Alfa Cappuccino TA-02 User manual

36206.9 -Dezembro / 2008
INSTRUCTIONS MANUAL
High Performance Industrial Blender
TA-02
TA-02

1.2 Main Components
1.3 Technical Characteristcs
1. Introduction
01
1.1 Safety
01
01
02
2. Installation and Pre Operation
2.1 Installation
2.2 Pre Operation
2.3 You must not...
02
02
02
4. General Safety Practices
4.1 Basic Operation Procedures
4.4 Operation
4.2 Safety Procedures and Notes Before Switching the Machine On
4.5 After Finishing the Work
4.3 Routine Inspection
4.6 Maintenance
4.7 Advices
05
05
06
06
07
07
07
07
5. Analysis and Problem Solving
5.1 Problems, Causes e Solutions
07
5.2 Electric Diagram Mod. TA-02
08
07
3. Operation
3.1 Starting
3.3 Cleaning
3.2 Feeding Procedures
03
03
04
03
SUMMARY
03

01
Picture - 01
07
01
02
03
05
04
06
01- Lid
02- Cup
03- Motor Support Flange
04- Motor Housing
05- Base
06- ON/OFF Switch
07- Cup Flange
08
Table - 02
5.2 Electrical Diagram Mod. TA-02
ON/OFF Switch
Motor
110 ou 220 V
Problems Causes Solutions
* Lack of power or
equipment is unplugged.
* Problem in the internal or
external electric circuit of
the machine.
* Check if machine is
plugged in and if there
is power in the power
supply source.
* The machine does not
switch On.
* Cup is leaking.
*Product does not
blend.
* Sealing system problem.
* Product pieces are too
big cannot reach the knive.
* Blunt Knives.
* C a l l t e c h n i c a l
assistance.
* Cut the product into
s m a l l e r p i e c e s o f
approximately 3,5 cm.
1. Introduction
1.1 Safety
The High Performance Industrial Blenders Model TA-02 are machines simple to
use and to clean. However for your safety read the following instructions in order to
avoid accidents:
1.1.1 Always unplug the machine when cleaning, servicing or when any other
operation is needed.
1.1.2 Never use tools that do not belong to the machine during operation.
1.1.3 Before using the machine check if Cup Nº02 (Pic.01) is properly fitted in its
position.
1.1.4 Never throw water directly to the machine.
1.1.5 Do not operate the machine wearing wet clothes or wet shoes.
1.1.6 Before operating the machine be sure it is grounded properly.
1.1.7 Always operate the machine on a clean and dry surface to avoid strange
substances or water to get inside the motor by air suction .
1.2 Main Components
All components are made with carefully selected materials, in accordance with
Siemsen experience and standard testing procedures.
* C a l l t e c h n i c a l
assistance.
* C a l l t e c h n i c a l
assistance.

