or visit us online at www.directwholesale.net.
Additional remote transmitters can be purchased through direct wholesale at www.directwhole-
sale.net.
Your Alert remote starter is equipped with an interactive install cd and installation kit.The kit will
consist of a computer friendly test light, wire ties and a roll of tape. Use only the computer friendly
test light or volt meter when testing and probing wires.
ForTechnical assistance www.alertautomotive.com can provide a detailed wiring diagram for your
vehicle including additional helpful install tips.
JBS Technologies
225 Technology Way
Steubenville, OH 43952
WARNINGS
As with any product that performs automatic functions, there are certain safety precautions that
you must practice and be aware of.
1. Keep the transmitter out of children’s reach.
2. Do not leave anyone in the vehicle while running on remote control.
3. Alert servicing personnel that the vehicle can be started automatically.
4. Do not start the vehicle by remote while it’s in an enclosed area or garage.
5. Always apply the parking brake and lock the vehicle as you exit the vehicle.
6. The vehicle windows must be rolled up.
7. Should the unit malfunction, disconnect the fuse until the problem is corrected.
8. The use and operations of this system is the sole responsibility of the operator.
9. Some areas may have local ordinances that prohibit leaving a vehicle running on public streets.
10. Do not start the vehicle by remote while the standard transmission vehicle is parked at a steep
place.

4
5
REMOTE START OPERATION
A. TO REMOTE START THE VEHICLE...........................................................................................11
B. ENGINE START MEMORIZING FOR THE VEHICLE WITH STANDARD ...................................... 12
C. TO OPERATE THE VEHICLE WHILE RUNNING ON THE REMOTE START................................... 13
D. TEMPORARY STOP FEATURE................................................................................................. 14
E. TURBO TIMER MODE............................................................................................................. 14
F. TIMER/TEMPERATURE START............................................................................................... 14
G. TEMPERATURE CHECK .......................................................................................................... 16
H. TO TURN OFF THE REMOTE START......................................................................................... 16
I. SHUTDOWN INPUT FOR REMOTE STARTER......................................................................... 16
J. DISABLING THE REMOTE START SYSTEM.............................................................................. 17
LCD REMOTE TRANSCEIVER
A. BATTERY REPLACEMENT ....................................................................................................... 18
B. THE REMOTE LCD ICONS WITH FUNCTION .............................................................................. 18
C. PROGRAMMING OF THE LCD REMOTE TRANSCEIVER .............................................................. 19
1. Screen Lamp ON
2. Clear the Flash Icon and Melody Sound
3. Stop theTrigger Melody Sound
4. Vibration/Melody Mode
5. Low Battery Indication
6. Set Up Fixed Count Down (Parking) Timer
7. Out of Range Indication
D. TIMER SETTING ..................................................................................................................... 21
1. Timer Setting.
2. Alert Alarm Timer Setting
3. Count DownTimer Setting
4. Time Set-up for Daily Timer Start
OPERATION
A.TRANSMITTER OPERATION:
Transmitter
Button System Function Remark
Lock Doors & Arm System
Car Locator Upon armed
(3-seconds) Panic function Press and Hold for 3 seconds
+ Silent Arming / Disarming Ignition in“o”position
Unlock Doors & Disarm System
– Two Steps Door Unlock & Disarm System Press twice within 3 seconds
(2-second) Trunk Release (Channel 3) Press and Hold for 2 seconds
– Passive Arming By-pass While the system Disarmed
– – Remote Control Entry/Exit Valet Mode While the system Disarmed, Press
within 3 seconds
✱ –✱Activate orTurn O the Remote Start Press twice within 3 seconds
+ Channel # 4Timer Output
+ Channel # 5Timer Output
✱+ Channel # 6 Timer Output
B. 2-WAY LCD REMOTE CONTROL TRANSCEIVER OPERATION ONLY:
Transceiver Button System Function Remark
F – F – (C) System’s Status Check Press within 3 seconds
F – (·)Monitor IndoorTemperature Press within 3 seconds
F –✱ (æ)Daily Timer Start Press within 3 seconds
F (1 second) LCD screen lamp turns on for
5 seconds Press and hold for 3 seconds
F – F – F
Clear the Flashing Icon and
Melody Sound on the LCD
Screen Transmitter
Press within 3 seconds

