Algo 8301 User manual

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 1 www.algosolutions.com
8301 Paging Adapter & Scheduler
FW Version 1.5
Installation & Configuration
Order Codes
8301 Paging Adapter & Scheduler

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 2 www.algosolutions.com
Table of Contents
IMPORTANT SAFETY INFORMATION ......................................................................................................9
ABOUT THE ALGO 8301 PAGING ADAPTER & SCHEDULER....................................................................10
TYPICAL APPLICATION ......................................................................................................................... 11
GETTING STARTED - QUICK INSTALL & TEST ......................................................................................... 12
INSTALLATION .....................................................................................................................................13
WEB INTERFACE...................................................................................................................................13
SIP PAGING: ONE ADAPTER ................................................................................................................. 14
SIP PAGING: MULTIPLE ALGO SIP ENDPOINTS (USING MULTICAST) .....................................................15
SIP PAGING: MULTIPLE ALGO SIP ENDPOINTS (USING INDIVIDUAL SIP EXTENSIONS) .......................... 16
BACKGROUND MUSIC STREAMING......................................................................................................16
MULTICAST PAGE ZONES .....................................................................................................................17
POLYCOMTM GROUP PAGING ...............................................................................................................18
SIP RING EVENT ...................................................................................................................................19
SIP ACTIVATED NOTIFICATION ALERTS.................................................................................................19
WIRING CONNECTIONS........................................................................................................................19
CONNECTING INPUT DEVICES TO 8301 .....................................................................................................19
NETWORK CONNECTION........................................................................................................................20
AUX IN (FRONT).................................................................................................................................21
AUX OUT (FRONT) .............................................................................................................................21
LINE IN XLR-MINI (BACK)...................................................................................................................21
LINE OUT XLR-MINI (BACK) ...............................................................................................................21
TERMINAL BLOCK LINE IN......................................................................................................................21
TERMINAL BLOCK LINE OUT ...................................................................................................................21
TERMINAL BLOCK RELAY IN....................................................................................................................22
TERMINAL BLOCK RELAY OUT .................................................................................................................22
BLUE LED INDICATORS .........................................................................................................................22
SIP...................................................................................................................................................22
MULTICAST ........................................................................................................................................22
INPUT................................................................................................................................................ 22
OUTPUT.............................................................................................................................................22
RESET...................................................................................................................................................23
WEB INTERFACE LOGIN........................................................................................................................ 24
STATUS..............................................................................................................................................24
BASIC SETTINGS TAB –SIP.................................................................................................................... 25
SIP DOMAIN (PROXY SERVER)................................................................................................................25
RING/ALERT MODE..............................................................................................................................26
RING EXTENSION .................................................................................................................................26

