ALGcom UHPX-5800-35-12-DP User manual

Rev01 –(09-Ago-22)
INSTALLATION GUIDE
ALGcom.com.br
NAME
GAIN
FREQUENCY
UHPX-5800-35-12-DP
35 dBi
4.9 –6.425 GHz
Point-to-point antennas' line, with excellent shielding.
ALGcom Quality and Safety
WE HAVE A STRONG QUALITY POLICY
UHP EXTREME ANTENNA
ATTENTION:
Read this manual carefully before installation or
maintenance procedures, which must be made by trained
professionals. In all operations, you should use PPE's that
have been duly approved for this purpose.

Rev01 –(09-Ago-22)
INSTALLATION GUIDE
ALGcom.com.br
LETTER
DESCRIPTION
QUANTITY
A
REFLECTOR
1
B
MOUNTING HARDWARE
1
C
FEEDER KIT
1
D
RADIO PLATE
1
E
V BOLT 3/8”
1
F
V BOLT 1/2"
1
G
ANTI-ROLL BAR
1
H
PIPE CLAMP
1
I
M5 SCREW
3
J
1/2” SCREW
1
K
M6 SCREW KIT
8
L
CENTRAL MOUNTING
HARDWARE
1
M
3/8’’ SCREW KIT
4
N
M5 ALLEN SCREW KIT
48
O
RADOME
1
P
SHIELD
3
DESCRIPTION
Wrench #19
Wrench #15
Allen Screwdriver #5
Allen Screwdriver #4
Phillips Screwdriver
TOOLS
COMPONENTS
P
M
N
O

Rev01 –(09-Ago-22)
INSTALLATION GUIDE
ALGcom.com.br
1) The pack of two antennas has one reflector with central mounting hardware already
assembled, and other with the components separated in the wooden package. For the
second antenna, please assemble the Reflector (A) and Central Mounting Hardware (L) with
the M6 screw kit (K), including the lock washers.
2) Assemble the Mounting Hardware (B) in the Reflector (A) using the 3/8” Screw Kit (M).
ASSEMBLY INSTRUCTION
Grease
A
B
M
A
L
A
K

Rev01 –(09-Ago-22)
INSTALLATION GUIDE
ALGcom.com.br
3) Mount the Feeder (C) with his flange, than fix it to the antenna, using his M6 screws.
4) Assemble the Radio Plate (D) in the antenna, using his 3 M5 screws.

Rev01 –(09-Ago-22)
INSTALLATION GUIDE
ALGcom.com.br
5) Mount the Shields (P) in the antenna, using M5 screws (N).
6) Place the Radome (O) inside the Shield (P), then fix it with M5 screw kit (N).
A
P
N
N
P
O
O
P

Rev01 –(09-Ago-22)
INSTALLATION GUIDE
ALGcom.com.br
7) Mount the antenna in the pole using V-bolt 3/8’’ (E).
8) To perform Azimuth and Elevation adjustment, just loosen or tighten the follow nuts.
B

Rev01 –(09-Ago-22)
INSTALLATION GUIDE
ALGcom.com.br
9) Finally, assemble the Anti-roll bar (G) to the antenna using 1/2’’ screw (J). Mount the Anti-
roll bar to the pole, using V-Bolt 1/2’’ (F) and pipe clamp (H).
10) It is essential that the link is aligned with the main lobe and not with the secondary
lobes, so carry out several tests until you get the best link performance.