6
7
C. LED INDICATORS
LED Status
O Disarmed
Slow ash Armed
Flash PAssive Starter Disabled
Fast ash Passive arming
On (solid) Valet mode
D. CHIRP INDICATORS E. PARKING LIGHT
Chirp Function Parking Light Function
1 chirp Arm 1 ash Arm
2 chirps Disarm 2 ashes Disarm
3 chirps Ajar
Warning 12 ashes Car locater
6 chirps Car locator Constant On Under Remote Start
F. SYSTEM OPERATING CONDITION
Horn Parking
Light LED Doors Starter Dome Light
1. Arming 1 or 3
Chirps 1 Flash Slow Flash Locking Disable
2. Disarming 2 or 4
Chirps
2 or 3
Flashes
Un-
locking
Turns on for
30-second
3. Passive Starter
Disable Fast Flash Disable
4. Panic Alarming Flashes Flashes
5. Car Locator 6 Chirps 12 Flashes Locking
G. ACTIVE ARMING - ARM & LOCK:
1. Press button on the transmitter.
2. The horn will chirp once and parking light will ash once indicating that the system is now
armed. The vehicle doors will lock upon
arming when interfaced with the security
system.
Clear The Flashing Icon: Press the F
button 3 times within 3 seconds will clear the
ashing icon on the LCD screen transceiver.
AJAR WARNING: If the siren sounds 3 chirps,
then you have left a door, trunk, or hood
lid ajar.
H. PASSIVE ARMING
Active arming / disarming is controlling your security system via the remote transmitter. This
security system is equipped with an optional Passive Arming feature, which allows the security
system to arm 30 seconds after the last door is closed. Operation is as follows.
1. Turn the ignition to the“OFF”position and exit the vehicle.
2. After all entrances are closed, the security system LED will ash fast for 30 seconds. If you
reopen any door / hood / trunk, the security system LED will stop ashing. It will begin ashing
again once the vehicle all entrances are closed.
3. After 30-second timer has elapsed, the security system will automatically“ARM”. The siren will
chirp [1] time and the parking lights will ash [1] time.
PASSIVE ARMING WITH PASSIVE DOOR LOCKING: The vehicle doors will automatically lock
after passive arming cycle has been completed.
PASSIVE ARMING BY-PASS: While the system disarmed, Press the button twice, the security
will respond with [1] chirp and LED will turn“ON”. The security system will remain in this tempo-
rally state for as long as you wish. To exit passive by-pass, press the transmitter or button
and the system will return to normal status.
I. ACTIVE DISARMING - UNLOCK & DISARM:
1. Press button on the transmitter.
2. The horn will chirp twice and parking light will ash twice to indicating that the security sys-
System Arm Door Ajar

8
9
tem is now disarmed. The vehicle doors will unlock and dome light will turn on for 30 seconds
upon disarming when interfaced with the security system.
System Disarm PATHWAY ILLUMINATION This feature turns the parking light“ON”for 30
seconds upon a unlock signal and for 10 seconds upon the lock signal.
TWO STEP DOOR UNLOCK:This feature will independently unlock the drives
door only when disarming the security system. Pushing the button on the
transmitter a second time within 3 seconds will unlock the entire vehicle.
AUTOMATIC RE-ARM (See Feature “I - 2” Programming): If this feature
is selected, the security system will automatically re-arm itself 60 seconds after disarming with
remote transmitter. Automatic rearm will cancel if any door is opened before the 60 seconds timer
has elapsed.
J. DISARMING WITHOUT A TRANSMITTER
The Override function may be used if the remote transmitter is lost or inoperative.
1. Enter the vehicle and turn the ignition switch to‘ON’position. (Alarm will sound.)
2. Within 10 seconds push and release the valet switch
The alarm will stop sounding and enter the disarm mode.You can now start and operate the
vehicle normally.
K. VALET MODE: (System in Disarm or Valet mode)
The valet switch allows you to temporarily bypass all alarm function, eliminating the need to
hand your transmitter to parking attendants or garage mechanics.When the system is in valet
mode, all alarm function is bypassed, however the remote panic feature and remote door locks
will remain operational.To use the valet mode, the system must rst be disarmed either by using
you remote transmitter, or by operating the Manual override sequence.
Enter Valet Mode:
1. From the disarmed condition, turn the ignition to“ON”
position.
2. Push and hold valet switch for 2 seconds until the
LED turns on. The LED wills remain on as long as the
system is in‘valet mode’.