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 3 www.algosolutions.com
PAGE EXTENSION .................................................................................................................................26
AUTHENTICATION ID ............................................................................................................................26
AUTHENTICATION PASSWORD................................................................................................................. 26
BASIC SETTINGS TAB –FEATURES ........................................................................................................27
RING/ALERT TONE...............................................................................................................................27
RING/ALERT VOLUME...........................................................................................................................28
RING LIMIT.........................................................................................................................................28
PAGE SPEAKER VOLUME........................................................................................................................28
PAGE MODE .......................................................................................................................................28
PAGE TIMEOUT ...................................................................................................................................28
PAGE TONE ........................................................................................................................................28
G.722 SUPPORT..................................................................................................................................29
AUTOMATIC GAIN CONTROL (AGC).........................................................................................................29
‘LINE OUT’ANALOG OUTPUT LEVEL .........................................................................................................29
MULTICAST IP ADDRESSES ...................................................................................................................30
BASIC SETTINGS TAB - MULTICAST (MASTER SETTINGS) ......................................................................31
MULTICAST MODE (MASTER/SENDER SELECTED) .......................................................................................31
NUMBER OF ZONES ..............................................................................................................................32
MULTICAST TYPE .................................................................................................................................32
POLYCOM GROUP SELECTION MODE ........................................................................................................32
ZONE SELECTION MODE ........................................................................................................................32
MASTER SINGLE ZONE ..........................................................................................................................33
SPEAKER PLAYBACK ZONES.....................................................................................................................33
BASIC SETTINGS TAB - MULTICAST (SLAVE SETTINGS)..........................................................................34
MULTICAST MODE (SLAVE SELECTED).......................................................................................................34
NUMBER OF ZONES ..............................................................................................................................34
MULTICAST TYPE -REGULAR ..................................................................................................................35
SLAVE ZONES ......................................................................................................................................35
MULTICAST TYPE –POLYCOM GROUP PAGING/PUSH-TO-TALK......................................................................35
ADDITIONAL FEATURES TAB –INPUT/OUTPUT ....................................................................................37
1202 CALL BUTTON ............................................................................................................................. 37
1203 CALL SWITCH ..............................................................................................................................37
AUDIO ALWAYS ON..............................................................................................................................38
ACTION –PLAY TONE ...........................................................................................................................39
ACTION -MAKE SIP VOICE CALL .............................................................................................................39
ACTION -MAKE SIP CALL WITH TONE ......................................................................................................39
ACTION –STREAM AUDIO......................................................................................................................39
ACTION WHEN TAMPER DETECTED (SUPERVISION)......................................................................................40
SPEAKER VOLUME/MUTE ...................................................................................................................... 40
DIALING EXTENSION .............................................................................................................................40
INTERVAL BETWEEN TONES ....................................................................................................................40
MAXIMUM TONE DURATION..................................................................................................................40
OUTBOUND RING LIMIT ........................................................................................................................40
RINGBACK TONE ..................................................................................................................................41
MAXIMUM CALL DURATION...................................................................................................................41

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 4 www.algosolutions.com
CALL BUTTON .....................................................................................................................................41
AUDIO INPUT PORT ..............................................................................................................................41
ADDITIONAL FEATURES TAB –EMERGENCY ALERTS ............................................................................42
ADDITIONAL FEATURES TAB –MORE PAGE EXTENSIONS..................................................................... 44
ADDITIONAL FEATURES TAB –MORE RING EXTENSIONS ..................................................................... 45
SCHEDULER TAB –CALENDAR ..............................................................................................................46
SCHEDULER TAB –SCHEDULES .............................................................................................................47
SCHEDULER TAB –DATA ...................................................................................................................... 48
DOWNLOAD .......................................................................................................................................48
RESTORE ............................................................................................................................................48
CLEAR ALL DATA.................................................................................................................................. 48
ADVANCED SETTINGS TAB - NETWORK ................................................................................................49
PROTOCOL .........................................................................................................................................49
VLAN MODE...................................................................................................................................... 49
VLAN ID ...........................................................................................................................................50
VLAN PRIORITY ..................................................................................................................................50
DIFFERENTIATED SERVICES (6-BIT DSCP VALUE) .........................................................................................50
ADVANCED SETTINGS TAB –ADMIN .................................................................................................... 51
PASSWORD.........................................................................................................................................51
CONFIRMATION ...................................................................................................................................52
DEVICE NAME (HOSTNAME)...................................................................................................................52
INTRODUCTION SECTION ON STATUS PAGE ................................................................................................52
WEB INTERFACE SESSION TIMEOUT..........................................................................................................52
PLAY TONE AT STARTUP ........................................................................................................................52
LOG LEVEL..........................................................................................................................................52
LOG METHOD .....................................................................................................................................52
LOG SERVER .......................................................................................................................................52
WEB INTERFACE PROTOCOL ...................................................................................................................52
FORCE STRONG PASSWORD....................................................................................................................53
ALLOW SECURE SIP PASSWORD ..............................................................................................................53
SNMP SUPPORT (V1GET ONLY) ............................................................................................................. 53
SA-ANNOUNCE SUPPORT ......................................................................................................................53
SA-ANNOUNCE SERVER ........................................................................................................................54
LOCAL MANAGEMENT PORT................................................................................................................... 54
ADVANCED SETTINGS TAB –TIME........................................................................................................55
TIMEZONE ..........................................................................................................................................55
NTP TIME SERVERS 1/2/3/4.................................................................................................................55
NTP TIME SERVER SOURCE ....................................................................................................................55
DEVICE DATE/TIME..............................................................................................................................55
ADVANCED SETTINGS TAB –PROVISIONING ........................................................................................57
MD5 CHECKSUM.................................................................................................................................58
GENERATING A GENERIC CONFIGURATION FILE ............................................................................................58

