1. µISP - At a Glance
Overview
Congratulations for purchasing a µISP In-System Programmer. Based on the
Algocraft proprietary WriteNow! Technology, the µISP Series of In-System
Programmers are professional programming instruments dedicated to the
programming of devices. µISP can either work connected to a host PC (RS 232,
USB, LAN connections are built in) or in standalone mode.
The programming cycle execution in standalone mode may occur by simply
pressing the START button or through some control lines.
Its compact size and versatility allows a simple integration into production
environments, manual and automatic.
The µISP series is compatible with the entire WriteNow! Series in order to allow an
easy migration between the models. This is very interesting in order to migrate to
multi-site solutions whenever needed into production.
The UISP1 in-system programmer

µISP User's Manual
6
Key Features
▪Universal In System Programmer.
▪Standalone operations or host controlled.
▪Easy to install and to use.
▪Compact size, fixture friendly.
▪Thousands of supported devices with different programming protocols.
Hardware Features
▪Supports microcontrollers, serial memories and other programmable
devices.
▪High-speed.
▪Small size (fixture friendly).
▪Designed for easy ATE integration.
▪Supports multiple interfaces (JTAG, SWD, UART, SPI/QSPI, BDM,
SWIM, I2C, DAP, cJTAG, C2, ICSP, PDI, UPDI, FINE, MUST/MICE,
MON08, ISSP, ICC, MDI, OUT, PSI5, SBW, custom, etc).
▪Memorizes data on a built-in memory card.
▪Programmable power supply output.
▪Programmable I/O voltage.
▪USB 2.0, LAN, RS-232 and low-level interface.
▪START Push button.
▪5V USB powered or 5V AC/DC adapter.
▪Dedicated outputs for relays barrier or demultiplexer modules.
Software Features
▪Project Generator GUI with built in utilities: Image File Creation, File
Manager, ISP Signal Connections, Memory Analysis.
▪SDK/ API for custom application (Visual C, Visual Basic, C#, LabView,
etc).
▪ASCII based command line protocol.
▪Variable data handling for serial numbering, MAC addresses,
production codes, etc.
▪Blank check/erase/program/verify/read operations;
Package Checklist
The µISP programmer package includes the following items:
1. UISP1 unit.
2. AC/DC power supply adapter (5V output).
3. USB and Ethernet cables.
4. UISP1 test board.
5. DIN41612 48-way board adapter.
6. 16-ways and 10-ways 20cm flat cables.
7. 48-ways, female wire-wrap DIN41612 connector.

µISP User's Manual
7
Connectors Overview
µISP has several connectors for interfacing to a host PC, to an Automatic Test
Equipment (ATE), and to the target system(s) to be programmed. The following
pictures show where the various connectors are located.
▪The USB connector is used to communicate with a host PC system. µISP
can also be powered by this USB type C (5V) port.
▪The LAN connector is used to communicate with a host PC system.
▪The multifunctional STATUS LED shows the status of programmer and the
result of the project execution.
▪The START button executes the programming process with the last
downloaded project.
▪The ISP connector is used to interface to the target system(s) to be
programmed.
▪The CONTROL connector is used to interface the instrument to an ATE or
other systems. After the configuration of the parameters, the programmer
can be controlled by I/O lines (START, BUSY, PASS/FAIL).
For details and pinout of the various connectors, see the “Connectors” chapter.
START button
STATUS LED
LAN
USB
CONTROL
connector
ISP connector

µISP User's Manual
8
LED STATUS indication
The multicolor LED on the rear panel of the instrument, shows the status of the
programmer. Solid on (BLUE color), blinks if the system needs user action.
Color
Status
Description
VIOLET
RESET/INIT
The programmer is in bootloader mode for internal
system boot
BLUE
IDLE/READY
The programmer is in idle state, powered and ready
to accept commands
RED
FAIL/ERR
Programming cycle completed with error
GREEN
PASS/OK
Programming cycle completed successfully
CYAN
BUSY
Programming cycle in execution
Additional Documentation
This hardware manual provides information about how to set up µISP and
its hardware characteristics.
For any information about µISP commands and their syntax, please refer to
the Programmer’s Manual included (in PDF format) in WriteNow! setup.

µISP User's Manual
9
2. Programming Installations
Algocraft’s µISP series finds different applications into the device programming
field: into an on-board programming system for standalone stations or into
automatic test equipment. It can be used for a single programming or for a multi-
device parallel programming using different units.
Stand-alone –Manual Programming
Once the programmer is configured, the programming cycle is executed by simply
pressing the START button. The result of the programming is verified by the status
of the multifunction LED (BUSY/PASS/FAIL). µISP can be used as a handheld
instrument in standalone mode for in-field programming.
Stand-alone –Automated Programming
After the configuration of the parameters, the programmer can only be controlled
by I/O lines (START, BUSY, PASS/FAIL). The needed signals to control the
instrument in standalone mode are located in the “CONTROL” connector.
Multiple Programming system
By using a simple USB HUB or LAN switch, it is possible to create a parallel
programming system.