02
1.3 Technical Characteristics
07
(*) Frequency and voltage will be only the ones indicated on motor characteristics label.
IMPORTANT
(**) Maximum capacity for TA-02 is 2 (two) liters, even though the cup volume is
bigger than that. This additional volume is to minimize the product overflowing
during the process. It is recommended to use a maximum volume of 1,5 liters
(one and a half liters) in this equipment.
2. Installation and Pre Operation
2.1 Installation
The Blender is to be installed onto a leveled surface approximately 850mm
high.
The High Performance Industrial Blenders TA-02 were developed to be used
with only one rated voltage: 110V (60Hz) or 220V (50Hz or 60Hz) . Upon receiving the
Blender check its voltage according to the information written on the cord label.
The cord has a plug with two pins and a grounding wire . It is mandatory the
three of them to be connected before to start to use the blender .
2.2 Pre Operation
IMPORTANT
When installing the Cup Nº02 (Pic.01) on the machine be sure it is perfectly fitted.
The Cup can be fitted on the machine in any position; which guarantees a perfect
operation.
First of all check if the Blender is firm in its position. It is recommended to work
with the machine on a flat surface with approximately 850 mm of height.
4.4 Operation
4.4.1 Advice
Be sure your hair is not loose in order to avoid getting caught by turning parts
which could lead to a serious accident. Tie your hair well up and/or cover your head with
a scarf.
The operation performed by not trained or skilled personnel shall be forbidden.
Never touch turning parts with your hands or in any other way.
NEVER operate machine without all original safety devices under perfect conditions.
4.5 After Finishing The Work
4.5.1 Precautions
Always TURN THE MACHINE OFF by removing the plug from the socket before
cleaning the machine.
Never clean the machine unless it has come to a COMPLETE STOP.
Put all components back to their functional positions before turning it ON again. DO
NOT place your fingers in between belts and pulleys nor chains and gears.
4.6 Maintenance
4.6.1 Danger
Any maintenance with the machine in working situation is dangerous. TURN IT
OFF BY PULLING THE PLUG OFF THE SOCKET DURING MAINTENANCE.
IMPORTANT
Always unplug the machine when emergency cases arise.
4.7 Advice
Electrical or mechanical maintenance must be done by qualified personal for
such operation.
Person in charge has to be sure that the machine is under TOTAL SAFETY
conditions when working.
5 Analysis and Problems Solving
5.1 Problem, causes and solutions
The High Performance Industrial Blenders were designed to operate with the
need of minimum maintenance but the natural wearing caused by longer use of the
equipment may occasionally cause some malfunctions.
If such problem occurs with your Blender refer to Table 02 in which the most
common situations are listed with recommended solutions.
Table - 01
Characteristics
Units
TA-02
110/220(*)
50 or 60
900
0,9
450
215
205
2,7
[V]
[Hz]
[W]
[kW/h]
[mm]
[mm]
[mm]
[kg]
[kg]
3,4
Voltage
Power Rating
Frequency
Consumption
Height
Width
Depth
Net Weigth
Gross Weigth
[L]
[ rpm]
2,0
22000
Maximum Cup Capacity
Rotation

0306
Before using the machine all parts that get in contact with food must be washed
with running water and neutral soap. To clean your Blender read item 3.3 Cleaning on this
Manual (pag.4).
2.3 You must not …
2.3.1 …expect your blender to replace any other kitchen appliance. This
equipment is not supposed to make mashed potatoes, it does not blend egg whites or any
other cream for coverings, it does not grind raw meat, it does not blend hard dough and it
does not extract pulp from fruits or vegetables.
2.3.2 …process blending for too long. Remember that the blender works in
seconds and not in minutes. Therefore, never let your blender working for more than one
minute. It is better to turn it off and check the mixture consistency after a few seconds to
avoid too much blending.
2.3.3 … OVERLOAD the motor with too big or too heavy portions as it will reduce
the blender´s life. If the motor stops, turn the equipment off immediately, unplug it and
remove part of the product before turning it on again.
3. Operation
3.1 Starting
IMPORTANT
Before removing or installing the Cup Nº02 (Pic.01) be sure the motor has
completely stopped.
The Blender is activated by turning the On/Off Switch Nº06 (Pic.01) located at the
Motor Housing Nº04 (Pic.01) to ON position.
3.2 Feeding Procedure
The High Performance Industrial Blender works at high speed approximately
22.000 rpm (empty) . To feed it proceed as follows:
Cut the product into small pieces of approximately 3,5cm. This process helps in
the blending process time, especially for frozen products. It is recommended to add water
when triturating ice.
1 - Remove the Lid Nº01 (Pic.01).
2 - Put product inside the Cup Nº02 (Pic.01) with the machine switched OFF.
3- Place the Lid Nº01 (Pic.01) and switch the machine ON.
4.2 Safety Procedures and Notes Before Switching Machine ON
IMPORTANT
Carefully read ALL INSTRUCTIONS of this manual before turning the machine ON.
Be sure to be familiar with the instructions and that you have well understood all
information contained in this manual. If you have any question contact your
supervisor or your nearest Dealer.
4.2.1 Danger
An electric cable or electric wire with damaged jacket or bad insulation could
cause electrical shocks as well as electrical leak. Before use, check conditions of all
wires and cables.
4.2.2 Advices
Be sure ALL INSTRUCTIONS in this manual have been thoroughly understood.
Every function and operational procedure have to be very clear to the operator. Contact
your nearest Dealer for further questions.
Any manual command (switch, button or lever) shall be given only after being
sure it is the correct one.
4.2.3 Precautions
The electric cable has to be compatible with the power required by the machine.
Cables touching the floor or close to the machine need to be protected against short
circuits.
4.3 Routine Inspection
4.3.1 Advice
When checking the tension of the belts or chains, DO NOT introduce your fingers
between the belts and the pulleys and nor between the chain and the gears.
4.3.2 Precautions
Check if motors and sliding or turning parts of the machine produce abnormal
noises.
Check the tension of the belts and chains and replace the set when belt or chain
show signs of being worn out.
When checking tensions of belts or chain DO NOT introduce your fingers
between belts and pulleys, nor between the chains and gears.
Check protections and safety devices to make sure they are working properly.