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 5 www.algosolutions.com
GENERATING A SPECIFIC CONFIGURATION FILE.............................................................................................59
ADVANCED SETTINGS TAB –TONES .....................................................................................................60
UPLOADING CUSTOM AUDIO FILES ..........................................................................................................60
TONE FILES INCLUDED IN MEMORY ..........................................................................................................61
ADVANCED SETTINGS TAB –ADVANCED AUDIO ..................................................................................62
DYNAMIC RANGE COMPRESSION (DRC) ...................................................................................................62
DYNAMIC RANGE COMPRESSION GAIN .....................................................................................................62
JITTER BUFFER RANGE...........................................................................................................................62
GENERATE IN-BAND DTMF TONES..........................................................................................................63
ALWAYS SEND RTP MEDIA ....................................................................................................................63
SPEAKER FILTER G.711 .........................................................................................................................63
MICROPHONE FILTER G.711 ..................................................................................................................63
SPEAKER FILTER G.722 .........................................................................................................................63
MICROPHONE FILTER G.722 ..................................................................................................................63
SPEAKER NOISE FILTER ..........................................................................................................................63
MICROPHONE NOISE FILTER ...................................................................................................................63
ADVANCED SETTINGS TAB –ADVANCED SIP ........................................................................................64
OUTBOUND PROXY ..............................................................................................................................64
STUN SERVER ....................................................................................................................................64
REGISTER PERIOD (SECONDS)..................................................................................................................64
KEEP-ALIVE METHOD............................................................................................................................65
DIFFERENT PORTS FOR EXTENSIONS .........................................................................................................65
SERVER REDUNDANCY FEATURE ..............................................................................................................65
BACKUP SERVER #1.............................................................................................................................. 65
BACKUP SERVER #2.............................................................................................................................. 65
POLLING INTERVALS (SECONDS)...............................................................................................................65
POLL ACTIVE SERVER ............................................................................................................................66
AUTOMATIC FAILBACK ..........................................................................................................................66
POLLING METHOD ...............................................................................................................................66
ADVANCED SETTINGS TAB –ADVANCED MULTICAST...........................................................................67
AUDIO SYNC (SLAVE MODE) ..................................................................................................................67
MASTER OUTPUT CODEC (MASTER MODE) ...............................................................................................67
MASTER OUTPUT PACKETIZATION TIME (MASTER MODE) ............................................................................68
ZONE DEFINITION ................................................................................................................................68
PAGE TONE AND PAGE VOLUME.............................................................................................................. 68
POLYCOM SLAVE TONES ........................................................................................................................69
SYSTEM TAB - MAINTENANCE..............................................................................................................70
DOWNLOAD CONFIGURATION FILE...........................................................................................................70
RESTORE CONFIGURATION FILE ...............................................................................................................70
RESTORE CONFIGURATION TO DEFAULTS ...................................................................................................70
REBOOT THE DEVICE .............................................................................................................................70
METHOD............................................................................................................................................71
FIRMWARE IMAGE ...............................................................................................................................71
MD5 CHECKSUM.................................................................................................................................71

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 6 www.algosolutions.com
SYSTEM –SYSTEM LOG ........................................................................................................................71
SPECIFICATIONS...................................................................................................................................72
FCC COMPLIANCE STATEMENT ............................................................................................................ 74