Exit Valet Mode:
1. Return to normal operation, turn ignition‘on’.
2. Push and hold valet switch for 2 seconds, The LED will turn o indicating the system is exiting
the valet mode.
REMOTE VALET: (System in Disarm or Valet mode)
Press and release button on the transmitter three times within 3 seconds to enter / exit valet
mode. A parking ash to conrm enters valet mode and two parking lights ashing to conrm exit
valet mode.
L. CAR LOCATOR
Press the button to activate the car locator function. The siren will
chirp 6 times.The parking light will ash 12 times, for you to easily locate
your car.
M. PANIC FUNCTION:
The transmitter can be used as a remote panic switch to manually trigger
the alarm in case emergency.
1. Press and hold the button for 3 second.The alarm will immediately
sound.
2. During panic mode, the normal function of this transmitter button will
be suspended. The and buttons can be used to lock and unlock
the doors (if the option is installed), however once the button is
pressed, the vehicle’s starter disable device, (where installed) will be
disabled allowing the vehicle to start.
3. To stop the alarm, press and hold the or button on the transmitter again for 3 seconds.
Also if any transmitter button other than or button is pressed and released, the panic
mode will be turned o immediately.
4. If the button is not pressed, the alarm will automatically stop after 30 seconds.
Remote Door
Lock
Remote Door
Unlock

10
11
N. SYSTEM’S STATUS CHECK
(For two-way transceiver operation only)
When you want to check the system’s present status through the LCD
screen, Press the transceiver Fbutton twice, within 3 seconds press
(C) button. It responds with one melody sound, the LCD screen should
be illuminated.
O. DRIVER PAGING
(For two-way transceiver operation only)
It is useful the event that someone wants to page the driver of the parked
vehicle. Under the ignition switch“o”condition, press and hold the valet
switch for 2 seconds to page the driver, one chirp sound shall be emitted
from the vehicle and the paging melody sound continues you Remote LCD
transceiver and“ ”indication ashes on the LCD screen.
P. DOME LIGHT CONVENIENCE DELAY & SUPERVISION
Upon disarming, the interior lights will remain on for 30 seconds. Note:Turn ON the ignition
switch or arm the alarm will turn o the dome light.
Q. IGNITION CONTROL POWER DOOR LOCK/UNLOCK
If the vehicles door locks have been interfaced to the system, the system will automatically lock
the vehicle’s doors when the ignition is turned“ON”and/or unlock the vehicle’s doors when the
ignition is turned“OFF”.
R. TRUNK RELEASE (CHANNEL 3) OUTPUT
Press and hold the button on transmitter for two seconds to
remote control the trunk release or other electric devices.
S. CHANNEL 4 TIMER CONTROL OUTPUT
Press the transmitter (4) and the (4) buttons at the same time to ac-
tive Channel 4 function. Channel 4 is user-programmable timer output. You
may program the built-in timer to send a ground signal for any time interval
between 1 second and 2 minutes. For instance, this timer output may be
used to turn on the headlight, power window or sunroof. (Factory defaults
setting at momentary output.)
T. CHANNEL 5 TIMER CONTROL OUTPUT
Press the transmitter (5) and (5) buttons at the same time to active
Channel 5 function. Channel 5 is user-programmable timer output.You may
program the built-in timer to send a ground signal for any time duration
from 1 second to 120 seconds. For instance, this timer output may be used to
turn on the headlight, power window or sunroof. (Factory defaults setting at
momentary output.)
U. CHANNEL 6 TIMER CONTROL OUTPUT
Press the transmitter ✱(6) and (6) buttons at the same time to active
Channel 6 function. Channel 6 is user-programmable timer output.You may
program the built-in timer to send a ground signal for any time duration
from 1 second to 120 seconds. For instance, this timer output may be used to
turn on the headlight, power window or sunroof. (Factory defaults setting at
momentary output.)
REMOTE START OPERATION
A. TO REMOTE START THE VEHICLE:
1. When you want to start your vehicle,
2. Press ✱button twice on the transmitter
3. The parking light will activate to indicate the remote start received the signal. (A melody
sounding from your Remote LCD transceiver and“ ”icon will ashes on the LCD screen to
conrm the remote start was activated.)
4. The engine will start approximately 5 seconds.

12
13
5. Once the engine is running, after couple seconds the parking light will turn on again
6. and climate controls will activate and adjust the vehicles interior temperature to your
7. preset setting. (While the vehicle is running, the “ ”icon and the“minutes”digit on the
LCD screen will ash and it will indicate count down timer based on the 5, 10, 20 or 30 minute
run time set up by your installation center.)