µISP User's Manual
10
3. System Setup
Software setup
Install the last software version of WriteNow! Setup available on our web site
www.algocraft.com under downloads > software menu.
To install the system software, you must log in as Administrator.
The WriteNow! system software setup installs all of the required components to
your hard drive. These components include:
•The WriteNow! Project Generator utility;
•Command-line utilities and Interface Library;
•Documentation in PDF format
Launch the Project Generator application, that is located under Programs >
Algocraft > WriteNow! Software > Project Generator.
Configure your µISP instrument. Choose Settings > Select Hardware Model, and
specify your µISP model and communication settings with the PC.
µISP can be connected through USB, LAN and serial port (RS232).
Hardware setup
To setup µISP, you must follow the steps below:
•Connect µISP to your PC through the provided Ethernet or USB cable.
•Power up µISP (by USB Type C (5V) or using the provided power supply).
•Set up LAN or USB port.
•Check µISP communication sending commands via WriteNow! Project
Generator utility.
Project setup
Projects are sequences of commands collected in a text file. The project file
contains all the target device information and user settings. Use the WriteNow!
Project Generator utility to create or edit a project file and then follow the Project
Creation Wizard steps.
Connect to Target Device
Connect µISP to your target system through the ISP connector. To view the
connections for your selected target device, select Project > Show ISP Connections.

µISP User's Manual
11
Interfacing with your Test/Programming
Equipment
µISP can be controlled in three ways:
•By manually sending commands and receiving answers, using the Project
Generator Terminal or any other terminal application;
•By configuring the instrument so that it can work in standalone, that is without
a connection to a PC;
•By building your own PC software that interfaces to the instrument (for more
information, see “WriteNow! API” on Programmer’s Manual).
Hardware Test
The diagnostic procedure is a very easy way to verify if any hardware faults occur.
Use the provided test-board to check the programmer hardware functionality.
Programming Drivers
µISP comes with preinstalled programming drivers (algorithms) that support
common microcontrollers and memories.

µISP User's Manual
12
4. Standalone Mode (low-level
interface)
Overview
µISP can work with no connection to a PC (standalone mode). In standalone
mode, the instrument is controlled through a low-level connection interface
(CONTROL connector). With this simple interface it is possible to start a project
(START) and check the result (OK/ERR).
Signals
The needed signals to control the instrument in standalone mode are located in the
“CONTROL” connector and are explained as below.
Signal
Description
START
Executes thelastdownloaded project. Active low
OK/ERR
Validattheendofprojectexecution(whenBUSYislow).Indicate,the
successstateoftheprogrammingproject.(OK=high,ERR=low).
BUSY
Indicatesthataprojectisbeingexecuted.Activehigh
Application Example

µISP User's Manual
13
5. Power Supply and Modules
Power Supply
µISP can be powered in two ways:
•Through a 5V power supply connected to a USB (5V) connector.
•Dedicated lines in the “CONTROL” connector.
Relays Lines
µISP features two lines (RLY0 and RLY1) on the “ISP” connector for driving an
external relay barrier or a demultiplexer module.
When you create a programming project using the Project Generator application,
relays are by default closed at the beginning of the project (with the #relay –o
close command) and opened at the end (with the #relay -o open command).
These signals are driven to ground when a #relay -o close command is
executed, and driven to a weak pull-up at 5.5V when a the #relay -o open
command is executed.
Demultiplexer Module
The demultiplexer module is designed to increase the number of ISP channels.
The Reed relay technology ensures true galvanic isolation.
If the BUP (board under programming) is powered through the µISP at
voltage greater then 5V, we suggest to use the AC/DC power adapter to
power the programmer in order to avoid to exceed the maximum USB current
limit (500mA)