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 7 www.algosolutions.com
Important Safety Information
This product is powered by a certified limited power source (LPS), Power
over Ethernet (PoE); through CAT5 or CAT6 connection wiring to an IEEE
802.3af compliant network PoE switch. The product is intended for
installation indoors. All wiring connections to the product must be in the
same building. If the product is installed beyond the building perimeter or
used in an inter-building application, the wiring connections must be
protected against overvoltage / transient. Algo recommends that this
product be installed by a qualified electrician.
If you are unable to understand the English language safety information
then please contact Algo by email for assistance before attempting an
installation [e-mail].
Consignes de Sécurité Importantes
Ce produit est alimenté par une source d’alimentation limitée certifiée
(alimentation par Ethernet); des câbles de catégorie 5 et 6 joignent un
commutateur réseau à alimentation par Ethernet homologué IEEE 802.3af.
Le produit est conçu pour être installé à l’intérieur. Tout le câblage rattaché
au produit doit se trouver dans le même édifice. Si le produit est installé
au-delà du périmètre de l’édifice ou utilisé pour plusieurs édifices, le
câblage doit être protégé des surtensions transitoires. Algo recommande
qu’un électricien qualifié se charge de l’installation de ce produit.
Si vous ne pouvez comprendre les consignes de sécurité en anglais,
veuillez communiquer avec Algo par courriel avant d’entreprendre
l’installation au [e-mail].
Información de Seguridad Importante
Este producto funciona con una fuente de alimentación limitada (Limited
Power Source, LPS) certificada, Alimentación a través de Ethernet (Power
over Ethernet, PoE); mediante un cable de conexión CAT5 o CAT6 a un
conmutador de red con PoE en cumplimiento con IEEE 802.3af. El producto
se debe instalar en lugares cerrados. Todas las conexiones cableadas al
producto deben estar en el mismo edificio. Si el producto se instala fuera
del perímetro del edificio o se utiliza en una aplicación en varios edificios,
las conexiones cableadas se deben proteger contra sobretensión o
corriente transitoria. Algo recomienda que la instalación de este producto
la realice un electricista calificado.

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 8 www.algosolutions.com
Si usted no puede comprender la información de seguridad en inglés,
comuníquese con Algo por correo electrónico para obtener asistencia antes
de intentar instalarlo: [e-mail].
Wichtige Sicherheitsinformationen
Dieses Produkt wird durch eine zertifizierte Stromquelle mit begrenzter
Leistung (LPS –Limited Power Source) betrieben. Die Stromversorgung
erfolgt über Ethernet (PoE –Power over Ethernet). Dies geschieht durch
eine Cat-5-Verbindung oder eine Cat-6-Verbindung zu einer IEEE 802.3af-
konformen Ethernet-Netzwerkweiche. Das Produkt wurde konzipiert für die
Installation innerhalb eines Gebäudes. Alle Kabelverbindungen zum
Produkt müssen im selben Gebäude bestehen. Wenn das Produkt jenseits
des Gebäudes oder für mehrere Gebäude genutzt wird, müssen die
Kabelverbindungen vor Überspannung und Spannungssprüngen geschützt
werden. Algo empfiehlt das Produkt von einem qualifizierten Elektriker
installieren zu lassenv.
Sollten Sie die englischen Sicherheitsinformationen nicht verstehen,
kontaktieren Sie bitte Algo per Email bevor Sie mit der Installation
beginnen, um Unterstützung zu erhalten. Algo kann unter der folgenden E-
Mail-Adresse erreicht werden: [e-mail].
安全须知
本产品由认证的受限电源（LPS），以太网供电（PoE），通过CAT5或CAT6线路联接至IEEE
802.3af兼容的PoE网络交换机供电。本产品适用于室内或建筑物周边安装。所有联接本产品的
线路必须源自同一建筑物。本产品如需用于超出建筑物周边范围或跨建筑物的安装，线路联接
部分必须有过压和瞬态保护。Algo建议本产品由专业电工安装。
如果您对理解英文版安全须知有问题，安装前请通过电子邮件和Algo联系，
[e-mail]。

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 9 www.algosolutions.com
Important Safety Information
EMERGENCY COMMUNICATION
If used in an emergency communication application, the 8301 Paging
Adapter & Scheduler should be routinely tested. SNMP supervision is
recommended for assurance of proper operation.
DRY INDOOR LOCATION ONLY
The 8301 Paging Adapter & Scheduler is intended for dry indoor
locations only. For outdoor locations Algo offers weatherproof speakers
and strobe lights.
CAT5 or CAT6 connection wiring to an IEEE 802.3af compliant
network PoE switch must not leave the building perimeter
without adequate lightning protection.
No wiring connected to the 8301 Paging Adapter & Scheduler
may leave the building perimeter without adequate lightning
protection.