8. The vehicle will run for 5 to 30 minute cycle and automatically shut down. (When the unit
shuts o the count down timer will turn o and the transmitter will play a melody.)
Activate Remote Start Engine Running
Note: The Remote Start Unit will not start the vehicle if any one of the following conditions exists:
1. The hood is opened.
2. The brake pedal is pressed.
3. Move the optional remote start enable toggle switch to OFF position. (If installed)
4. The gear selector is in any gear other then“PARK”or“NEUTRAL”
5. Pull down the hand brake. (for StandardTransmission Gear Vehicle)
SAFE START (Child safety mode)
Factory defaults setting to press the ✱button twice on the transmitter to start the vehicle.
Programming this feature to eliminate an accidental remote start. It requires the user presses the
transmitter and ✱buttons at the same time to start the vehicle.
B. ENGINE START MEMORIZING FOR THE VEHICLE WITH STANDARD
(MANUAL)
TRANSMISSION GEAR (Cut the VIOLET LOOPWIRE for Standard transmission gear vehicle)
The system senses the neutral transmission gear position automatically and there is no prior set-
up required.The system in the standard transmission vehicle operates as following process when
you exit the vehicle to sense and memorize the neutral transmission gear position. If the vehicles
are of automatic transmission gear, this process is omitted.
1. While engine is running by ignition key, pull up the hand brake and place the transmission
gear in the neutral position.
2. Before turning o the engine, press the ✱button twice on the transmitter.
-- The LED indicator will ash 3 times to conrm enter.
3. Pull o the“Ignition Key”from the key cylinder.
-- Engine continues running until the pre-programmed time elapsed or shutdown input is
received.--
4. Exit from the vehicle and Close all doors.
-- The engine still continues running and it is normal operating process.--
5. Within 1 minute from the time of step 1, press the button on the transmitter to lock the
doors.
6-1. If the engine shuts down immediately and the system is now ready for next remote (or
programmable) engine starts.
6-2. If the engine not shuts down immediately, the system is failed in engine start memorize set
up, repeat above process again.
If the door is opened after above process, the prior memorization for the next remote or pro-
grammed engine start sequence is delete and the function shall not work until you repeat above
process again.
Note: If the engine start memorize is set up, the dome light convenience delay function will be
temporarily By-pass.
C. TO OPERATE THE VEHICLE WHILE RUNNING ON THE REMOTE
START:
To operate the vehicle while engine running on the remote start.
1. Insert the ignition key and turn it to“ON”(not the start) position.

14
15
2. Press the brake pedal.
Note: If the brake pedal is pressed before the key is in the ON position, the engine will shut down.
D. TEMPORARY STOP FEATURE:
This feature allows the vehicle to remain running after the key has been removed from the
ignition. This feature is useful for occasions when you wish to exit and lock the vehicle for short
periods of time, but would like to leave the motor running and the climate control on.
1. Before turning o the engine, press the ✱button twice on the transmitter and the LED
indicator will ash 3 times to conrm enter.
2. Turn the ignition key to OFF position. (The engine will stay running.)
3. The engine will run until the pre-programmed time elapsed or shutdown input is received.
Note: For StandardTransmission Gear Vehicle: Before press the ✱button, Pull up the hand brake
rst.
E. TURBO TIMER MODE:
Turbo timer mode keeps the engine running after arriving at you destination for a programmable
period of 1/ 3 or 5 minutes,This allows the system’s time to conveniently cool down the turbo after
you have left the vehicle.To activate:
1. While engine is running, place the transmission gear in the park position and pull up the hand
brake.
2. Before turning o the engine, press and release and ✱buttons at the same time.
-- The parking light wills turn on to indicate the remote start has entered turbo charge mode. --
3. Pull o the“Ignition Key”from the key cylinder.
-- Engine keeps running. --
4. Exit and secure the vehicle.
-- Engine continues running until the pre-programmed time elapsed. --
F. TIMER / TEMPERATURE START:
This unit can be programmed to start and run the engine every 3 hours or punctually at the same
time next morning,The engine will run for the programmed running time and then shut down.
IMPORTANT: Timer Start should be used only in open areas, Never start and run the vehicle in on
enclosed space as a garage or carport.