µISP User's Manual
14
6. Connectors
“ISP”Connector
ISP Signal Definitions
Description
Signal Name
Pin#
Pin#
Signal Name
Description
ISP Line 1
S1L01
1
2
RLY0
Relay Output 0
ISP Line 2
S1L02
3
4
RLY1
Relay Output 1
ISP Line 3
S1L03
5
6
5V5 OUT
Reserved
ISP Line 4
S1L04
7
8
GND
Ground
ISP Line 5
S1L05
9
10
GND
Ground
ISP Line 6
S1L06
11
12
GND
Ground
ISP Line 7
S1L07
13
14
GND
Ground
Target Programmable
Power Supply
S1PPS
15
16
GND
Ground
“CONTROL”Connector
CONTROL Interface Signals
Description
Signal
Name
Pin#
Pin#
Signal
Name
Description
Input Power Supply
5V_EXT
1
2
GND
Ground
Input Power Supply
5V_EXT
3
4
GND
Ground
RS-232 TX (Output)
TX_RS232
5
6
RX_232
RX_RS232 (Input)
Project Start (Input with pull-up)
START
7
8
BUSY
Busy (Output, push-pull)
OK/ERR (Output, push-pull)
OK/ERR
9
10
GND
Ground

µISP User's Manual
15
“UISP1-DIN-ADP” Board Connector
A UISP1-DIN-ADP board adapter is included in the package. This adapter has
been designed for an easy fixture wire-wrapping connection and it’s also signal
compatible with all the WriteNow! Series connectors.
UISP1-DIN-ADP Signals
Signal
Description
UISP1-DIN-ADP Pin
ISP Signals
S1L01
ISP Line 1
A1
S1L02
ISP Line 2
A2
S1L03
ISP Line 3
A3
S1L04
ISP Line 4
A4
S1L05
ISP Line 5
B1
S1L06
ISP Line 6
B2
S1L07
ISP Line 7
B3
S1PPS
Target Programmable Power Supply
B4
S1GND
Ground
C1/C2
RLY0
Relay Output 0
C4
RLY1
Relay Output 1
C3
CONTROL Signals
GND
Power Supply Ground
C13/C14/C15/C16
TX_RS232
RS-232 TX (Output)
A16
RX_RS232
RS-232 RX (Input)
B16
START
Project Start (Input, internal pull-up)
B13
BUSY
Busy (Output, push-pull)
B14
OK/ERR
Site OK/ERR (Output, push-pull)
A13
One of the most important parameters to take into account for ISP wiring is
the connection length.
For this reason, the programmer should be placed as close as possible to the
BUP (Board Under Programming) keeping the ISP wiring length as short as
possible.
All the ground lines available on the ISP connector should be wired to the
BUP.

µISP User's Manual
16
7. Specifications
Electrical Specifications
Feature
Value
Maximum Ratings
Power supply voltage
6.5V
ISP S1L[1..7] voltage
-0.7-6.5V
ISP S1L[1..7] current
±50mA
ISP S1PPS voltage
-0.7-18V
ISP S1PPS current(*)
170mA
ISP S1RLY[0..1] voltage
-1.0-30V
Control interface START, BUSY, OK/ERR voltage
-0.7-6.0V
Operating Ranges
Power supply voltage
USB powered or external 4.5V-5.5V
ISP S1L1 voltage
0-15V
ISP S1L[2..7] voltage
0-5.5V
ISP S1L[1..7] adjustable voltage resolution
100mV
ISP S1PPS voltage
1.5-12.5V
ISP S1PPS current
150mA
ISP S1PPS adjustable voltage resolution
100mV
ISP S1RLY[0..1] voltage
0-28V
Control interface START, BUSY, OK/ERR voltage
0-5.5V
LAN
100Mbit/s
USB
2.0 full-speed
(*) Current limited, recovers automatically after fault condition is removed.

µISP User's Manual
17
Physical and Environmental Specifications
Parameter
Value
Dimension (with enclosure):
90.0 x 60.9 x 23.4 mm
Dimension (without enclosure):
74.0 x 47.5 x 11.0 mm
“ISP” connector type:
Box header 8x2 pitch = 2mm (male)
“CONTROL” connector type:
Box header 5x2 pitch = 2mm (male)
UISP1-DIN-ADP connector type:
48 way, 3 row, DIN 41612, pitch = 2.54mm (male)
“USB” connector type:
USB Type C
“LAN” connector type:
RJ-45 connector
Operating conditions
0-40°C, 90% humidity max (without condensation)
SD card size:
16GB min.
Storage conditions
-10-60°C, 90% humidity max (without condensation)
EMC (EMI/EMS)
CE
Spare Parts
For wire wrapping:
DIN41612 connector, 3 rows, 48 pins, 180° female, C style
Manufacturer: Conec
Manufacturer Part Number: 122A10619X
Catalog Part Number: Mouser 706-122A10619X
For soldering:
DIN41612 connector, 3 rows, 48 pins, female, R/A C style
Manufacturer: FCI
Manufacturer Part Number: 86093488613755E1LF
Catalog Part Number: Mouser 649-8693488637E1L