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 10 www.algosolutions.com
About the Algo 8301 Paging Adapter &
Scheduler
The 8301 Paging Adapter & Scheduler is a PoE SIP compliant and
multicast capable IP adapter designed for integrating consumer,
commercial, and professional audio amplifiers into an IP based
Unified Communications environment for voice paging and
notification. The 8301 is also a Scheduler. Relying on the NTP server,
the 8301 can provide bells, tones, and customer service or
emergency announcements for schools, retail, manufacturing,
healthcare, etc. 1GB of memory is available in the device to store
WAV files, which can be played via the 8301 Line Out and, if desired,
as a multicast to other Algo speakers, paging adapters and strobes.
Dual SIP extensions provide both voice paging and notification (ring)
capability. One or both extensions can be registered with any
Communication Server (hosted or enterprise) that supports 3rd party
SIP Endpoints.
Connection to the amplifier is made using a balanced and isolated
line level output provided as both a XLR-mini connection and
pluggable terminal block for twisted pair wiring. Audio level can be
adjusted manually or set to a defined level independent of input.
Multiple adapters in a SIP environment require only one adapter to
register as a SIP extension. Multicasting capabilities allow the SIP
registered adapter to page and simultaneously stream multicast
audio to the other adapters.
The 8301 Paging Adapter & Scheduler is configured using central
provisioning features or by accessing a web interface using browsers
such as Google Chrome, Firefox, or Internet Explorer.
What is Included
8301 Paging Adapter & Scheduler
Network Cable
Wall Mount Bracket
What is not Included
Optional Wall Switch (Algo 1202 or 1203)
Optional 2504 Output XLR-Mini Female to XLR Male
Optional 2505 Input XLR-Mini Male to XLR Female
This Installation Guide (www.algosolutions.com/8301/guide)

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 11 www.algosolutions.com
Typical Application
The 8301 Paging Adapter & Scheduler is typically used to connect an
existing paging amplifier to a UC environment either as a SIP
extension or multicast endpoint.
The Line Output of the 8301 is connected directly to the dry audio
input on an amplifier with an input impedance between 600 Ohm and
10 kOhm.
For amplifiers connected directly to the dry page port of an existing
telephone system, the 8301 will provide a very similar interface
providing both dry page audio and dry contact closure to activate the
amplifier (if required).
For amplifiers connected to a FXS port or ATA through a “telephone
answering device” the 8301 will replace the answering device and
eliminate the need for a FXS port or ATA.

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 12 www.algosolutions.com
Getting Started - Quick Install & Test
This guide provides important safety information which should be
read thoroughly before permanently installing the adapter.
1. Connect the 8301 Paging Adapter & Scheduler to an IEEE 802.3af
compliant PoE network switch. The blue lights on the front will
remain on until boot up is completed –about 30 seconds.
2. After the blue lights turn off, press the reset switch (RST) to hear the
IP address over the analog outputs (eg. headset can be connected to
the green output port). The IP address may also be discovered by
downloading the Algo locator tool to find Algo devices on your
network: www.algosolutions.com/locator
3. Connect the adapter LINE OUT to an amplifier using the mini-XLR
connector or pluggable terminal block.
4. Access the 8301 Paging Adapter & Scheduler web page by entering
the IP address into a browser (Chrome, IE, Firefox etc) and login
using the default password algo.
5. Enter the IP address for the SIP server into the SIP Domain field
under the BASIC SETTINGS > SIP tab.
6. Enter the page SIP extension and password. (Note the adapter
supports two types of SIP extensions. The page extension auto-
answers for voice page announcements. The ring extension plays an
audio WAV file over the speaker without answering.)
7. Make a call to the adapter by dialling the page SIP extension of the
adapter from a telephone.