3 hours timer start with Temperature-control OFF:This feature is design for an extreme cold
climate usage.The system will auto start the vehicle every 3 hours, to prevent engine freezing and
hard to start.
A MAXIMUM OF SIX CYCLES CAN OCCUR.
3 hours timer start with Temperature-control: If you programmed the temperature ON to
operate. The system can be programmed to automatically start the vehicle engine whenever the
temperature inside the vehicle reaches or drops below the preprogrammed temperature level.
The system will monitor the air temperature every 3 hour and will only start the engine during
extreme cold temperatures. There is three-temperature level to choose form.
Daily Timer Start: The feature is very useful for the driver who wants to run the vehicle punctu-
ally at the same time next morning. Before set-up of the“Daily Timer Start”, you should set you
time for engine start.( see Timer Setting / Timer set-up for“Daily Timer Start, page 20)
ENTER:
1. Press the ✱button twice to remote start the vehicle. As soon as the vehicle is running and
the parking light have turned on or ashing.
2. Immediately depress the button once, within 2 seconds
3-a. 3 Hours Timer Start: Rapidly depresses the ✱button.The parking light will ash (3)
times.The siren or horn chirps (3) times.The vehicle is now programmed to start every 3 hours.
3-b. Daily Timer Start: Depress the transceiver Fbutton rst, within 3
seconds press ✱(∏) button.The parking light will ash (6) times. The
siren chirps (6) times.The vehicle is now programmed to start at the real
time of the of the next day. Your set time for the next day engine start
ashes for approx. 3 seconds on the LCD screen. After 3 seconds the ∏icon
stays displayed on the LCD screen.
4. Press the brake pedal to stop the vehicle running.
Exit the timer start:
Timer start can be exited manually as follows:

16
17
1. Make sure the remote start system is not operating the engine.
2. Turn the ignition on. The LED and parking light will ash (4) times.The horn chirps (4) times.
OR
1. Press the ✱button twice to remote start the vehicle. As soon as the vehicle is running and
the parking light have turned on or ashing.
2. Immediately depress the button then press and hold the ✱button for 2 seconds.The
parking light will ash (4) times.The siren or horn chirps (4) times. The vehicle is no longer
programmed to start automatically.
G. TEMPERATURE CHECK
You can monitor through the LCD screen, the present indoor temperature of the passenger
compartment before cooling or heating your vehicle.
Press the transceiver Fbutton rst, within 3 seconds press the (·) button; the in-door
temperature will be shown on the LCD screen. This reading may be higher than actual ambient
temperature due to the greenhouse and is relative only the inside vehicle temperature.
H. TO TURN OFF THE REMOTE START:
When the engine is running (by remote start), if you want to stop it,
1. Press button twice on the remote transmitter under remote start mode.
2. Move the optional remote start enable toggle switch to OFF position. (If installed)
3. Press the brake pedal
4. Pull down the hand brake. (for Standard Transmission Gear Vehicle)
The vehicle will shut down and turn o the parking light to indicate engine stopped.
I. SHUT-DOWN INPUT FOR REMOTE STARTER:
If any of the following conditions exist while the system is operating, the engine will not start or
will shut down immediately:
1. The hood is opened.
2. The brake pedal is pressed.
3. The hand brake is released (for StandardTransmission GearVehicle)
4. Engine is over-revved. {“Tachometer checking type”only}
5. The pre-programmed run time (5 /10 / 20 / 30 minutes) has elapsed.
6. Press ✱button twice on the remote transmitter under remote start mode .
7. Move the optional remote start enable toggle switch to OFF position. (If installed)
8. The vehicle refused to start running after {3} unsuccessful attempts.
J. DISABLING THE REMOTE START SYSTEM: (If installed)
This feature allows your system’s remote start unit to be temporarily disabled to prevent the
vehicle from being remote started accidentally. This feature is useful if the vehicle is being serviced
or stored in an enclosed area. To disable the remote start, move the optional remote start enable
toggle switch to the OFF position.
LCD REMOTE TRANSCEIVER
Note: If the system is interfered by
stronger radio frequency around, sources
of high voltage electric power or such
Obstacles like tall buildings and so on, the
transmission range may get shorter as the
system uses low output power frequency.

18
19
A. BATTERY REPLACEMENT:
A 1.5V type AAA Alkaline battery powers the RemoteTransceiver. When the power of the battery
weakens a icon shall be displayed on the LCD screen.When the old battery is replaced to new
one, there will be beep sounds indicate the power is up and the clock on the LCD screen returns to
AM12:00 after displaying all the icons. Correct the time by pressing Ffor 3 seconds before using
(See Timer Setting).
