ALFRA AMTE 300 User manual

AMTE 300
ELECTRIC ASSEMBLY TABLE
ASSEMBLY
INSTRUCTIONS
SAVE THESE INSTRUCTIONS:
Any user or installer of this assembly table must study this instruction manual carefully. If this table is sold,
please provide the manual to the buyer, installers, or support personnel assembling the product.
Also watch our assembly video
found on www.alfratools.com
v1.2018.01.15

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15
AMTE-300 ASSEMBLY MANUAL
2

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15 3
AMTE-300 ASSEMBLY MANUAL
TABLE OF CONTENTS
4
SAFETY PRECAUTIONS
5
TOOLS REQUIRED
6
HARDWARE INCLUDED
8
HARDWARE PLACEMENTS
9
ASSEMBLY INSTRUCTIONS

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15
AMTE-300 ASSEMBLY MANUAL
4
SAFETY PRECAUTIONS
Safety is essential to the use and maintenance of ALFRA tools and equipment. This assembly manual and any
markings on the tool provide information for avoiding hazards and unsafe practices related to the use of this tool.
When using electrical equipment, basic precautions should always be followed. Read all instructions before using the
table.
FAILURE TO COMPLY WITH OR OBSERVE ALL INSTRUCTIONS AND WARNINGS REGARDING THE
ASSEMBLY AND USE OF THIS PRODUCT MAY RESULT IN BURN, ELECTRICAL SHOCK, SEVERE INJURY
OR SERIOUS PROPERTY DAMAGE.
DANGER - To reduce the risk of electric shock, Always unplug this equipment from the electrical outlet before
cleaning, or before putting on or taking o parts.
SAFETY AND WARNINGS - To reduce the risk of burns, re, electric shock, or injury to persons:
• Do not attempt to install replacement batteries. Injury or possible damage to the equipment can occur
if this warning is violated. Contact ALFRA TOOLS LLC if a replacement battery is required.
• Do not modify the product without written consent from the equipment manufacturer, ALFRA TOOLS
LLC.
• The table operation is not permitted if:
a) ammable or explosive gases or vapors may be present in the work area
b) the operator is untrained or a child
c) children are present in the immediate area
• Inappropriate use of this product may cause property or bodily injury.
• Check surroundings on all sides before using the table. Body parts and property can be crushed if
trapped between an immobile obstacle and the desk’s range of motion.
• Keep the table close to the power socket/outlet to be easily accessible.
• Keep the cords away from heated surfaces.
• Loading and unloading must be carried out only with the table in the horizontal position.
• Keep all electrical components away from liquids.
USAGE
• Do not exceed the rated maximum duty ratio of operation of the device. Each linear actuator is rated for
2 minutes of continuous operation only, followed by a required rest for 18 continuous minutes. Failure
to comply may cause injury or equipment failure
• Do not OVERLOAD the mounting table! Maximum allowed load weight is 1100 lbs.
• Only use the mounting table on a flat, level surface that can withstand the weight of the table, including
the maximum load.
• Ensure that all table wheels are locked or otherwise unable to rotate before mounting any object on the
table.
• Ensure the load is evenly distributed over the mounting table work surface.
• During use, no one must sit or stand on the mounting table.
• Never operate this table if it has a damaged cord or plug, if it is not working properly, if it has been
dropped or damaged, or dropped into water.
• This table was designed for indoor use only. Do not operate the table outdoors.

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15 5
AMTE-300 ASSEMBLY MANUAL
TOOLS REQUIRED
WRENCH
SOFT
HEADED
HAMMER
PLIERS
BALL
PEEN
HAMMER
ALLEN
WRENCH
(4MM)
LEVEL

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15
AMTE-300 ASSEMBLY MANUAL
6
HARDWARE INCLUDED
ITEM QTY PART NUMBER DESCRIPTION
11 31003-100 Base Frame
21 31003-106 Middle Support
31 31003-114 Table Top
41 31003-124 Lower Extension
51 31003-123 Upper Extension
62 31003-127-L Clamping Unit Standard - Left Hand
72 31003-127-R Clamping Unit Standard - Right Hand
84 31003-006 Bolt with pad M16 x 150 mm Leveling Pad
91 31003-117 Actuator
10 1 31003-002 Battery
11 1 31003-018 1 Axis Controller
12 1 31003-024 2 Button Keypad
13 1 31003-020 1 Amp Power Supply
14 1 31003-126 Quick-Release Pin 3/16 Dia X 1-3/8 Lg
15 4 31003-115 Extension Star Knob
16 1 31003-111 Upper Acuator Pin 10mm Dia, 45mm Lg
17 1 31003-110 Lower Actuator Pin 12mm Dia, 30mm Lg
18 4 31003-122 2" Square Tubing Plug
19 1 31003-113 Hinge Connecting Rod 5/8 Dia-19.625" Lg
20 4 31003-105 Hex Nut M16 x2, Plain
21 4 31003-104 Lock Washer M16, Plain
22 4 31003-103 Flat Washer M16, Plain
23 8 31003-131 Hex Nut M16 x2, Zinc-Pl, Class 8
24 4 31003-129 Flat Washer M16, Zinc-Pl
25 4 31003-130 Lock Washer M16, Zinc-Pl
26 3 31003-112 Button Head Cap Screw M6 x1-10mm Lg
27 2 31003-108 Cotter Pin 7/64 x1.00" Lg, Zinc-Pl
1x1 2x1 3x1 4x1 5x1

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15 7
AMTE-300 ASSEMBLY MANUAL
6x2 7x1 8x1 9x4 10 x4
11 x4 12 x1 13 x4 14 x1 15 x1
16 x1 17 x1 19 x4
20 x4
18 x1
22 x8
21 x4
23 x4 24 x4 25 x3 26 x2 27 x1