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 13 www.algosolutions.com
Installation
The 8301 is wall mountable in a horizontal orientation using the
supplied bracket.
Example installation on ½” drywall:
Use appropriate drywall anchors for #8 screws,
and pre-drill per anchor manufacturer’s
instructions. Insert 4 anchors into the wall, and
then attach bracket to wall anchors using #8
screws. Snap the 8301 into the bracket.
Connect the 8301 to a PoE network switch.
Connect the audio output of the 8301 to an amplifier using either the
mini-XLR output (male pins) or pluggable terminal block. The 8301
provides a dry audio output and dry contact closure.
An optional XLR output audio cable (Algo 2504) may be ordered for
audio amplifiers using standard XLR input connectors.
Web Interface
The 8301 Paging Adapter & Scheduler is configurable using the web
interface or provisioning features.
After boot up the blue lights on the front will turn off and the adapter
will have obtained an IP address. If there is no DHCP server the 8301
Paging Adapter & Scheduler will default to the static IP address
192.168.1.111.
The IP address may be discovered by downloading the Algo locator
tool to find Algo devices on your network:
www.algosolutions.com/locator
Enter the IP address (eg. 192.168.1.111) into a browser such as
Google Chrome, Firefox, or Internet Explorer (other than IE9). The
web interface should be visible and the default password will be algo
in lower case letters.

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 14 www.algosolutions.com
SIP Paging: One Adapter
The 8301 Paging Adapter & Scheduler can be registered as a third
party SIP extension with a hosted or enterprise Communications
Server supporting 3rd party SIP endpoints.
To register the adapter with the SIP server, use the Basic Settings >
SIP tab in the web interface to enter the Communication Server IP
address, extension, username, and password. This information will be
available from the IT Administrator.
If VLAN is used, navigate to the Advanced Settings >Network tab
to set VLAN options.
(Note, once the adapter is using VLAN you will need to be on the same
VLAN to access the web interface.)
The adapter may now be accessed by dialling its assigned extension
from a telephone, device, or client. The adapter will auto-answer, play
the default WAV pre-announce tone, and allow voice paging until
disconnected.
There are a number of configurable adapter options:
Increase or Decrease Speaker Volume
Enable AGC (automatic gain control)
Customize pre-announce tone WAV file
The best voice paging quality and intelligibility will be obtained using
the G.722 wideband audio codec. Most current IP telephones support
G.722 which is sometimes referred to as “HD” voice or audio.

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 15 www.algosolutions.com
SIP Paging: Multiple Algo SIP Endpoints
(Using Multicast)
Multicast features in the 8301 Paging Adapter & Scheduler require
that only the first adapter be registered as a SIP extension.
Additional Algo SIP endpoints, including any combination of paging
adapters, speakers, and strobes, may be added as multicast Slaves
receiving a stream from the SIP registered Master adapter, provided
that only a single audio stream will be active at any given time
across any or all of the devices. If multiple unique audio streams are
needed simultaneously more than one Master device will be required.
The Master adapter will simultaneously stream audio to the Slave
adapters. The Slave adapters do not require SIP extensions and do
not need to register with the SIP Communication Server.
To enable multicast streaming from the Master adapter, go to the
web interface and navigate to the Basic Settings > Multicast tab.
Choose multicast mode “Master/Sender” and pick “All Call”for the
Master single zone.
To enable multicast monitoring in the Algo SIP endpoint Slaves, go to
the web interface for each endpoint and navigate to the Basic
Settings > Multicast tab. This time though, choose multicast mode
“Slave/Receiver”. There is no need to select a zone as the
endpoint will automatically monitor the “All Call”zone IP address.
The page pre-announce tone is generated from the Master. The
speaker volume can be increased or decreased for each multicast
Slave individually.

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 16 www.algosolutions.com
SIP Paging: Multiple Algo SIP Endpoints
(Using Individual SIP extensions)
In some cases it may be desirable for every adapter to have a SIP
extension. Multicast may still be used to page multiple Algo SIP
endpoints, but each endpoint can also be called individually or
generate a call when appropriately configured.
An Algo SIP endpoint configured as a SIP Multicast Slave will give its
highest priority to a page using its SIP extension.
Communication Servers with the capability of dialling many SIP
extensions simultaneously for paging may be able to create zones by
calling “paging groups”in order to page telephone speakers in
conjunction with speaker endpoints.
Background Music Streaming
The 8301 Paging Adapter & Scheduler, set as a Multicast master, can
stream background music to other Algo slave devices on the network
from a music source connected to the 8301’s AUX Input.
When multicasting music, ensure that Automatic Gain Control (AGC)
is ‘Disabled’ in Basic Settings > Features tab on all the slave
devices. Meanwhile, on the Multicast master device, select ‘G.722’ for
the Master Output Codec setting in Advanced Settings >
Advanced Multicast tab.