Note: Press the button
two times when the
battery compartment is
empty, then insert the new
battery.
B. THE REMOTE LCD ICONS WITH FUNCTION
Door Lock
Your vehicle doors are locked Door Unlock Your vehicle doors are unlocked
and the system is Disarmed
ARM Armed Mode
Your vehicle is in armed mode
Valet Mode
All the function shall be temporar-
ily on hold
Remote Transmission
You are transmitting the signal to
control unit
In - Range Indicator
Your are within the remote control
range.
Door Open Warning
Doors are illegally opened (Zone 3)
Trunk/Hood Trigger
Trunk or Hood is illegally opened
(Zone 2)
Shock Sensor Trigger
Trigger on Shock Sensor (Zone 4)
Warn Away Trigger
Trigger on Shock Sensor (Zone 1)
Engine Starting
Your vehicle wngine starting by
remote control
Engine Running
Your vehicle's engine is running
¿Timer Control Start
Engine will start automatically at
the same time next day or every
2/3-hour.
Temperature Monitor
Indoor temperature for your
vehicle
C3 Activate Channel 3
(Trunk Release).
C4 Activate Channel 4
C5 Activate Channel 5 C6 Activate Channel 6
Time Monitor Alert Alarm
You have set morning call alarm
Count Down (Parking) Timer
Reminder when time is up for
parking
Vibration Mode
Remote Control vibrates when the
system is triggered
Driver Paging
Someone is paging you in front of
your vehicle
Low Battery
You have to replace the battery of
remote control.
C. PROGRAMMING OF THE LCD REMOTE TRANSMITTER:
Transmitter Button Description Operation
F(1 second) LCD screen lamp turns on for
5 seconds
Press and hold for 1 second
1 melody sound to conrm
enters
F(3 seconds) Timer Programming Mode Press and hold for 3 seconds
2-melody sounds to conrm
enter
F - F - F Clear the Flashing Icon and
Melody Sound on the LCD
Screen Transmitter
Press within 3 seconds
F - (2-second) Melody / Vibration ( ) Mode Press within 3 seconds

20
21
F - (2-second) Program Count Down (Parking)
Timer (10-Minute / 20M / 30
M /1Hour /1.5H / 2.0H)
Press within 3 seconds to cycle
*leave the buttons starting
count down then ashes
1. Screen Lamp ON: Press and hold the Fbutton one second, with one melody sound and the
LCD screen lamp will turns on for 5 seconds
2. Clear the Flash Icon and Melody Sound: Press the Fbutton 3 times within 3 seconds will
clear the ash icon and melody sound on the LCD screen transceiver
3. Stop The Trigger Melody Sound: While triggering the alarm the LCD screen will alert user
through melody sound and ashing trigger icon, press any button on the LCD remote transmit-
ter to stop melody sound only.
4. Vibration / Melody Mode: It is useful when you are in a noisy place and
dicult to hear beep sound from the remote control as the remote control
in this mode, vibrates itself if your security system is triggered.
Press the Fbutton rst, within 3 seconds press and hold the button
for 2 seconds to select the mode of vibration or melody, the icon
will displayed on the LCD screen to show the LCD remote transceiver is on
vibration mode.
5. Low Battery Indication:When the power of the battery weakens, it has two short“beep”
sound and ash icon while pressing the button of the LCD screen transceiver.
6. Set Up Fixed Count Down (Parking) Timer:
1. Press the Fbutton rst, within 3 seconds press and hold the button for 2 seconds, the
LCD screen will shows icon and timer (ie. 0:10) ,
2. Press the button again showing next order time on the screen ( ie.0:20), press it again
(ie.0:30)…..and so on.
3. Leave the buttons starting count down then icon ashes
Note:
1. The count down period is xed as 10 minutes, 20 minutes, 30 minutes, 1 hour, 1.5 hours and
2 hours maximum.
2. When count down timer showing 0:00 means to turn o the timer.
3. Press Fbutton for real time indication when the timer is counting down.
7. Out Of Range Indication: If this feature is selected, the security system will automatically
check the range every 20 minutes after armed.
1. If user is within the range, the icon will display on the LCD screen.
2. If user is out of range, it has ve short“beep”sounds and the icon will disappear on the
LCD screen.
