Alfa Network Tube-AH User manual

Quick Installation Guide
Tube-AH

1
Package Contents
1 x Tube-AH Outdoor AP/CPE
1 x Outdoor N-type Antenna
1 x Passive PoE Adapter
2 x Pole mount cable ties
1 x Outdoor Water Resistant Tape
1 x User Guide
1 x Power Cord

2
Product Overview
Power Indicator (Green)
Wi-Fi Indicator (Green)
System Indicator (Blue/Green)
RJ45 Waterproof Connector
N-type Antenna Connector
PoE LAN Port
Descriptions
On - Power on
Off - No power
Blinking - Wi-Fi is sending or receiving data
On - Device is running properly (Green)
Blinking - Device is sending or receiving data (Blue)
Waterproof connector to prevent water and dust from
entering the device.
ANT port is used to connect 1 x outdoor N-type antenna
Fast Ethernet with passive PoE and ESD protection
(Passive PoE 12~36 VDC)
1
2
3
4
5
6
LED Indicator / Interface

3
Hardware Installation
21
3
4 5

4
Hardware Installation
PC
1.Pass the network cable through the various components of the waterproof
connector, Connect the Tube-AH and PoE adapter’s PoE port using Ethernet
cable. Rotate the waterproof connector until it is tight.
2.Attach Outdoor Omni Antenna to the Tube-AH and rotate the antenna until
it is tight. Seal the gap on the connector with the water resistant tape.
3.Connect the PoE adapter’s LAN port to Computer using Ethernet cable.
4.Connect power cord to PoE adapter and plug in the power outlet.
6 7
8 9

5
Open Setup Page and Login
After logging in, the dashboard page will be shown.
Open a browser then type 192.168.100.1 into the address bar to access the
setup page, default username and password are "admin".

6
This setting page allow you to change Device IP、AH Mode (Default: AP
Mode)、Channel、Network Name...etc. After the setting is completed,
please click the "OK" button.
Please go to the dashboard page and click the "EDIT" button.
How to Setup AP Mode

7
How to Setup AP Mode
When the Client connects to the AP, it will be shown on the dashboard page.

8
How to Setup Client Mode
Please change Device IP (Same network segment as AP, but different IP.)
、AH Mode (change to: Client Mode), and click the "Search" button.
Please go to the dashboard page and click the "EDIT" button.

9
How to Setup Client Mode
After the setting is completed, please click the "OK" button.
Please select the AP you want to connect and click the "Select" button.

10
How to Setup Client Mode
When the Client connects to the AP, it will be shown on the dashboard page.
When you reload the web page, please note whether you have changed
the device IP!

11
How to Setup with the Router
For example, your front-end router settings are as follows:
Gateway IP: 192.168.0.1
DHCP Server Range: 192.168.0.2~192.168.0 253
Please go to the “Network” page modification settings examples are as follows:
For Tube-AH AP
IP Address: 192.168.0.111
Gateway: 192.168.0.1
DHCP Server: Disable
Please click the "SAVE" button.

12
How to Setup with the Router
For Tube-AH Client
P Address: 192.168.0.112
Gateway: 192.168.0.1
DHCP Server: Disable
Please click the "SAVE" button.

13
How to Setup with the Router
After the setting is completed, it will be shown as follows
For Tube-AH AP
For Tube-AH Client
When you reload the web page, please note whether you have changed
the device IP!

14
How to Factory Reset or Reboot
Reboot
In the “Admin” drop-down menu on the upper right, click the "Reboot" item.
Factory Reset
Please go to the system page and click the "Factory Reset" button.

15
Application Scenario
Sensor
Tube-AH Client
Tube-AH AP

16
Troubleshootin
LED indicators shown abnormally
Please check to see if all cable connectors (PoE adapter and Ethernet cable)
are connected to your device properly.
Please use the PoE adapter, which is included in the package content.