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 17 www.algosolutions.com
Multicast Page Zones
The 8301 Paging Adapter & Scheduler supports nine “basic” multicast
zones. These zones are defined by the multicast IP addresses.
Somewhat arbitrarily, these zones are defined below but may be
used in other ways. The important consideration is that there is a
priority hierarchy –streaming activity on a zone higher on the list will
be treated as a higher priority than a zone lower on the list –with
music being the lowest priority.
Priority
All Call
Zone 1
Zone 2
Zone 3
Zone 4
Zone 5
Zone 6
Music
There are two options for Paging to multiple zones: “DTMF Selectable
Mode” or via multiple page extensions.
The “DTMF Selectable Mode” offers a dynamic page zone selection
and requires only the Master device to have a registered SIP
Extension. To page, dial the SIP extension of the Master device and
then dial the desired DTMF page zone (e.g. 1, 2, etc.) on the keypad.
Note: DTMF codes for zones 10 and higher start with an “*”.

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 18 www.algosolutions.com
Alternatively, multiple SIP extensions can be registered on the
Master device. Each extension is mapped to a unique zone, allowing
zones to be called directly (for instance from speed-dial keys)
without the use of DTMF. See “Additional Features > More Page
Extensions”.
“Expanded” zones can also be enabled, allowing up to 50 zones in
total. These have the same behaviours as the basic zones, but are
hidden by default to simplify the interface.
PolycomTM Group Paging
The 8301 Paging Adapter & Scheduler has been designed to support
Polycom Group Paging.
The 8301 Paging Adapter & Scheduler can be added to a Polycom
Group Page so that voice paging is heard over Polycom telephone
speakers and overhead paging simultaneously.
Polycom Group Paging can be configured on the Basic Settings >
Multicast tab.
The 8301 Paging Adapter & Scheduler may be accessed remotely via
SIP and may generate a multicast page within the LAN sending voice
page to both Algo paging endpoints and Polycom telephones. Audio
delay may be added to the 8301 Paging Adapter & Scheduler to
synchronize with voice page over the Polycom telephone speakers.

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 19 www.algosolutions.com
SIP Ring Event
Set Monitoring Mode to "Monitor Ring". When a call is made to the
SIP extension the 8301 Paging Adapter & Scheduler will play the
selected WAV file from memory. Often, the 8301 will be part of a
hunt group or ring group to ring in conjunction with a telephone.
SIP Activated Notification Alerts
In addition to voice paging, the 8301 Paging Adapter & Scheduler can
play audio files for emergency, safety, and security announcements,
customer service, shift changes, etc.
Audio WAV files can be stored in adaptor memory and played over a
speaker in response to an event such as a ring, relay input or
automated schedule, and also multicast to other Algo SIP endpoints
on the network. See Additional Features > Emergency Alerts and
Additional Features > Input/Output tabs for more details.
Wiring Connections
Connecting Input Devices
to 8301
The input relay to the Algo 8301
Paging Adapter & Scheduler can
be prompted by any normally
open, normally closed switch,
Algo 1202 Call Button, or Algo
1203 Call Switch. The input
switches can be connected to the
back of the 8301 via a Terminal
Block on the “Relay SW Input”
pair.

8301 Paging Adapter & Scheduler (FW 1.5)
Document 90-00070 Algo Communication Products Ltd [phone]
2017-08-30 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 20 www.algosolutions.com
1202 Call Button: A pair of wires from the
terminal block Relay Input on the back of the
8301 Paging Adapter & Scheduler can connect to
the centre pair of the modular connector at the
back of the Call Button.
1203 Call Switch: A pair of wires can be run from
the back of the device via a screw output connector
to the 8301 Paging Adapter & Scheduler via the
Relay Input.
8301 Paging Adapter & Scheduler: Front View
8301 Paging Adapter & Scheduler: Back View
Network Connection
Connect RJ45 jack from PoE network switch or non-PoE network
and 48V 350 mA IEEE 802.3af compliant power injector.
There are two lights on the Ethernet jack:
Green light: On when Ethernet is working, flickers off to indicate
activity on the port.
