Alfresco Home BAY LEAF 48 User manual

1
BAY LEAF 48〞Round Dinning Table
Alfresco Home, LLC.
1000 Armand Hammer Blvd | Pottstown PA 19464 USA |
[phone] | [phone] fax

2
WARNING!
PARTS LIST
Please read instructions carefully and thoroughly before assembling. Check parts against the parts list to make sure
you have all the parts needed for proper assembly. Familiarize yourself with the inventory of parts and the accompa-
nying illustrations to ensure safe and proper assembly.
Place the table on a non-abrasive flat surface to prevent scratching.
 Failure to tighten bolts may cause injury.
PART DESCRIPTION PICTURE QTY
A TABLE TOP 1
B TABLE LEG 4
C LEG CONNECTOR RING 4
D BOLT 1 (5/16*40) (Pre-attached) 8
E BOLT 2 (5/16*40) (Pre-attached) 4
F FLAT WASHER (Pre-attached) 12
G LOCK WASHER (Pre-attached) 12
H NUT (Pre-attached) 12
I NUT COVER 12
J WRENCH 1
K UMBRELLA HOLE CAP 1

3
Remove all protective material
carefully. Avoid cutting the surface
of the furniture while removing the pack-
aging material.
From the inside of the leg connector
brace (C), loosely attach the leg con-
nector ring (C) to the legs (B) with the
bolts (D) through the flat washers (F),
lock washers (G) and nuts (H) using
wrench (J).
As shown in figure 1.
DO NOT TIGHTEN BOLTS AT THIS POINTS.
Carefully turn the table top (A) up-
side down on a soft surface. Align
the holes in the legs (B) with the holes in
the table top (A). Loosely secure table
legs (B) to table top (A) by the bolts (E)
through the flat washers (F), lock wash-
ers (G) and nuts (H) using wrench (J).
As shown in figure 2.
DO NOT TIGHTEN BOLTS AT THIS POINTS.
Check the alignment of all table
legs (B), and adjust if necessary.
Once the alignment is correct and all
bolts (D&E) and nuts (H) are in place,
tighten all bolts (D&E) and nuts (G) us-
ing wrench (J) . Cover all nuts (H) with
nut cover (I) .
With the help of another person, careful-
ly turn the table to the upright position.
Put the umbrella hole cap (K) on its
place.
The table is ready for your enjoyment.
3
1
Figure 2
B
A
C
Figure 3
A
C
B
Figure 1
I
H
G
F
E
2
C
B
C