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15
AMTE-300 ASSEMBLY MANUAL
8
HARDWARE PLACEMENT
1
2
6
7
5
6
3
4
1
18
15
22
24
23
22
10
3
5
19
20
21
7
9
5
18
9
26
14
26
16
25
17
12
3
15
11
12
6
13
13
7
5
3
1
13
8
4
13
6

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15 9
AMTE-300 ASSEMBLY MANUAL
ASSEMBLY INSTRUCTIONS
1
Place the base frame1on a
wooden pallet or other raised
platform so that it is raised off of
the ground.
2
Thread hex nut23 onto assembled leveling pad8about half way
down shaft. Repeat for all four leveling pads8. X4
FIGURE 1
FIGURE 2

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15
AMTE-300 ASSEMBLY MANUAL
10
3
Position assembled leveling pad8underneath corner
of base frame1and insert through center hole.
Place flat washer24 onto the bolt of leveling pad8over
the top side of base frame1 followed by lock washer25.
Loosely thread hex nut23 over flat washer24. Repeat for
all four corners of base frame1.
Once all four leveling pads8are installed, remove base
frame1from raised platform. Using a level, utilize hex
nut23 on the underside of base frame corners to level
base frame1. Once completely level, secure hex nut23
on top side of base frame1tightly with a wrench.
10
24
22
23
22
Optional
If you purchased the tilting table caster wheels
(#031003-010 - non-locking or #31003-025 -
locking) separately, use caster wheels and caster
hardware that was provided to install instead of
the leveling pads. Instead of using center hole on
corner of base frame, use the four surrounding
holes in each corner.
(See figure 4)
FIGURE 3
FIGURE 4

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15 11
AMTE-300 ASSEMBLY MANUAL
4
Place the middle support2on to center of base frame1aligning the bolts on base frame1
with holes on middle support2. The mount for the actuator on middle support (see figure 5)
should be facing the rear of the table. (See figure 6)
Once positioned, place flat washer22 onto bolts of base frame followed by lock
washer21. Finally, thread hex nut20 over and secure tightly using a wrench.
5
19
20
21
ACTUATOR
MOUNT
TABLE REAR
TABLE FRONT
FIGURE 5
FIGURE 7FIGURE 6

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15
AMTE-300 ASSEMBLY MANUAL
12
5
On right side of middle support2(when standing at the rear of the table) place and hold
controller11 while aligning the three screw holes.
Take button head cap screw26 and secure tightly into side of middle support2and controller11
using an allen wrench. Repeat for all three button head cap screws25.
25
17
FIGURE 8

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15 13
AMTE-300 ASSEMBLY MANUAL
12
6
With the actuator9shaft pointing downward, align bottom hinge of actuator9and the
actuator mount located on the middle support2together. Slide flanged pin17 through
both units, insert cotter pin17 and secure with pliers.
9

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15
AMTE-300 ASSEMBLY MANUAL
14
7
26
14
26
5
7
Align center mounting hinges of table top3with top holes on middle support2. Felted
surface of table top3should be positioned upwards. (See figure 11)
Slide hinge connecting rod19 through both the table top3hinges and the middle
support2. Using pliers, secure and tighten a cotter pin27 on each side of hinge
connecting rod19.
IMPORTANT: Fit of hinge connecting rod19 will be snug, you may need to use a ball
peen hammer to position it in place.
BACK MOUNTING HINGES ON TABLE TOP
SHOULD BE ON THE BACKSIDE OF TABLE
SAME SIDE AS ACTUATOR MOUNT
FIGURE 10
FIGURE 11

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15 15
AMTE-300 ASSEMBLY MANUAL
7
11
15
8
Rotate actuator9so that shaft is
pointing upwards. Tilt table top3to
align mounting hinge on table top37
with the very end of the actuator9
shaft. Slide flanged pin16 through
both units, insert cotter pin16 and
secure with pliers.
9
Using a soft head hammer, insert the
square tubing plug18 into end of
arm of upper extension5. Hammer in
square tubing plug18 so it is wedged
tightly into place. Repeat for all four
arms on upper and lower extension4.
Arms of table top3will not have
square tubing plugs.
2
13
13
FIGURE 12
FIGURE 13

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15
AMTE-300 ASSEMBLY MANUAL
16
10
Hang 2 button keypad12 on hook of
middle support2. Plug actuator9power
cord and cord of 2 button keypad12
into controller11.
11
Install battery10 into controller11 by
sliding battery10 on top and firmly
pressing on handle until it clicks into
place.
Use key pad of 2 button keypad12 to
verify table is working properly.
FIGURE 14
FIGURE 15

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15 17
AMTE-300 ASSEMBLY MANUAL
12
Using the 2 button keypad12, bring the table top3into horizontal position and adjust
the extension3+4 positions as needed to accommodate the panel you will be working
on.
Before adjusting the lower extension4, remove the quick release pin14 inserted
into the safety splinter. Loosen the lower extension’s4star knob15. Adjust the lower
extension4position as needed. Tighten the star knob15 (2 per each extension).
Re-insert the quick release pin14
13
To adjust the upper extension5Loosen the star knob15 (2 per each extension). Adjust the
upper extension5position as needed. Tighten the star knob15.
FIGURE 16
FIGURE 17

WWW.ALFRATOOLS.COM | 847-844-8900 | V1.2018.01.15
AMTE-300 ASSEMBLY MANUAL
18
12
6
BEFORE INITIAL OPERATION
Charge battery10 with power supply13 fully before
operating assembly table.
14
Install clamping units6&7 on upper and lower extensions4&5 by aligning rectangle nut and
stud with the uni-rail. Once in position, tighten quick release lever on clamping units6&7.
FIGURE 18