D. TIMER SETTING:
Transceiver Button Description PressTransceiver Button
1 Press & Hold the F
button for 3 seconds
Timer Setting (Hour)
*Flashes digit for adjusting ✱ for –and for +
Press the Fbutton once Time setting (Minute)
*Flashes digit for adjusting
✱ for –and for +
2 Press the Fbutton once. Alert Alarm Time Setting (Hour)
*Flash digit for adjusting ✱for –and for +
Press the Fbutton once Alert Alarm Time Setting (Minute)
*Flashes digit for adjusting ✱ for –and for +
Press the Fbutton once Alert Alarm Setting ON / OFF ✱ for OFF and
for ON
3 Press the Fbutton once Count DownTimer Setting (Hour)
*Flashes digit for adjusting
(Max.19 hours 59 minutes)
✱ for –and for +
Press the Fbutton once Count downTimer Setting (Minute)
*Flashes digit for adjusting
✱ for –and for +
4Press & hold the but-
ton for 2 seconds
Daily Timer Start Timer Setting
Flashes ¿/ Icon and“Hours”for
adjusting
✱ for –and for +
EXIT: Press and hold the Fbutton for 2 seconds or leave it for 10 seconds, the system will exit the
programming mode.

22
23
1. Timer Setting: Example to AM10:30
1. Press & hold the Fbutton for 3 seconds, with two-melody sound and the“Hours”digit
ashes for adjusting.
2. Press the ✱or button to decrease or increase the“Hour”digit until AM10:xx
3. Press the Fbutton once again then the“Minute”digit ashes for adjusting.
4. Press the ✱ or button to decrease or increase the“Minutes”digit until AM 10:30
5. Press the Fbutton for 2 seconds with one-melody sound to conrm exit the timer
program mode.
2. Alert Alarm Timer Setting: Example to PM 6:30
1. Press & hold the SET button for 3 seconds, with two-melody sound and the“Hours”digit
ashes for adjusting.
2. Press the Fbutton twice, the LCD screen will shows %icon and“Hours”digit is ashes
for adjusting.
3. Press the ✱or button to decrease or increase the“Hour”digit until PM 6:xx
4. Press the Fbutton once again then the“Minutes”digit ashes for adjusting.
5. Press the ✱or button to decrease or increase the“Minutes”digit until PM 6:30
6. Press the Fbutton once again then %icon ashes for alert alarm“ON / OFF”setting
7. Press the button to start the“Alert Alarm Timer”, and the“ON”icon will show on the
LCD screen.
8. Press the ✱button to stop the“Alert Alarm Timer”, and the“OFF”icon will show on the
LCD screen.
9. Press Fbutton for 2 seconds with one-melody sound to conrm exit the timer
program mode.
3. Count Down Timer (Parking) Setting: Example Set count down
timer at 2:30
1. Press & hold the Fbutton for 3 seconds, with two-melody sound and the“Hours”digit
ashes for adjusting.
2. Press the Fbutton 5 times, the LCD screen will shows icon and“Hours”digit is ashes
for adjusting.
3. Press the ✱or button to decrease or increase the“Hour”digit until 2:xx
4. Press the Fbutton once again then the“Minutes”digit ashes for adjusting.
5. Press the ✱or button to decrease or increase the“Minute”digit until 2:30
6. Press the Fbutton once again then icon ashes for alert alarm “ON / OFF”setting
7. Press the button to start the count down timer, and the“ON”icon will show on the
LCD screen.
8. Press the ✱button to stop the count down timer, and the “OFF”icon will show on the
LCD screen.
9. Press the Fbutton for 2 seconds with one-melody sound to conrm exit the timer
program mode.
Note: Maximum is 19 hours.
4. Time Set-Up For“Daily Timer Start”: Example to AM 6:30
1. Press & hold the SET button for 3 seconds, with two-melody sound and the“Hours”digit
ashes for adjusting.
2. Press & hold the button for 2 seconds, the LCD screen will ash ¿/ icon and“Hours”
digit for Hour set-up.
3. Press the ✱or button to decrease or increase the hour digit until AM 6:00
4. Press the Fbutton once again then the minute digit ashes.
5. Press the ✱or button to decrease or increase the minutes digit until AM 6:30
6. Press the Fbutton for 2 seconds with one-melody sound to conrm exit the timer program
mode.
550R 12/2006
6876 V.A

24