04
01
02
03
01 - LID
02 - CUP.
03 - MOTOR HOUSING
PICTURE - 02
05
IMPORTANT
Do not use this equipment to process thick textures .
IMPORTANT
The blending time depends on each product.
IMPORTANT
NEVER SWITCH THE MACHINE ON WITHOUT LOAD INSIDE BECAUSE IT WILL
CAUSE IRREPARABLE DAMAGES.
3.3 Cleaning
IMPORTANT
Never do cleaning with the machine plugged in. Always unplug the machine
before cleaning. Before removing the Cup be sure the motor has completely
stopped.
Follow the below instructions to wash the removable parts:
3.3.1 Unplug the machine.
3.3.2 Remove the Lid Nº01 (Pic.02) first then the Cup Nº02 (Pic.02).
3.3.3 Wash all removable parts with running water and neutral soap.
3.3.4 To reinstall them, follow the above order inversely.
3.3.5 To clean the Motor Housing Nº03 (Pic.02) use a wet cloth with alcohol.
IMPORTANT
When washing inside the Cup be careful with the knife as it has sharp edges.
4. General Safety Practices
The following safety instructions are addressed to both the operator of the
machine as well as the person in charge of maintenance. The machine has to be
delivered to the operator in perfect conditions of use by the Distributor to the user. The
user shall operate the machine only after being well acquainted with the safety
procedures described in the present manual. READ THIS MANUAL WITH ATTENTION.
4.1 Basic Operation Practices
4.1.1 Dangerous parts
Some parts of the electric devices are connected to high voltage points. These
parts when touched may cause severe electrical shocks or even be FATAL.
Never touch commands such as buttons, switches and knobs with wet hands,
wet clothes and/or shoes. By not following these instructions operator could be exposed
to severe electrical shocks or even to a FATAL situation.
4.1.2 Warnings
The operator has to be well familiar with the position of ON/OFF Switch to make
sure the Switch is easy to be reached when necessary. Before any kind of maintenance,
physically remove plug from the socket.
Provide space for a comfortable operation thus avoiding accidents.
Water or oil spilled on the floor will turn it slippery and dangerous. Make sure
the floor is clean and dry.
Before giving any manual command (switch, buttons, turn keys or lever) be sure
the command is the correct one. Check this manual for further details if necessary.
Never use a manual command (switch, buttons, lever) unadvisedly.
If any work is to be made by two or more persons, coordination signs will have to be
given for each operation step. Every step of the operation shall be taken only if the sign
has been made and responded.
4.1.3 Advices
In case of power shortage, immediately turn the machine OFF.
Use recommended or equivalent lubricants, oils or greases.
Avoid mechanical shocks as they may cause failures or malfunction.
Avoid penetration of water, dirt or dust into mechanical or electrical components
of the machine.
DO NOT MODIFY original characteristics of the machine.
DO NOT REMOVE, TEAR OFF or MACULATE ANY SAFETY or IDENTIFICATION
LABELS stuck on the machine. If any label has been removed or is no longer legible,
contact your nearest dealer for replacement.
